Endpoint Discriminator Class/Address

The following table describes the
commands.
Class Description
0 Null Class
1 Locally Assigned
Address
2 Internet Protocol (IP)
Address
3 IEEE 802.1 Globally
Assigned MAC Address
4 PPP Magic-Number
Block
5 Public Switched
Network Directory
Number
255 Accept Any Remote
Endpoint Discriminator
list of classes and permitted addresses for certain MultiLink PPP
Address Format
No address is used.
Uses a hexadecimal format with a maximum length of 40
characters.
Valid characters: "0-9, a-f" . The number of digits must be even (ex.
AT%M3=b3c665ac11).
Uses a numerical format with a maximum length of 15 characters.
Valid characters: "0-9" (ex. AT%M4=192.219.23.100).
Uses a hexadecimal format with an exact length of 12 characters.
Valid characters: "0-9, a-f" (ex. AT%M3=b3c665ac1fff).
Uses a hexadecimal format with a maximum length of 40
characters, and the length must be a multiple of 8.
Valid characters: "0-9, a-f" (ex. AT%M3=b3c665acffff0001).
Uses a normal telephone number with a maximum length of 15.
Valid characters are "0-9, *, #" .
No address is used. This class is valid only for remote endpoint
discriminators (EPDs), and is used to accept any remote EPDs
received that are all part of the same bundle.
DIVA T/A ISDN Modem Reference Guide N Page 48
