Shared Storage Configuration
Parameter
From HBA or
hub/switch
To VA 7100
To VA 7400
GBICs
Intra-Cluster (Heartbeat) LAN Configuration
Parameter
Network
Connection
NIC
Quantity
Model
Driver
Client LAN Configuration
Parameter
Network
Connection
NIC
Quantity
Model
Driver
2 meter cable, product number A3583A (GBICs not included)
16 meter cable, product number A3531A (GBICs not included)
50 meter cable, product number A3735A (GBICs not included)
100 meter cable, product number A3736A (GBICs not included)
2 meter cable, product number C7529A (GBIC not included)
16 meter cable, product number C7530A (GBIC not included)
Short wavelength optical GBIC (for HBA or Loop switch/Brocade switch), prod-
uct number A5225A or D6975A
HP D5954A crossover cable, or equivalent.
The intra-cluster LAN may only be used for cluster node communication. It may
not be used for client communication.
One, minimum
Integrated NIC, HP 10/100 IPSec 3DES, Model P3492A, or any LAN adapter that
is on both the HP Tested Products List and the Microsoft
Compatibility List
For integrated NIC or P3492A, latest version from Navigator CD-ROM or HP
technical support web site.
For other NICs, any vendor-supported driver.
Any LAN
One, minimum
Any model that is on both the HP Tested Products List and the Microsoft
Hardware Compatibility List
Vendor-supported driver
If the NIC used is the same as that of the intra-cluster LAN, then the client LAN
driver must be the same as that of the intra-cluster LAN.
Specification
Specification
®
Hardware
Specification
4/15/02
tc4100nt71-74
