- Page 1 INSTRUCTION BOOKLET MODELS R6 & R8 F O R T H E C L O S E S T A P P R O A C H T O T H E O R I G I N A L S O U N D...
-
Page 2: Table Of Contents
SAFETY REGULATIONS MUST BE FOLLOWED. IF YOU ARE NOT Specifications ................ 0 8 PROPERLY QUALIFIED OR DO NOT KNOW OF PERTINENT Contact Information: REGULATIONS, CONSULT QUALIFIED PERSONNEL FOR ADVICE QUAD Industrial Contact Information ......BACK COVER AND ASSISTANCE. Limited Liability QUAD Industrial assumes no liability whatsoever for any damage or loss, either direct or consequential arising from the installation and use of these products. Liability is limited to replacement of product or refund, at the QUAD Industrial’s discretion. Your rights to compensation may vary by ter-... -
Page 3: Product Descriptions
The Concourse R6 and R8 are two-way high performance in-wall mounted speaker systems designed for distributed music, paging and speech applications. The R6 and R8 are packaged in pairs and combine premium drive units with a discrete ABS front baffle and attractive metal grille. -
Page 4: Product Features
PR O DUC T FE AT UR E S I N S TAL LATI ON The Concourse R6 and R8 are designed to be installed in a wall NOTE: Installations in existing buildings require that you first cavity and are supplied with a unique latching bar for wall mount- ensure that the location is suitable and that there are no obstacles ing. -
Page 5: Installation Instructions
Step Install the latching bars to the rear of the speaker assembly by inserting only the top two screws on each bar. Do not tighten the screws yet, leaving enough slack to permit installation into the wall cavity. Step Pull the speaker wire from inside wall cavity and terminate to speaker. -
Page 6: Wiring & Connections
Black (-) Red (+) Black (-) CO M PL IA NCE This product is in compliance with CE directives and bears the CE mark. For detailed information on specific directives please contact your local QUAD Industrial sales office or distributor. -
Page 7: Specifications
SP E C IF ICATI O NS Power Handling: Continuous 100W Program 100W 200W Peak 200W 400W 40Hz−20kHz 35Hz−20kHz Frequency Response: (-10dB) 70Hz−16kHz 45Hz−20kHz Frequency Response: (+/-3dB) Sensitivity (@2.83V): 89dB 90dB 112dB 115dB Max SPL: 140˚ x 110˚ 130˚ x 100˚ Coverage (H x V): 6.14 6.82... - Page 8 F O R T H E C L O S E S T A P P R O A C H T O T H E O R I G I N A L S O U N D © 2006 QUAD Industrial. QUAD Industrial is a member of the International Audio Group. IAG America Inc. 8440 154th Avenue NE · Redmond, WA 98052...
