Elation Power Spot 700 CMY II Technical Specifications

Power Spot 700 CMY II
The Power Spot 700 CMY II by Elation Professional is a 700W CMY color mixing moving head hybrid (spot or
wash in one) with use of the variable frost effect. Featuring CMY color system plus a fixed color wheel with
8 static colors as well as variable CTO, two gobo wheels with 9 fixed and 7 rotating gobos featuring the new
Quick Snap™ rotating gobo and animation wheel system. The animation wheel can simulate effects such as
running water, fire, clouds, etc. Additional effects include rotating 3-facet prism, Iris, mechanical dimmer /
shutter system. This unit includes a motorized variable zoom beam angle from 14° to 32° and is equipped with
unique modular internal construction allowing for easy access to key components. Control data input is via
3 pin or 5 pin DMX data connections first in and out cables. The unit's lamp fuse housing holds a 250v/10A
GMA fuse (120v operation). The Power Spot 700 CMY II is equipped with the Philips MSR700 SA/2 Gold lamp
and is IP20 rated, designed for indoor applications only and and features a multi-voltage electronic ballast
and power supply. Rigging for this unit includes 2 x 1/4 turn omega brackets. Additional gobos and animation
wheels are supplied.
FEATURES
• 700W short arch discharge lamp moving head hybrid
• Full Color mixing with Cyan Magenta Yellow flag system
+ 8 dichroic filters plus white
• 2 gobo wheels with 9 fixed and 7 rotating and interchangeable
• 1 variable speed replaceable rotating animation wheel
• 4 extra animation wheels included
• 8 optional animation wheels available
• Variable frost control hard edge to soft edge
• 3-facet rotating/Indexing Prism
• Sound active mode - built in mic. lamp on/off
power con mains
• Motor driven focus from near to far
• Maximum PAN-movement 540° 16-bit resolution
• TILT-movement 280° 16-bit resolution
• 4 digit L.E.D. display
• On board menu settings
• DMX control via 24 channels
• Modular design allows easy access to key components
Power Spot 700 CMY II Dimensions
©Elation Professional • Elation Professional 6122 S. Eastern Ave. Los Angeles, Ca 90040
www.ElationLighting.com • Toll Free ( 866 ) 245-6726
TECHNICAL SPECIFICATIONS
• DMX Channels: 24 DMX Channels,
RDMX - Remote DMX Addressing
• Control: USITT DMX-512 (16-bit resolution),
3-pin and 5-Pin XLR serial input/output
• Dimmer: Dual Flag mechanical dimming system
• Strobe: Variable speed strobe effect
(1-10) flashes per second
• IP Rating: IP 20
• Iris: Beam narrow to wide (4% - 100%)
• Zoom: 14° - 32° linear zoom
• Power Supply: AC 90-260V 50/60Hz
• Power Consumption: 900W
• Fuse: Electronic ballast
• Lamp: Phillips MSR 700 SADE/2
• Lamp life: 700W, 72V, 7500°K, 1000 HRS
• Dimensions: ( L x W x H ) 19" x 14" x 29" /
482.6 x 355.6 x 736.6 mm
• Weight: 63 lbs. / 28.5 kg
• Rigging: 2 x 1/4 Turn omega brackets
4 x M-10 threaded holes for clamps
