Z600 Series Color Jetprinter™
User's Guide for Mac OS X
• Setup troubleshooting
A checklist to find solutions to common setup
problems.
• Printer overview
Learn about the printer parts and the printer software.
• Printing ideas
How to print several projects on various types of
paper.
• Maintenance
Caring for your cartridges and ordering supplies.
• General troubleshooting
Error messages, print quality problems, paper jams,
and much more.
January 2003
www.lexmark.com
Advertisement
Table of Contents
Troubleshooting
Related Manuals for Lexmark Z601
Summary of Contents for Lexmark Z601
- Page 1 Learn about the printer parts and the printer software. • Printing ideas How to print several projects on various types of paper. • Maintenance Caring for your cartridges and ordering supplies. • General troubleshooting Error messages, print quality problems, paper jams, and much more. January 2003 www.lexmark.com...
- Page 2 Lexington, Kentucky 40550, U.S.A. In the United Kingdom and Eire, send to Lexmark International Ltd., Marketing and Services Department, Westhorpe House, Westhorpe, Marlow Bucks SL7 3RQ. Lexmark may use or distribute any of the information you supply in any way it believes appropriate without incurring any obligation to you. You can purchase additional copies of publications related to this product by calling 1-800-553-9727.
-
Page 3: Table Of Contents
Contents Chapter 1: Printer overview ............5 Understanding the printer parts..............5 Understanding the printer software ..............6 Chapter 2: Printing ideas............. 12 Printing on plain paper ................. 12 Printing on premium paper ................15 Printing cards ....................17 Printing envelopes..................18 Printing color images in black and white ............ - Page 4 Chapter 5: General troubleshooting........... 44 Solving network printing problems, if the printer is connected to a network adapter..................44 Understanding error messages and flashing lights ........45 Resolving unsuccessful or slow printing............46 Clearing paper misfeeds or jams..............49 Solving print quality problems ..............50 Solving specialty media problems ..............
-
Page 5: Chapter 1: Printer Overview
Printer overview Understanding the printer parts Button Paper support Front cover Paper guide Paper exit tray Power supply connector USB cable connector Printer overview... -
Page 6: Understanding The Printer Software
Use this: When you want to: Button • Turn the printer on or off. • Eject paper from the printer. • Cancel print jobs. • Check the printer status. For more information, see “Understanding error messages and flashing lights” on page 45. Front cover •... -
Page 7: Page Setup Dialog
Page Setup dialog While the document you want to print is open, use the Page Setup dialog to select settings such as paper size. To customize the settings in the Page Setup dialog: From the software program, choose File Page Setup. A screen similar to the following appears. -
Page 8: Print Dialog
Print dialog While your document is open, you can use the Print dialog to select settings that affect the appearance of your document. To customize the settings in the Print dialog: From the software program, choose File Print. A screen similar to the following appears. From the Printer pop-up menu, choose Z600 Series. - Page 9 Services Troubleshooting Get a direct link to the Help Center. Order Supplies Get a direct link to the Lexmark Web site. Software Version View installed files on the printer software version. Summary View a summary of the current print settings.
- Page 10 Print Test Page Verify if your printer is functioning properly. Order Supplies Order supplies, such as print cartridges, from the Lexmark Web site. For more information, see “Ordering supplies” on page 38. Offers Access the Lexmark Web site for offers.
- Page 11 Click the: Select: When you want to: Advanced menu Select Printer • Select a printer and make it the default printer. • Find the IP address for the selected printer. • Add a printer located on a remote subnet. You can add a single printer or search the subnet for all available printers.
-
Page 12: Chapter 2: Printing Ideas
Printing ideas Printing on plain paper You can print up to 100 sheets of paper at a time, depending on the thickness of the paper. Step 1: Load the paper • Load the paper vertically against the right side of the paper support. •... - Page 13 Step 2: Customize the print settings If you are using A4 or letter size paper and you want to print with Normal print quality, you do not need to adjust the settings. If you are using specialty media, customize the settings by following the steps for your paper type. Step 3: Print your document From the software program, choose File Print.
- Page 14 • Squeeze and slide the paper guide to the left edge of the paper. Note: If you are using Letter size paper, adjusting the paper guide may not be necessary. Step 2: Customize the print settings Choose a paper size and orientation: From the software program, choose File Page Setup.
-
Page 15: Printing On Premium Paper
Step 3: Print your photos Click Print. Note: To prevent smearing, remove each photo as it exits the printer, and then let it dry before stacking. Printing on premium paper You can load up to 100 pages of premium paper, depending on the thickness of the paper. Step 1: Load the premium paper •... - Page 16 • Squeeze and slide the paper guide to the left edge of the paper. Note: If you are using Letter size paper, adjusting the paper guide may not be necessary. Step 2: Customize the print settings Choose a paper size and orientation: From the software program, choose File Page Setup.
-
Page 17: Printing Cards
Printing cards You can load up to 25 greeting cards, index cards, photo cards, or postcards into the paper support, depending on the thickness of the cards. Step 1: Load the cards • If your cards include instructions, read them carefully. •... -
Page 18: Printing Envelopes
Step 2: Customize the print settings Choose a paper size and orientation: From the software program, choose File Page Setup. From the Format for pop-up menu, choose Z600 Series. From the Settings pop-up menu, choose Page Attributes. From the Paper Size pop-up menu, choose a card size. From Orientation, click the portrait, landscape, or reverse landscape icon. - Page 19 Step 1: Load the envelopes • Load the envelopes vertically against the right side of the paper support. Note: Do not use envelopes with holes, windows, deep embossing, metal clasps, string ties, or metal folding bars. • Make sure your envelopes are not used or damaged. •...
-
Page 20: Printing Color Images In Black And White
From Orientation, make sure to click the landscape icon. Note: Many software programs are designed to override the envelope settings in Page Setup. Make sure landscape orientation is also selected in your software program. Click OK. Choose a paper type and print quality: From the software program, choose File Print. -
Page 21: Load The Paper
Load the paper • Load the paper vertically against the right side of the paper support. • Make sure your paper is not used or damaged. • Make sure the print side is facing you. • Do not force the paper into the printer. •... -
Page 22: Printing Labels
Step 3: Print your document Click Print. Note: The paper exit tray holds up to 50 sheets of paper or 10 photo cards. To print more than 50 sheets of paper, remove the first 50 sheets, and then continue printing. To print more than 10 photo cards, remove the first 10 cards, and then continue printing. - Page 23 • Squeeze and slide the paper guide to the left edge of the sheet of labels. Step 2: Customize the print settings Choose a paper size and orientation: From the software program, choose File Page Setup. From the Format for pop-up menu, choose Z600 Series. From the Settings pop-up menu, choose Page Attributes.
-
Page 24: Printing Handouts
Printing handouts You can conserve paper by printing handouts. Handouts are multiple pages of a document printed on one sheet of paper. You can load up to 100 sheets of paper, depending on the thickness of the paper. Step 1: Load the paper •... - Page 25 Step 2: Customize the print settings You can print your handouts on one side or on both sides of the paper. Choose a paper size and orientation: From the software program, choose File Page Setup. From the Format for pop-up menu, choose Z600 Series. From the Settings pop-up menu, choose Page Attributes.
-
Page 26: Printing Iron-On Transfers
Printing iron-on transfers You can load up to 100 iron-on transfers, depending on the thickness of the iron-on transfers. You may want to print your image on plain paper before printing it on an iron-on transfer. This ensures you do not waste iron-on transfers perfecting the image you want to print. When the image prints to your satisfaction, load the iron-on transfers. - Page 27 • Squeeze and slide the paper guide to the left edge of the iron-on transfers. Note: If you are using Letter size paper, adjusting the paper guide may not be necessary. Step 2: Customize the print settings Choose a paper size and orientation: From the software program, choose File Page Setup.
-
Page 28: Printing Transparencies
• From the pop-up menu in the upper left corner, choose Advanced Layout. • Make sure Mirror is not checked. Step 3: Print your iron-on transfers Click Print. Note: To prevent smudging, remove each iron-on transfer as it exits the printer, and then let it dry before stacking. - Page 29 • Squeeze and slide the paper guide to the left edge of the transparencies. Note: If you are using Letter size paper, adjusting the paper guide may not be necessary. Step 2: Customize the print settings Choose a paper size and orientation: From the software program, choose File Page Setup.
-
Page 30: Printing Your Document In Reverse Order
Step 3: Print your transparencies Click Print. Note: To prevent smudging, remove each transparency as it exits the printer, and then let it dry before stacking. Transparencies may require up to 15 minutes to dry. Printing your document in reverse order Step 1: Load the paper •... - Page 31 Step 2: Customize the print settings Choose a paper size and orientation: From the software program, choose File Page Setup. From the Paper Size pop-up menu, choose the paper size for your document. From Orientation, click the portrait, landscape, or reverse landscape icon. Click OK.
-
Page 32: Chapter 3: Maintenance
Maintenance Replacing the print cartridges The Z600 Series uses the following cartridges: Item: Part number: Black cartridge 16 or 17 Color cartridge 26 or 27 Note: You can use the printer with just a color cartridge or just a black cartridge. For information about ordering supplies, see page 38. - Page 33 Lift the cartridge carrier lids. Remove the used cartridges. Store them in an airtight container or dispose of them properly. Install the cartridges If you are installing new cartridges, remove the sticker and transparent tape from the backs and bottoms of the cartridges. Warning: Do not touch or remove the gold contact areas on the backs and bottoms of the cartridges.
- Page 34 Insert the color cartridge in the left carrier. Insert the black cartridge in the right carrier. Note: To extend the life of your color cartridge and improve printing speed, install a black cartridge along with the color cartridge. Snap the lids closed. Close the front cover.
-
Page 35: Specifying Cartridge Settings In The Printer Software
Specifying cartridge settings in the printer software Before you specify the print cartridge settings in the printer software, install the cartridges. For help, see “Install the cartridges” on page 33. After installing the cartridges, open the printer utility by double-clicking the Z600 Series Printer folder on your desktop, and then double-clicking Z600 Series Utility. -
Page 36: Improving Print Quality
Use the arrows in the Align Cartridges dialog to select the number that matches the darkest arrow on the printed page for each alignment group. Click OK. If the alignment page does not print, see “Alignment page does not print” on page 48. Improving print quality If you are not satisfied with the print quality of your document, first make sure you: •... -
Page 37: Preserving The Print Cartridges
The print cartridges do print correctly if left exposed for an extended period. Lexmark’s printer warranty does not cover repair of failures or damage caused by a refilled cartridge. We do not recommend the use of refilled cartridges. Refilling cartridges can affect print quality and cause damage to the printer. -
Page 38: Ordering Supplies
Ordering supplies To order supplies or locate a dealer near you, contact the Lexmark Web site at www.lexmark.com. Item: Part number: Color cartridge 26 or 27 Black cartridge 16 or 17 USB cable 12A2405 Ordering supplies... -
Page 39: Chapter 4: Setup Troubleshooting
Are both your printer and computer on? If you are using your printer on a network, make sure your computer is connected to the network, your Lexmark adapter is on, and all indicator lights are on. For more information, refer to the adapter documentation. - Page 40 Is the printer set as the default or current printer? To make sure that your printer is set as the default printer: From the Dock, click the Print Center icon. The Printer List dialog appears. Make sure that the Z600 Series is highlighted in the list. To make sure that your printer is set as the current printer: With your document open, choose File Page Setup.
-
Page 41: Solving Printer Software Installation Problems
There are two ways to uninstall the printer software. One way to uninstall it is as follows: From your desktop, double-click the Lexmark Z600 Series CD icon. If the CD icon is not on your desktop, insert the printer software CD to relaunch it. - Page 42 For help, see “Clearing paper misfeeds or jams” on page 49. Using the World Wide Web Make sure Stuffit Expander is loaded on your system. From the Lexmark Web site, www.lexmark.com, select the appropriate driver for your operating system. Click the binhex (.hqx) file to download and install.
- Page 43 Double-click Install. Follow the instructions on your screen to install the printer software. Solving printer software installation problems...
-
Page 44: Chapter 5: General Troubleshooting
General troubleshooting For information about: See page: Solving network printing problems, if the printer is connected to a network adapter Understanding error messages and flashing lights Resolving unsuccessful or slow printing Clearing paper misfeeds or jams Solving print quality problems Solving specialty media problems Solving network printing problems, if the printer is connected to a network adapter... -
Page 45: Understanding Error Messages And Flashing Lights
Understanding error messages and flashing lights Use this section to understand printer software error messages on your computer screen and blinking lights on your printer.For information about lights on a Lexmark adapter, refer to the adapter documentation. Understanding error messages and flashing lights... -
Page 46: Resolving Unsuccessful Or Slow Printing
The printer is on and the printer cable is securely attached at both ends. If your printer is connected to a network, make sure the Lexmark adapter is on and all indicator lights are on. For help, refer to the adapter documentation. -
Page 47: Printing A Test Page
• The printer is not held or paused. To check the printer status: From the Dock, click the Print Center icon. The Printer List dialog appears. Highlight the Z600 Series in the list. From Queue menu, choose Start Queue. From the Printers menu, choose Show Queue. Select your job from the list. - Page 48 You loaded the paper correctly and did not force the paper into the printer. • If you are connected to a network with a Lexmark adapter, the indicator lights are on. For more information, see the adapter documentation. Printer ejects a blank page after appearing to print Make sure: •...
-
Page 49: Clearing Paper Misfeeds Or Jams
Clearing paper misfeeds or jams The following topics can help you correct paper misfeeds or jams. Paper misfeeds or multiple sheets feed Make sure: • The edges of your paper are not curled. • Your paper is designed for inkjet printers. •... -
Page 50: Solving Print Quality Problems
From the Printers menu, choose Show Queue. Select a job from the list. Click Resume or Retry. Printer has a paper jam If the paper is lodged too far into the printer and cannot be removed: Turn the printer off. Turn the printer back on. -
Page 51: Printed Characters Are Improperly Formed Or Misaligned
• Try aligning the print cartridge nozzles. For help, see “Aligning the print cartridges” on page 35. • Try cleaning the print cartridge nozzles. Follow the steps in “Improving print quality” on page 36. Print smears on the page • The next page exiting the printer may be smearing the ink. - Page 52 Make sure that the Z600 Series is highlighted in the list. From the Queue menu, choose Start Queue. From the Printers menu, choose Show Queue. Select the job you want to delete. Click Delete. Repeat steps 5 through 6 until all jobs are deleted. •...
-
Page 53: Solving Specialty Media Problems
Solving specialty media problems Use this section to help solve problems with specialty media. Glossy/photo papers or transparencies stick together • Use glossy/photo paper or transparency designed for inkjet printers. • Make sure you loaded the paper correctly (with print side facing you) and selected the appropriate settings in the printer software. -
Page 54: Notices
Federal Communications Commission (FCC) compliance information statement The Lexmark Z600 Series Color Jetprinter, type 4126-001, has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. - Page 55 Japanese VCCI notice...
-
Page 56: Glossary
Glossary alignment page. A page with printed alignment patterns that ejects from your printer during cartridge alignment. alignment values. Numbers corresponding to patterns on the alignment page. application. See program. automatic alignment. A feature that automatically aligns the print cartridges. banner paper. - Page 57 Page orientation in which text runs parallel with the long edge of the paper. Lexmark adapter. An external device that connects your network-capable printer to a network. local subnet. See LAN (local area network). long-edge binding. A printer software option that arranges duplexed pages so they can be bound along the long side of the pages.
- Page 58 network-capable printer. A printer that you can connect to a network. Some network-capable printers may require an external network adapter. operating system. The software that provides the basic functions needed for operating your computer. For example, Windows 98 or Macintosh OS X. paper type sensor.
- Page 59 reverse order printing. A printer software option that lets you print the last page of your document first so your pages are in sequential order on the exit tray. short-edge binding. A printer software option that arranges duplexed pages so they can be bound along the short side of the pages.
-
Page 60: Index
36 T-shirt transfers installing 33 labels 22 See iron-on transfers ordering 38 last page first, printing 30 part numbers 38 Lexmark Utility 9 preserving 37 loading dark or smudged print 50 removing 32 cards 17 downloaded printer driver, replacing 32... - Page 61 See handouts printer settings, customizing 6 printer software installing 41 ordering supplies 38 Lexmark Utility 9 removing print cartridges 32 overview 6 replacing the print cartridge 32 Page Setup dialog 7 page settings, changing 6 Print dialog 8...
- Page 62 50 paper misfeeds 49 print quality 50 printer cable 39 printer not printing 46 printer software installation software 41 specialty paper 53 unsuccessful or slow printing uninstalling printer software 41 USB cable connector 6 ordering 38 Utility, Lexmark 9...
- Page 63 Lexmark and Lexmark with diamond design are trademarks of Lexmark International, Inc., registered in the United States and/or other countries. Color Jetprinter is a trademark of Lexmark International, Inc. © 2003 Lexmark International, Inc. 740 West New Circle Road Lexington, Kentucky 40550...
