Many of the components of the Pro-Flo system are available separately. Many are standard OEM
parts. In the event that one of these parts need to be replaced, you are likely to find a
replacement at your local parts supplier, in addition to your local Edelbrock dealer or directly
from Edelbrock.
Edelbrock Pro-Flo
Fuel Injection System..........................................................................................Edelbrock #3500
Ignition Amplifier.................................................................................................Edelbrock #3518
ECU power relay/Fuel pump relay .......................................................................Edelbrock #3586
Manifold Absolute Pressure sensor .....................................................................Edelbrock #3587
Manifold Air Temperature sensor (Push-In) .........................................................Edelbrock #3579
Coolant Temperature sensor...............................................................................Edelbrock #3589
Throttle Position sensor ......................................................................................Edelbrock #3590
Oxygen (O
High pressure fuel pump.....................................................................................Edelbrock #3594
Fuel filter ............................................................................................................Edelbrock #3596
Fuel pressure regulator.......................................................................................Edelbrock #3584
Fuel injectors (set of eight)............................................................................................................
#3550 Kit use .....................................................................................................Edelbrock #3684
#3551 Kit use .....................................................................................................Edelbrock #3598
Fuel injectors (one)........................................................................................................................
#3550 Kit use .....................................................................................................Edelbrock #3685
#3551 Kits use ...................................................................................................Edelbrock #3585
Hall Effect Sensor ...............................................................................................Edelbrock #3517
Calibration Module..............................................................................................Edelbrock #3519
Calibration Module Cord/Plug..............................................................................Edelbrock #3571
Idle air control solenoid.......................................................................................Edelbrock #3599
Throttle Cable Bracket #3550 or #3501 ..............................................................Edelbrock #8031
Rev. 10/05
PART NUMBERS
) sensor .............................................................................................Edelbrock #3591
2
Pro-Flo EFI Installation Instructions
Ford FOAE-9F715 B1A
33
Delphi 10482803
GM 14089936
GM 16006835
AC12160244
GM 25036979
GM 25055065
GM 17107010
©2005 Edelbrock Corporation
Brochure No. 63-0115
