QUAD CONCOURSE R8 Datasheet

Concourse R8 version3 19/3/04
CONCOURSE R8
ARCHITECTURAL SERIES
RECTANGULAR TWO WAY
WALL/CEILING SPEAKER
KEY FEATURES:
✓
Two way ported rectanuglar wall/ ceiling loudspeaker with 8" bass driver,
2" soft dome tweeter, 1" soft dome tweeter and passive crossover
✓
200watts program, 400watts peak
✓
Optional 4ohm or 16ohm low impedance models
✓
Integral mounts s to allow
simple installation from below the ceiling.
APPLICATIONS:
✓
Corporate Meeting Rooms
✓
Classrooms
✓
Training Rooms
✓
Restaurants
✓
Retail Outlets
✓
Hotels
✓
Health Clubs
DESCRIPTION:
The QUAD Industrial CONCOURSE R8 is a two way rectangular wall/ ceiling
speaker with a 8" LF, 2" soft dome tweeter, 1" soft dome tweeter and passive
crossover. The Concourse R8 is intended for small to medium room applications
requiring high quality speech reinforcement and/or background music.
The CONCOURSE R8 can be ordered as either 4 or 16 ohm low impedance,
allowing efficient use of amplifier power and parallel looping connections with no
transformer losses or signal degradation.
The CONCOURSE R8 includes a pair of clamp mountings for weight distribution
on ceiling finishes.
10:49 am Page 1
SPECIFICATIONS:
SYSTEM:
POWER HANDLING: 100watts continuous, 200watts program,
400watts peak
Recommended amplifier: 10-100 watts
Impedance: Selectable 4 or 16 ohms nominal
Frequency response (-10dB): 35Hz-20kHz
Frequency response (+/-3dB): 45Hz-20kHz
Sensitivity: 90dB/1watt/1meter
Max SPL: 115dB
Coverage: 130*100
Directivity (Q): 6.82
TRANSDUCERS:
LF Driver: 8" Cone
HF Driver: 1" Dome tweeter
Crossover Frequency:1.2kHz & 5.2kHz
PHYSICAL:
Type: Two way passive ported design
Material: Plastic ABS
Connector: Terminal strip
Dimensions (HxWxD): 444mm x 284mm x110mm
Nett Weight: 4.8kg
