Whirlpool WED5510VQ Parts List page 4

TOP AND CONSOLE PARTS
For Model: WED5510VQ0
(Designer White)
Illus. Part
No. No. DESCRIPTION
1 8274261 Panel, Rear
Console
2 8539893 Wire, Jumper
(Temp. Switch)
3 694419 Buzzer
4 8271365 Cap, End (L.H.)
5 3399639 Switch, Rotary
6 388326 Screw, Console
7 693995 Screw, Hex Head
8 8271359 Cap, End (R.H.)
9 3395683 Housing, Connector
(Motor)
10 8557857 Screen, Lint
11 8536939 Clip, Spring
12 8533971 Screw, 8−18 x 5/16
13 688983 Screw, 8−18 x 5/8
14 8533951 Screw, Grounding
15 3401684 Wire, Jumper
(Timer−Signal)
16 8557930 Top
17 3347243 Connector,
(6−Circuit)
18 94614 Terminal
19 3397269 Connector, Timer
20 3401144 Connector,
(PTS Relay)
21 3979617 Timer, 60 Hz.
22 8565944 Knob, Control
23 3394427 Clip, Harness
24 8533971 Screw, 8−18 x 5/16
25 357213 Nut, Push−In (2)
26 8576503 Harness, Wiring
27 3398095 Switch,
Push−To−Start
28 8566061 Timer Knob
Assembly
29 8566073 Knob,
Push−To−Start
30 3936144 Connector
31 8544895 Bracket, Control
32 W10226241 Panel, Control
4
W10252020
