Cabinet Parts - Whirlpool WED5510VQ Parts List

Illus. Part
No. No. DESCRIPTION
1 Literature Parts
W10150612 Installation
Instructions
W10042960 Sheet,
Cycle Feature
W10150610 Use & Care Guide
8576817 Wiring Diagram
Following May Be Purchased
DO−IT−YOURSELF
REPAIR MANUALS
677818 Dryer
2 343641 Screw, 10−16 x 1/2
3 693995 Screw, Hex
Washer Head
4 8541400 Bracket, Cabinet
5 3396795 Cover,
Terminal Block
6 342043 Screw, 10−32 x 3/8
7 3396805 Panel, Rear
8 691366 Idler & Pulley
Assembly
9 W10131364 Belt, Drive
10 3406107 Door Switch
Assembly

CABINET PARTS

For Model: WED5510VQ0
(Designer White)
Illus. Part
No. No. DESCRIPTION
11 697773 Screw, 6−20 x 7/8
12 348780 Base, Motor
13 3357011 Screw, 10−16 x 1/2
14 W10041960 Spring, Door (2)
15 3394083 Clip, Front
Panel (2)
16 3392100 Foot, Dryer
279810 Foot − Optional
(Extended Length
Package Of 2)
(Not Included)
17 279318 Terminal, Tinned
& Brass (3)
(Includes Illus. 39)
18 8530603 Cabinet
(Includes
Illus. 4)
19 98234 Clip, Ground
20 690363 Lock, Front Top (2)
21 695620 Panel, Front
22 3400500 Bolt,
5/16−18 x 3/4
23 685203 Clip, Felt Pad (3)
24 3389441 Catch, Door
Assembly
25 8066184 Pulley, 60 Hz.
2
Illus. Part
No. No. DESCRIPTION
26 337189 Clip, Hinge (2)
27 694091 Screw, 8−18 x 3/8
28 8066056 Hinge, R.H.
8066057 Hinge, L.H.
29 W10194250 Motor Assembly
60 Hz.
30 W10121316 Clamp, Motor
31 3404162 Clamp, Motor
(W/Shield)
32 3390731 Seal, Door
33 696144 Strike, Door
34 697776 Screw, 10−32 x 5/8
(External Ground)
35 695737 Door, Rear
36 3393549 Door, Front
37 W10095180 Handle, Door
38 3406129 Seal & Bearing
Assembly
39 279393 Terminal Block
Kit (For
Terminal Block)
40 3393008 Screw, 10−16 x 1/2
41 3397659 Block, Terminal
42 8066217 Hinge, Top (2)
W10252020
