R E M O V I N G T H E C O N T R O L / S U R G E B O A R D S
1
1
1
2
REV A
3
SINGLE OR MASTER ONLY
MOTOR
BRAKE
LIMITS
1
2
3
4
5
6
4
M O U N T I N G
Caution:
Do Not make new mounting holes, or enlarge existing holes in control box.
Use the four mounting holes provided.
Remove the four nuts and remove battery rack.
Reverse this process to reinstall.
Unscrew the 4 Phillips head screws from the cover.
1
2
Unplug the J1 and J3 plugs.
3
Unplug battery connector.
4
Unplug all accessory wires from Surge Suppressor's removable
terminals.
Disconnect ground wire.
5
6
Remove three Phillips screws from control board and remove board.
7
Remove three Phillips screws from surge suppressor board and
remove board.
®
LAKE FOREST, CALIFORNIA
www.eliteaccess.com
2
5
SLAVE ONLY
MOTOR
BRAKE
LIMITS
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
4
T H E
15
REV A
SINGLE OR MASTER ONLY
SLAVE ONLY
MOTOR
BRAKE
LIMITS
MOTOR
BRAKE
LIMITS
1
2
3
4
5
6
7
8
9
10
11
C O N T R O L
Mount control box with four screws and washers
(recommend #10 thru 1/4-20 Bolts or Screws)
Do Not over tighten.
6
®
LAKE FOREST, CALIFORNIA
www.eliteaccess.com
7
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
B O X
