1 Desktop Board Features

This chapter briefly describes the main features of Intel
Table 1 summarizes the features of the Desktop Board.
Table 1. Feature Summary
Form Factor
Processor
Main Memory
Chipset
Integrated
Graphics
Audio
Expansion
Capabilities
Peripheral
Interfaces
Legacy I/O Control
Hardware Monitor
Subsystem
LAN Support
Mini-ITX ([170 millimeters [6.7 inches] x 170 millimeters [6.7 inches])
Passively-cooled, soldered-down dual-core Intel
integrated graphics and memory controllers.
• Two 204-pin Double Data Rate 3 (DDR3) Small Outline Dual Inline
Memory Module (SO-DIMM) sockets with gold-plated contacts
• Support for DDR3 800/1066/1333 MHz SO-DIMMs (DDR3 1066 MHz
and DDR3 1333 MHz SO-DIMMs operate at 800 MHz only)
• Support for up to 4 GB of system memory
®
Intel NM10 Express Chipset
®
Intel
Graphics Media Accelerator 3150 (Intel
graphics subsystem with support for analog displays (VGA)
RealTek* ALC662 audio codec for 5.1 (6-channel) Intel
®
Definition Audio (Intel
• Back panel connectors
• Front panel microphone/headphone header with support for
®
Intel HD Audio or AC '97 Audio
• S/PDIF digital audio header
One PCI* bus add-in card connector
One PCI Express* Full-Mini Card slot with optional Half-Mini Card
support
• Seven USB 2.0 ports:
― Four back panel ports
― Three front panel ports (via two internal headers; one header
®
supports an Intel
device
• Two Serial ATA (SATA) 3.0 Gb/s connectors
Winbond* W83627DGH-A legacy I/O controller providing:
• One serial port header
• One serial port back panel connector
• One parallel port back panel connector
• PS/2 keyboard and mouse connectors
Hardware monitoring through the Winbond legacy I/O controller,
including:
• Remote thermal sensor
• One 3-pin chassis fan header with speed control
10/100/1000 Mb/s (Gigabit) Ethernet LAN Subsystem using a RealTek*
8111E Gigabit Ethernet Controller
®
Desktop Board D525MW.
®
HD Audio) and AC '97 Audio. Included are:
Z-U130 USB Solid-State Drive or compatible
® ™
Atom processor with
GMA 3150) integrated
®
High
