For Windows Users; For Macintosh Users; In Mac Os X Version 10.5 Or Later - Lexmark Color Laser Connection Manual

For Windows users

1
Insert the Software and Documentation CD.
Wait for the Welcome screen to appear.
If the CD does not launch after a minute, then do the following:
a
Click or click Start, and then click Run.
b
In the Start Search or Run box, type D:\setup.exe, where D is the letter of your CD or DVD drive.
c
Press Enter, or click OK.
2
Click Install, and then follow the instructions on the computer screen.
Note: To configure the printer using a static IP address, using IPv6, or to configure printers using scripts, select Advanced
Options > Administrator Tools.
3
Select Ethernet connection, and then click Continue.
4
Attach the appropriate cable to the computer and to the printer when instructed to do so.
5
Select the printer from the list, and then click Continue.
Note: If the configured printer does not appear on the list, then click Modify Search.
6
Follow the instructions on the computer screen.

For Macintosh users

1
Allow the network DHCP server to assign an IP address to the printer.
2
Obtain the printer IP address. You can:
a
View the information on the printer control panel home screen, or in the TCP/IP section under the Networks/Ports menu.
b
Print a network setup page or menu settings page and locate the information in the TCP/IP section.
Note: You will need the IP address if you are configuring access for computers on a different subnet than the printer.
3
Install the printer drivers, and then add the printer.
a
Install a printer driver file on the computer:
1
Insert the Software and Documentation CD, and then double-click the installer package for the printer.
2
Follow the instructions on the computer screen.
3
Select a destination, and then click Continue.
4
From the Easy Install screen, click Install.
5
Type the user password, and then click OK.
All the necessary software is installed on the computer.
6
Click Close when installation is complete.
b
Add the printer:
•
For IP printing:

In Mac OS X version 10.5 or later

1
From the Apple menu, navigate to:
System Preferences > Print & Fax
2
Click +, and then click the IP tab.
3
Type the printer IP address in the Address field, and then click Add.
