Dell Latitude XT3
Setup And Features Information
About Warnings
WARNING: A WARNING indicates a potential for property damage, personal injury,
or death.
Front And Back View
Figure 1. Front View
1. microphone (optional)
2. camera (optional)
3. camera status light (optional)
4. volume control buttons
5. fingerprint reader
6. security cable slot
7. USB 2.0 connector
8. eSATA/USB 2.0 connector
9. wireless on/off switch
10. keyboard
Regulatory Model:P17G
Regulatory Type:P17G001
2011 – 04

Advertisement

loading

Related Manuals for Dell Latitude XT3

Summary of Contents for Dell Latitude XT3

  • Page 1 Dell Latitude XT3 Setup And Features Information About Warnings WARNING: A WARNING indicates a potential for property damage, personal injury, or death. Front And Back View Figure 1. Front View 1. microphone (optional) 6. security cable slot 2. camera (optional) 7.
  • Page 2 18. power button 12. smart card reader 19. Windows security button 13. trackstick buttons (3) 20. screen rotate button 14. touchpad 21. Dell Feature Enhancement Pack/ settings button 15. display latch lock 22. device status lights 16. touchpad buttons (2) 17. trackstick Figure 2.

  • Page 3: Quick Setup

    WARNING: Do not block, push objects into, or allow dust to accumulate in the air vents. Do not store your Dell computer in a low-airflow environment, such as a closed briefcase, while it is running. Restricting the airflow can damage the computer or cause a fire.
  • Page 4 3. Connect USB devices, such as a mouse or keyboard (optional). Figure 5. USB Connector 4. Connect IEEE 1394 devices, such as a 1394 hard drive (optional). Figure 6. 1394 Connector 5. Connect to an external monitor using one of the following cables (optional): Figure 7.

  • Page 5: Specifications

    Figure 9. Power Button 7. To retrieve or store the pen, push pen inward until you hear a click, then release. Figure 10. Pen NOTE: It is recommended that you turn on and shut down your computer at least once before you install any cards or connect the computer to a docking device or other external device, such as a printer.
  • Page 6 Video NOTE: The video memory will differ depending on the operating system and computer memory. Memory Memory connector two SODIMM slots Memory capacity 1 GB, 2 GB, 4 GB, and 8 GB Memory type DDR3 1333MHz Minimum memory 1 GB Maximum memory up to 8 GB Smart Card...
  • Page 7 Battery Voltage 11.1 VDC Temperature range: Operating 0 °C to 50 °C (32 °F to 122 °F) Non-operating -20 °C to 65 °C (-4 °F to 149 °F) Coin-cell battery 3 V CR2032 lithium ion AC Adapter Input voltage 100 VAC to 240 VAC Input current 1.50 A (maximum)

  • Page 8: Finding More Information And Resources

    G1 or lower as defined by ISA-S71.04–1985 Finding More Information and Resources See the safety and regulatory documents that shipped with your computer and the regulatory compliance website at www.dell.com/ regulatory_compliance for more information on: • Safety best practices • Regulatory certification •...
  • Page 9 Other trademarks and trade names may be used in this publication to refer to either the entities claiming the marks and names or their products, Dell Inc. disclaims any proprietary interest in trademarks and trade names other than its own.
