OSD TURN OFF
The OSD control menu will stay on as long as it is in use. In the OSD TURN OFF submenu, you can select how
long the monitor waits after the last touch of a button to shut off the OSD control menu. The preset choices are
10 - 120 seconds by 5 seconds step.
OSD LOCK OUT
This control completely locks out access to all OSD control functions without BRIGHTNESS and CONTRAST. When
attempting to activate OSD controls while in the Lock Out mode, a screen will appear indicating the OSD are
locked out. To activate the OSD LOCK OUT function, press "1
simultaneously. To de-activate the OSD LOCK OUT, press "1
simultaneously.
EXPANSION
Selects the zoom mode.
This function works, when input signal timing is under Native Resolution.
FULL: The image is expanded to full screen, regardless of the resolution.
ASPECT: The image is expanded without changing the aspect ratio.
SIGNAL INFORMATION
If you select "ON", monitor displays "VIDEO INPUT MENU" after change Input-Port.
If you select "OFF", monitor doesn't display "VIDEO INPUT MENU" after change Input-Port.
DDC/CI
Turns ON or OFF the two way communication and control of the monitor.

MONITOR INFO

Indicates the model and serial numbers of your monitor.
CARBON SAVINGS
Display the estimated carbon saving information in kg.
The carbon footprint factor in the carbon saving calculation is based on the OECD (2008 Edition).
The carbon saving information can be reset by pressing the 1
CARBON USAGE
Displays the estimated carbon usages information in kg. This is the arithmetic estimation, not actual measurement
value.
INPUT RESOLUTION
This function works, when user selects below special input signal timing.
Select resolution's priority of input signal to one of the following signal: 1280x768, 1360x768, 1366x768.
OSD Warning
OSD Warning menus disappear with SELECT button.
NO SIGNAL: This function gives a warning when there is no signal present. After power is turned on or when there is
a change of input signal or video is inactive, the NO SIGNAL window will appear.
OUT OF RANGE: This function gives a recommendation of the optimized resolution and refresh rate. After the power
is turned on or there is a change of input signal or the video signal doesn't have proper timing, the OUT OF RANGE
menu will appear.
2/RESET", then "+" key and hold down
2/RESET", then "+" key and hold down
2/RESET button.
English-10
