System Example

Connection of a USB Memory
USB connector
• Do not leave USB memory, in a vehicle for a long time. Heat and humidity may damage the USB memory.
Connection of an iPod/iPhone
USB connector
1
* If iPod VIDEO is supported, use the iPod VIDEO extension cable.
• Do not leave a iPod/iPhone in a vehicle for a long time. Heat and humidity may damage the iPod/iPhone and you may not be able to play it again.
• To connect an iPod/iPhone, an optional connection kit KCU-461iV is required.
USB extension cable
(Included)
iPod VIDEO input
connector
iPod VIDEO AV extension cable*
(Included with KCU-461iV)
USB extension cable (Included)
USB Memory (Sold separately)
1
Connection kit KCU-461iV
(Sold separately)
iPod/iPhone
(Sold separately)
