Edelbrock offers cylinder heads machined to the proper
specifications for use with Fel-Pro Locwire head gaskets only
as shown in the table to the right:
Head Bolt Torque:
Intake Bolt Torque:
Rocker Studs:
Rocker Stud Torque:
Rocker Pedestal Bolt Torque:
Combustion Chamber Volume:
Intake Port Volume:
Exhaust Port Volume:
Deck Thickness:
Valve Seats:
Valve Size:
#60259, #60359 & #60399:
#60229, #60329 & #60379:
Valve Locks:
Valve Spring Retainers:
9
10
Front Cylinder
Catalog # 60219 - #60399
Rev. 3/09 - AJ/mc
7/16" bolts - 70/80 ft./lbs. (short/long
bolts)1/2" bolts - 100/110 ft./lbs.
(short/long bolts)
16-18 ft./lbs.
3/8" (#6022, 6025, 6032, 6035)
45 ft./lbs. (7/16"-14; #6022-#6035)
18-20 ft./lbs. (5/16"-18; #6036-39)
58-60cc
170cc
60cc
5/8"
Hardened, interlocking ductile iron,
compatible with unleaded fuels
Intake - 2.02", Exhaust - 1.60"
Intake - 1.90", Exhaust - 1.60"
11/32" x 7° (#9611)
7° 4140 steel (#9724)
5
6
Figure 1 - Head Bolt Tightening Sequence
#5 Cylinder
LH Bank
(Driver Side)
Figure 2 - Steam Hole Locations for Early 289 & 302 Engine Blocks
Edelbrock Corporation • 2700 California St. • Torrance, CA 90503
Tech Line: 800-416-8628 • Office: 310-781-2222
Standard Head #
60259
60359
60379
60399
SPECIFICATIONS
Valve Spring Diameter:
Valve Spring Installed Height:
Valve Spring Seat Pressure:
Max. Valve Lift:
Pushrod Guideplates:
Rocker Arms:
Pushrods:
Spark Plugs:
Recommended Intake Gasket:
Recommended Exhaust Gasket:
1
2
1/8" Holes Drilled
into the Water Jacket.
Position Hole Location
Using the Head Gasket.
Page 3 of 3
Machined for Locwire Head Gaskets
60269
60279
60289
60299
1.45"
1.800"
110-120 lbs.
.575"
5/16" Hardened steel (#6022, #6025,
#6032 & #6035 only)
#6022, #6025, #6032, & #6035 accept
stock (except rail style) or aftermarket
roller type#6037, & #6039 accept stock
5.0/5.8L or aftermarket pedestal bolt
down style
#6022, #6025, #6032, #6035 require
5/16" hardened pushrods for use with
guideplates#6037 & #6039 use stock
pushrods
14mm x ¾" reach gasketed seat
Fel-Pro #1250
Fel-Pro #1415
3
7
4
8
#1 Cylinder
Front Cylinder
RH Bank
(Pass. Side)
©2009 Edelbrock Corporation
Brochure #63-0009
