- Page 1 User Manual Get Ready to Enjoy - The New Way to Phone!
-
Page 2: Welcome To Vonage
You will need your MAC ID, which is located on your Vonage VWR Device. The MAC ID is a combination of twelve letters and numbers. Be sure to enter all of the characters. After you have chosen a plan and activated, please follow the step-by-step installation guide to set up your equipment. D-Link VWR User Manual... -
Page 3: Table Of Contents
Wireless Security....................15 WEP ......................15 802.1x......................16 WPA/WPA2 ....................17 Password ......................18 System....................... 19 Virtual Server..................... 20 Filters......................... 22 Custom IP Filters ..................23 Performance ...................... 24 Routing ......................25 Dynamic Routing ....................26 D-Link VWR User Manual... - Page 4 Connection Status ..................... 34 DDNS Status ..................... 35 DHCP Client ...................... 36 Product Info ....................... 37 Ping Test ......................38 Logout........................ 39 Appendix A - Troubleshooting................... 40 IVR Messages ....................43 Appendix B - Technical Specifications ..............44 D-Link VWR User Manual...
-
Page 5: Chapter 1 - Product Overview
Chapter 1 - Product Overview Chapter 1 - Product Overview Product Overview D-Link VWR User Manual... -
Page 6: Package Contents
Any high speed DSL or Cable connection A valid Vonage account If you purchased your D-Link VWR at a retail location, make sure to first activate your device at www.vonage.com/activate. Please wait 30 minutes before checking for a dial tone. -
Page 7: Front Panel
Ethernet cable to the to reset the Vonage adapter. Vonage phone line, an standard Ethernet Cable or DSL modem. VWR Device back to optional phone or FAX cables. the default settings. machine into phone port #2. D-Link VWR User Manual... -
Page 8: Chapter 2 - Installation
Chapter 1 - Product Overview Installation D-Link VWR User Manual... -
Page 9: Network Overview
Chapter 2 - Installation Network Overview Please refer to your Quick Start Guide included with your Vonage VWR Device for basic installation instructions. D-Link VWR User Manual... -
Page 10: Chapter 3 - Configuration
Chapter 3 - Configuration Chapter 3 - Configuration Configuration D-Link VWR User Manual... -
Page 11: Login
Open a web browser such as Internet Explorer and enter the IP address (e.g. 192.168.15.1) of the Vonage VWR router. Enter user for the username and your password (default password is user). Click the Login button. D-Link VWR User Manual... -
Page 12: Wan
Internet port’s MAC address with the MAC address of your Ethernet card. Apply ISP DNS and SNTP - Check this box to use the DNS servers and time server (SNTP) supplied by your ISP. D-Link VWR User Manual... -
Page 13: Static Ip Address
Default Gateway Address - Enter the Gateway assigned by your ISP. DNS1/DNS2 - The DNS server information will be supplied by your ISP. Apply ISP DNS and SNTP - Check this box to use the DNS servers and time server (SNTP) supplied by your ISP. D-Link VWR User Manual... -
Page 14: Pppoe
TCP maximum segment size to PPP MTU. If it is disabled, you may have issues accessing some Internet sites. Apply ISP DNS and SNTP - Check this box to use the DNS servers and time server (SNTP) supplied by your ISP. D-Link VWR User Manual... -
Page 15: Lan
IP address in your browser to get back into the configuration utility. Subnet Mask - Enter the Subnet Mask. The default subnet mask is 255.255.255.0. HostName - Enter a host name (Optional). Domain - Enter your network domain name (Optional). D-Link VWR User Manual... -
Page 16: Dhcp
Vonage VWR Device. The DHCP Server will automatically allocate an unused IP address from the IP address pool to the requesting computer. You must specify the starting and ending address of the IP address pool. D-Link VWR User Manual... - Page 17 Hostname - Enter a name of the computer. MAC Address - Enter the MAC address of the computer you want to assign the IP address to. If your computer is already listed, simply check the reserve box and click Apply. D-Link VWR User Manual...
-
Page 18: Wireless
Mixed - Select if using both 802.11b and 802.11g wireless devices. B Only - Select if using all 802.11b wireless devices. B+ - Select if using both 802.11b and b+ wireless devices. G Only - Select if using all 802.11g wireless devices. D-Link VWR User Manual... -
Page 19: Wireless Security
Authentication Type - Select Open or Shared. Cipher - Select the level of encryption desired: 64, 128, or 256-bit. Encryption Key - Enter a WEP key. You may enter up to 4 different keys. D-Link VWR User Manual... -
Page 20: 802.1X
Port - Enter the port your RADIUS server is using. 1812 is the default setting. Secret - Enter the secret or key. This secret must be used by your wireless clients. Group Key Interval - Enter the Group Key Interval. 3600 is the default setting. D-Link VWR User Manual... -
Page 21: Wpa/Wpa2
RADIUS Server - If you are using a RADIUS server for authentication, click the radio button and enter the RADIUS server’s IP address, Port, and Secret (key). Pre-Shared Key - To use a passphrase for authentication, click the radio button and then enter the PSK String (WPA passphrase). D-Link VWR User Manual... -
Page 22: Password
Chapter 3 - Configuration Password You may change the User password on this page. Enter a new password and click Apply to save. D-Link VWR User Manual... -
Page 23: System
Factory Reset - Click to reset the Vonage VWR Device back to the default settings. Reboot - Click to reboot or restart the Vonage VWR Device. Restart Access Point - Click to restart the wireless function. D-Link VWR User Manual... -
Page 24: Virtual Server
Each virtual service that is created will be listed at the bottom of the screen in the Virtual Servers List. There are pre-defined virtual services already in the table. You may use them by enabling them and assigning the server IP to use that particular virtual service. D-Link VWR User Manual... - Page 25 Applied Rules - This will list the applications that are active to the LAN IP address you have selected from the LAN IP list. Delete - Highlight an application from the Applied Rules list and click Delete to remove View - Highlight an application and click View to review its settings. D-Link VWR User Manual...
-
Page 26: Filters
Block Outgoing Ping - Check to block outgoing ICMP traffic from the selected IP address. This is useful if your host has a virus that attempts a Ping-of-Death Denial of Service attack. Custom IP Filters - Click to create your own filter rules (see next page). D-Link VWR User Manual... -
Page 27: Custom Ip Filters
Destination Netmask - Enter the destination subnet mask (255.255.255.255 for all). Port Start - Enter the starting port to block. Port End - Enter the ending port to block. Protocol - Select the protocol (TCP, UDP, TCP and UDP, ICMP, and ANY). D-Link VWR User Manual... -
Page 28: Performance
Fragmentation - The fragmentation threshold, which is specified in bytes, determines whether packets will be fragmented. Packets exceeding the 2346 byte setting will be fragmented before transmission. 2346 is the default setting. D-Link VWR User Manual... -
Page 29: Routing
Mask - Enter the network subnet mask. Gateway - Enter the gateway IP address. This is the gateway or router WAN IP address on the destination network. Metric - The Metric is the number of hops to the destination network. D-Link VWR User Manual... -
Page 30: Dynamic Routing
Password - Enter your password. Interface/Direction - You may control the ports and direction that the Vonage VWR Device will route to and from. LAN - Select None, To, From, or Both. WAN - Select None, To, From, or Both. D-Link VWR User Manual... -
Page 31: Dmz
DMZ - Select Enabled or Disabled. By default the DMZ is disabled. IP Address - Enter the IP Address of the computer to be in the DMZ. D-Link VWR User Manual... -
Page 32: Misc
Chapter 3 - Configuration Misc The Misc page will allow you to configure UPnP, DDNS, SSH Access Control, and Web Access Control. D-Link VWR User Manual... -
Page 33: Upnp
Chapter 3 - Configuration UPnP Click Enable to use UPnP (Universal Plug and Play). UPnP provides compatibility with networking equipment, software and peripherals. D-Link VWR User Manual... -
Page 34: Ddns
Enabled. Username - Enter the username for your DDNS account. Password - Enter the password for your DDNS account. Domain Name - Enter the domain or host name for your DDNS account. D-Link VWR User Manual... -
Page 35: Ssh Access Control
Remote Host IP - Enter the IP address of the remote computer. Enter 0.0.0.0 to allow any remote computer to connect. Remote Netmask - Enter the subnet mask of the remote computer. Enter 255.255.255.255 to allow any remote computer to connect. D-Link VWR User Manual... -
Page 36: Web Access Control
Remote Netmask - Enter the subnet mask of the remote computer. Enter 255.255.255.255 to allow any remote computer to connect. Redirect Port - Enter the port number you would like to use. D-Link VWR User Manual... -
Page 37: Network Statistics
Chapter 3 - Configuration Network Statistics The Network Statistics page will display traffic statistics of the Vonage VWR device. D-Link VWR User Manual... -
Page 38: Connection Status
Chapter 3 - Configuration Connection Status The Connection Status page will display traffic statistics of the Vonage VWR device. D-Link VWR User Manual... -
Page 39: Ddns Status
Chapter 3 - Configuration DDNS Status The DDNS Status page will display Dynamic DNS statistics. Connection - WAN is selected. DDNS Server - Select the DDNS service to display statistics for. D-Link VWR User Manual... -
Page 40: Dhcp Client
IP Address - The IP address that the Vonage VWR Device assigned the device. Host Name - The host name of the device. If the device does not have a host name, it will be displayed as Unknown. Lease Time - The remaining DHCP lease time. D-Link VWR User Manual... -
Page 41: Product Info
Chapter 3 - Configuration Product Info The Product Info page will display the following: • Model Number • Ethernet MAC Address • Gateway - Software Version • Bootloader - Firmware Version D-Link VWR User Manual... -
Page 42: Ping Test
Enter IP Address to Ping - Type in the IP address you want to ping. Packet Size - Enter the size of the packet (32 is the default size). Number of Echo Requests - Enter the number of requests (4 is default). D-Link VWR User Manual... -
Page 43: Logout
Chapter 3 - Configuration Logout Click Logout to exit the configuration utility. Click OK to verify. D-Link VWR User Manual... -
Page 44: Appendix A - Troubleshooting
Appendix A - Troubleshooting Appendix A - Troubleshooting Troubleshooting D-Link VWR User Manual... - Page 45 At this point, you should have both a dial tone and Internet connectivity. 3. Try opening your web browser to view a web page. If you cannot view a web page, check to see whether your Cable or DSL prover is having connection problems in your area. D-Link VWR User Manual...
- Page 46 3 blinks (3 blinks, pause, repeat) VWR is obtaining configuration from Vonage 4 blinks (4 blinks, pause, repeat) VWR is registering with Vonage Rapid Blinking Downloading/upgrading firmware (do not power down) Solid Startup process is complete D-Link VWR User Manual...
-
Page 47: Ivr Messages
Vonage service. If you are plugged into Port 2, try moving to Port 1. In addition, you can check the status of your Vonage service by logging into your web account. For more troubleshooting tips, visit www.vonage.com/help. D-Link VWR User Manual... -
Page 48: Appendix B - Technical Specifications
Appendix B - Technical Specifications Appendix B - Technical Specifications Technical Specs D-Link VWR User Manual... - Page 49 • RTP Packets Fax Support • FAX Relay • PCM (G.711) LEDs • Power ON/OFF • LAN Link & Activity • Phone ON/OFF Hook & Ringing Power • External AC Power Adapter • Output: 12V AC, 1.25A D-Link VWR User Manual...
- Page 50 August 3, 2006 Copyright ©2006 D-Link Corporation/D-Link Systems, Inc. All rights reserved. D-Link and the D-Link logo are registered trademarks of D-Link Corporation or its subsidiaries in the United States and other countries. Other trademarks are the property of their respective owners.
