  • Page 1 GPSMAP ® 695/696 Portable Aviation Receiver Quick Reference Guide...
  • Page 3 Garmin. Garmin hereby grants permission to download a single copy of this manual and of any revision to this manual onto a hard drive or other electronic storage medium to...
  • Page 4 Added menu options to WPT page for viewing departure and destina- tion airports. • Added displaced runway threshold distance on airport review page. • Added suggested indicated altitude on E6B page. RR-4 Garmin GPSMAP 695/696 Quick Reference Guide 190-00959-00 Rev. E...
  • Page 5 Updated AOPA Airport Directory to just Airport Directory where ap- plicable. • Updated System Messages. • Updated Data Field Options. • Updated database information. August, System Software Version 4.90-6.00 changes: • Added GDL 39 support 2012 RR-5 190-00959-00 Rev. E Garmin GPSMAP 695/696 Quick Reference Guide...
  • Page 6 Blank Page RR-6 Garmin GPSMAP 695/696 Quick Reference Guide 190-00959-00 Rev. E...

  • Page 7: Table Of Contents

    Terrain ..........................19 Traffic Source ........................20 Traffic Information Service (TIS-A) ................21 Data Link Traffic (GDL 39) ....................21 Additional Features ..................23 SafeTaxi ...........................23 ChartView (Optional) .....................23 FliteCharts........................24 Airport Directory Data ....................25 RR-7 190-00959-00 Rev. E Garmin GPSMAP 695/696 Quick Reference Guide...
  • Page 8 Airspace Messages ......................29 Aural Alerts ........................29 Utilities ......................31 Flight Log ........................31 Track Log .........................31 E6B Calculator ........................32 Aircraft Profile ........................32 Weight & Balance ......................33 Proximity Waypoints ......................33 RR-8 Garmin GPSMAP 695/696 Quick Reference Guide 190-00959-00 Rev. E...

  • Page 9: Overview

    OVERVIEW 7” WVGA (800x480) Color Display Power Button SD Card Slot External GPS Antenna Connector Audio (Head- phones/Line Out) USB Connector External Power/Serial Port Connector Backlit Keypad Battery Pack Unit Overview 190-00959-00 Rev. E Garmin GPSMAP 695/696 Quick Reference Guide...
  • Page 10 Press to display the Nearest Page for viewing the nearest airports, weather (696 ONLY), Cities, intersections, NDBs, VORs, waypoints, frequencies, and airspaces Softkey Press to select the softkey shown above the bezel key on the unit Selection Keys Garmin GPSMAP 695/696 Quick Reference Guide 190-00959-00 Rev. E...

  • Page 11: Softkeys

    PANEL Displays/removes the Panel Press the BACK Softkey to return to the top-level softkeys. VFR MAP IFR MAP TOPO SAT VIEW BACK VFR MAP IFR MAP LOW AWY HIGH AWY BACK 190-00959-00 Rev. E Garmin GPSMAP 695/696 Quick Reference Guide...

  • Page 12: Waypoint Page Softkeys

    PAN MAP INFO ANIMATE LEGEND PAN MAP Activates the map pointer for panning the map ANIMATE Animates NEXRAD Radar and Satellite Mosaic weather INFO Displays weather source information LEGEND Displays weather legends Garmin GPSMAP 695/696 Quick Reference Guide 190-00959-00 Rev. E...

  • Page 13: Traffic Page Softkeys (Optional Gdl 39)

    9900 feet below the aircraft. INFO Softkey selected Stations Displays ADS-B ground station(s) information. SETUP Select to set pressure altitude sensor on or off in the GDL 39. EXIT Returns to the Traffic Page. 190-00959-00 Rev. E Garmin GPSMAP 695/696 Quick Reference Guide...

  • Page 14: Siriusxm Audio Page Softkeys (Gpsmap 696 Only)

    VOL - BACK VOL + MUTE VOL - Decreases SiriusXM audio volume VOL + Increases SiriusXM audio volume MUTE Toggles SiriusXM audio on/off BACK Returns to top-level softkeys Garmin GPSMAP 695/696 Quick Reference Guide 190-00959-00 Rev. E...

  • Page 15: Data Entry

    2) Turn or move the FMS Joystick to scroll through a list of available options (a scroll bar always appears to the right of the window/box when the option list is longer than the window/box). 190-00959-00 Rev. E Garmin GPSMAP 695/696 Quick Reference Guide...

  • Page 16: Pages

    1) Press the FPL or the NRST Key. 2) If necessary, press the FMS Joystick to begin interaction with the Navigation Bar. 3) Turn the FMS Joystick until the desired page is selected. Garmin GPSMAP 695/696 Quick Reference Guide 190-00959-00 Rev. E...

  • Page 17: Gps Navigation

    2) Turn or move the FMS Joystick to highlight ‘Set OBS and Hold’, and press the ENT Key. 3) Turn the FMS Joystick to select the desired course to the destination, and press the ENT Key. 190-00959-00 Rev. E Garmin GPSMAP 695/696 Quick Reference Guide...

  • Page 18: Waypoint Page

    From the User Waypoint Information Page, press the DELETE, or EDIT softkeys to make changes to the selected user waypoint. 5) To return to the Nearest Page, press the FMS Joystick, the ENT Key, or the CLR Key. Garmin GPSMAP 695/696 Quick Reference Guide 190-00959-00 Rev. E...

  • Page 19: User Waypoints

    2) With ‘Yes’ highlighted, press the ENT Key. The New Waypoint Window is displayed. 3) Move the FMS Joystick to the User Waypoint Name Field and enter the waypoint name, if desired. 190-00959-00 Rev. E Garmin GPSMAP 695/696 Quick Reference Guide...

  • Page 20: Direct-To

    CLR Key to remove it), press the RECENT Softkey to display a list of recent waypoints, or move the FMS Joystick to select the facility name, or city field. 3) Press the ENT Key. 4) With ‘Activate’ highlighted, press the ENT Key. Garmin GPSMAP 695/696 Quick Reference Guide 190-00959-00 Rev. E...

  • Page 21: Flight Planning

    4) Press the ENT Key. The Saved Flight Plan Page is displayed showing departure, destination, total distance, and enroute safe altitude information for the selected Flight Plan. 5) Press the FMS Joystick or the DONE Softkey to exit the Saved Flight Plan Page. 190-00959-00 Rev. E Garmin GPSMAP 695/696 Quick Reference Guide...

  • Page 22: Flight Plan Activation

    4) Press the Direct-to Key twice. The “Activate Leg XXXXX - XXXXX?” window is displayed. 5) With ‘Yes’ highlighted, press the ENT Key. To cancel the request, press the CLR Key, the FMS Joystick, or highlight ‘No’ and press the ENT Key. Garmin GPSMAP 695/696 Quick Reference Guide 190-00959-00 Rev. E...

  • Page 23: Adjusting Fuel Flow

    Loading an approach from the active or saved flight plan page: 1) Press the FPL Key. 2) Turn the FMS Joystick to display the Active Flight Plan Page or Saved Flight Plan Page. 190-00959-00 Rev. E Garmin GPSMAP 695/696 Quick Reference Guide...

  • Page 24: Activating Vectors-To-Final

    From the Active Flight Plan Page (with an approach activated), press the VECTORS Softkey. 1) From the Active Flight Plan Page, press the MENU Key. 2) Turn or move the FMS Joystick to highlight ‘Cancel Vectors-to-Final’ and press the ENT Key. Garmin GPSMAP 695/696 Quick Reference Guide 190-00959-00 Rev. E...

  • Page 25: Hazard Avoidance

    4) Use the FMS Joystick to highlight the desired weather product with the Map Pointer. 5) With the desired weather product highlighted, press the ENT Key to get detailed information (if available). 190-00959-00 Rev. E Garmin GPSMAP 695/696 Quick Reference Guide...

  • Page 26: Data Link Weather (Fis-B) (695 And 696)

    4) Use the FMS Joystick to highlight the desired weather product with the Map Pointer. 5) With the desired weather product highlighted, press the ENT Key to get detailed information (if available). Garmin GPSMAP 695/696 Quick Reference Guide 190-00959-00 Rev. E...

  • Page 27: Terrain

    4) Move the FMS Joystick to highlight the ‘Terrain Shading’ field. 5) Turn the FMS Joystick to select ‘On’ or ‘Off’, and press the ENT Key. Enabling/Disabling terrain alerts: From the Terrain Page, press the DISABLE Softkey. 190-00959-00 Rev. E Garmin GPSMAP 695/696 Quick Reference Guide...

  • Page 28: Traffic Source

    Traffic Page (TRF). Traffic Source Description Displaying TIS-A traffic from a Mode S transponder. Displaying ADS-B/TIS-B traffic from a GDL 39 Traffic Source Annunciation Garmin GPSMAP 695/696 Quick Reference Guide 190-00959-00 Rev. E...

  • Page 29: Traffic Information Service (Tis-A)

    Configuring the GDL 39 for a Pressurized or Non-Pressurized Aircraft: 1) Press the MENU Key twice to display the Main Menu. 2) Turn or move the FMS Joystick to highlight ‘Data Link’ and press the ENT Key. 190-00959-00 Rev. E Garmin GPSMAP 695/696 Quick Reference Guide...
  • Page 30 9000 feet below the aircraft. Typically used during descent phase of flight. • UNREST (unrestricted): All traffic is displayed. 3) To return to the Traffic Page, press the BACK Softkey. Garmin GPSMAP 695/696 Quick Reference Guide 190-00959-00 Rev. E...

  • Page 31: Additional Features

    Turn or move the FMS Joystick to select the desired chart, and press the ENT Key. 1) From the Active Flight Plan Page (with a waypoint entered), press the SEL APPR Softkey. The Select Approach Window is displayed. 190-00959-00 Rev. E Garmin GPSMAP 695/696 Quick Reference Guide...

  • Page 32: Flitecharts

    2) Turn or move the FMS Joystick to select ‘Show Chart’, and press the ENT Key. The selected chart is displayed. 3) Press the EXIT Softkey to return to the previous page. Garmin GPSMAP 695/696 Quick Reference Guide 190-00959-00 Rev. E...

  • Page 33: Airport Directory Data

    ENT Key. The Airport Information Window is displayed. 2) Press the AOPA or DIRECTORY Softkey. 3) To return to the map, press the ENT Key, the CLR Key, or the FMS Joystick. 190-00959-00 Rev. E Garmin GPSMAP 695/696 Quick Reference Guide...
  • Page 34 Additional Features Blank Page Garmin GPSMAP 695/696 Quick Reference Guide 190-00959-00 Rev. E...

  • Page 35: Messages & Alerts

    Internal problem with your GXM 40 antenna. Contact Garmin Product Support. Database Error Internal problem with the unit. Contact your dealer or Garmin Product Support to have the unit repaired. Fuel Tank A reminder for switching fuel tanks. The reminder message repeats at the specified interval after the beginning of each trip.
  • Page 36 A waypoint with the same name already exists. Waypoint Memory Full The unit has stored the maximum number of waypoints. XM Antenna Not Responding The unit is unable to communicate with the GXM 40. Garmin GPSMAP 695/696 Quick Reference Guide 190-00959-00 Rev. E...

  • Page 37: Airspace Messages

    “caution, terrain ahead” ahead” “obstacle ahead! pull “terrain ahead! pull up!” up!” “sink rate, pull up!” Warning “terrain! terrain! pull up! “obstacle! obstacle! “pull up!” pull up!” pull up! pull up!” Aural Alerts 190-00959-00 Rev. E Garmin GPSMAP 695/696 Quick Reference Guide...
  • Page 38 Messages & Alerts Blank Page Garmin GPSMAP 695/696 Quick Reference Guide 190-00959-00 Rev. E...

  • Page 39: Utilities

    5) Turn the FMS Joystick to select ‘On’ or ‘Off’, and press the ENT Key. 6) Press the FMS Joystick, the CLR Key, or the EXIT Softkey to return to the Map Page. 190-00959-00 Rev. E Garmin GPSMAP 695/696 Quick Reference Guide...

  • Page 40: E6B Calculator

    ENT Key. Repeat for the ‘Maximum Speed’ and ‘Fuel Flow’ fields. 4) Move the FMS Joystick to highlight the ‘Map Symbol’ field, and turn the FMS Joystick to select the desired map symbol. Garmin GPSMAP 695/696 Quick Reference Guide 190-00959-00 Rev. E...

  • Page 41: Weight & Balance

    6) Select the desired waypoint using the Map or Select Waypoint Window, and press the ENT Key. The ‘Distance’ field is highlighted. 7) Using the FMS Joystick, enter the desired distance and press the ENT Key. 190-00959-00 Rev. E Garmin GPSMAP 695/696 Quick Reference Guide...
  • Page 42 Utilities Blank Page Garmin GPSMAP 695/696 Quick Reference Guide 190-00959-00 Rev. E...
  • Page 44 Hounsdown Business Park Southampton, SO40 9RB, U.K. p: 44/0870.8501241 f: 44/0870.8501251 Garmin Corporation No. 68, Jangshu 2nd Road Shijr, Taipei County, Taiwan p: 886/2.2642.9199 f: 886/2.2642.9099 www.garmin.com © 2009, 2012 Garmin Ltd. or its subsidiaries 190-00959-00 Rev. E Printed in Taiwan...
