HP Tower Server tc4100 with
HP Surestore Virtual Array 7100/7400
Introduction
This document defines the server cluster configurations supported by Hewlett-Packard for interconnection of
two HP tc4100 servers and one or two HP VA 7100 or 7400 disk drive enclosure(s), with Microsoft
Server software. These configurations provide high server cluster availability and minimize single points of
failure (SPOFs). Hewlett-Packard will support any cluster configuration that conforms to the guidelines of
this document. Deviations from the supported configurations can result in an inoperative cluster, an
operating cluster with degraded performance, or hidden SPOFs. Therefore, deviations are not supported. For
revision/update information on this document, refer to
Cluster Configuration Elements
This section identifies the hardware components, system software, network interfaces, and power distribution
arrangement required to build an operational server cluster supported by Hewlett-Packard. The various
server cluster elements are listed below, and their associated configuration data is detailed in separate tables
and illustrations that follow.
· Server configuration
· Shared storage configuration
· Intra-cluster (heartbeat) LAN configuration
· Client LAN configuration
· FC cabling configuration
· Supported Fibre Channel topologies
· Power distribution configuration
Server Configuration
Parameter
Server
Type
Number of nodes
Clock speed
Number of CPUs
BIOS
CPU cache
RAM
Number of power
supplies
â
Windows
2000 Advanced Server
Cluster Configuration Guide
HP Tower Server tc4100
Two
Each node must be the same server type, but nodes may differ in their CPU clock
speeds and cache sizes, and amounts of main memory.
1.40 GHz, or any CPU within the same processor family
Two
Version 4.06.12 RI, or later
Any size
Recommended 512 MB, minimum. Must be HP.
One standard, two required for redundancy
Versions
on page 10.
Specification
5/2/02
Cluster
â
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the Tc4100 - Server - 256 MB RAM and is the answer not in the manual?

Questions and answers

Related Manuals for HP Tc4100 - Server - 256 MB RAM

Summary of Contents for HP Tc4100 - Server - 256 MB RAM

  • Page 1 Server software. These configurations provide high server cluster availability and minimize single points of failure (SPOFs). Hewlett-Packard will support any cluster configuration that conforms to the guidelines of this document. Deviations from the supported configurations can result in an inoperative cluster, an operating cluster with degraded performance, or hidden SPOFs.

  • Page 2: Specification

    tc41002k71-74 Server Configuration Parameter Specification I/O slots Added cards may be installed in any appropriate slot, considering the server default boot order provided below. Default boot order IDE CD-ROM, FDD, embedded SCSI A, embedded SCSI B, PCI slot 6, PCI slot 5, PCI slot 4, PCI slot 3, PCI slot 2, PCI slot 1, integrated NIC Local Storage Controller...
  • Page 3 tc41002k71-74 Shared Storage Configuration Parameter Specification Number of enclosures One or two per cluster Number of clusters One or two per Virtual Array enclosure Consult your HP Reseller or HP storage specialist if planning configurations that may require support for additional MSCS clusters or additional non-clustered servers.
  • Page 4 tc41002k71-74 Shared Storage Configuration Parameter Specification Fiber Optic Only an optical fiber connection is supported to the storage, either directly from the HBA or from a switch. HBA to Brocade 50 meter cable, product number D6980A (includes two SW GBICs) 2800 or loop 100 meter cable, product number D6981A (includes two SW GBICs) switch...
  • Page 5 tc41002k71-74 Intra-Cluster (Heartbeat) LAN Configuration Parameter Specification Model Integrated NIC, HP 10/100 IPSec 3DES, Model P3492A, or any LAN adapter that ® is on both the HP Tested Products List and the Microsoft Hardware Compatibility List Driver For integrated NIC or P3492A, latest version from Navigator CD-ROM or HP technical support web site.
  • Page 6 tc41002k71-74 VA 7100 Dual HBA Cluster Public Network Private Server Server Network FC Hub/Switch FC Hub/Switch (LUN owner) Primary Active Path* Secondary Path for Failover *Preferred path mode only. 5/2/02...
  • Page 7 tc41002k71-74 VA 7400 Dual HBA Cluster Public Network Private Server Server Network FC Hub/Switch FC Hub/Switch HOST FC HOST FC Redundancy Group1 owner Redundancy Group 2 owner Primary path for RG 1* Primary path for RG 2* Secondary path for RG 2 Secondary path for RG 1 *Preferred path mode only.

  • Page 8: Direct Connection

    tc41002k71-74 tc4100 tc4100 VA7X00 NL_Port NL_Port NL_Port optical fiber cable Direct Connection tc4100 tc4100 VA7X00 Brocade or Brocade or Loop Switch Loop Switch FL_Port FL_Port NL_Port NL_Port NL_Port optical fiber or copper cables optical fiber cable Private Arbitrated Loop with Two Switches and Two HBAs - Redundant Paths Using AutoPath (No other servers can be connected to the Virtual Array)
  • Page 9 tc41002k71-74 Power Cabling to Separate Power Circuits 5/2/02...
  • Page 10 Added support for DS2405 for additional storage. 25 April 2002 Removed discontinued S10/L10 hub and Brocade 2400 switch. 17 April 2002 Updated topology diagram. Added 2 GB FC switches and cables. 01 April 2002 Initial release ãCopyright 2002, Hewlett-Packard Company 5/2/02...
