The front/back panel audio connectors are configurable through the audio device
drivers. Table 3 lists the supported functions of the front panel and back panel jacks.
Table 3. Audio Jack Support
Line
Audio Jack
Front panel – Green
Front panel – Pink
Back panel – Blue
Back panel – Green
Back panel – Pink
Figure 2 shows the default assignment of the back panel audio connectors.
NOTE
The back panel audio line out connector is designed to power headphones or amplified
speakers only. Poor audio quality occurs if passive (non-amplified) speakers are
connected to this output.
Line/ Rear Out
In Front Out
No Yes
No No
Yes No
No Yes
No No
Item Description
A Line In
B Line Out
C Mic In
Figure 2. Back Panel Audio Connectors
Desktop Board Features
Center/
LFE Microphone
No No
No No
Yes No
No No
No Yes
Headphones
No Yes
Yes No
No No
No Yes
Yes No
