Onboard Power Button

CAUTION
Electrostatic discharge (ESD) can damage components. Perform the procedure
described in this section only at an ESD workstation using an antistatic wrist strap and
a conductive foam pad. If such a station is not available, you can provide some ESD
protection by wearing an antistatic wrist strap and attaching it to a metal part of the
computer chassis.
A power button on the desktop board (see Figure 4) can be used to turn the computer
on or off. This button is intended for use at integration facilities to remove standby
power before making changes to the system configuration, or for testing purposes.
The power button on the front panel is recommended for all other instances of turning
the computer on or off. To turn off the computer using the onboard power button,
keep the button pressed down for three seconds.

Speaker

A speaker is mounted on the desktop board. The speaker provides audible error code
(beep code) information during the Power-On Self-Test (POST).

Battery

A battery on the desktop board keeps the values in CMOS RAM and the clock current
when the computer is turned off. See Chapter 2 starting on page 25 for instructions
on how to replace the battery.

Real-Time Clock

The desktop board has a time-of-day clock and 100-year calendar. The battery on the
desktop board keeps the clock current when the computer is turned off.
Figure 4. Location of Onboard Power Button
