System setups

AVN7000 + DCU105
Adding a DCU105 to the AVN7000 instantly
opens up a wealth of system expansion
possibilities that satisfy all occupants in a
car with personalized entertainment options.
Front 1-way
Expansion options
iPC-106
Interface Adapter for iPod ®
Allows enjoying favorite music from an
iPod. Also recharges when connected.
Dimensions (W × H × D) 4-11/16˝ × 1-5/16˝ × 3-9/16˝
120 × 32 × 90mm
Note: Only for iPods with dock connection.
Please refer to iPod Control Function chart on p18 for other AVN models.
8
E505CSP
Front 3-way
Photo: AVN6600
MRE-700
7˝ Widescreen Monitor
Its slim and silver-colored enclosure adds the perfect touch
of style to rear entertainment systems, featuring automatic
screen dimming to suit ambient light, a built-in speaker and
headphones jack. Dedicated WHP-100 wireless headphones
can also be used. AV inputs are on front and back of unit.
MRE-700W
7˝ Widescreen Monitor Package
Contains all the components and hardware that is required
to create an ideal rear entertainment system.
Includes MRE-700 ✕ 2, RAS-100 (AV Matrix), dedicated wireless
remote control.
MRE-700
MRE-700
WHP-100
DCU105
Dimensions (W × H × D):
6-3/4˝ × 1-1/16˝ × 4-9/16˝
171.5 × 25.5 × 115.1mm
WHP-100
SW8200
Recommended options
SIRIUS Satellite Radio SIR-ECL1
HD Radio HDR105
TV Tuner TVR105
CD Changer CH3083
Rear view camera BEC105
WHP-100
Wireless Headphones
These wireless headphones are ideal for
rear entertainment when different program
sources are simultaneously being played.
Switchable between 2 frequencies.
E505CSP
Center Speaker with 20W Power Amplifier
A simple way to enjoy surround sound by
adding a central active speaker.
