Intel Desktop Board D975XBX2 Product Guide
Table 1. Feature Summary (continued)
Peripheral
Interfaces
Power Management
Hardware
Management

Related Links

For more information about Intel Desktop Board D975XBX2, including the Technical
Product Specification (TPS), BIOS updates, and device drivers, go to:
http://support.intel.com/support/motherboards/desktop/
10
• One front panel audio header (yellow)
• Up to eight USB 2.0 ports:
― Four ports routed to the back panel
― Four ports routed to two USB headers
• Eight Serial ATA channels (one device per channel):
― Four RAID capable Serial ATA (3.0 Gb/s) connectors (black) via
the ICH7DH
― Three RAID capable Serial ATA (3.0 Gb/s) connectors (blue) via
the Marvell RAID controller
― One RAID capable Serial ATA (3.0 Gb/s) connector via the Marvell
RAID controller, compatible with an external Serial ATA drive
(red)
• Up to two IEEE 1394a ports:
― One IEEE 1394a port routed to the back panel
― One IEEE 1394a header (blue)
• One IDE interface with ATA-66/100 support
• One diskette drive interface
• One parallel port
• One serial port
• RJ-45 LAN port
• PS/2* keyboard and mouse ports
• Support for Advanced Configuration and Power Interface (ACPI)
• Suspend to RAM (STR)
• Wake on USB, PCI, PCI Express, PS/2, LAN, and front panel
Hardware monitor with:
• Four fan sensing inputs used to monitor fan activity
• Remote diode temperature sensing
®
• Intel Precision Cooling Technology fan speed control
• Voltage sensing to detect out of range values
