Set Feature - Reset

This is a request to perform a controller reset. Soft resets are automatic after any block
parameter changes.
Table 11. Reset - Setup Stage
Offset
0
1
2
4
6
Table 12. Reset – Data Stage
Offset
0
1
2
3--7
A Hard Reset will cause the controller to re-enumerate.
In the case of a Soft Reset, after sending the command, the controller will acknowledge
(ACK) the transfer, but the command will not yet be completed. Before sending any other
commands, the host should poll with GetStatus until the command status field returns
"Soft Reset Occurred," "Command Complete," or "Fail". Any timeout for this status
polling should be 2 seconds minimum.
Set Feature –Restore Defaults
This is a request to restore parameter defaults.
Table 13. Restore Defaults -- Setup Stage
Offset
0
1
2
4
6
Field Size
bmRequestType 1
bRequest 1
wValue 2
wIndex 2
wLength 2
Field Size
Report ID 1
Report Subtype 1
bResetType 1
5
Field Size
bmRequestType 1
bRequest 1
wValue 2
wIndex 2
wLength 2
3M Touch Systems, Inc. Proprietary Information – TSD-39373B
3M™ Multi-Touch Chassis Display User Guide
Value Description
0x21 Class,H2D,Interface
0x09 Set Report
0x0303 msb=03=Feature
lsb=03= Feature Report ID
0 Always 0
8 Always 8
Value Description
0x03 Feature Report ID
0x07 Indicates a reset request
0x01 Soft Reset
0x02 Hard Reset
0 Not used
Value Description
0x21 Class,H2D,Interface
0x09 Set Report
0x0303 msb=03=Feature
lsb=03= Feature Report ID
0 Always 0
8 Always 8
