AN1600 F1 Network Storage System Quick Specification

Product Overview

Acer AN1600 F1 storage system is a cost-effective storage solution, powered by Microsoft Windows Storage
Server offering an easy way for storage centralization, file sharing, data protection, and remote access.
Processors and chipset
®
®
2 x Intel
Xeon
E5620 processors (2.4 GHz, 12 MB L3 cache, 5.86 GT/s, DDR3-1066, 80 W, HT)
®
Intel
5520 Chipset
Memory
Type
Maximum memory by O/S
# of DIMM sockets
Minimum (standard) memory on
system

Network controller

®
Integrated Intel
82576EB dual-port Gigabit Ethernet controller
1
Storage
Maximum capacity
Minimum capacity
External storage

Storage controller

LSI SAS MegaRAID SAS PCIe 2.0 x16 9260-16i with 16-internal ports, 512 MB, supporting RAID 0/1/10/5/50/6/60
(default bundle in system)

Expansion slots

Seven PCI-Express slots
Two PCI-Express Gen 2.0 x8 slots (in x4 connector; left)
One PCI-Express Gen 2.0 x16 slot (in x8 connector left)
Three PCI-Express Gen 2.0 x8 slots (in x4 connector; right*)
One Acer Flex I/O (PCIe Generation 2.0 x8 connector (left)
*Right hand side PCI-Express space has limitation for low-profile card, length within 5.6"

Operating System

®
Microsoft
Windows
Management
• Acer Smart Console
• Acer Smart Server Manager
• iBMC management controller, supporting base board management and KVM-over-IP
• LSI MSM (MegaRAID Storage Manager) on-line utility is the OS level utility for data volume RAID configuration
• LSI WebConsole utility is a ROM-based utility provided by HBA FW for data volume RAID configuration
• Windows Disk Management is OS built-in feature on Windows Storage Server 2008 R2
• Microsoft Windows Storage Server Administration Tools
Deployment/serviceability
BIOS Update Tool
Input/output interface
Front
• Power button
• HDD activity indicator LED
• PSU failure LED
1. Storage capacity
2
External storage is available through fiber channel connection for additional storage devices
3. 16 ports RAID card is now available starting from January, 2011
DDR3-1333 Registered (RDIMM) with ECC capabilities
32 GB
12
6 GB (2 GB x 3)
1)
2)
3)
600 GB (300 GB x 2) internal SAS HDD
Optional
3
®
Storage Server 2008 R2, Standard x64 edition
• IPMI Firmware Update Tool
• Power indicator LED
• Two LAN activity LEDs (LAN1, LAN2)
• System status/fault indicator LED
Up to 12 x 3.5" Hot pluggable SAS/SATA HDD capacity
Up to 24 TB raw internal SATA
Up to 7.2 TB raw internal SAS
2
1

Advertisement

   Also See for Acer AN1600 F1

   Related Manuals for Acer AN1600 F1

   Summary of Contents for Acer AN1600 F1

  • Page 1: Product Overview

    AN1600 F1 Network Storage System Quick Specification Product Overview Acer AN1600 F1 storage system is a cost-effective storage solution, powered by Microsoft Windows Storage Server offering an easy way for storage centralization, file sharing, data protection, and remote access. Processors and chipset ®...
  • Page 2 AN1600 F1 Network Storage System Quick Specification Rear • PS/2 Mouse port • Two USB 2.0 ports • Serial port • Video port • Two Gigabit LAN ports (RJ-45) • ID LED button • Management port (RJ-45) (dedicate management NIC) Chassis/form factor 2U rack optimized up to 12 hot-pluggable 3.5"...
  • Page 3 AN1600 F1 Network Storage System Quick Specification 1. PCIe/Flex I/O expansion – 7 slots in total 2. Riser card supporting PCIe, PCI (LAN card), and Flex I/O expansion ® ® 3. Intel Xeon processor 5600 series 4. 12 DDR3 dual-channel DIMMs (6 per CPU), ECC support 5.
  • Page 4: Features And Benefits

    Designing from server infrastructure by using server processors, industry storage level features standard HDDs, interconnections, DDR3 memory, and hot-plug redundant power supply, AN1600 F1 is equipped with enterprise level features such as file de-duplication, snapshots, and distributed file system replication.
  • Page 5: Standard Features

    AN1600 F1 Network Storage System Quick Specification Standard Features Acer Smart Server Manager • Offers 24-7 monitoring for system health and performance. • Delivering proactive event management features including system event logging, event handling from e- mail and SNMP Trap (PET) alerting.
  • Page 6: System Specifications

    AN1600 F1 Network Storage System Quick Specification Server Manager Manage your Microsoft iSCSI Software Target from Server Integration Manager. Improved CHAP Secret Microsoft iSCSI Software Target 3.2 uses a more secure and Storage customizable storage method for CHAP secrets. ERL0 Compliant Connection and session reinstatement is now fully ERL0 compliant.
  • Page 7 AN1600 F1 Network Storage System Quick Specification ® ® Processor Type Two Intel Xeon E5620 DP Quad-Core (2.4 GHz, 12 MB L3 cache, 5.86 GT/s, DDR3-1066, 80 W, HT) ® Features Intel QuickPath Interconnect up to 5.86 GT/s, each direction. Per link ®...
  • Page 8 AN1600 F1 Network Storage System Quick Specification Network 10Base-T / 100Base-TX / 1000Base-TX interface Compatibility IEEE 802.3 Ethernet interface for 10BASE-T, IEEE 802.3ab Ethernet interface for 1000BASE-T, IEEE 802.3u Ethernet interface for 100BASE-TX, ® Virtualization Intel I/O Acceleration Technology acceleration...
  • Page 9: Language Support

    AN1600 F1 Network Storage System Quick Specification Back I/O Panel Two PS2 ports Two USB 2.0 ports Two RJ45 connectors (Dual Gigabit NIC) with Activity and Link indicators One RJ45 (dedicate management NIC) with Activity and Link indicators One Serial port (DB-9)
  • Page 10: Technical Specifications

    AN1600 F1 Network Storage System Quick Specification Technical Specifications Form Factor 2U rack-optimized Dimensions Metric Units (mm) 438.4 x 705 x 88.1 mm (W x D x H) Imperial Units (inch) 17.26 x 27.76 x 3.47 inches Maximum 38.0 kg (84 lb)
  • Page 11 AN1600 F1 Network Storage System Quick Specification Data transfer modes Legacy model • Combined mode • Protocol SAS/SATA Feature NCQ (Native Command Queuing) • AHCI (Advanced Host Controller • Interface) RAID (Redundant Array of Independent • Disks) RAID level supported...
  • Page 12 AN1600 F1 Network Storage System Quick Specification System Cooling Support 10° to 35° C (50° to 95° F) environment • Two CPU heat-sink (2U height) supporting Intel Xeon processors up • to TDP 95W Support memory full-populated configuration • Support up to 12*SAS/SATA HDDs •...
  • Page 13 AN1600 F1 Network Storage System Quick Specification Classification Normative standards EN 55022 Class A, EN 61000-3-2/- (EMC) 3-3, CISPR 22 Class A NOTE: Product conformance to cited product specifications is based on sample (type) testing, evaluation, or assessment. This product or family of...
  • Page 14 AN1600 F1 Network Storage System Quick Specification RAID Volume and Setup Layout Default 2 HDDs RAID Volume and system partition Default 8 HDDs RAID Volume and system partition Default 12 HDDs RAID Volume and system partition...
  • Page 15: Memory Specifications

    AN1600 F1 Network Storage System Quick Specification Memory Specifications Each processor has three memory channels (1, 2 and 3) and each channel has two slots - A (PxDIMM1A, 2A, 3A in blue) and B (PxDIMM1B, 2B, 3B in black). So, the system has a total of twelve memory slots. The memory slots support DDR3-1333 registered/unbuffered ECC memory modules, but it’s not allowed to mix RDIMM and...
  • Page 16 AN1600 F1 Network Storage System Quick Specification Dual processor configuration (subjected to change if any update) Total P1DIMM P2DIMM Physical Memory 12GB 16GB 18GB 24GB 12GB 16GB 24GB 32GB...
  • Page 17: Sparing Mode

    AN1600 F1 Network Storage System Quick Specification Mirroring or Lockstep mode: Mirroring mode & Lockstep mode need the channel 1 & channel 2 with identical DIMMs. 1A and 2A should be the same type, size and manufacturer. 1B and 2B memory should be the same type, size and manufacturer.
  • Page 18 AN1600 F1 Network Storage System Quick Specification Total DIMM DIMM DIMM DIMM DIMM DIMM Physical Memory 12GB 24GB 24GB* Dual processor configuration Total P1DIMM P2DIMM Physical Memory 12GB 18GB 24GB 12GB 24GB 36GB...
  • Page 19 AN1600 F1 Network Storage System Quick Specification Storage The AN1600 F1 chassis was designed to support twelve 3.5" SAS/SATA hot-swappable hard drives. As a system, ach server board supports the use of three SATA drives. A single SATA backplane works to apply system-based control for power and fan speed functions.
  • Page 20: Power Specifications

    AN1600 F1 Network Storage System Quick Specification Power Specifications 720W Power Supply Operational Input 100 to 240 Voltage Range (Vrms) Frequency Range 60/50 (Nominal) (Hz) Nominal Input Voltage (Vrms) Max. Rated Output Wattage Nominal Input Current 8.46 6.97 3.80 3.87 3.74...
  • Page 21 AN1600 F1 Network Storage System Quick Specification Options Memory Samsung 2GB, RDIMM, M393B5673EH1-CH9, DDR3-1333 3.5”HDD SAS 600 GB 600GB , Seagate 3.5" SAS, 15K RPM, Cheetah 15K.7, 6Gb/s, 16MB SAS 300 GB 300GB , Seagate 3.5" SAS, 15K RPM, Cheetah 15K.7, 6Gb/s, 16MB...
  • Page 22 AN1600 F1 Network Storage System Quick Specification Revision History Date version Note/changes 2009/07/28 1-0-0 First release 2010/12/31 2-0-0 1) Minor wording and format updates 2) Now supported Windows Storage Sever 2008 R2 3) Added Windows Storage Server 2008 R2 features in specification...
