Table 2. Board Components Shown in Figure 1
Item/callout
from Figure 1 Description
A Front panel audio header
B Speaker
C PCI Conventional bus add-in card connector
D Battery
E PCI Express x1 connector
F PCI Express x1 connector
G Chassis intrusion header
H PCI Express x16 connector
I Back panel connectors
J Processor core power connector (2 X 2)
K Rear chassis fan connector
L LGA775 processor socket
M Intel 82G33 GMCH
N Processor fan header
O DIMM Channel A sockets
P DIMM Channel B sockets
Q Serial port header
R Main Power connector (2 X 12)
S Front panel header
T Auxiliary front panel power LED header
U Intel 82801IR I/O Controller Hub (ICH9R)
V BIOS Setup configuration jumper block
W Front chassis fan header
X Serial ATA connectors [5]
Y External Serial ATA (eSATA) connector
Z Front panel USB header
AA Front panel USB header
BB Front panel CIR receiver (input) header
CC Back panel CIR emitter (output) header
DD Front panel USB header
EE Parallel ATA connector
FF IEEE-1394a header
GG High Definition Audio Link header
