Basic safety precautions should always be followed, including the following: Failure to follow instructions can cause severe
injury and/or death.
This is the safety-alert symbol. When you see this symbol on your equipment or in this manual, look for one of the
following signal words and be alert to the potential for personal injury.
WARNING
warns about hazards that could cause serious personal injury, death or major property damage and if
ignored presents a potential hazard.
CAUTION
warns about hazards that will or can cause minor or moderate personal injury and/or property damage
and if ignored presents a potential hazard. It can also make consumers aware of actions that are unpredictable and unsafe.
The NOTICE label indicates special instructions that are important but not related to hazards.
Use only High Rate Sand No. 20 Silica Sand (.45mm - .55mm)
620 Division Street
OWNER'S MANUAL
INSTALLATION, OPERATION & PARTS
SAVE THIS INSTRUCTION MANUAL
Elizabeth, NJ 07207
WWW.HAYWARDPOOL.COM
SERIES:
SM1700T
SM1900T
HIGH-RATE SAND
FILTER
Tel: 908-351-5400
ISSM170T
Rev. B
