Intel Desktop Board DG33TL Technical Product Specification
1.1

Overview

1.1.1

Feature Summary

Table 1 summarizes the major features of the Desktop Board DG33TL.
Table 1. Feature Summary
Form Factor
Processor
Memory
Chipset
Audio
Video
Legacy I/O Control
Peripheral
Interfaces
LAN Support
BIOS
10
ATX (9.60 inches by 9.60 inches [243.84 millimeters by 243.84 millimeters])
Support for the following:
®
• Intel Core™2 Quad processor in an LGA775 socket with a 1066 MHz
system bus
®
• Intel Core™2 Duo processor in an LGA775 socket with a 1333 or 1066 or 800
MHz system bus
® ®
• Intel Pentium Dual-Core processor in an LGA775 socket with an 800 MHz
system bus
® ®
• Intel Celeron processor in an LGA775 socket with an 800 MHz system bus
• Four 240-pin DDR2 SDRAM Dual Inline Memory Module (DIMM) sockets
• Support for DDR2 800 or DDR2 667 MHz DIMMs
• Support for up to 8 GB of system memory using DDR2 800 or DDR2
667 DIMMs
®
Intel G33 Express Chipset, consisting of:
®
• Intel 82G33 Graphics and Memory Controller Hub (GMCH)
®
• Intel 82801IR I/O Controller Hub (ICH9R)
8-channel (7.1) audio subsystem using the IDT* STAC9271D audio codec and
Dolby* Home Theater certification
®
Intel Graphics Media Accelerator (Intel
subsystem.
Legacy I/O controller for serial port header and Consumer Infrared (CIR)
• 12 USB 2.0 ports
• Two IEEE-1394a interfaces: one back panel connector and one front-panel
header
• Six Serial ATA (3 Gbps) interfaces, including one red-colored external Serial
ATA (eSATA) interface
• One Parallel ATA IDE interface with UDMA 33, ATA-66/100 support
• One serial port header (may require specialized chassis or cable for use)
Gigabit (10/100/1000 Mbits/sec) LAN subsystem using the Intel
Gigabit Ethernet Controller
®
• Intel BIOS (resident in the SPI Flash device)
• Support for Advanced Configuration and Power Interface (ACPI), Plug and Play,
and SMBIOS
®
GMA) 3100 onboard graphics
®
82566DC
continued
