Intel Desktop Board D945GCCR Product Guide
Table 2. Desktop Board D945GCCR Components
Label Description
A Front panel audio header
B PCI bus connector 2
C PCI bus connector 1
D PCI Express x1 connector
E PCI Express x16 connector
F Back panel connectors
G 12 V processor core voltage connector (2 x 2 pin )
H Processor fan header (4-pin)
I Rear chassis fan header (3-pin)
J Processor socket
K DIMM 0, Channel A socket
L DIMM 0, Channel B socket
M Chassis intrusion header
N Main power connector (2 x 12 pin)
O Diskette drive connector
P IDE connector
Q Front chassis fan header (3-pin)
R Serial ATA connectors
S Front panel header
T Speaker
U Hi-speed USB 2.0 headers
V Alternate front panel power LED header
W Battery
X BIOS configuration jumper block

Related Links:

Go to the following links for more information about:
• Desktop Board D945GCCR
• Supported processors
• Audio software and utilities
• LAN software and drivers
12
http://www.intel.com/design/motherbd
http://support.intel.com/support/motherboards/desktop
http://www.intel.com/go/FindCPU
http://www.intel.com/design/motherbd
http://www.intel.com/design/motherbd
