USER MANUAL
AXIS P1346 Network Camera

Advertisement

Table of Contents
loading

Related Manuals for Axis P1346

Summary of Contents for Axis P1346

  • Page 1 USER MANUAL AXIS P1346 Network Camera...
  • Page 2 Later version Consult the dealer or an experienced radio/TV technician for help of this document will be posted to the Axis website, as required. See Canada also the product’s online help, available via the web-based interface.

  • Page 3: Table Of Contents

    AXIS Media Control (AMC) ........
  • Page 4 AXIS P1346 Network Camera Table of Contents Symptoms, possible causes and remedial actions ..... . Technical Specifications ........

  • Page 5: Hardware Overview

    AXIS P1346 Network Camera Hardware overview Hardware overview 3 4 5 SD card slot Microphone Status LED indicator Zoom puller Focus puller Audio in Audio out Network connector (PoE) Power LED indicator 10 Network LED indicator 11 Control button 12 Iris connector...

  • Page 6: Connectors

    Enabling the Focus Assistant. Press and very quickly release the Control button. • Connecting to an AXIS Video Hosting System service. See page 44. To connect, press and hold the button for about 1 second until the Status LED flashes green.

  • Page 7: Led Indicators

    AXIS P1346 Network Camera Hardware overview Digital output — For connecting external devices such as relays and LEDs. Connected devices can be activated by • the VAPIX® Application Programming Interface, output buttons on the Live View page or by an Action Rule. The output will show as active (shown under System Options >...

  • Page 8: Status Led When Using Focus Assistant

    Note There is no need to restart the Axis product after changing the lens. However, the product must be restarted if you are interchanging between a P-iris, DC-Iris or fixed/manual iris lens. In order to set the focus and position the lens, the Axis product must be connected to the network.
  • Page 9 Hardware overview Note For iris lenses not listed in the drop-down list, download the iris configuration file from www.axis.com To upload and use the downloaded configuration file, click the Upload tab. Click Browse and select the configuration file. Click Upload. The installed iris lens should now be included in the Iris Selection drop-down list, select it and press OK.

  • Page 10: Accessing The Product

    Macintosh computer (Mac OS X), click on the Bonjour tab and select the product from the drop-down list. If you do not know the IP address, use AXIS IP Utility to locate the product on the network. For more information on how to discover and assign an IP address, refer to the Installation Guide.

  • Page 11: Access From The Internet

    Set the root password To gain access to the Axis product, you must set the password for the default administrator user root. This is done in the Configure Root Password dialog, which appears when the product is accessed for the first time.

  • Page 12: The Live View Page

    See also Capture Mode, on page 21. The Live View page If the Axis product has been customized to meet specific requirements, not all the items described below will appear in the Live View page. The following provides an overview of each available button.
  • Page 13 Play button. AXIS Media Control viewer toolbar The AXIS Media Control viewer toolbar is available in Internet Explorer only. See AXIS Media Control (AMC), on page 15 for more information. The toolbar displays the following buttons: The Play button connects to the Axis product and starts playing a media stream.

  • Page 14: Ptz Controls

    AXIS P1346 Network Camera Accessing the product Use the slider to control the volume of the speakers and the microphone. Half-duplex mode The Talk/Listen button is used to switch between sending and receiving audio. The button can be configured from the Audio tab in the AMC Control panel: •...

  • Page 15: Media Streams

    Note also that all multicast viewers count as one unicast viewer in the maximum total of 20 simultaneous connections. AXIS Media Control negotiates with the Axis product to determine the transport protocol to use. The order of priority, listed in the AMC Control Panel, can be changed and the options disabled, to suit specific requirements.

  • Page 16: Alternative Methods Of Accessing The Video Stream

    AXIS P1346 Network Camera Media streams The AMC Control Panel can be used to configure various video and audio settings. Please see the AXIS Media Control User’s Manual for more information. The AMC Control Panel is automatically installed on first use, after which it can be configured. Open the AMC Control Panel from: •...

  • Page 17: Accessing Audio Streams

    • The Axis product supports QuickTime 6.5.1 and later. • QuickTime adds latency to the video stream. • It may be possible to use other players to view the H.264 stream using the paths above, although Axis does not guarantee this.

  • Page 18: Setting Up The Product

    Setting up the product Setting up the product The Axis product can be configured by users with administrator or operator rights. Click Setup in the top right-hand corner of the Live View page. Administrators have unrestricted access to all settings.

  • Page 19: Video And Audio

    AXIS P1346 Network Camera Video and Audio Video and Audio The video and audio settings can be used to optimize video and audio quality. You can configure the following: • Video stream settings. See page 19. • Stream profiles. See page 20.

  • Page 20: Stream Profiles

    AXIS P1346 Network Camera Video and Audio Video & Audio > Video Stream. Under Preview, click Open and select the Show pixel counter option to enable the • rectangle in the image. Use the mouse to move and resize the rectangle, or enter the number of pixels in the Width and Height fields and click Apply.

  • Page 21: Camera Settings

    The Video & Audio > Camera Settings page provides access to advanced image settings for the Axis product. Capture Mode Capture mode defines the maximum resolution and maximum frame rate available in the Axis product. A capture mode with a large maximum resolution has a reduced maximum frame rate and vice versa.

  • Page 22: White Balance

    White balance White balance is used to make colors in the image appear the same regardless of the color temperature of the light source. The Axis product can be set to automatically identify the light source and compensate for its color. Alternatively, select the type of light source from the drop-down list.

  • Page 23: View Areas

    An overlay image can be used to provide extra information, or to mask a part of the video image. To use your own image, such as a logo, first upload the image to the Axis product. Go to Video & Audio > Overlay Image, click Browse to locate the file and then click Upload.

  • Page 24: Focus

    AXIS P1346 Network Camera Video and Audio The Privacy Mask List (Video & Audio > Privacy Mask) shows all the masks that are currently configured in the Axis product and indicates if they are enabled. You can add a new mask, re-size the mask with the mouse, choose a color for the mask, and give the mask a name.

  • Page 25: Audio Input

    AAC requires a license for both encoding and decoding. AAC is the least complicated and most widely used codec. If achieving the best possible audio quality is a priority, AAC is the recommended codec to use. An AAC license is included in the Axis product. G711 •...
  • Page 26 AXIS P1346 Network Camera Video and Audio You can add, play, download, modify and remove audio clips from Video & Audio > Audio Clips. For more information see the online help Note Audio clips cannot be used if the product’s audio functionality is enabled. The audio functionality is enabled on the Audio...

  • Page 27: Live View Config

    AXIS P1346 Network Camera Live View Config Live View Config You can customize the Live View page and alter it to suit your requirements. It is possible to define the following features of the Live View page. • Stream Profile. See page 20.
  • Page 28 Output Buttons An output on the Axis product can be controlled directly from the Live View page, by enabling the display of output buttons. To display the output buttons in the Live View page, select the type of control to use for the port from the drop-down list under Live View Config >...

  • Page 29: Ptz (Pan Tilt Zoom)

    AXIS P1346 Network Camera PTZ (Pan Tilt Zoom) PTZ (Pan Tilt Zoom) The PTZ menu is available if digital PTZ (pan, tilt and zoom) is enabled in the selected view area. For more information on view areas, see View Areas, on page 23.

  • Page 30: Guard Tour

    AXIS P1346 Network Camera PTZ (Pan Tilt Zoom) Guard Tour A guard tour displays the video stream from different preset positions, one-by-one, in a predetermined order or at random and for configurable time periods. The enabled guard tour will keep running after the user has logged off or closed the browser.

  • Page 31: Camera Tampering

    AXIS P1346 Network Camera Detectors Detectors Camera Tampering Camera Tampering can generate an alarm whenever the camera is repositioned, or when the lens is covered, sprayed or severely defocused. To send an alarm, for example an email, an action rule must be set up.

  • Page 32: Motion Detection Parameters

    AXIS P1346 Network Camera Detectors Set Up Motion Detection To set up a motion detection Include Window, follow these instructions: 1. Go to Detectors > Motion Detection. 2. Select a desired resolution for viewing while setting up Motion Detection from the View in list.

  • Page 33: Audio Detection

    Audio detection The Axis product can be configured to generate an alarm when audio rises above or falls below the threshold value. The threshold value can be set in the range 0–100 where 0 is the most sensitive and 100 the least sensitive.

  • Page 34: Applications

    Internet, Automatic Installation appears in the web page. If the product is not connected to the Internet, go to www.axis.com/applications to acquire a License key. You will need a license code and the product’s serial number (found on the label and under System Options >...

  • Page 35: Events

    Events The Axis product can be configured to perform actions when different events occur, for example, start a recording when motion is detected. The set of conditions that defines how and when the action is triggered is called an Action Rule.

  • Page 36: Convert Event Types To Action Rules

    Convert Event Types to Action Rules If the Axis product is upgraded to firmware version 5.40 or later, it is recommended to convert Event Types to Action Rules. The legacy user Event Types in the camera will continue to work but will not be visible in the user interface of the camera. The Event Types need to be converted to Action rules to become visible in the user interface.

  • Page 37: Recipients

    AXIS P1346 Network Camera Events To add additional criteria, select the Additional conditions option and add additional triggers. To prevent an action from being triggered repeatedly, a Wait at least time can be set. Enter the time in hours, minutes and seconds, during which the trigger should be ignored before the action rule can be activated again.
  • Page 38 AXIS P1346 Network Camera Events To set up a recurrence: 1. Go to Events > Recurrences and click Add. 2. Enter a descriptive name and recurrence pattern. 3. Click OK. To use the recurrence in an Action Rule, first select Time from the Trigger drop-down list in the Action Rule Setup page and then select the recurrence from the second drop-down list.

  • Page 39: Recording List

    Continuous recording The Axis product can be configured to continuously save video to a storage device. See Storage, on page 47 for more information about storage devices. To prevent the disk from becoming full, it is recommended to configure the disk to automatically remove old recordings.
  • Page 40 AXIS P1346 Network Camera Recordings Note If a new stream profile is selected while a recording is ongoing, the recording will be stopped and saved in the recording list and a new recording with the new stream profile will start. All previous continuous recordings will remain in the recording...

  • Page 41: System Options

    IP address filtering is enabled on the System Options > Security > IP Address Filter page. Once enabled, the listed IP address are allowed or denied access to the Axis product. Select Allow or Deny from the list and click Apply to enable IP address filtering.

  • Page 42: Date & Time

    Check the box to enable the IEEE 802.1X protocol. Audio Support Select Enable audio support to allow clients to retrieve audio streams from the Axis product. For information on how to configure audio settings, see Audio Settings, on page 24.

  • Page 43: Network

    IPv4 Address Configuration By default, the Axis product is set to use IPv4 (IP version 4) and to obtain the IP address automatically via DHCP. The IPv4 settings are configured under System Options > Network > TCP/IP > Basic.
  • Page 44 Host Name Configuration The Axis product can be accessed using a host name instead of an IP address. The host name is usually the same as the assigned DNS name. The host name is configured under System Options > Network > TCP/IP > Advanced.
  • Page 45 This function can be disabled under System Options > Network > TCP/IP > Advanced. HTTP The HTTP port used by the Axis product can be changed under System Options > Network > TCP/IP > Advanced. In addition to the default setting, which is 80, any port in the range 1024–65535 can be used.
  • Page 46 SOCKS is a networking proxy protocol. The Axis product can be configured to use a SOCKS server to reach networks on the other side of a firewall or proxy server. This functionality is useful if the Axis product is located on a local network behind a firewall, and notifications, uploads, alarms, etc need to be send to a destination outside the local network (for example the Internet).

  • Page 47: Storage

    To use SNMP v3, HTTPS must be enabled, see HTTPS, on page 41. To enable SNMP v3, check the box and provide the initial user password. Note The initial password can only be set once. If the password is lost, the Axis product must be reset to factory default, see Reset to factory default settings, on page 50. UPnP The Axis product includes support for UPnP .

  • Page 48: Ports & Devices

    The Axis product provides several maintenance functions. These are available under System Options > Maintenance. Click Restart to perform a correct restart if the Axis product is not behaving as expected. This will not affect any of the current settings.

  • Page 49: Support

    Click Default to reset all settings, including the IP address, to the factory default values. This button should be used with caution. The Axis product can also be reset to factory default using the control button, see Reset to factory default settings, on page 50.

  • Page 50: Advanced

    For more information, see www.axis.com/developer File Upload Files, for example web pages and images, can be uploaded to the Axis product and used as custom settings. To upload a file, go to System Options > Advanced > File Upload. Uploaded files are accessed through http://<ip address>/local/<user>/<file name> where <user> is the selected user group (viewer, operator or administrator) for the uploaded file.

  • Page 51: Troubleshooting

    Always read the upgrade instructions and release notes available with each new release, before upgrading the firmware. To upgrade, follow these instructions: 1. Save the firmware file to your computer. The latest version of the firmware is available free of charge from Axis website at www.axis.com/techsup 2.

  • Page 52: Symptoms, Possible Causes And Remedial Actions

    Identify the product using its model or serial number. Move the Axis product to an isolated network, or to one with no DHCP or BOOTP server. Set the IP address again, using AXIS IP Utility or ARP/Ping (see the Installation Guide). Open the Setup pages and disabled DHCP in the TCP/IP settings.

  • Page 53: Performance Considerations

    The product is accessible locally but not externally Router configuration To configure your router to allow incoming data traffic to the Axis product, enable the NAT-traversal feature which will attempt to automatically configure the router to allow access to the Axis product, see NAT traversal (port mapping) for IPv4, on page 45.
  • Page 54 Also, make sure that AXIS Media Control is installed on your computer. only) Installation of additional Configure the Axis product to use a Java applet for updating video images in Internet Explorer. Go ActiveX component to Setup > Live View Config and select Java applet under Default viewer.
  • Page 55 AXIS P1346 Network Camera Troubleshooting Motion Detection triggers unexpectedly Changes in luminance Motion detection is based on changes in luminance in the image. This means that if there are sudden changes in the lighting, motion detection may trigger mistakenly. Lower the sensitivity setting to avoid problems with luminance.
  • Page 56 AXIS P1346 Network Camera Technical Specifications Technical Specifications Item Specifications Function/group Model Camera AXIS P1346 Image sensor Progressive scan RGB CMOS 1/3” (effective) Lens Varifocal f=3.5 – 10 mm, F1.6, P-Iris, CS mount Horizontal angle of view: 72° – 27°...
  • Page 57 *This product includes software developed by the Open SSL Project for use in the Open SSL Toolkit (www.openssl.org) Application System Open API for software integration, including VAPIX® and AXIS Camera Application Integration Programming Platform from Axis Communications; specifications available at www.axis.com Interface Includes the ONVIF specification available at www.onvif.org...

  • Page 58: Performance Considerations

    Stand, connector kit, Installation Guide, CD with installation tools, recording software accessories and User Manual, Windows decoder 1-user license Video AXIS Camera Station — Video management software for viewing and recording up to 100 management cameras software (not See www.axis.com/products/video/software/ for more software applications via partners...
  • Page 59 AXIS P1346 Network Camera Technical Specifications • Accessing Motion JPEG and H.264 video streams simultaneously. Frame rate and bandwidth affected. • Heavy usage of event settings affect the product’s CPU load. Frame rate affected. • Heavy network utilization due to poor infrastructure. Bandwidth affected.
  • Page 60 User Manual Ver. M3.3 AXIS P1346 Network Camera Date: January 2012 Part No. 45967 © Axis Communications AB, 2011 - 2012...
