Setup Manual
Important
Please read this User's Manual and Setup
Manual (separate volume) carefully to
familiarize yourself with safe and effective
usage.
PRECAUTIONS
Chapter 1 Features and Overview
1-1 Features
1-2 Buttons and Indicators
1-3 Functions and Basic Operation
Chapter 2 Settings and Adjustments
2-1 Utility Disk
2-2 Screen Adjustment
2-3 Color Adjustment
2-4 Speaker Volume Adjustment
2-5 Off Timer/Power Saving Settings
2-6 EIZO Logo Display Setting
2-7 Locking Buttons
2-8 Setting Adjustment menu Display
2-9 Viewing Information/Setting Language
2-10 Resumption of Default Setting
Chapter 3 Connecting Cables
3-1 Connecting Two PCs to the Monitor
3-2 Connecting Speaker
Chapter 4 Troubleshooting
Chapter 5 Reference
5-1 Attaching an Arm (Option)
5-2 Cleaning
5-3 Specifi cations
5-4 Glossary
5-5 Preset Timing
How to Setup
Please read the Setup Manual (separate volume)
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Eizo FlexScan M1900
Summary of Contents for Eizo FlexScan M1900
- Page 1 2-1 Utility Disk 2-2 Screen Adjustment 2-3 Color Adjustment 2-4 Speaker Volume Adjustment 2-5 Off Timer/Power Saving Settings 2-6 EIZO Logo Display Setting 2-7 Locking Buttons 2-8 Setting Adjustment menu Display 2-9 Viewing Information/Setting Language 2-10 Resumption of Default Setting...
-
Page 2: Safety Symbols
EIZO NANAO CORPORATION’s receipt of said information Although every effort has been made to ensure that this manual provides up-to-date information, please note that EIZO monitor specifi cations are subject to change without notice. -
Page 3: Precautions
PRECAUTIONS IMPORTANT • This product has been adjusted specifi cally for use in the region to which it was originally shipped. If the product is used outside the region, it may not operate as specifi ed in the specifi cations. •... - Page 4 WARNING Place the unit at the strong and stable place. A unit placed on an inadequate surface may fall and result in injury or equipment damage. If the unit falls, disconnect the power immediately and ask your dealer for advice. Do not continue using a damaged unit.
- Page 5 WARNING Handle the power cord with care. • Do not place the cord underneath the unit or other heavy objects. • Do not pull on or tie the cord. If the power cord becomes damaged, stop using it. Use of a damaged cord may result in fi re or electric shock.
- Page 6 CAUTION Handle with care when carrying the unit. Disconnect the power cord and cables when moving the unit. Moving the unit with the cord attached is dangerous. It may result in injury. When handling the unit, grip the bottom of the unit fi rmly with both hands ensuring the panel faces outward before lifting.
-
Page 7: Lcd Panel
LCD Panel In order to suppress the luminosity change by long-term use and to maintain the stable luminosity, use of a monitor in lower brightness is recommended. The screen may have defective pixels. These pixels may appear as slightly light or dark areas on the screen. This is due to the characteristics of the panel itself, and not the product defect. -
Page 8: Table Of Contents
[VESA DPMS/DVI DMPM] ... 17 ● To mute the speaker with power-saving setting [Power-saving mute] ... 18 CONTENTS EIZO Logo Display Setting ... 19 ● To display EIZO logo [EIZO Logo Appearing Function] ... 19 Locking Buttons ... 19 ●... -
Page 9: Chapter 1 Features And Overview
Chapter 1 Features and Overview Thank you very much for choosing an EIZO color LCD monitor. 1-1 Features • Dual-input compliant (DVI-D and D-sub mini 15-pin connectors) • DVI digital input (TMDS) compliant Resolution: 1280 dots × 1024 lines • Easy screen adjustment with Auto Adjustment function •... -
Page 10: Functions And Basic Operation
1-3 Functions and Basic Operation To adjust the screen and color • The Adjustment menu and the FineContrast menu cannot be displayed at the same time. FineContrast menu Color Adjustment Simple Adjustment [FineContrast mode] This function allows easy selection of a desired mode from fi... -
Page 11: Basic Operation Of Adjustment Menu
……………………………… see page 19 EIZO Logo Display Setting ● [EIZO Logo Appearing Function] to display or not to display the EIZO logo …………… see page 19 Connecting Signal Cables ● 3-1 Connecting Two PCs to the Monitor ……………………………………… see page 22 Connecting Speaker ●... -
Page 12: Chapter 2 Settings And Adjustments
Chapter 2 Settings and Adjustments 2-1 Utility Disk An “EIZO LCD Utility Disk” (CD-ROM) is supplied with the monitor. The following table shows the disk contents and the overview of the application software programs. ● Disk contents and software overview The disk includes a monitor information file, application software programs for adjustment, and User’s Manual. -
Page 13: Screen Adjustment
5 “Range Adjustment”. Run the Screen Adjustment Program. Load the EIZO LCD Utility Disk on the PC, and start the Screen Adjustment Program compatible with the PC in use. After the program starts up, perform the adjustment in step 4 following the instructions of the program. - Page 14 Perform advanced adjustments for the following using the <Screen> menu of the Adjustment menu. ● To eliminate vertical bars [Clock] (1) Choose <Clock> from the <Screen> menu, and press The <Clock> menu appears. (2) Adjust the clock with The adjustment is completed. ●...
- Page 15 Adjust the signal output range ● To adjust color gradation automatically [Range Adjustment] Every color gradation (0 to 255) can be displayed by adjusting the signal output level. (1) Choose <Range Adjustment> from the <Screen> menu, and press A message “Your setting will be lost it you press AUTO button” appears. (2) Press again while the message is displayed.
-
Page 16: Color Adjustment
2-3 Color Adjustment Simple adjustment [FineContrast menu] This function allows you to select the best display mode for monitor brightness, etc. ● FineContrast Mode An appropriate display mode is selectable out of fi ve modes. Mode Custom Available for making desired setting. Suitable for color matching with sRGB compatible sRGB peripherals. -
Page 17: Advanced Adjustments [Adjustment Menu]
Advanced Adjustments [Adjustment menu] Independent setting and saving of color adjustment are available for each FineContrast mode. ● To select an appropriate mode for images ✓ : Adjustment/setting available −: Factory setting Icon Function Custom ✓ Brightness ✓ Temperature ✓ Gamma ✓... -
Page 18: To Set/Adjust Color
Menu Description Gain To adjust red, green, and blue to a desired color tone respectively NOTE • Values shown in percentage are available only as reference. • The <Temperature> setting invalidates this setting. The <Gain> setting returns to the default setting. Reset To reset the color settings of the selected... -
Page 19: Off Timer/Power Saving Settings
2-5 Off Timer/Power Saving Settings ● To set monitor power-off time [Off Timer] This function allows the monitor to automatically turn off after a specifi ed time has passed. This function serves to reduce afterimages caused when the monitor screen is left on for a long time period without use. Use this function when an image is displayed throughout the day. -
Page 20: To Mute The Speaker With Power-Saving Setting [Power-Saving Mute]
■ Digital input This monitor complies with the “DVI DMPM” standard. [Power Saving System] Monitor Operating Operating Power saving Power saving [Procedure] (1) Choose <PowerManager> from the Adjustment menu, and press The <Set> menu appears. (2) Select “DVI DMPM” with The power saving setting is completed. -
Page 21: Eizo Logo Display Setting
● To display EIZO logo [EIZO Logo Appearing Function] When this unit is turned on, the EIZO logo appears at the center of the screen. Selection to display or not to display the logo is available with this function. [Procedure] (1) Press to power off the unit. -
Page 22: Setting Adjustment Menu Display
2-8 Setting Adjustment menu Display ● To update menu settings [Menu Position/Translucent/Menu Off Timer] Menu Position Adjust the menu position using the following procedure. (1) Choose <Others> from the Adjustment menu, and press (2) Choose <Menu Settings> from the <Others> menu, and press (3) Choose <Menu Position>... -
Page 23: Viewing Information/Setting Language
2-9 Viewing Information/Setting Language ● To check settings, usage time, etc. [Information] This function allows you to check settings, model name, serial number, and usage time of the monitor. (1) Choose <Information> from the Adjustment menu, and press The <Information> menu appears. (2) Then, press to check settings, etc. -
Page 24: Chapter 3 Connecting Cables
Chapter 3 Connecting Cables 3-1 Connecting Two PCs to the Monitor Two PCs can be connected to the monitor through the DVI-I and the D-Sub mini 15 pin connector on the back of the monitor. Connection examples DIV-D connector (SIGNAL1) PC 1 Signal cable (FD-C39 supplied) -
Page 25: To Set Auto-Switching Of Input Signals [Input Signal]
● To set auto-switching of input signals [Input Signal] The monitor recognizes the connector through which PC signals are input. When either PC is turned off or enters the power-saving mode, the monitor automatically displays signals of another PC. Priority setting Auto Manual [Input signal setting]... -
Page 26: Chapter 4 Troubleshooting
Chapter 4 Troubleshooting If a problem still remains after applying the suggested remedies, contact your local dealer. • No-picture problems → See No.1 - No.2. • Imaging problems → See No.3 - No.11. • Other problems → See No.12 - No.15. Problems No picture •... - Page 27 Problems The screen is too bright or too dark. Afterimages appear. Green/red/blue/white dots or defective dots remain on the screen. 10. Interference patterns or fi ngerprints remain on the screen. 11. The [Smoothing] icon on the Adjustment menu [Screen] cannot be selected. 12.
-
Page 28: Chapter 5 Reference
5-1 Attaching an Arm (Option) The stand can be removed and replaced with an arm (or another stand) to be attached to the monitor. Use an arm or stand of EIZO option. [Attaching] Lay the LCD monitor on a soft cloth spread over on a stable surface with the panel surface facing down. -
Page 29: Specifi Cations
5-3 Specifi cations LCD Panel 19.0-inch (480 mm) TFT color LCD with anti-glare hard coating Viewing angle: Horizontal: 170°; Vertical: 155° (CR>5) Dot Pitch 0.294 mm Horizontal Scan Frequency Analog: 24.8 - 80 kHz (Automatic) Digital: 31 - 64 kHz Vertical Scan Frequency Analog: 50 - 75.1 Hz (Automatic) Digital: 59 - 61 Hz... - Page 30 Main default settings (factory settings) Brightness Smoothing FineContrast Mode PowerManager Input Signal Off Timer Language Outside Dimensions Connector Pin Assignment • DIV-D connector 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 19 20 21 22 23 24 Pin No.
-
Page 31: Glossary
Characteristic”. A small gamma value produces a low-contrast image, while a large gamma value produces a high- contrast image. Pin No. Signal Red ground Green ground Blue ground Ground EIZO ScreenCleaner Pin No. Signal (Short-circuited to pin 10) Data (SDA) H. Sync V. Sync Clock (SCL) - Page 32 Resolution The LCD panel consists of numerous pixels of specifi ed size, which are illuminated to form images. The EIZO M1900 monitor consists of 1280 horizontal pixels and 1024 vertical pixels. At a resolution of 1280 × 1024, all pixels are illuminated as a full screen (1:1).
-
Page 33: Preset Timing
5-5 Preset Timing The following table shows factory preset video timing. Mode Dot clock VGA Graphic 320×200 25.2 MHz VGA TEXT 720×400 28.3 MHz VGA 640×480 25.2 MHz Macintosh 640×480 30.2 MHz Macintosh 832×624 57.3 MHz Macintosh 1152×870 100.0 MHz Macintosh 1280×960 126.2 MHz VESA 640×480... - Page 34 [Applicable to gray cabinet.] Congratulations! The display you have just purchased carries the TCO’03 Displays label. This means that your display is designed, manufactured and tested according to some of the strictest quality and environmental requirements in the world. This makes for a high performance product, designed with the user in focus that also minimizes the Impact on our natural environment.
- Page 35 [Applicable to black cabinet.] Congratulations! You have just purchased a TCO’99 approved and labelled product! Your choice has provided you with a product developed for professional use. Your purchase has also contributed to reducing the burden on the environment and also to the further development of environmentally adapted electronics products.
-
Page 36: Fcc Declaration Of Conformity
Changes or modifi cations not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Note Use the attached specifi ed cable below or EIZO signal cable with this monitor so as to keep interference within the limits of a Class B digital device. - AC Cord... - Page 37 Hinweise zur Auswahl des richtigen Schwenkarms für Ihren Monitor Dieser Monitor ist für Bildschirmarbeitsplätze vorgesehen. Wenn nicht der zum Standardzubehör gehörige Schwenkarm verwendet wird, muss statt dessen ein geeigneter anderer Schwenkarm installiert werden. Bei der Auswahl des Schwenkarms sind die nachstehenden Hinweise zu berücksichtigen: Der Standfuß...
- Page 38 Recycle Auskunft Die Rücknahme dieses Produktes nach Nutzungsende übernimmt EIZO in Deutschland zusammen mit dem Partner eds-r gmbh rucknahmesysteme. Dort werden die Geräte in ihre Bestandteile zerlegt, die dann der Wiederverwertung zugeführt werden. Um einen Abholtermin zu vereinbaren und die aktuellen Kosten zu erfahren, benutzen Sie bitte folgende Rufnummer: 02153-73 35 00.
