VMware vCenter AppSpeed User's Guide
6 (Optional) Click Save to save your changes.
When you click Save, you have the following options:
You can overwrite the existing layout with your customized layout by selecting Update the current
n
layout.
You can select Create a new layout to save your customized layout with a new name. If you do not
n
enter a name, the layout name is saved as
7 Click Apply to apply your customized layout, without saving.
The layout is visible only to you, and remains in effect until you close your AppSpeed session.
The table appears, showing the columns that you defined.

Performance Charts and Graphs

The graphs and charts displayed depend on the selected view and object type. Charts or graphs are available
in the Analysis view for services and servers, and the Thresholds view for services.
You can perform actions from the graphic display pane.
Show or hide latency standard deviation indicators on the graph.
n
Export the graph or the graph data.
n
Chart and Graph Types
Charts and graphs are provided to display information about different performance indicators.
Table 2-2 describes the graphs and charts that are available.
Table 2-2. Chart and Graph Types
Chart/Graph Type
Usage vs. Latency
Latency
Usage
Latency Breakdown
Latency vs. Baseline
Throughput Breakdown
of Servers
Availability
For details on the performance indicators shown in each of the charts and graphs, see
Indicators," on page 19.
Filter the Graphic Display
You can view data for specific objects in the chart or graph.
N You cannot filter the Latency Breakdown and Throughput Breakdown graphs.
OTE
Procedure
Select or deselect the check boxes in the table in the lower portion of the data display pane.
u
The data in the graphic display changes according to the filter you apply.
18
Copy of <name of current layout>
Description
Compares the latency and usage behaviors for the selected object type.
Displays the latency behavior during a selected period of time.
Reports the use during the selected time frame for the objects selected in the display area.
Displays a chart that reports the end-to-end latency analysis for the selected service or
transaction. The content of this chart is not linked to your selections in the tabular display area.
Shows the average usage and latency for either services or servers, with the corresponding
baseline.
Reports the analysis of throughput for servers for the selected service.
Reports trends in error behavior for the selected time frame and selected object type.
.
"Performance
