Logic control (ver. 2.0) industrial duty door operator
Hide thumbs Also See for GT:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Owner's Manual, User Manual
OWNER'S MANUAL
INDUSTRIAL DUTY DOOR OPERATOR
2 YEAR WARRANTY
Serial #
(located on electrical box cover)
Installation Date
Wiring Type
MODEL GT
LOGIC CONTROL (VER. 2.0)
L
F A C T O R Y S E T
C2 Wiring
See pages 14 and 15
for other wiring
configurations
PATENT PENDING
The Maintenance Alert System
allows the installer to set an internal
Maintenance Cycle Counter. An LED
on the 3-button station will signal when
the set number of cycles is reached or
when the opener requires immediate
service.
NOT FOR RESIDENTIAL USE
41B6
LISTED DOOR OPERATOR
TM
