WELLTECH ATA-171 - V2.0 User Manual

V2.0 1-port fxs and 1-port fxo voip terminal adapter (ata)
Hide thumbs
Table of Contents

Advertisement

Quick Links

ATA-171/172/171P/171M (ATA-S1/S2/P/M)
User's Guide
ATA-171/172/171P
/171M
(ATA-S1/S2/P/M)
User's Guide
V2.0
2007/08/23
0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ATA-171 - V2.0 and is the answer not in the manual?

Questions and answers

Related Manuals for WELLTECH ATA-171 - V2.0

Summary of Contents for WELLTECH ATA-171 - V2.0

  • Page 1 ATA-171/172/171P/171M (ATA-S1/S2/P/M) User’s Guide ATA-171/172/171P /171M (ATA-S1/S2/P/M) User’s Guide V2.0 2007/08/23...
  • Page 2 User’s Guide Copyright and Trademarks Specifications are subject to change without notice. WELLTECH is a registered trademark and/or its affiliates in Taiwan and certain other countries. Copyright © 2007 WELLTECH Computer Co., Ltd. All rights reserved. Other brands and product names are trademarks or registered trademarks of their respective holders.
  • Page 3 Firmware & It’s due to the continuous evolution of WELLTECH Computer Co., Ltd., this Documents model will be regularly upgraded. Please consult the WELLTECH web site for Updates more information on latest firmware, tools and documents.

  • Page 4: Table Of Contents

    ATA-171/172/171P/171M (ATA-S1/S2/P/M) User’s Guide Introduction............................4 Hardware Overview....................... 4 Software Overview ........................ 4 Keypad Interface for The ATA......................5 Setup the ATA by Web Browser (LAN connection)................7 Login............................7 System Information for the ATA..................... 9 Phone Book........................... 9 Phone Setting........................10 Hot line ..........................20 Alarm setting ........................21 Network ..........................21...

  • Page 5: Introduction

    ATA-171/172/171P/171M (ATA-S1/S2/P/M) User’s Guide Introduction This user’s manual is for 1-port FXS and 1-port FXO (FXO only supported in ATA171M) VoIP terminal adapter (ATA). This user’s manual will explain the IVR instruction, web configuration, and command line configuration for the ATA. Before using the ATA, some setup processes are required to make the ATA work properly.

  • Page 6: Keypad Interface For The Ata

    ATA-171/172/171P/171M (ATA-S1/S2/P/M) User’s Guide Keypad Interface for The ATA You can use the PSTN phone keypad to operate the ATA. Please follow the instruction to configure your terminal adapter. Group IVR Action IVR Menu Choice Parameter(s) Notes: Press 0* can pass call to PSTN Dial out from 0＊...
  • Page 7 ATA-171/172/171P/171M (ATA-S1/S2/P/M) User’s Guide Client type Enter IP address using numbers on Set Static IP the telephone keypad. Use the * DHCP will be disabled and system Setting #112xxx*xxx*xxx*xxx# Address (star) key when entering a decimal will change to the Static IP type. point.

  • Page 8: Setup The Ata By Web Browser (Lan Connection)

    ATA-171/172/171P/171M (ATA-S1/S2/P/M) User’s Guide Setup the ATA by Web Browser (LAN connection) The ATA provides a built-in web server. You can use a Web browser to configure the ATA. For more detail instructions, please refer to the procedures below. Step 1 Connect a straight through cable from the ATA’s LAN port to a hub or switch, while making sure that your computer is also connected to the same hub or switch.
  • Page 9 ATA-171/172/171P/171M (ATA-S1/S2/P/M) User’s Guide 3.1.2 Click the “Login” button will move into the ATA web based management information page. 3.1.3 If you change the setting in the Web Management interface, please do remember to click the “Submit” button in that page. After you finished the change of the setting, click the “Save” function in the left side, and click the Save Button.

  • Page 10: System Information For The Ata

    ATA-171/172/171P/171M (ATA-S1/S2/P/M) User’s Guide System Information for the ATA. 3.2.1 When you login the web page, you can see the ATA current system information like firmware version, company… etc in this page. 3.2.2 Also you can see the function lists in the left side. You can use mouse to click the function you want to set up.

  • Page 11: Phone Setting

    ATA-171/172/171P/171M (ATA-S1/S2/P/M) User’s Guide Figure 2. Speed Dial Phone Setting 3.4.1 In Phone Setting contains Call Forward, SNTP Settings, Volume Settings, DND Settings, Auto Answer, Caller ID, Dial Plan Settings, Flash Time Settings, Call Waiting, and T.38(FAX) Setting, Hot line Settings and Alarm Settings functions. 3.4.2 Call Forward function: you can setup the phone number you want to forward in this page.
  • Page 12 ATA-171/172/171P/171M (ATA-S1/S2/P/M) User’s Guide Figure 3. Forward Setting 3.4.3 SNTP Setting function: you can setup the primary and second SNTP Server IP Address, to get the date/time information. Also you can base on your location to set the Time Zone, and how long need to synchronize again.
  • Page 13 ATA-171/172/171P/171M (ATA-S1/S2/P/M) User’s Guide 3.4.4 Volume Setting function: you can setup the Handset Volume, Ringer Volume, and the Handset Gain. When you finished the setting, please click the Submit button. Handset Volume is to set the volume for you can hear from the handset. Ringer Volume is to set the ringer volume for you can hear.
  • Page 14 ATA-171/172/171P/171M (ATA-S1/S2/P/M) User’s Guide Figure 6. DND Setting 3.4.6 Auto Answer (For 171M only) You can choose to disable or enable Auto Answer feature. Auto Answer Counter: Specifies how many ring tones will be heard before it is switched to IP or PSTN line (depending on the type of incoming call). Default value is 3, you can set between 0~8.
  • Page 15 ATA-171/172/171P/171M (ATA-S1/S2/P/M) User’s Guide 3.4.7 Caller ID function: you can set the device to show Caller ID in your PSTN Phone or IP Phone. There are four selection of Caller ID. You need to base on your environment to set the Caller ID function for FSK or DTMF.
  • Page 16 ATA-171/172/171P/171M (ATA-S1/S2/P/M) User’s Guide 3.4.8 Dial Plan Settings function: This function is when you input the phone number by the keypad but you don’t need to press “#”. After time out the system will dial directly. When you finished the setting, please click the Submit button. If there is nothing need to change, please click the Save Change Item in the left side, then click the Save button.
  • Page 17 ATA-171/172/171P/171M (ATA-S1/S2/P/M) User’s Guide For example: 1: Drop prefix: No, Replace rule 1: 002, 8613+8662 Explanation ： If you dial a number that has a prefix matching 8613 or 8662, the device will automatically append the number 002 in front of the dialed number, therefore the number that will be dialed out is [002+8613+xxx] or [002+8662+xxx] depending on which of the two numbers were dialed.
  • Page 18 ATA-171/172/171P/171M (ATA-S1/S2/P/M) User’s Guide 4:Drop prefix: No, Replace rule 4: 007, 5xxx+35xx+21xx Explanation： This replacement rule will check if the first digit of the number is 5 followed by any three digits, if it is, the device will automatically append 007 to the dialed number. Therefore the number that will be dialed out is [007+5xxx].
  • Page 19 ATA-171/172/171P/171M (ATA-S1/S2/P/M) User’s Guide 3.4.9 Flash Time Setting function: When you use the PSTN Phone and you need to press the Hook to do the Flash (Switch to the other phone line or HOLD), this function is for you to set the time you press the Hook to represent the Flash function.
  • Page 20 ATA-171/172/171P/171M (ATA-S1/S2/P/M) User’s Guide 3.4.10 Call Waiting Setting function: You can Enable/Disable the Call Waiting function, When you are talking with someone, there is a new incoming call, you will hear the call waiting tone. When you finished the setting, please click the Submit button. If there is nothing need to change, please click the Save Change Item in the left side, then click the Save button.

  • Page 21: Hot Line

    ATA-171/172/171P/171M (ATA-S1/S2/P/M) User’s Guide 3.4.11 T.38 Setting function: You can Enable/Disable the T.38 function. When you finished the setting, please click the Submit button. If there is nothing need to change, please click the Save Change Item in the left side, then click the Save button. The change you made will save into the system and the system will Reboot automatically (Note: T.38 Port of Phone 2 is only supported in...

  • Page 22: Alarm Setting

    ATA-171/172/171P/171M (ATA-S1/S2/P/M) User’s Guide Alarm setting Alarm time: setting telephone ring time,when you setting time with current time are match device should produce a ring ,this time format is 24 hours. Network 3.7.1 In Network you can check the Network Status, WAN Settings, LAN Settings, DDNS Settings, VLAN Settings, DMZ Setting, Virtual Server and PPTP Settings.
  • Page 23 ATA-171/172/171P/171M (ATA-S1/S2/P/M) User’s Guide 3.7.3 WAN and LAN Settings: If you change the WAN port’s setting to Fix IP Mode, then you have to make sure the IP address. Net Mask, Gateway, and DNS setting is suitable in your current network environment The WAN port is DHCP Client mode, You can change the setting to Fixed IP or PPPoE Mode.
  • Page 24 ATA-171/172/171P/171M (ATA-S1/S2/P/M) User’s Guide Bridge Setting: If you don’t want to use the NAT Mode, then you can set the network setting in this page. The TCP/IP Configuration item is to setup the LAN port’s network environment. You may refer to your current network environment to configure the VoIP Phone properly. If you change the LAN port’s setting to Fix IP Mode, then you have to make sure the IP address.
  • Page 25 ATA-171/172/171P/171M (ATA-S1/S2/P/M) User’s Guide 3.7.4 DDNS Setting: You can configure the DDNS setting in this page. You need to have the DDNS account and input the informations properly. You can have a DDNS account with a public IP address then others can call you via the DDNS account. But now most of the VoIP applications are work with a SIP Proxy Server.
  • Page 26 ATA-171/172/171P/171M (ATA-S1/S2/P/M) User’s Guide 3.7.5 VLAN Setting: You can set the VLAN setting in this page. There are two parts in this page. First one is to set the packets related to the TA, and the second parts is if you use the VLAN setting in the NAT Mode.

  • Page 27: Virtual Server Setting

    ATA-171/172/171P/171M (ATA-S1/S2/P/M) User’s Guide Virtual Server Setting Virtual Server Page To browse through different pages, click on the drop down box and select the page number you wish to view. This column displays the serial numbers, ranging from 0-23. There are 24 records in total.

  • Page 28: Dmz Setting

    ATA-171/172/171P/171M (ATA-S1/S2/P/M) User’s Guide DMZ Setting Default setting is Off (not executed). When activated, all packets (excluding SIP related packets) will be sent to the designated IP address DMZ Host IP Input the special IP address of the DMZ host. Submit [Button] Saves the configuration Reset [Button]...

  • Page 29: Pptp Settings

    ATA-171/172/171P/171M (ATA-S1/S2/P/M) User’s Guide 3.10 PPTP Settings PPTP Default setting is Off (not executed). When set to On (executed), PPTP function will be activated. PPTP Server Input the IP address of the PPTP server’s location. PPTP Username Input the username (login details). PPTP Password Input the password (login details).

  • Page 30: Sip Settings

    ATA-171/172/171P/171M (ATA-S1/S2/P/M) User’s Guide 3.11 SIP Settings 3.11.1 In SIP Settings you can setup the Service Domain, Port Settngs, Codec Settings, RTP Setting, RPort Setting and Other Settings. If the VoIP service is provided by ISP, you need to setup the related informations correctly then you can register to the SIP Proxy Server correctly.
  • Page 31 ATA-171/172/171P/171M (ATA-S1/S2/P/M) User’s Guide Figure 17. Service Domain Setting 3.11.4 Port Settings: you can setup the SIP and RTP port number in this page. Each ISP provider will have different SIP/RTPport setting, please refer to the ISP to setup the port number correctly.
  • Page 32 ATA-171/172/171P/171M (ATA-S1/S2/P/M) User’s Guide Figure 18. Port Setting 3.11.5 Codec Settings: you can setup the Codec priority, RTP packet length, and VAD function in this page. You need to follow the ISP suggestion to setup these items. When you finished the setting, please click the Submit button.
  • Page 33 ATA-171/172/171P/171M (ATA-S1/S2/P/M) User’s Guide 3.11.6 Codec ID Setting: Sometimes 2 VoIP device with different Codec ID will cause the interopability issue. If you are talking with others got some problems, you may ask the other one what kind of Codec ID he use, then you can change your Codec ID. When you finished the setting, please click the Submit button.
  • Page 34 ATA-171/172/171P/171M (ATA-S1/S2/P/M) User’s Guide Figure 22. DTMF Setting 3.11.8 RPort Function: you can setup the RPort Enable/Disable in this page. To change this setting, please following your ISP information. When you finished the setting, please click the Submit button. If there is nothing need to change, please click the Save Change Item in the left side, then click the Save button.

  • Page 35: Nat Trans

    ATA-171/172/171P/171M (ATA-S1/S2/P/M) User’s Guide 3.11.9 Other Settings: you can setup the Hold by RFC, Voice/SIP QoS and SIP expire time in this page. To change these settings please following your ISP information. When you finished the setting, please click the Submit button. The QoS setting is to set the voice packets’ priority. If you set the value higher than 0, then the voice packets will get the higher priority to the Internet.

  • Page 36: Others

    ATA-171/172/171P/171M (ATA-S1/S2/P/M) User’s Guide Figure 195. STUN Setting 3.13 Others 3.13.1 In Others you can setup Auto Config, PTT Setting and ICMP Setting function. The function can configure your VoIP Phone automatically. 3.13.2 Auto Config: you can setup the Auto Configuration Enable/Disable and auto configuration by FTP or TFTP.
  • Page 37 ATA-171/172/171P/171M (ATA-S1/S2/P/M) User’s Guide Figure 206. Auto Configuration Setting Auto Configuration Default setting is Off (not executed). Specify the methods on how auto configuration will be performed, the options are TFTP, FTP or HTTP. TFTP Server Set the TFTP Server’s location, you can input IP address or Domain Name information in this text box.
  • Page 38 ATA-171/172/171P/171M (ATA-S1/S2/P/M) User’s Guide 3.13.5 Auto configuration example Example 1: Auto Configuration: HTTP，HTTP Server: 192.168.1.50，HTTP Path: /file/。 Explanation： device will connect to the HTTP Server’s /file/ folder path and search the matching file。 2：Auto Configuration: FTP，FTP Server: 192.168.1.150，FTP Username: test，FTP Password: test， File Path: /file/。...
  • Page 39 ATA-171/172/171P/171M (ATA-S1/S2/P/M) User’s Guide 3.13.6 How to produce auto Configuration file. 1： Firstly, you need to find the MAC address of the device that you want to configured，for e.g. MAC Address: 00059e812118。 Explanation 1 ： open the [MACList.txt] file then enter the these information in order[MAC Address, Display Name, User Name, Register Name, Register Pass](example ：00059e812118, UN_DO, 105, 105, 105)，when completed, please save your file.
  • Page 40 ATA-171/172/171P/171M (ATA-S1/S2/P/M) User’s Guide 3.13.7 Advanced Setting ICMP Setting: you can setup the ICMP echo Enable/Disable in this page. This function can disable echo when someone ping this device, it can avoid haker try to attack the device. When you finished the setting, please click the Submit button.
  • Page 41 ATA-171/172/171P/171M (ATA-S1/S2/P/M) User’s Guide ICMP Not Echo Default setting is No (do not activate). Once activated all ping messages will not be responded. Send Anonymous Default setting is No (do not activate). Once activated the device will not send its own number. Management from Default setting is Yes (do not activate).
  • Page 42 ATA-171/172/171P/171M (ATA-S1/S2/P/M) User’s Guide 3.13.8 FXS and FXO impedence Setting: you can setup the FXS and FXO in this page. When you are using different country’s PSTN Phone, you have to set the country’s setting to meet the requirement. When you finished the setting, please click the Submit button. (Note: Configuration for FXO is only supported in ATA171M).
  • Page 43 ATA-171/172/171P/171M (ATA-S1/S2/P/M) User’s Guide 3.13.9 (Call Transfer Operation) Blind Transfer (Unconditional Transfer) B calls A, A and B establishes a connection and during the conversation, A performs a call transfer to a third party. Firstly, A holds B’s conversation channel, presses #510# then keys in the number of the third party.

  • Page 44: Mac Clone Setting

    ATA-171/172/171P/171M (ATA-S1/S2/P/M) User’s Guide 3.14 MAC Clone setting MAC Clone setting: This function changes the MAC Addresses of workstations in a LAN to which that are identical to the WAN port; this is done due to the fact that some ISP companies restrict the use of multiple MAC Addresses through PPPoE.

  • Page 45: Save Change

    ATA-171/172/171P/171M (ATA-S1/S2/P/M) User’s Guide 3.16 Save Change 3.16.1 In Save Change you can save the changes you have done. If you want to use new setting in the ATA, You have to click the Save button. After you click the Save button, the ATA will automatically restart and the new setting will effect.

  • Page 46: Update Rom Firmware

    ATA-171/172/171P/171M (ATA-S1/S2/P/M) User’s Guide 3.17 Update Rom firmware: 3.17.1 In Update you can update the ATA’s firmware to the new one or do the factory reset to let the ATA back to default setting. 3.17.2 In New Firmware function you can update new firmware via HTTP in this page. You can ugrade the firmware by the following steps: Select the firmware code type, ROM code.
  • Page 47 ATA-171/172/171P/171M (ATA-S1/S2/P/M) User’s Guide 3.17.3 In Default Setting you can restore the TA to factory default in this page. You can just click the Restore button, then the TA will restore to default and automatically restart again. The Default Setting will be NAT Mode, WAN port is DHCP Client Mode, LAN port is Fixed IP Mode and the IP Address is 192.168.123.1.

  • Page 48: Reboot

    ATA-171/172/171P/171M (ATA-S1/S2/P/M) User’s Guide 3.18 Reboot 3.18.1 Reboot function you can restart the ATA. If you want to restart the ATA, you can just click the Reboot button, then the ATA will automatically. Figure 34. Reboot System...

  • Page 49: Setup The Ata By Using Console (Hyper Terminal)

    ATA-171/172/171P/171M (ATA-S1/S2/P/M) User’s Guide Setup the ATA by using Console (Hyper Terminal) Configure the COM port First Open the hyper terminal window, select the connection by the COM port, and then click the “Setting” button. Figure 23. Console Setting-1 Set the COM port’s setting as following setting. Then click OK. Figure 24.

  • Page 50: Login Into The Ata

    ATA-171/172/171P/171M (ATA-S1/S2/P/M) User’s Guide Login into the ATA After finished the setting, click the “Connect” button (looks like a telephone icon). Then the hyper terminal is ready to connect to the ATA. Press “Enter” and the hyper terminal will show the “Login: “. Input “root” and press the “Enter”...

  • Page 51: Using Cli Command To Configure The Ata

    ATA-171/172/171P/171M (ATA-S1/S2/P/M) User’s Guide Using CLI command to configure the ATA 4.3.1 CLI command list as below: Index Command Description Show CLI Command ARP Configuration ipconfig Interface Configuration save Save to flash reboot Reboot exit Exit debugmode Enter Debug Mode update Update Flash Code/RAM auth...
  • Page 52 ATA-171/172/171P/171M (ATA-S1/S2/P/M) User’s Guide (3-1) ipconfig –ifN function N is 0, 1, 2 Index Command Description Show 'ipconfig -ifN' Option Set Host Type Set MAC Address Set IP Address Set Net Mask Set Gateway -dns0 Set Primary DNS server -dns1 Set Secondary DNS server Set Default Route -nat...
  • Page 53 ATA-171/172/171P/171M (ATA-S1/S2/P/M) User’s Guide auth function Index Command Description Show 'auth' Option -admin Change Administrator user name/password -sys0 Change System user0 user name/password -sys1 Change System user1 user name/password -sys2 Change System user2 user name/password -sys3 Change System user3 user name/password -sys4 Change System user4 user name/password -norm0...
  • Page 54 ATA-171/172/171P/171M (ATA-S1/S2/P/M) User’s Guide -13- sip function Index Command Description Show 'sip' Option -proxy0 sip -proxy0 -proxy1 sip -proxy1 -proxy2 sip -proxy2 -upnp sip -upnp on/off/show -exts sip -exts sip upnp external-port -extr sip -extr rtp upnp external-port -sipp sip udp port -rtpp sip rtp port -stun...
  • Page 55 ATA-171/172/171P/171M (ATA-S1/S2/P/M) User’s Guide -16- vlan function Index Command Description Show 'vlan' Option Tx Vlan setting Rx Vlan setting (null) Show Vlan Setting -17- time function Index Command Description Show 'Time' Option Modify Time: hour:min:sec Modify date: year:mon:date (null) Show Data & Time -18- mactab function is to show MAC learning table.
  • Page 56 ATA-171/172/171P/171M (ATA-S1/S2/P/M) User’s Guide -24- weblogo function Index Command Description Show 'weblogo' Option Vender Logo -off Default Logo (null) Show weblogo Setting -25- dsp function is to show dsp code type. -26- addport function is to add Nat Port Mapping -27- cid function Index...

  • Page 57: How To Make A Phone Call

    ATA-171/172/171P/171M (ATA-S1/S2/P/M) User’s Guide How to make a phone call When your ATA is configured properly, you can make a phone call to your friend in the same Service provider. If you want to make a phone call, you can dial the phone number and press “#” button to start to dial the phone number.
