- Page 1 Series Loudspeakers the closest approach to the original sound.
- Page 3 The Quad Philosophy Quad has, since the 1950s, led the field in loudspeaker development. The famous Quad electrostatics are now, quite rightly, regarded amongst the very finest loudspeakers money can buy. With a fifty-strong R&D team, our research into acoustics and reproduction leads the field in development of quality hi-fi equipment.
- Page 4 Quad’s commitment to quality and performance. Voiced for a clean, natural mid-range performance with crisp, clean detail and a taut, punchy bass performance, series loudspeakers excel with well- recorded, complex music scores.
- Page 5 The original L-series entered hi-fi’s hall of fame in 2002, with the 11L winning What Hi-Fi? magazine’s prestigious ‘Product of the Year’ Award – an accolade that was repeated the following year, and again in 2004, winning best in class. Around the world the pattern was repeated with major awards from leading magazines on every continent.
-
Page 7: Technical Improvements
‘ghosting’ of a television signal. At Quad, we are fortunate as we have the capability of designing and manufacturing any chassis structure. With our own tool shop, die-casting... -
Page 8: Good Design
The art of a good crossover is simplicity, but for other manufacturers the crossover needs to compensate for slight miss-matches between bought in components – Quad doesn’t buy in components, we make them all in-house, so our loudspeakers are designed in perfect synergy. Our... - Page 10 – it’s as if the cone were itself just floating in free space. The new L2 series tweeter is the first of it’s kind to use an aluminium voice coil. This provides much wider bandwidth, and hence resolution.
- Page 11 Dual Catenary tweeter dispersion plate – cast from Aluminium, the new tweeter plate enhances the dispersion characteristic, to prevent ‘beaming’ and to widen the listening ‘sweet spot’. Polar response is exceptional with the frequency range, even 45 degrees off-axis, being flat and extended. This results in a consistently high standard of performance, regardless of where the listener is sat in the room and reduces the effect that room furnishings have on the in-room response.
- Page 13 -Subwoofer A revolutionary drive unit material is only the start of the technological innovations that make this new Quad subwoofer a fine addition to any surround or stereo system. The ‘tri-lam’ cone is a composite construction comprising hydraulically moulded and thermoset lamination of three materials.
-
Page 14: Specifications
Specifications Model Transducer Complement 2 Way Bass Driver 4” / 100mm Mid Driver Soft Dome Tweeter 1” / 25mm Nominal Impedance 6 Ohms Freq Response +/- 6dB 50Hz-28kHz Upper Freq Limit -10dB 32kHz SPL 1W @ 1m 85dB Power Handling Continuous Programme 75 Watts Recommended Amp... - Page 15 Electronics • 99 CDP-2 • 99 CD-S • 99 Pre • 99 Stereo • 99 Tuner • 909 Stereo • 909 Mono ESL - 2805 99 - Pre Amp 99 - Power Amp Quad ll-Forty Power Amp QC24 Pre Amp...
- Page 16 IAG House, Sovereign Court, Ermine Business Park, Huntingdon, Cambs, PE29 6XU Tel :- 01480 447700, Fax :- 01480 431767 www.quad-hifi.co.uk The information in this brochure is subject to change without notice.All rights reserved © 2006 Quad Quad is a member of the International Audio Group Qu.L2.11.2006...
