- Page 1 Trumpet/Cornet/Flugelhorn/ Rotary Trumpet Owner’s Manual Trompete/Kornett/Flügelhorn/ Drehventiltrompete Bedienungsanleitung Trompette/Cornet/Bugle/ Trompette à palettes Mode d’emploi Trompeta/Corneta/Fliscorno/ Trompeta de cilindros Manual de instrucciones 小号 / 短号 / 富鲁格号 / 转阀式小号 使用手册 Труба/Корнет/Флюгельгорн/ Педальная труба Руководство пользователя 트럼펫 / 코넷 / 후루겔혼 / 로터리...
- Page 2 Usted es ahora propietario de un instrumento musical de alta calidad. Le agradecemos su elección de un instrumento Yamaha. Le aconsejamos que lea todo este manual de instrucciones para ver las instrucciones para el montaje correcto del instrumento y para aprender a conservar el instrumento P.51...
- Page 3 Trumpet/Cornet/ Fluegelhorn/Rotary Trumpet Owner’s Manual Precautions Please read before using The precautions given below concern the proper and safe use of the instrument, and are to protect you and others from any damage or injuries. Please follow and obey these precautions. If children are using the instrument, a guardian should clearly explain these precautions to the child and make sure they are fully understood and obeyed.
- Page 4 Nomenclature ■ Trumpet 1st Valve 2nd Valve Bell 3rd Valve Mouthpiece Receiver 3rd Valve Water Key Lead Pipe Finger Hook Mouthpiece 1st Valve Slide Hook 3rd Valve Slide 1st Valve Slide Main Water 3rd Valve Slide Ring 2nd Valve Slide Main Tuning Slide Valve 3rd Valve Slide...
- Page 5 Nomenclature ■ Flugelhorn 1st Valve 2nd Valve 3rd Valve Bell Finger Hook Mouthpiece Receiver Mouthpiece 2nd Valve Slide 1st Valve Slide Main Water Key Valve Casing 3rd Valve Water Key 3rd Valve Slide Trigger 1st Valve Water Key 3rd Valve Slide ■...
-
Page 6: Before You Play
Before You Play Handling the Instrument As the trumpet is made of thin metal, handle the instrument carefully. Do not apply any excessive force, or bump the instrument so as to dent or damage it. ■ Applying Oil Apply oil to the pistons Applying Oil To The Rotors (Rotary Trumpets Only) Unscrew the valve cap and pull the piston... -
Page 7: Setting The Mouthpiece
Before You Play ■ Applying Oil To The Valve ■ CAUTION—Preventing The Slides 3rd Valve Slide From Falling Off. Depress the piston that corresponds to the slide that you want to apply oil and partially On instruments fitted with a stopper screw, remove the slide. - Page 8 Before You Play ■ Tuning Slide the main tuning slide in or out to Flugelhorn/Piccolo Trumpet/ tune the instrument. Since changes in temperature can have an effect on the Eb Cornet pitch, blow some warm air into the in- Loosen the mouthpipe screw and slide the strument to warm it up before tuning.
-
Page 9: Other Maintenance
Maintenance ■ After playing After playing, make sure that moisture or dirt is removed from the instrument using the method described below. ● ● Valve slide maintenance Other maintenance Depress the piston that corresponds to the Apply some valve oil to the pistons and move valve slide you want to clean, and remove the piston up and down a few times, the same the slide. - Page 10 Maintenance ■ Once or twice a month main- Return the piston to its corresponding valve casing. tenance After confirming that the number stamped on the piston matches the number stamped ● Piston and valve casing maintenance on the valve casing, carefully insert the pis- The trumpet’s valves are designed with very little ton straight into the valve casing with the clearance between the piston and the casing there-...
-
Page 11: Rotor Maintenance
Maintenance ● Rotor maintenance ● Valve slide maintenance (Rotary trumpets only) Apply a thin coating of slide grease to the Remove the rotary valve cap and apply some main tuning slide, 2nd valve slide, and valve rotor spindle oil to the place to the spindle slides that are not equipped with a slide trig- in the center of the rotor. - Page 12 Maintenance ■ Twice Yearly Maintenance ● Cleaning the mouthpiece ● Cleaning the instrument Dip the mouthpiece brush in the brass soap water solution and clean the mouthpiece Make a brass soap water solution. throat with the brush. Rinse the mouthpiece Prepare a brass soap water solution using out with clean water.
-
Page 13: Troubleshooting
Troubleshooting Tone is not clear and pitch is poor. The screw is too tight and cannot be removed. • The valves are dirty. ➞ Clean the valves. • The screw is corroded. • There is a large dent or air is leaking •... - Page 14 /Fingering Chart/Grifftabelle/ Alternative Griffe stehen in Klammern ★ ★ Les autres doigtés de remplacement Alternate fingerings are given in paren- ★ ★ sont indiqués entre parenthèse thesis /Trumpet/Trompete/ /Cornet/Kornett/ ■ ■ Trompette/Trompeta/ 小号 Cornet/Corneta/ 短号 /Корнет/ 트럼펫 코넷 /Труба/ (1.3) 1.2.3 2.3 1.2.3...
- Page 15 /Таблица аппликатуры/ 운지법 Tablature/Tabla de digitaciones/ 指法表 Se muestran digitaciones alternativas Д о п о л н и т е л ь н а я а п п л и к а т у р а ★ ★ entre paréntesis указана...
- Page 16 This document is printed on chlorine free (ECF) paper with soy ink. Auf Umweltpapier mit Sojatinte gedruckt. Ce document a été imprimé sur du papier non blanchi au chlore avec de l’encre d’huile de soja. Este documento se ha impreso en papel sin cloro alguno, con tinta de soja. 此说明书纸张为无氯漂染纸...
