Connector Pin Assignments
Line-Out Audio
Connector and Icon (1/8" miniphone)
1 2 3
External Infrared Transceiver
Pin
Signal
1
Transmit
2
Receive
3
Ground
Monitor
Pin
Signal
1
Red Analog
2
Green Analog
3
Blue Analog
4
Not used
5
Ground
A–4
Pin
1 (Tip)
2 (Ring)
3 (Shield)
Connector and Icon
Pin
Signal
4
5V
5
Mode
6
Not Used
Connector and Icon
Pin
Signal
6
Ground
7
Ground
8
Ground
9
+5V (fused)
10
Ground
433612-001
Signal
Audio_Out_Left
Audio_Out_Right
Ground
Pin
Signal
7
Not Used
8
Not Used
Pin
Signal
1 1
Not used
12
DDC Serial Data
13
Horizontal Sync
14
Vertical Sync
15
DDC Serial Clock
Service Reference Guide, dc7700
