- Page 2 H872 PART LIST Item name Specifications Handlebar kit Computer cover Grey Handlebar Cone cross tapping screw M4x12L Cone hex. Screw M8xP1.25x20L Spring washer φ8 Flat washer φ8xφ16x2t Computer cover(back) 432C grey Round head cross tapping screw M3x12L End cap φ1"(STR) Handlebar post 50x100x1.5x650L Cone hex.
- Page 3 Cone cross screw M5x14L Load resistance φ28*248L (225W 20Ω) Hex. Screw M6xP1.0x20L C ring φ17 65Mn Flat washer φ17.5xφ25x0.3t Wave washer φ17.5xφ25x0.3t Bearing 6203 (RS) Pulley φ289*6J(φ20) Axle φ17 Hex. Screw M8xP1.25x12Lx3t Belt J6 1126m/m Hex. Screw M5xP0.8x20L Cone cross screw φ5x1.5t 65Mn φ102xφ35x38W Flywheel holder...
