Connecting to the Front Panel Header

Before connecting to the front panel header, observe the precautions in "Before You
Begin" on page 23. See Figure 12, E on page 33 for the location of the front panel
header.
Table 11 shows the pin assignments for the front panel header.
Table 11. Front Panel Header Signal Names
Pin Signal
Hard Drive Activity LED
1 HD_PWR
3 HDA#
Reset Switch
5 Ground
7 FP_RESET# In
9 +5 V
Connecting to the Front Panel Wireless Activity LED
Header
Before connecting to the front panel wireless activity LED header, observe the
precautions in "Before You Begin" on page 23. See Figure 12, F on page 33 for the
location of the front panel wireless activity LED header.
Table 12 shows the pin assignments for the front panel wireless activity LED header.
Table 12. Front Panel Wireless Activity LED Header
Pin Signal Name
1 LED (+)
2 Ground
36
In/Out Description
Hard disk LED pull-
Out
up (330 Ω) to +5 V
Hard disk active
Out
LED
Ground
Reset switch
Power
Power
Pin Signal In/Out
Power LED
2 HDR_BLNK_GRN Out
4 HDR_BLNK_YEL Out
On/Off Switch
6 SWITCH_ON# In
8 Ground
Not Connected
10 N/C
Description
Front panel
green LED
Front panel
yellow LED
Power switch
Ground
No pin
