GENERAL INFORMATION

Your Hayward SwimClear
corrosion-free construction. With filtration ratings to 9000 gallons (34,000 liters) per hour, they are designed for
continuous or intermittent operation, for installation above or below the pool water line, for fresh or salt water swimming
pools or spas. SwimClear™ filters utilize multiple reusable, reinforced polyester filter cartridge elements to provide a
high degree of water clarity and long filter cycles with minimum care.

INSTALLATION

B
SWIMCLEAR CARTRIDGE FILTER
TM
cartridge filter combines superior water filtration with ease of operation and totally
A
IN CM
C2025 32.5 83
C3025 34.5 88
C4025 40.5 103
C5025 46.5 118
C7000 52.5 133
REQUIRED CLEARANCE
"B" SIDE "C" ABOVE
IN CM IN
18 46 15
18 46 16
18 46 18
18 46 22
18 46 28
WARNING
This product should be installed and
serviced only by a qualified pool professional.
1. The filter system should be installed
2. Position filter body such that all
3. Position filter so the filter will drain by
4. If practical, place pump and filter in
5. Connect the pool suction plumbing
6. Install the plumbing from the filter to
7. Do not locate pump controls over or
8. Verify water discharge from the
USE ONLY HAYWARD GENUINE REPLACEMENT PARTS
ISC2028 REV C
CM
38
41
46
56
71
on a level concrete slab or other rigid
base. Select a well drained and
vented area, one that does not flood
when it rains. Position the filter so
that the piping connections, and
winter drain are convenient and
accessible for operation, service,
maintenance and winterizing.
operation and safety labels are
visible.
gravity.
the shade to shield it from continuous,
direct heat from the sun.
between the skimmer, pool outlet
(from the pool) and the pump.
the pool (return to the pool).
near filter.
manual air relief valve(MAR) is
directed away from electrical devices.
