MULTIMEDIA PROJECTOR
LC-XB29N
MODEL
OWNER'S MANUAL
Network Supported
❏ Wireless LAN (optionally available)
IEEE802.11b/g
❏ Wired LAN
100-Base-TX/10-Base-T
Memory Viewer
❏ USB Memory Viewer (optionally available)
Compatible with a dedicated USB memory
✽Refer to the owner's manuals below for details
about network and memory viewer function.
■ Network Set-up and Operation
■ Owner's Manual USB Memory
This manual is provided with optionally
supplied USB memory (Model: WL-10).

Advertisement

Table of Contents
loading

Summary of Contents for Eiki LC-XB29N

  • Page 1 MULTIMEDIA PROJECTOR LC-XB29N MODEL OWNER’S MANUAL Network Supported ❏ Wireless LAN (optionally available) IEEE802.11b/g ❏ Wired LAN 100-Base-TX/10-Base-T Memory Viewer ❏ USB Memory Viewer (optionally available) Compatible with a dedicated USB memory ✽Refer to the owner's manuals below for details about network and memory viewer function.
  • Page 2: Features And Design

    Features and Design This Multimedia Projector is designed with the most advanced technology for portability, durability, and ease of use. This projector utilizes built-in multimedia features, a palette of 16.77 million colors, and matrix liquid crystal display (LCD) technology. ◆ Compact Design This projector is designed compact in size and weight.
  • Page 3: Table Of Contents

    Table of Contents Features and Design ....2 Table of Contents ..... .3 To the Owner .
  • Page 4: To The Owner

    NOTE: This symbol and recycle system are applied only to EU countries and not applied to the countries in the other area of the world. Your EIKI product is designed and manufactured materials and components which can be recycled and reused.
  • Page 5: Safety Instructions

    Safety Instructions All the safety and operating instructions should be read before the product is operated. Read all of the instructions given here and retain them for later use. Unplug this projector from AC power supply before cleaning. Do not use liquid or aerosol cleaners. Use a damp cloth for cleaning.
  • Page 6: Air Circulation

    Safety Instructions Air Circulation Openings in the cabinet are provided for ventilation. To ensure reliable operation of the product and to protect it from overheating, these openings must not be blocked or covered. CAUTION Hot air is exhausted from the exhaust vent. When using or installing the projector, the following precautions should be taken.
  • Page 7: Installing The Projector In Proper Directions

    Installing the Projector in Proper Directions Use the projector properly in specified positions. Improper positioning may reduce the lamp life and result in severe accident or fire hazard. Positioning Precautions Avoid positioning the projector as described below when installing. 20˚ Do not tilt the projector more than 20 degrees from side to side.
  • Page 8: Compliance

    Model Number : LC-XB29N Trade Name : EIKI Responsible party : EIKI International, Inc. Address : 30251 Esperanza Rancho Santa Margarita CA 92688-2132 Telephone No. : 800-242-3454 (949-457-0200) The AC Power Cord supplied with this projector meets the requirement for use in the country you purchased it.
  • Page 9: Part Names And Functions

    Part Names and Functions Front Back Bottom ✽ q USB Terminal w LAN Connection Terminal e Zoom Lever r Projection Lens t Focus Ring y Lens Cover (See page 60 for attaching.) u Infrared Remote Receiver i Top Controls and Indicators o Speaker !0 Air Intake Vent !1 Power Cord Connector...
  • Page 10: Rear Terminal / Side Terminal

    Part Names and Functions Rear Terminal / Side Terminal SERVICE PORT COMPUTER IN 1 Rear Terminal q USB (Series B) In order to operate the computer with the remote control and use the PAGE ed buttons on the remote control during a presentation, connect the USB port of the computer to the USB terminal with a USB cable.
  • Page 11: Top Control

    Top Control SELECT button – Execute the selected item. (p.23) – Expand or compress the image in Digital zoom mode. (p.37) POWER ON–OFF button Turn the projector on or off. (pp.21, 22) MENU button Open or close the On-Screen Menu. (p.23) POWER indicator Emit a red light until the projector gets ready to be turned on.
  • Page 12: Remote Control

    Part Names and Functions Remote Control To ensure safe operation, please observe the following precautions: – Do not bend, drop, or expose the remote control to moisture or heat. – For cleaning, use a soft dry cloth. Do not apply benzene, thinner, splay, or any chemical material.
  • Page 13: Laser Pointer Function

    Laser Pointer Function This remote control emits a laser beam from the laser light window. Press the LASER button to activate the laser pointer. The signal emission indicator lights red and the red laser beam is emitted. If the LASER button is pressed for more than one minute or if it is released, the laser light goes off.
  • Page 14: Pointer Function

    Part Names and Functions Wireless Mouse Operation The remote control can be used as a wireless mouse for your computer. Before operating the wireless mouse, connect your computer and the projector with the supplied USB cable. See “Connecting to a Computer” on page 17.
  • Page 15: Remote Control Battery Installation

    Remote Control Battery Installation Open the battery compartment lid. Press the lid downward and slide it. To insure safe operation, please observe the following precautions : ● Use two (2) AAA or LR03 type alkaline batteries. ● Always replace batteries in sets. ●...
  • Page 16: Installation

    Installation Positioning the Projector For projector positioning, see the figures below. The projector should be set perpendicularly to the plane of the screen. ✔ Notes: •The brightness in the room has a great influence on picture quality. It is recommended to limit ambient lighting in order to obtain the best image.
  • Page 17: Connecting To A Computer

    Connecting to a Computer Cables used for connection • VGA Cable (Mini D-sub 15 pin) ✽ • DVI Cable ✽ • DVI-VGA Cable • USB Cable • Audio Cables ✽ (✽ = Not supplied with this projector.) Audio Output USB port USB cable Audio cable (stereo) ✽...
  • Page 18: Connecting To Video Equipment

    Installation Connecting to Video Equipment Cables used for connection • Video and Audio Cable (RCA x 3) ✽ • S-VIDEO Cable ✽ • Audio Cable ✽ (✽ = Not supplied with this projector.) S-video cable ✽ COMPUTER IN 1 SERVICE PORT ✔...
  • Page 19: Connecting To Component Video Equipment

    Connecting to Component Video Equipment Cables used for connection • Audio Cables ✽ • Scart-VGA Cable ✽ • Component Cable ✽ • Component-VGA Cable ✽ (✽ = Not supplied with this projector.) Audio Output RGB Scart 21- Audio cable ✽ Scart-VGA cable ✽...
  • Page 20: Connecting The Ac Power Cord

    Installation Connecting the AC Power Cord This projector uses nominal input voltages of 100–120 V or 200–240 V AC and it automatically selects the correct input voltage. It is designed to work with single-phase power systems having a grounded neutral conductor. To reduce the risk of electrical shock, do not plug into any other type of power system.
  • Page 21: Basic Operation

    Basic Operation Turning On the Projector Complete peripheral connections (with a computer, VCR, etc.) before turning on the projector. Connect the projector’s AC power cord into an AC outlet. The POWER indicator lights red. Press the POWER ON-OFF button on the top control or on the remote control.
  • Page 22: Turning Off The Projector

    Basic Operation Turning Off the Projector Press the POWER ON-OFF button on the top control or on the remote control, and “Power off?” appears on the screen. Press the POWER ON-OFF button again to turn off the projector. The POWER indicator starts to blink red, and the cooling fans keep running.
  • Page 23: How To Operate The On-Screen Menu

    How to Operate the On-Screen Menu The projector can be adjusted or set via the On-Screen Menu. For each adjustment and setting procedure, refer to the respective sections in this manual. Press the MENU button on the top control or the remote control to display the On-Screen Menu.
  • Page 24: Menu Bar

    Basic Operation Menu Bar For detailed functions of each menu, see “Menu Tree” on pages 64–65. For computer source Guide Window PC System Menu Show the selected Used to select Menu of the On- computer Screen Menu. system (p.30). Input Menu PC Adjust Menu Used to select an Used to adjust...
  • Page 25: Sound Adjustment

    Sound Adjustment Direct Operation Volume Press the VOLUME+/– buttons on the top control or on the remote control to adjust the volume. The volume dialog box appears on the screen for a few seconds. Mute Press the MUTE button on the remote control to temporarily turn off the sound.
  • Page 26: Auto Setup Function

    Basic Operation Auto Setup Function Auto setup function is provided to automatically correct Keystone distortion according to the projector’s tilt and adjust the computer display parameters (Fine sync, Total dots, and Picture position) by just pressing the AUTO SET UP button on the top control or the AUTO SET button on the remote control.
  • Page 27 FREEZE button Press the FREEZE button on the remote control to freeze the picture on the screen. To cancel the Freeze function, press the FREEZE button again or press any other button. AUTO PC button Press the AUTO PC button on the remote control to operate the Auto PC Adj.
  • Page 28: Computer Input

    Computer Input Input Source Selection (RGB: Computer 1 (Analog)/Computer 2 ) Direct Operation Choose either Computer 1 (Analog) or Computer 2 by pressing the INPUT button on the top control or press the COMPUTER button on the remote control. Before using these buttons, correct input source should be selected through Menu operation as described below.
  • Page 29: Input Source Selection (Rgb(Pc Digital), Rgb(Av Hdcp))

    Input Source Selection (RGB(PC digital), RGB(AV HDCP)) Direct Operation Choose Computer 1(Digital) by pressing the INPUT button on the top control or press the COMPUTER button on the remote control. Before using these buttons, correct input source should be selected through Menu operation as described below. Menu Operation Press the MENU button to display the On-Screen Menu.
  • Page 30: Computer System Selection

    Computer Input Computer System Selection This projector automatically tunes to various types of computers based on VGA, SVGA, XGA, SXGA, WXGA, or UXGA with its Multi-scan system and Auto PC Adjustment. If a computer is selected as a signal source, this projector automatically detects the signal format and tunes to project a proper image without any additional settings.
  • Page 31: Auto Pc Adjustment

    Auto PC Adjustment Auto PC Adjustment function is provided to automatically adjust Fine sync, Total dots, Horizontal and Vertical positions to conform to your computer. Direct Operation The Auto PC adjustment function can be operated directly by pressing the AUTO PC button on the remote control. Menu Operation Auto PC Adj.
  • Page 32: Manual Pc Adjustment

    Computer Input Manual PC Adjustment Some computers employ special signal formats which may not be tuned by Multi-scan system of this projector. Manual PC Adjustment enables you to precisely adjust several parameters to match those signal formats. The projector has five independent memory areas to store those parameters manually adjusted. It allows you to recall the setting for a specific computer.
  • Page 33 Display area H Use the Point buttons to adjust the horizontal area displayed by this projector. Display area V Use the Point buttons to adjust the vertical area displayed by this projector. Reset To reset the adjusted data, select Reset and press the SELECT button.
  • Page 34: Image Mode Selection

    Computer Input Image Mode Selection Direct Operation Select the desired image mode from among Dynamic, Standard, Real, Blackboard (Green), Image 1, Image 2, Image 3, and Image 4 by pressing the IMAGE button on the remote control. Dynamic For viewing pictures in a bright room. Standard Normal picture mode preset on the projector.
  • Page 35: Image Adjustment

    Image Adjustment Press the MENU button to display the On-Screen Menu. Use the Point buttons to move the red frame pointer to the Image Adjust Menu icon. Use the Point buttons to move the red frame pointer to the desired item and then press the SELECT button to display the adjustment dialog box.
  • Page 36: Screen Size Adjustment

    Computer Input Store To store the adjusted data, select Store and press the SELECT button. Use the Point from Image 1 to 4 and press the SELECT button. A confirmation box appears and then select [Yes]. Stored data can be called up by selecting an “Image (1–4)” in the Image Mode Selection on page 34.
  • Page 37 For zooming in and out the images Digital zoom + Select Digital zoom +. The On-Screen Menu disappears and “D. zoom +” appears. Press the SELECT button to expand the image size. Use the Point ed7 8 image. The Panning function can work only when the image is larger than the screen size.
  • Page 38: Video Input

    Video Input Input Source Selection (Video, S-video) Direct Operation Choose Video by pressing the INPUT button on the top control or the VIDEO button on the remote control. Before using these buttons, correct input source should be selected through menu operation as described below. Menu Operation Press the MENU button to display the On-Screen Menu.
  • Page 39: Input Source Selection (Component, Rgb Scart 21-Pin)

    Input Source Selection (Component, RGB Scart 21-pin) Direct Operation Choose Computer 2 by pressing the INPUT button on the top control or press the COMPUTER button on the remote control. Before using these buttons, correct input source should be selected through Menu operation as described below. Menu Operation Press the MENU button to display the On-Screen Menu.
  • Page 40: Video System Selection

    Video Input Video System Selection Press the MENU button to display the On-Screen Menu. Use the Point frame pointer to the AV System Menu icon. Use the Point buttons to move the red arrow pointer to the desired system and then press the SELECT button.
  • Page 41: Image Mode Selection

    Image Mode Selection Direct Operation Select the desired image mode from among Dynamic, Standard, Cinema, Blackboard (Green), Image 1, Image 2, Image 3, and Image 4 by pressing the IMAGE button on the remote control. Dynamic For viewing pictures in a bright room. Standard Normal picture mode preset on the projector.
  • Page 42: Image Adjustment

    Video Input Image Adjustment Press the MENU button to display the On-Screen Menu. Use the Point frame pointer to the Image Adjust Menu icon. Use the Point buttons to move the red frame pointer to the desired item and then press the SELECT button to display the adjustment dialog box.
  • Page 43 Sharpness Press the Point button to decrease the sharpness of the image; press the Point button to increase the sharpness of the image (from 0 to 15). Gamma Use the Point buttons to adjust the gamma value to obtain a better balance of contrast (from 0 to 15). Noise reduction Noise interference on the screen can be reduced.
  • Page 44: Screen Size Adjustment

    Video Input Screen Size Adjustment This projector has the picture screen resize function, which enables you to customize the image size. Press the MENU button to display the On-Screen Menu. Use the Point frame pointer to the Screen Menu icon. Use the Point buttons to move the red frame pointer to the desired function and then press the...
  • Page 45: Setting

    Setting Setting This projector has a Setting menu that allows you to set up the other various functions described below. Press the MENU button to display the On-Screen Menu. Use the Point frame pointer to the Setting Menu icon. Use the Point buttons to move the red frame pointer to the desired item and then press the SELECT button.
  • Page 46 Setting Keystone This function is used to store or reset the keystone correction when the AC power cord is unplugged. Use the Point buttons to switch between each option. Store ... Keep the keystone correction even when the AC power cord is unplugged. Reset ...
  • Page 47 Logo (Logo and Logo PIN code lock settings) This function allows you to customize the screen logo with Logo select, Capture, and Logo PIN code lock functions. ✔ Note: •When “On” is selected in the Logo PIN code lock function, Logo select and Capture functions cannot be selected.
  • Page 48 Setting Logo PIN code lock This function prevents an unauthorized person from changing the screen logo. Off... The screen logo can be changed freely from the Logo Menu (p.47). On ... The screen logo cannot be changed without a Logo PIN code. If you want to change the Logo PIN code lock setting, press the SELECT button and the Logo PIN code dialog box appears.
  • Page 49 Ceiling When this function is set to “On,” the picture will be top/bottom and left/right reversed. This function is used to project the image from a ceiling-mounted projector. Rear When this function is set to “On,” the picture will be left/right reversed.
  • Page 50 Setting Standby mode This function is available when operating the projector via network. Normal ... Supply the power to the network function even after turning off the projector. You can turn on/off the projector via network, modify network environment, and receive an e-mail about projector status while the projector is powered off.
  • Page 51 On start When this function is set to “On,” the projector will be automatically turned on just by connecting the AC power cord to a wall outlet. ✔ Note: •Be sure to turn off the projector properly (see “Turning Off the Projector”...
  • Page 52 Setting Security (Key lock and PIN code lock settings) This function allows you to use the Key lock and PIN code lock function to set the security for the projector operation. Key lock This function locks the top control and remote control buttons to prevent operation by unauthorized persons.
  • Page 53 Enter a PIN code Use the Point buttons to enter a number. Press the Point button to fix the number and move the red frame pointer to the next box. The number changes to “✳.” If you fixed an incorrect number, use the Point move the pointer to the number you want to correct, and then enter the correct number.
  • Page 54 Setting This function provides the following options in the cooling fans’ operation when the projector is turned off (p.22). L1... Normal operation L2... Slower and lower-sound than the normal operation (L1), but it takes more time to cool the projector down.
  • Page 55 Filter counter This function is used to set a frequency for the filter cleaning. When the projector reached a specified time between cleanings, a Filter warning icon appears on the screen, notifying the cleaning is necessary. After cleaning the filter, be sure to select RESET and set the timer.
  • Page 56: Maintenance And Cleaning

    Maintenance and Cleaning Warning Indicator The WARNING indicator shows the state of the function which protects the projector. Check the state of the WARNING indicator and the POWER indicator to take proper maintenance. The projector is shut down and the WARNING indicator is blinking red.
  • Page 57: Cleaning The Filter

    Cleaning the Filter Filters prevent dust from accumulating on the optical elements inside the projector. Should the filters become clogged with dust particles, it will reduce cooling fans’ effectiveness and may result in internal heat buildup and adversely affect the life of the projector. If a “Filter warning” icon appears on the screen, clean the filters immediately.
  • Page 58: Lamp Replacement

    For continued safety, replace with a lamp of the same type. Do not drop a lamp or touch a glass bulb! The glass can shatter and may cause injury. Lamp Cover Handle Screw : LC-XB29N : POA-LMP106 (Service Parts No. 610 332 3855) LAMP REPLACE indicator Screw...
  • Page 59: Resetting The Lamp Counter

    Resetting the Lamp Counter Be sure to reset the Lamp counter after the lamp is replaced. When the Lamp counter is reset, the LAMP REPLACE indicator stops lighting and the Lamp replacement icon disappears. Press the MENU button to display the On-Screen Menu.
  • Page 60: Attaching The Lens Cover

    Maintenance and Cleaning Attaching the Lens Cover When moving this projector or while not using it over an extended period of time, replace the lens cover. Attach the lens cover according to the following procedures. Pass the string through a hole of the lens cover. Turn over the projector and remove the screw with a screwdriver.
  • Page 61: Appendix

    Appendix Indicators and Projector Condition Check the indicators for projector condition. Indicators LAMP WARNING POWER REPLACE red/green yellow • • • green. • • • blinks green. When the projection lamp reaches its end of life, the LAMP REPLACE indicator lights yellow. When this indicator lights yellow, replace the projection lamp with a new one promptly.
  • Page 62: Troubleshooting

    Appendix Troubleshooting Before calling your dealer or service center for assistance, check the items below once again. –Make sure you have properly connected the projector to peripheral equipment as described on pages 17–19. –Make sure all equipment is connected to AC outlet and the power is turned on. –When the projector does not project an image from the connected computer, restart the computer.
  • Page 63 Some displays are not seen during the operation. PIN code dialog box appears at start-up. Computer 2 cannot be selected. The Terminal function cannot be selected. The Remote Control does not work. WARNING : High voltages are used to operate this projector. Do not attempt to open the cabinet. If problems still persist after following all operating instructions, contact the dealer where you purchased the projector or the service center.
  • Page 64: Menu Tree

    Appendix Menu Tree Computer Input/Video Input Input Computer 1 (Analog) Computer 1 (Digital) Computer 2 Video Wired Wireless* Memory Viewer* Sound Sound Volume Mute Quit Computer Input System ✽Systems displayed in the System Menu vary depending on an input signal. PC Adjust Auto PC Adj.
  • Page 65 Video Input System Auto 1080i 1035i 720p 575p 480p 575i 480i System Auto SECAM NTSC NTSC 4.43 PAL-M PAL-N Image Select Dynamic Standard Cinema Blackboard (Green) Image 1 Image 2 Image 3 Image 4 Image Adjust Contrast Brightness Color Tint Color temp.
  • Page 66: Compatible Computer Specifications

    Appendix Compatible Computer Specifications Basically this projector can accept the signal from all computers with the V-, H-Frequency mentioned below and less than 140 MHz of Dot Clock for analog signal and 110 MHz of Dot Clock for digital signal. When selecting these modes, PC adjustment can be limited.
  • Page 67 When the input signal is digital from DVI terminal, refer to the chart below. ON-SCREEN RESOLUTION DISPLAY D-VGA 640 x 480 D-480p 640 x 480 D-575p 768 x 575 D-SVGA 800 x 600 D-XGA 1024 x 768 D-WXGA 1 1366 x 768 D-WXGA 2 1360 x 768 D-WXGA 3...
  • Page 68: Technical Specifications

    Appendix Technical Specifications Mechanical Information Projector Type Dimensions (W x H x D) Net Weight Feet Adjustment Panel Resolution LCD Panel System Panel Resolution Number of Pixels Signal Compatibility Color System High Definition TV Signal Scanning Frequency Optical Information Projection Image Size (Diagonal) Throw Distance Projection Lens Projection Lamp...
  • Page 69: Optional Parts

    Accessories Owner’s Manual (CD-ROM) Quick Reference Guide AC Power Cord Remote Control and Batteries DVI-VGA Cable USB Cable Lens Cover with String PIN Code Label Network Application (CD-ROM) Soft Carrying Case ● The specifications are subject to change without notice. ●...
  • Page 70: Pj Link Notice

    Appendix PJ Link Notice This projector is compliant with PJLink Standard Class 1 of JBMIA (Japan Business Machine and Information System Industries Association). This projector supports all commands defined by PJLink Class 1 and is verified conformance with PJLink Standard Class 1. For PJ Link password, see page 49 on the owner’s manual “Network Set-up and Operation.”...
  • Page 71: Configurations Of Terminals

    Configurations of Terminals COMPUTER IN 2 /COMPONENT IN /MONITOR OUT (ANALOG) Terminal: Analog RGB (Mini D-sub 15 pin) DVI-I TERMINAL (DIGITAL/ANALOG) C1 C2 USB CONNECTOR (Series A) VCC(5V) – DATA + DATA Ground LAN TERMINAL TX + TX – RX + ----- 8 7 6 5 4 3 2 1 SERVICE PORT CONNECTOR...
  • Page 72: Pin Code Number Memo

    Appendix PIN Code Number Memo Write down the PIN code number in the column below and keep it with this manual securely. If you forgot or lost the number and unable to operate the projector, contact the service station. PIN Code Lock No. Logo PIN Code Lock No.
  • Page 73 Fax : 86-21-5396-0318 E-Mail : info@eikichina.com.cn WorldWide Website http://www.eiki.com KW6BC Canada EIKI CANADA - Eiki International, Inc. P.O. Box 156, 310 First St. - Unit 2, Midland, ON, L4R 4K8, Canada Tel : 800-563-3454 (705)-527-4084 Fax : 800-567-4069 (705)-527-4087 E-Mail : canada@eiki.com Eastern Europe EIKI CZECH spol.
