SPECIFICATIONS AND LICENSING
SPECIFICATIONS
CHASSIS DIMENSIONS
Depth 168mm - 6-5/8"
Width 180mm - 7-1/8"
Height 52mm - 2-1/16"
FACE PLATE DIMENSIONS
Depth 35mm - 1-3/8"
Width 217mm - 8-9/16"
Height 79mm - 3-1/8"
OPERATING VOLTAGE:
10.2 - 16VDC Negative ground
FUSE RATING: 15 Amp
OUTPUT POWER: 70 Watts x 4 (Max)
26 Watts RMS @ 4 Ohms
43 Watts RMS @ 2 Ohms
SPEAKER IMPEDANCE:
2 - 4 Ohms per channel
PRE - OUTPUT VOLTAGE:
3V
TUNING RANGE
Europe and Australasia:
FM Radio AM Radio
Frequency Range: 87.5 - 108 MHz Frequency Range: 522 - 1620 MHz
Frequency step: 100 kHz Frequency step: 9 kHz
USA
FM Radio AM Radio
Frequency Range: 87.5 - 107.9 MHz Frequency Range: 530 - 1710 MHz
Frequency step: 200 kHz Frequency step: 10 kHz
PUBLISHED BY FUSION ELECTRONICS LIMITED. © Copyright 2009 by FUSION Electronics Limited. All rights reserved. Specifications and design are subject to change without notice. v5.2
YOU CAN HELP PROTECT THE ENVIRONMENT Please remember to respect the local regulations: Hand in the non-working electrical equipment to an appropriate waste disposal centre.
CD PLAYER
Laser power Class 1
SUPPORTED MEDIA
» Only use discs with the following logo' s on the label.
» If you use discs without the above logo' s , correct performance
cannot be guaranteed.
You can play audio discs recorded on DVD +R -R,
»
CD-R (Recordable), or CD-RW (Re Writable) media
» MP3 formatted audio files can also be played on DVD +R -R , CD-R
and CD-RW containing these files.
COMPATIBLE WITH THE FOLLOWING iPod MODELS:
» iPod classic, 80GB 120GB 160GB (2007, 2009);
» iPod with video, 30GB 60GB 80GB;
» iPod touch; iPod touch (2nd Gen);
iPod nano (3nd Gen); iPod nano (4th Gen);
»
» iPod nano (5th Gen)
For latest news on supported iPod models visit
www.fusionelectronics.com
LICENSING
Apple, the Apple logo, iPod and iTunes are Trademarks of Apple
Computer, Inc., registered in the U.S. and other countries.
© 2007 SIRIUS Satellite Radio Inc. "SIRIUS" and the SIRIUS dog logo
are trademarks of Sirius Satellite Radio Inc. All rights reserved.
CONTENTS
BUTTON DESCRIPTION
INSTALLATION
CONNECTIONS
WIRING DIAGRAM
GENERAL OPERATION
RADIO OPERATION
SIRIUS SATELLITE RADIO
(USA ONLY)
CD/MP3 OPERATION
AUX OPERATION
iPod OPERATION
DVD OPERATION
MS-AV600 IR REMOTE OPERATION
ZONE OPERATION
MENU STRUCTURE
TROUBLESHOOTING
FUSION MARINE ACCESSORIES
SPECIFICATIONS AND LICENSING
