6.1 Specifications/Technische Daten

GENERAL DESCRIPTION AND FEATURES
N8000 System Controller
Audio
Networking
Safety / Redundancy
PC Configuration and Control Software
AUDIO SPECIFICATIONS
Audio Inputs - Analog Input Module AI-1
Connectors
Input Level (nominal)
Input Level (max. before clip)
Input Impedance
Common Mode Rejection
A/D Conversion
Audio Outputs - Analog Output Module AO-1 8 analog audio outputs per module, line level, electronically
Connectors
Output Level (nominal)
Output Level (max. before clip)
Output Impedance
Min. Load Impedance
D/A Conversion
Frequency Response
Signal to Noise Ratio (A-weighted)
THD+N
Signal Delay
Crosstalk
Modular NetMax system manager including signal proces-
sing, routing, system control and supervision
32 Audio Channels
4 Audio Slots, modular
8-Channel Input and Output cards, analog or digital
Module Slot for optional CobraNet™ Interface
32 I/O Audio and Control
Internal Supervision, System Monitoring, Watchdog, Fault
Output, Redundant Audio Network possible
IRIS-Net - Intelligent Remote & Integrated Supervision
Integration of N8000, Remote Amplifiers, peripheral control
Configuration, Control and Supervision for complete Audio
Systems
Freely programmable User Control Panels and Access Le-
vels
8 analog audio inputs per module, line level, electronically
balanced
8 x 3-pole Euro block connectors
+6 dBu / 1.55 V
+21 dBu / 8.7 V
20 kΩ
> 70 dB
24 Bit, Sigma-Delta, 128 times oversampling
balanced
8 x 3-pole Euro block connectors
+6 dBu / 1.55 V
+21 dBu / 8.7 V
100 Ω
600 Ω
24 Bit, Sigma-Delta, 128 times oversampling
20 Hz...20 kHz (-0.5 dB)
AI-1: 117 dB typical
AO-1: 118 dB typical
N8000 analog In to analog Out: 115 dB typical
< 0.005 %
AI-1: 1.3958 ms
AO-1: 0.646 ms
N8000 analog In to analog Out: 2.2917 ms
< -110 dB @ 1 kHz
