WELLTECH ATA-171 - V1.6 User Manual

V1.6 1-port fxs voip terminal adapter
Hide thumbs
Table of Contents

Advertisement

Quick Links

ATA-171/172/171P (ATA-S1/S2/P)
User's Guide
ATA-171/172/17
1P
(ATA-S1/S2/P)
User's Guide
V.1.6
2006/10/27
0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ATA-171 - V1.6 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for WELLTECH ATA-171 - V1.6

Summary of Contents for WELLTECH ATA-171 - V1.6

  • Page 1 ATA-171/172/171P (ATA-S1/S2/P) User’s Guide ATA-171/172/17 (ATA-S1/S2/P) User’s Guide V.1.6 2006/10/27...

  • Page 2: Table Of Contents

    ATA-171/172/171P (ATA-S1/S2/P) User’s Guide Introduction............................2 Hardware Overview....................... 2 Software Overview ........................ 2 Keypad Interface for The ATA......................3 Setup the ATA by Web Browser......................4 Login............................4 System Information for the ATA..................... 5 Phone Book........................... 5 Phone Setting........................6 Network ..........................

  • Page 3: Hardware Overview

    ATA-171/172/171P (ATA-S1/S2/P) User’s Guide Introduction This user’s manual is for 1-port FXS VoIP terminal adapter (ATA). This user’s manual will explain the IVR instruction, web configuration, and command line configuration for the ATA. Before using the ATA, some setup processes are required to make the ATA work properly. Please refer to the Setup Menu for further information.

  • Page 4: Keypad Interface For The Ata

    ATA-171/172/171P (ATA-S1/S2/P) User’s Guide Keypad Interface for The ATA You can use the PSTN phone keypad to operate the ATA. Please follow the instruction to configure your terminal adapter. Group IVR Action IVR Menu Choice Parameter(s) Notes: Press O# can pass relay to PSTN Dial out from 0＊...

  • Page 5: Setup The Ata By Web Browser

    ATA-171/172/171P (ATA-S1/S2/P) User’s Guide Setup the ATA by Web Browser The ATA provides a built-in web server. You can use Web browser to configure the ATA. First please input the IP address in the Web page. In the end of IP address, please add the port number “:9999”. Ex: http://192.168.1.100:9999 Login.

  • Page 6: System Information For The Ata

    ATA-171/172/171P (ATA-S1/S2/P) User’s Guide System Information for the ATA. 3.2.1 When you login the web page, you can see the ATA current system information like firmware version, company… etc in this page. 3.2.2 Also you can see the function lists in the left side. You can use mouse to click the function you want to set up.

  • Page 7: Phone Setting

    ATA-171/172/171P (ATA-S1/S2/P) User’s Guide Figure 3. Speed Dial Phone Setting 3.4.1 In Phone Setting contains Call Forward, SNTP Settings, Volume Settings, Block Setting, Caller ID, Auto Dial Setting, Flash Time Setting, Call Waiting, and T.38(FAX) Setting functions. 3.4.2 Call Forward function: you can setup the phone number you want to forward in this page. There are three type of Forward mode.
  • Page 8 ATA-171/172/171P (ATA-S1/S2/P) User’s Guide Figure 4. Forward Setting 3.4.3 SNTP Setting function: you can setup the primary and second SNTP Server IP Address, to get the date/time information. Also you can base on your location to set the Time Zone, and how long need to synchronize again.
  • Page 9 ATA-171/172/171P (ATA-S1/S2/P) User’s Guide 3.4.4 Volume Setting function: you can setup the Handset Volume, Ringer Volume, and the Handset Gain. When you finished the setting, please click the Submit button. Handset Volume is to set the volume for you can hear from the handset. Ringer Volume is to set the ringer volume for you can hear.
  • Page 10 ATA-171/172/171P (ATA-S1/S2/P) User’s Guide Figure 7. DND Setting 3.4.6 Caller ID function: you can set the device to show Caller ID in your PSTN Phone or IP Phone. There are four selection of Caller ID. You need to base on your environment to set the Caller ID function for FSK or DTMF.
  • Page 11 ATA-171/172/171P (ATA-S1/S2/P) User’s Guide 3.4.7 Auto Dial Setting function: This function is when you input the phone number by the keypad but you don’t need to press “#”. After time out the system will dial directly. When you finished the setting, please click the Submit button. If there is nothing need to change, please click the Save Change Item in the left side, then click the Save button.
  • Page 12 ATA-171/172/171P (ATA-S1/S2/P) User’s Guide 。 ： ， ； 。 ： ， ； 。 ： ； ： ， ， ； 。 ： ， ， ； 。 。 ： ， ； 。 。 ： ， ； 。 ： ， ； 。 ： ，...
  • Page 13 ATA-171/172/171P (ATA-S1/S2/P) User’s Guide Figure 10. Flash Time Setting 3.4.9 Call Waiting Setting function: You can Enable/Disable the Call Waiting function, When you are talking with someone, there is a new incoming call, you will hear the call waiting tone. When you finished the setting, please click the Submit button.
  • Page 14 ATA-171/172/171P (ATA-S1/S2/P) User’s Guide Save Change Item in the left side, then click the Save button. The change you made will save into the system and the system will Reboot automatically. Figure 12. T.38 (FAX) Setting Hot line This function is support auto dial to you setting hot line number, when you setting this function device should can not dial any number.

  • Page 15: Network

    ATA-171/172/171P (ATA-S1/S2/P) User’s Guide Alarm time: setting telephone ring time,when you setting time with current time are match device should produce a ring ,this time format is 24 hours. Network 3.7.1 In Network you can check the Network status, WAN setting,LAN setting,DDNS settings and VLAN Settings.
  • Page 16 ATA-171/172/171P (ATA-S1/S2/P) User’s Guide Figure 14. Network Settings Bridge Setting: If you don’t want to use the NAT Mode, then you can set the network setting in this page. The TCP/IP Configuration item is to setup the LAN port’s network environment. You may refer to your current network environment to configure the VoIP Phone properly.
  • Page 17 ATA-171/172/171P (ATA-S1/S2/P) User’s Guide Figure 155. WAN Settings...
  • Page 18 ATA-171/172/171P (ATA-S1/S2/P) User’s Guide 3.7.4 DDNS Setting: You can configure the DDNS setting in this page. You need to have the DDNS account and input the informations properly. You can have a DDNS account with a public IP address then others can call you via the DDNS account. But now most of the VoIP applications are work with a SIP Proxy Server.
  • Page 19 ATA-171/172/171P (ATA-S1/S2/P) User’s Guide 3.7.5 VLAN Setting: You can set the VLAN setting in this page. There are two parts in this page. First one is to set the packets related to the TA, and the second parts is if you use the VLAN setting in the NAT Mode.
  • Page 20 ATA-171/172/171P (ATA-S1/S2/P) User’s Guide 。 。...

  • Page 21: Ip Settings

    ATA-171/172/171P (ATA-S1/S2/P) User’s Guide PPTP setting PPTP Server : the server address provided by your ISP. PPTP Username : the username is provided by your ISP. PPTP Password : the password is provided by your ISP. 3.10 SIP Settings 3.10.1 In SIP Settings you can setup the Service Domain, Port Settngs, Codec Settings, RTP Setting, RPort Setting and Other Settings.
  • Page 22 ATA-171/172/171P (ATA-S1/S2/P) User’s Guide Figure 18. Service Domain Setting 3.10.4 Port Settings: you can setup the SIP and RTP port number in this page. Each ISP provider will have different SIP/RTPport setting, please refer to the ISP to setup the port number correctly.
  • Page 23 ATA-171/172/171P (ATA-S1/S2/P) User’s Guide Figure 19. Port Setting 3.10.5 Codec Settings: you can setup the Codec priority, RTP packet length, and VAD function in this page. You need to follow the ISP suggestion to setup these items. When you finished the setting, please click the Submit button.
  • Page 24 ATA-171/172/171P (ATA-S1/S2/P) User’s Guide 3.10.6 Codec ID Setting: Sometimes 2 VoIP device with different Codec ID will cause the interopability issue. If you are talking with others got some problems, you may ask the other one what kind of Codec ID he use, then you can change your Codec ID. When you finished the setting, please click the Submit button.
  • Page 25 ATA-171/172/171P (ATA-S1/S2/P) User’s Guide Figure 22. DTMF Setting 3.10.8 RPort Function: you can setup the RPort Enable/Disable in this page. To change this setting, please following your ISP information. When you finished the setting, please click the Submit button. If there is nothing need to change, please click the Save Change Item in the left side, then click the Save button.

  • Page 26: Nat Trans

    ATA-171/172/171P (ATA-S1/S2/P) User’s Guide 3.10.9 Other Settings: you can setup the Hold by RFC, Voice/SIP QoS and SIP expire time in this page. To change these settings please following your ISP information. When you finished the setting, please click the Submit button. The QoS setting is to set the voice packets’ priority. If you set the value higher than 0, then the voice packets will get the higher priority to the Internet.

  • Page 27: Others

    ATA-171/172/171P (ATA-S1/S2/P) User’s Guide Figure 205. STUN Setting 3.12 Others 3.12.1 In Others you can setup Auto Config, FXS Port Setting and MAC clone Setting function. The function can configure your VoIP Phone automatically. 3.12.2 Auto Config: you can setup the Auto Configuration Enable/Disable and auto configuration by FTP or TFTP.
  • Page 28 ATA-171/172/171P (ATA-S1/S2/P) User’s Guide Figure 216. Auto Configuration Setting 。...
  • Page 29 ATA-171/172/171P (ATA-S1/S2/P) User’s Guide ， ， 。 ： 。 ： ， ， ， ， 。 ： 。...
  • Page 30 ATA-171/172/171P (ATA-S1/S2/P) User’s Guide ： ， 00059e812118。 ： ：00059e812118, UN_DO, 105, 105, 105)， ： ， 。 ： MakeMACF.exe ， ， ， 。 ： 。 00059e812118.dat ： 00059e812118.dat [HTTP or FTP or TFTP Server] file path。 3.12.7 Advanced Setting 1. ICMP Setting: you can setup the ICMP echo Enable/Disable in this page. This function can disable echo when someone ping this device, it can avoid haker try to attack the device.
  • Page 31 ATA-171/172/171P (ATA-S1/S2/P) User’s Guide Figure 228. Advanced Setting 3.12.8 FXS impedence Setting: you can setup the FXS in this page. When you are using different country’s PSTN Phone, you have to set the country’s setting to meet the requirement. When you finished the setting, please click the Submit button.
  • Page 32 ATA-171/172/171P (ATA-S1/S2/P) User’s Guide 3.13 MAC Clone setting 3.14 Auto update...
  • Page 33 ATA-171/172/171P (ATA-S1/S2/P) User’s Guide ： ， ， ， ， ； 。 ： ： ： ， ， ， ， ； 。 ：...
  • Page 34 ATA-171/172/171P (ATA-S1/S2/P) User’s Guide ： ： ， Blind Transfer (Unconditional Transfer) Attendant Transfer...

  • Page 35: System Auth

    ATA-171/172/171P (ATA-S1/S2/P) User’s Guide 3.15 System Auth. 3.15.1 In System Authority you can change your login name and password. When you finished the setting, please click the Submit button. If there is nothing need to change, please click the Save Change Item in the left side, then click the Save button. The change you made will save into the system and the system will Reboot automatically.

  • Page 36: Update

    ATA-171/172/171P (ATA-S1/S2/P) User’s Guide Figure 31. Save Change 3.17 Update Rom firmware: 3.17.1 In Update you can update the ATA’s firmware to the new one or do the factory reset to let the ATA back to default setting. 3.17.2 In New Firmware function you can update new firmware via HTTP in this page. You can ugrade the firmware by the following steps: Select the firmware code type, ROM code.
  • Page 37 ATA-171/172/171P (ATA-S1/S2/P) User’s Guide Figure 32. Update Firmware 3.17.3 In Default Setting you can restore the TA to factory default in this page. You can just click the Restore button, then the TA will restore to default and automatically restart again. The Default Setting will be NAT Mode, WAN port is DHCP Client Mode, LAN port is Fixed IP Mode and the IP Address is 192.168.123.1.

  • Page 38: Reboot

    ATA-171/172/171P (ATA-S1/S2/P) User’s Guide Figure 33. Restore Default Setting 3.18 Reboot 3.18.1 Reboot function you can restart the ATA. If you want to restart the ATA, you can just click the Reboot button, then the ATA will automatically. Figure 34. Reboot System...

  • Page 39: Setup The Ata By Using Console (Hyper Terminal)

    ATA-171/172/171P (ATA-S1/S2/P) User’s Guide Setup the ATA by using Console (Hyper Terminal) Configure the COM port First Open the hyper terminal window, select the connection by the COM port, and then click the “Setting” button. Figure 24. Console Setting-1 Set the COM port’s setting as following setting. Then click OK. Figure 25.

  • Page 40: Login Into The Ata

    ATA-171/172/171P (ATA-S1/S2/P) User’s Guide Login into the ATA After finished the setting, click the “Connect” button (looks like a telephone icon). Then the hyper terminal is ready to connect to the ATA. Press “Enter” and the hyper terminal will show the “Login: “. Input “root” and press the “Enter”...

  • Page 41: Using Cli Command To Configure The Ata

    ATA-171/172/171P (ATA-S1/S2/P) User’s Guide Using CLI command to configure the ATA 4.3.1 CLI command list as below: Index Command Description Show CLI Command ARP Configuration ipconfig Interface Configuration save Save to flash reboot Reboot exit Exit debugmode Enter Debug Mode update Update Flash Code/RAM auth...
  • Page 42 ATA-171/172/171P (ATA-S1/S2/P) User’s Guide Show 'ipconfig -ifN' Option Set Host Type Set MAC Address Set IP Address Set Net Mask Set Gateway -dns0 Set Primary DNS server -dns1 Set Secondary DNS server Set Default Route -nat Set NAT Enable Interface Disable Interface -dhcps DHCP Server Setting...
  • Page 43 ATA-171/172/171P (ATA-S1/S2/P) User’s Guide -sys1 Change System user1 user name/password -sys2 Change System user2 user name/password -sys3 Change System user3 user name/password -sys4 Change System user4 user name/password -norm0 Change Normal user0 user name/password -norm1 Change Normal user1 user name/password -norm2 Change Normal user2 user name/password -norm3...
  • Page 44 ATA-171/172/171P (ATA-S1/S2/P) User’s Guide -13- sip function Index Command Description Show 'sip' Option -proxy0 sip -proxy0 -proxy1 sip -proxy1 -proxy2 sip -proxy2 -upnp sip -upnp on/off/show -exts sip -exts sip upnp external-port -extr sip -extr rtp upnp external-port -sipp sip udp port -rtpp sip rtp port -stun...
  • Page 45 ATA-171/172/171P (ATA-S1/S2/P) User’s Guide -16- vlan function Index Command Description Show 'vlan' Option Tx Vlan setting Rx Vlan setting (null) Show Vlan Setting -17- time function Index Command Description Show 'Time' Option Modify Time: hour:min:sec Modify date: year:mon:date (null) Show Data & Time -18- mactab function is to show MAC learning table.
  • Page 46 ATA-171/172/171P (ATA-S1/S2/P) User’s Guide -24- weblogo function Index Command Description Show 'weblogo' Option Vender Logo -off Default Logo (null) Show weblogo Setting -25- dsp function is to show dsp code type. -26- addport function is to add Nat Port Mapping -27- cid function Index...

  • Page 47: How To Make A Phone Call

    ATA-171/172/171P (ATA-S1/S2/P) User’s Guide How to make a phone call When your ATA is configured properly, you can make a phone call to your friend in the same Service provider. If you want to make a phone call, you can dial the phone number and press “#” button to start to dial the phone number.
