1.2

Legacy Considerations

This board differs from other Intel Desktop Board products, with specific changes
including (but not limited to) the following:
• No parallel port
• No floppy drive connector
• No serial port on the back panel
• The serial port header is located near the memory sockets and may require a
specialized chassis or cabling solution to use
1.3

Online Support

To find information about...
®
Intel Desktop Board DG33TL
Desktop Board Support
Available configurations for the
Desktop Board DG33TL
Supported processors
Chipset information
BIOS and driver updates
1.4

Processor

The board is designed to support the following processors:
• Intel Core 2 Quad processor in an LGA775 socket with a 1066 MHz system bus
• Intel Core 2 Duo processor in an LGA775 socket with a 1333 or 1066 or 800 MHz
system bus
• Intel Pentium Dual-Core processor in an LGA775 socket with an 800 MHz
system bus
• Intel Celeron processor in an LGA775 socket with an 800 MHz system bus
Other processors may be supported in the future. This board is designed to support
processors with a maximum wattage of 105 W. The processors listed above are only
supported when falling within the wattage requirements of the DG33TL board. See
the Intel web site listed below for the most up-to-date list of supported processors.
For information about...
Supported processors
CAUTION
Use only the processors listed on the web site above. Use of unsupported processors
can damage the board, the processor, and the power supply.
INTEGRATOR'S NOTE
Use only ATX12V-compliant power supplies.
For information about
Power supply connectors
Visit this World Wide Web site:
http://www.intel.com/products/motherboard/DG33TL/index.htm
http://support.intel.com/support/motherboards/desktop
http://www.intel.com/products/motherboard/DG33TL/index.htm
http://www.intel.com/go/findcpu
http://www.intel.com/products/desktop/chipsets/index.htm
http://downloadcenter.intel.com
Refer to:
http://www.intel.com/go/findcpu
Product Description
Refer to
Section 2.2.2.4, page 49
15
