Hayward SWIMPURE Owner's Manual

SAFETY INSTRUCTIONS
The SwimPure™ Natural Pool Purifying System featuring
Nature 2 ® can be used with every type of chemical treatment
available except bromine and bromide based chemicals
biguanide products 2 (e.g. Baquacil* or Softswim**), and copper
based algaecides 3 .
1. Bromine/Bromide will reduce the effectiveness of the purifying system.
2. Metals (e.g. silver) combine with biguanides to form cloudy water.
3. Copper based algaecides may cause staining of pool walls.
* A Trademark of Zeneca, Inc.
** A Trademark of Biolab, Inc.
Caution: Model N2SABG is rated for above-ground pools
from 5,000 gallons to 25,000 gallons. Model N2SIG is rated
for inground pools from 10,000 gallons to 35,000 gallons.
Using a SwimPure system on an undersized pool may
cause staining of the pool.
1. INSTALL THE SYSTEM
To install New Filter Factory-Equipped with SwimPure:
A. Follow the installation instructions packaged with your sand
filter to install the filter system. After filling the filter with sand
and removing the sand shield (step 3), proceed with the
following instructions:
B. Remove center pipe extension from the center pipe by
pulling the center pipe extension upward with a twisting
motion.
C. Properly place the purifying system onto the center pipe. The
side showing "SwimPure by HAYWARD" must face up as
shown in Installation (3).
D. Proceed with steps 4, 5, 6 and 7 in the sand filter installation
instructions.
To Install SwimPure Retrofit Kit to New Filter:
A. Follow the installation instructions packaged with your sand
filter to install the filter system. After filling the filter with sand
and removing the sand shield (step 3), proceed with the
following instructions:
Cut the center pipe, following these steps:
B.
Note the filter control valve model number indicated on
1)
the label on the top of the valve. Model number will be
either SP0714, SP071113, or SP0704.
OWNER'S GUIDE
S P
WIM URE
NATURAL POOL PURIFYING SYSTEM
Your Hayward SwimPure™ Natural Pool Purifying System has established a new
horizon in swimming pool water purification. The system is designed to fit into all Hayward
top mount sand filters using SP0704, SP071113 or S0714T valve. It will release minerals
into the water to make your pool water clean and healthy.
1 ,
™
FOR SAND FILTERS
Place the cutter
2)
handle through the
appropriate hole in
the cutter body, as
shown in Illustration
(1). For the SP0714T
valve, use the top
hole. For SP071113
valve or SP0704
valve, use the middle
hole.
3) Slip the cutter over
the center pipe until
the cutter handle
rests on the top of
the filter, as shown in
Illustration (2). Now
cut the center pipe
by:
a)
Turning the eyescrew in a clockwise direction until the
screw point lightly contacts the center pipe.
Turning the cutter in a clockwise direction. Keep cutter
b)
handle firmly rested on top of the filter during turning.
After every two revolutions of the cutter, turn the eye-
screw an additional one-quarter turn in the clockwise
direction.
Repeat Step b) until the center pipe is cut.
c)
Remove the cutter.
d)
C. Properly place the
purifying system onto
the center pipe. The
side showing "Swim
Pure by HAYWARD"
must face up,
shown in Illustration
(3).
D. Proceed with steps 4,
5, 6 and 7 in the
sand filter installation
instructions.
ISN2S-00
Illustration 1
Illustration 2
as
Illustration 3
