- Page 1 IP8100 series Quick Start Guide www.vonage.com/vtech...
-
Page 2: Parts Checklist
Parts Check List The IP8100 series telephone is an advanced broadband cordless telephone set, capable of supporting up to four handsets. Your package contains: 1. Base Unit 6. Charger Wall Mounting Bracket(s) 2. Handset(s) 7. Belt Clip(s) 3. Handset Charger(s) 8. -
Page 3: Getting Started
IP8100 series Quick Start Guide Getting Started Installation of Batteries in Handset Follow the steps below: 1. Place the new battery in the handset and align the two holes in the plug with the socket pins to snap the plug into place. 2. - Page 4 If the answer is no to both questions, continue on page 4. Helpful Hint: If you purchased this VTech broadband phone from a retail store, you need to activate your device at www.vonage.com/activate.
-
Page 5: Installation Without A Router
Installation Without A Router INTERNET DSL or Cable Modem Handset 1 & 2 PC/LAN Port WAN Port Base Unit NOTE: The IP8100 series telephone is expandable up to a total of 4 handsets. Uses model IP 811 (sold separately) Warning: Do not route the ethernet cable to outdoors, and ensure that you are using a safety approved DSL or Cable modem with proper electrical isolation. - Page 6 IP8100 series Quick Start Guide Installation Without A Router STEP 2 Disconnect all cables between your Cable or DSL modem and your computer. STEP 3 Connect one end of the yellow ethernet cable to the yellow port, labeled “PC/LAN,” located on the back of the base unit and connect the other end of the yellow cable to the ethernet port of your computer.
- Page 7 Congratulations! Even if you are transferring your number, you are ready to start taking advantage of the great sav- ings and superior quality of Vonage right now! Please call 800-342-1791 to setup your voicemail service and to learn about other free Vonage features included with every Vonage calling plan.
-
Page 8: Installation With A Router
IP8100 series Quick Start Guide Installation With A Router INTERNET Base Unit DSL or Cable Modem WAN Port Laptop Existing Network Router Handset 1 & 2 NOTE: The IP 8100 series telephone is expandable up to a total of 4 handsets. Uses model IP 811 (sold separately) Warning: Do not route the ethernet cable to outdoors, and ensure that you are using a safety approved DSL or Cable modem with proper electrical isolation. - Page 9 Congratulations! Even if you are transferring your number, you are ready to start taking advantage of the great sav- ings and superior quality of Vonage right now! Please call 800-342-1791 to setup your voicemail service and to learn about other free Vonage features included with every Vonage calling plan.
-
Page 10: Installation With A Modem Router
IP8100 series Quick Start Guide Installation With A Modem Router INTERNET Base Unit WAN Port Laptop DSL or Cable Modem Handset 1 & 2 NOTE: The IP8100 series telephone is expandable up to a total of 4 handsets. Uses model IP 811 (sold separately) Warning: Do not route the ethernet cable to outdoors, and ensure that you are using a safety approved DSL or Cable modem with proper electrical isolation. - Page 11 Congratulations! Even if you are transferring your number, you are ready to start taking advantage of the great sav- ings and superior quality of Vonage right now! Please call 800-342-1791 to setup your voicemail service and to learn about other free Vonage features included with every Vonage calling plan.
- Page 12 VTech Telecommunications LTD. A member of THE VTECH GROUP OF COMPANIES. Distributed in the U.S.A. by VTech Communications, Inc. Beaverton Copyright 2005 for VTECH COMMUNICATIONS LTD. Printed in China All rights reserved. 96-006057-010-000 www.vtechphones.com ISSUE 0...
