- Page 1 ..................... EOC5951AA EN OVEN USER MANUAL...
-
Page 2: Table Of Contents
16. EUROPEAN GUARANTEE ..........43 WE’RE THINKING OF YOU Thank you for purchasing an Electrolux appliance. You’ve chosen a product that brings with it decades of professional experience and innovation. Ingenious and stylish, it has been designed with you in mind. -
Page 3: Safety Information
ENGLISH 1. SAFETY INFORMATION Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible if an incorrect installation and use causes in- juries and damages. Always keep the instructions with the appliance for future reference. 1.1 Children and vulnerable people safety WARNING! Risk of suffocation, injury or permanent disability. -
Page 4: Safety Instructions
• Do not use harsh abrasive cleaners or sharp metal scrapers to clean the glass door since they can scratch the surface, which may result in shattering of the glass. • Excess spillage must be removed before the pyrolytic cleaning. - Page 5 ENGLISH • The electrical installation must have an • To prevent damage or discoloration to isolation device which lets you discon- the enamel: nect the appliance from the mains at all – Do not put ovenware or other objects poles. The isolation device must have a in the appliance directly on the bottom.
-
Page 6: Pyrolytic Cleaning
Pyrolytic Ovens when Pyrolytic cleaning the Pyrolytic self cleaning program is in WARNING! operation. Risk of fire and burns. • Non-stick surfaces on pots, pans, trays, utensils etc., can be damaged by • Before carrying out a Pyrolitic self-... -
Page 7: Product Description
ENGLISH 3. PRODUCT DESCRIPTION Control panel Electronic programmer Socket for the food probe sensor Heating element Lamp Rear wall heating element Bottom heat Shelf support, removable Shelf positions Wire shelf For cookware, cake tins, roasts. Trivet • For roasting and grilling. Use the trivet only with the Grill- / roasting pan. -
Page 8: Before First Use
Telescopic runners For shelves and trays. 4. BEFORE FIRST USE WARNING! 4.2 First Connection Refer to the Safety chapters. When you connect the appliance to the mains the display shows a welcome text. 4.1 Initial Cleaning You have to set the language (for the first connection only), date and time of the •... - Page 9 ENGLISH Use the sensor field to operate the appliance. Sensor Function Comment field Right, Left To move within the main menu. To confirm or start the set function. To move within the submenus and set the set- tings in them. To set the values: Down, Up •...
-
Page 10: Daily Use
10 www.electrolux.com Area Comment Can show: • Heating function name and symbol • Automatic programme name and symbol • Temperature(s) Main content area • Food Probe status • Help text • Name of the day (only when the appliance is deacti- vated) •... - Page 11 ENGLISH Symbol Menu item Description It contains a list of favourite cooking My Programmes programmes made by the user. It contains a list of automatic cooking Recipes programmes. Temperature It shows the settings of the appliance. Submenu for: Heating Functions Heating function Description True Fan Cooking...
- Page 12 12 www.electrolux.com Heating function Description Plate Warming To preheat a plate for serving. Submenus for: Timers Symbol Submenu Set duration Set start time Set end time Set+Go Count up timer Set reminder Submenus for: Food Probe Symbol Submenu Core temp. 60°...
- Page 13 ENGLISH Symbol Submenu Description To set if the is to scroll up the Up key goes list or to go to the upper item. To set all settings back to factory Factory settings settings (also My programmes ). Submenus for: My Programmes Symbol Submenu Add new Names of saved programmes...
- Page 14 14 www.electrolux.com Sym- Submenu Dish Lemon Sponge Cake Ring Cake Savarin Cake Swedish Cake Brownies Biscuit Muffins Cake Cheese Cake Sweet Tart Fruit Cake Carrot Cake Streusel Cake Almond Cake Rich Yeast Plait Fruit Tart Yeast Plait Pizza Cheese Pastry...
-
Page 15: Clock Functions
ENGLISH 7. CLOCK FUNCTIONS Symbol Function Description To set a count down. Set duration Set start time To set when the appliance activates. To set when the appliance deactivates. Set end time To set the settings for the heating function and acti- Set+Go vate it later. -
Page 16: Automatic Programmes
16 www.electrolux.com 8. AUTOMATIC PROGRAMMES WARNING! Activating the function: Refer to the Safety chapters. Activate the appliance. Set the Recipes menu. Touch OK. The automatic programmes give the opti- Set the category and dish. Touch mum settings for each type of meat or other recipes. - Page 17 ENGLISH The display shows the oven temperature Put the plug of the Food Probe into and the core temperature of the food. the socket, which is in the front wall of the appliance. The display shows the Food Probe menu. Touch to set the core tem- perature of the food in less than 5...
-
Page 18: Inserting The Oven Accessories
18 www.electrolux.com 9.2 Inserting the oven accessories The deep pan and the wire shelf have side edges. These edges and the shape of the guide-bars are a special device to prevent the cookware from slipping. Installing the wire shelf and the deep pan together Put the wire shelf on the deep pan. -
Page 19: Additional Functions
ENGLISH 9.4 Inserting the wire shelf and the deep pan together Put the wire shelf on the deep pan. Put the wire shelf and the deep pan on the telescopic runners. 9.5 Trivet and Grill- / Roasting WARNING! Be careful when you remove the accessories from a hot appliance. -
Page 20: Child Lock
20 www.electrolux.com Set the My Programmes menu. 10.3 Child lock Touch to set the Add new The Child lock function prevents an acci- option. Touch OK. The display shows dental operation of the appliance. a possible name for the programme. -
Page 21: Helpful Hints And Tips
ENGLISH 11. HELPFUL HINTS AND TIPS ature, cooking times) and shelf posi- 11.1 Inner side of the door tions to the values in the tables. In some models, on the inner side of • With longer baking times, you can de- the door you can find: activate the appliance approximately 10 •... - Page 22 22 www.electrolux.com Baking results Possible cause Remedy Set a longer baking time. The cake sinks and be- The baking time is too You cannot decrease comes soggy, lumpy or short. baking times by setting streaky. higher temperatures. Use less liquid. Be careful...
- Page 23 ENGLISH Type of bak- Oven func- Shelf posi- Temperature Time (min.) tion tion °C Apple pie / True Fan 60 - 90 Apple pie (2 Cooking tins Ø20 cm, diagonally off set) Apple pie / Conventional 70 - 90 Apple pie (2 Cooking tins Ø20 cm, diagonally off...
- Page 24 24 www.electrolux.com Type of bak- Oven func- Shelf posi- Temperature Time (min.) tion tion °C Fruit flans (made with yeast dough / True Fan 35 - 55 sponge mix- Cooking ture) Fruit flans (made with yeast dough / Conventional 35 - 55...
- Page 25 ENGLISH Type of bak- Oven func- Shelf posi- Temperature Time (min.) tion tion °C Biscuits made True Fan with yeast 150 - 160 20 - 40 Cooking dough True Fan Puff pastries 20 - 30 170 - 180 Cooking True Fan Rolls 10 - 25 Cooking...
-
Page 26: Multileveled Baking
26 www.electrolux.com 11.7 Multileveled Baking Cakes / pastries / breads on baking trays True Fan Cooking Type of bak- Temperature Shelf position Time (min.) in °C 2 levels 3 levels Cream puffs / 1 / 4 25 - 45 160 - 180... -
Page 27: Cooking Times
ENGLISH • Use a dripping pan for very fatty food to peratures no more than 65 °C. Slow Cook prevent the oven from stains that can is not applicable to such recipes as pot be permanent. roast or fatty roast pork. You can use the Food Probe to guarantee that the meat •... -
Page 28: Roasting With Turbo Grill
28 www.electrolux.com Type of baking Shelf position Temperature °C Time (min.) Puff pastry flan 45 - 55 160 - 180 Flammekuchen (Pizza-like dish 12 - 20 230 - 250 from Alsace) Piroggen (Russian 15 - 25 180 - 200 version of calzone) 1) Preheat the oven. - Page 29 ENGLISH Oven Shelf po- Tempera- Time Type of meat Quantity function sition ture °C (min.) Pork knuckle 750 g - 1 Turbo Grill 150 - 170 90 - 120 (precooked) Veal Type of Quantity Oven Shelf posi- Tempera- Time meat function tion ture °C...
- Page 30 30 www.electrolux.com Type of Quantity Oven Shelf posi- Tempera- Time meat function tion ture °C (min.) Turkey 4 - 6 kg Turbo Grill 140 - 160 150 - 240 Fish (steamed) Type of Quantity Oven Shelf posi- Tempera- Time meat...
-
Page 31: Convenience Food
ENGLISH Defrosting Further defrost- Dish Comment time (min.) ing time (min.) Put the chicken on an upturned saucer placed Chicken, 1000 g 100 - 140 20 - 30 on a large plate. Turn halfway through. Meat, 1000 g 100 - 140 20 - 30 Turn halfway through. - Page 32 32 www.electrolux.com Frozen Ready Meals Food to be Oven func- Shelf posi- Temperature Time (min.) cooked tions tion (°C) as per manu- as per manu- Frozen pizza Conventional facturer’s in- facturer’s in- structions structions French fries as per manu- Conventional 200 - 220 facturer’s in-...
- Page 33 ENGLISH • Fill the jars equally and close with a 11.18 Preserving clamp. Things to note: • The jars cannot touch each other. • Use only preserve jars of the same di- • Put approximately 1 / 2 litre of water in- mensions available on the market.
-
Page 34: Care And Cleaning
34 www.electrolux.com Pork Food Food Core Temperature °C Shoulder / Ham / Neck joint of pork 80 - 82 Chop (saddle) / Smoked pork loin 75 - 80 Meatloaf 75 - 80 Veal Food Food Core Temperature °C Roast veal... -
Page 35: Cleaning Reminder
ENGLISH • To clean metal surfaces, use a usual – AUTO - the appliance automatical- cleaning agent. ly calculates which pyrolytic cycle to use. • Clean the appliance interior after each use. Then you can remove dirt more – LIGHT - for a low level of dirt (1 h) easily and it does not burn on. -
Page 36: Shelf Supports
36 www.electrolux.com 12.3 Shelf supports Removing the shelf supports You can remove the shelf supports to clean the side walls. Pull the front of the shelf support away from the side wall. Pull the rear end of the shelf support... -
Page 37: Cleaning The Oven Door
ENGLISH Replace the lamp with a suitable 300 °C heat-resistant lamp. Install the glass cover. Install the left shelf support. 12.5 Cleaning the oven door Removing the door and the glass panels You can remove the oven door and the internal glass panels to clean it. -
Page 38: What To Do If
38 www.electrolux.com Hold the door glass panels on their top edge one by one and pull them up out of the guide. Clean the glass panel with water and soap. Dry the glass panel carefully. Installing the door and the glass the above steps in the opposite se- quence. -
Page 39: Installation
ENGLISH Serial number (S.N.) ......... 14. INSTALLATION WARNING! - Earth terminal Refer to the Safety chapters. CAUTION! This appliance must be earthed! The appliance is designed to be connec- ted to 230 - 240V ~ (50Hz) electricity sup- The cable used to connect the oven to ply. - Page 40 40 www.electrolux.com min. 50 mm 560 min. 20 min. ! 530 min.
- Page 41 ENGLISH 560 min. 530 min. 590 min. alternativ 100 max. R1200 mm H05VV-F H05RR-F min. 1600 mm 90 º...
-
Page 42: Great Britain & Ireland - Guarantee/Customer Service
• Damage, calls resulting from transport, improper use, neglect, light bulbs, re- movable parts of glass, plastic. We, Electrolux, undertake that if within 12 • Costs for calls to put right appliance months of the date of the purchase this... -
Page 43: European Guarantee
Depart- poses) contact us at the address ment, below: Electrolux 08445 613 613 Electrolux Group (Irl) Ltd, Long Mile Road, Dublin 12, Republic of Ireland AEG- 08445 611 611 Tel: +353 (0)1 4090751, Email: serv- Electrolux ice.eid@electrolux.ie 16. - Page 44 +41 62 88 99 111 Industriestrasse 10, CH-5506 Svizzera Mägenwil Slovenija +38 61 24 25 731 Gerbičeva ulica 110, 1000 Ljubljana Slovensko +421 2 32 14 13 34-5 Electrolux Slovakia s.r.o., Electrolux Domáce spotrebiče SK, Galvaniho 17/ B, 821 04 Bratislava...
-
Page 45: Environment Concerns
Suomi 030 600 5200 Lankapuhelinverkosta 0,0828€/puhelu+0,032€/min Matkapuhelinver- kosta 0,192€/min Sverige +46 (0)771 76 76 76 Electrolux Service, S:t Göransga- tan 143, S-105 45 Stockholm Türkiye +90 21 22 93 10 25 Tarlabaşı caddesi no : 35 Taksim İstan‐ Россия 8-800-200-3589 129090 Москва, Олимпийский... - Page 46 46 www.electrolux.com...
- Page 47 ENGLISH...
- Page 48 www.electrolux.com/shop...
