Summary of Contents for Dodge 2009 KA Nitro

Page 1 2009 OWNER’S MANUAL...
Page 2: Vehicles Sold In Canada
VEHICLES SOLD IN CANADA With respect to any Vehicles Sold in Canada, the name Chrysler LLC shall be deemed to be deleted and the name Chrysler Canada Inc. used in substitution there- fore. DRIVING AND ALCOHOL Drunken driving is one of the most frequent causes of accidents.
Page 3: Introduction
TABLE OF CONTENTS SECTION ............. 3 INTRODUCTION THINGS TO KNOW BEFORE STARTING YOUR VEHICLE UNDERSTANDING THE FEATURES OF YOUR VEHICLE...
Page 5: Table Of Contents
CONTENTS Introduction ......4 Rollover Warning ......4 How To Use This Manual .
Page 6: Introduction
4 INTRODUCTION INTRODUCTION This Owner’s Manual has been prepared with the assis- tance of service and engineering specialists to acquaint you with the operation and maintenance of your vehicle. It is supplemented by a Warranty Information Booklet and various customer-oriented documents. You are urged to read these publications carefully.
Page 7: How To Use This Manual
Rollover Warning Label Failure to use driver and passenger seat belts provided is a major cause of severe or fatal injury. In fact, the U.S. government notes that the universal use of existing seat belts could cut the highway death toll by 10,000 or more each year and could reduce disabling injuries by two million annually.
Page 8 6 INTRODUCTION...
Page 9: Warnings And Cautions
The Vehicle Identification Number (VIN) is found on the left front corner of the instrument panel. The VIN is visible from outside of the vehicle through the wind- shield. This number also appears on the Automobile Vehicle Identification Number Information Disclosure Label affixed to a window on NOTE: It is illegal to remove the VIN.
Page 10: Vehicle Modifications/Alterations
8 INTRODUCTION VEHICLE MODIFICATIONS/ALTERATIONS WARNING! Any modifications or alterations to this vehicle could seriously affect its roadworthiness and safety and may lead to an accident resulting in serious injury or death.
Page 11 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE CONTENTS A Word About Your Keys ....12 Ignition Key Removal ....12 Key-In-Ignition Reminder .
Page 12 10 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Battery Replacement ....23 General Information ....24 Remote Starting System —...
Page 13 Engine Break-In Recommendations ..75 Safety Tips ......76 Exhaust Gas .
Page 14: Things To Know Before Starting Your Vehicle 9
12 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE A WORD ABOUT YOUR KEYS The keys for your vehicle are double-sided. You can insert the keys into the locks with either side up. Vehicle Key The keys for your new vehicle are enclosed in a plastic bag with the key code number on it.
Page 15: Key-In-Ignition Reminder
Ignition Switch Positions 1 — Lock 3 — On 2 — Acc 4 — Start THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 13 WARNING! Never leave children alone in a vehicle. Leaving unattended children in a vehicle is dangerous for a number of reasons.
Page 16: Sentry Key
14 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: The Key-In-Ignition reminder only sounds when the ignition key is placed in the LOCK or ACC position. SENTRY KEY The Sentry Key Immobilizer System prevents unautho- rized vehicle operation by disabling the engine. The system does not need to be armed or activated.
Page 17: Replacement Keys
NOTE: The Sentry Key Immobilizer System is not compat- ible with some aftermarket remote starting systems. Use of these systems may result in vehicle starting problems and loss of security protection. Exxon/Mobil Speedpass™, additional Sentry Keys , or any other transponder-equipped components on the same key chain will not cause a key-related (transponder) fault unless the additional part is physi- cally held against the ignition key being used when...
Page 18: Customer Key Programming
16 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE procedure. This procedure consists of programming a blank key to the vehicle electronics. A blank key is one that has never been programmed. NOTE: When having the Sentry Key System serviced, bring all vehicle keys with you to an authorized dealer.
Page 19: General Information
Repeat this procedure to program up to eight keys. If you do not have a programmed Sentry Key , contact your authorized dealer for details. NOTE: If a programmed key is lost, see your authorized dealer to have all remaining keys erased from the sys- tem’s memory.
Page 20: To Arm The System
18 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To Arm the System: Remove the keys from the ignition switch and exit the vehicle. Lock the doors and liftgate by pressing the power door LOCK switch or the LOCK button on the Remote Keyless Entry (RKE) transmitter.
Page 21: Illuminated Entry
ILLUMINATED ENTRY The interior lights come on when you open any door. They will remain on for about 30 seconds after all doors are closed then fade to off. The lights also will fade to off if you turn on the ignition after you close all the doors.
Page 22: To Unlock The Doors And Liftgate
20 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To Unlock the Doors and Liftgate Press and release the UNLOCK button on the RKE transmitter once to unlock the driver’s door, or twice to unlock all doors and the liftgate. The parking lights will flash to acknowledge the unlock signal.
Page 23: To Lock The Doors And Liftgate
To Lock the Doors and Liftgate Press and release the LOCK button on the RKE transmit- ter to lock all doors and the liftgate. If the ignition is OFF when the doors are locked, the parking lights will flash once and the horn will sound a single chirp. Sound Horn with Lock This feature will cause the horn to chirp when the doors are locked with the RKE transmitter.
Page 24: Express Down Window Feature - If Equipped
22 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Flash Lights with Lock The feature will cause the parking lights to flash when the doors are locked or unlocked with the RKE transmit- ter. This feature can be turned on or off. To change the current setting, proceed as follows: On Electronic Vehicle Information Center (EVIC) equipped vehicles, refer to “Flash Lights with Lock,”...
Page 25: Using The Panic Alarm
Using the Panic Alarm NOTE: The PANIC and SECURITY alarms are quite different. Please take a moment to activate the PANIC and SECURITY modes to hear the differences in the horn. If one should sound in the future, you will need to know which mode has been activated in order to deactivate it.
Page 26: General Information
24 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 2. With the RKE transmitter buttons facing down, use a flat blade to pry the two halves of the RKE transmitter case apart. Make sure not to damage the seal during removal. Separating Case Halves 3.
Page 27: Remote Starting System - If Equipped
NOTE: Changes or modifications not expressly ap- proved by the party responsible for compliance could void the user’s authority to operate the equipment. If your RKE transmitter fails to operate from a normal distance, check for these two conditions: 1. Weak batteries in RKE transmitter. The expected life of the batteries is from one to two years.
Page 28: Door Locks
26 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Once the engine starts it will run for 15 minutes. To cancel remote start, press and release the REMOTE START button once. To enter the vehicle while the engine is running during a remote start, you must first unlock the vehicle using the UNLOCK button on the RKE transmitter.
Page 29: Manual Door Locks
If any other active warnings including “GATE” or “GAS- CAP” are present, they will be shown in the VF display and will also continue to cycle. If the vehicle is moving, three single chimes will occur (one chime for each complete display cycle, three cycles total).
Page 30: Power Door Locks
28 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! (Continued) When leaving the vehicle, always remove the key from the ignition lock, and lock your vehicle. Do not leave unattended children in the vehicle, or with access to an unlocked vehicle. Unsupervised use of vehicle equipment may cause severe per- sonal injuries and death.
Page 31: Automatic Door Locks
Automatic Door Locks The doors will lock automatically on vehicles with power door locks if all of the following conditions are met: 1. The automatic door locks feature is enabled. 2. The transmission is in gear. 3. All doors are closed. 4.
Page 32: Automatic Unlock Doors On Exit
30 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 4. A single chime will indicate the completion of the programming. 5. Repeat these steps if you want to return this feature to its previous setting. NOTE: Use the automatic door locks feature in accor- dance with local laws.
Page 33: Child-Protection Door Lock System (Rear Doors)
4. A single chime will indicate the completion of the programming. 5. Repeat these steps if you want to return this feature to its previous setting. NOTE: Use the automatic unlock doors on exit feature in accordance with local laws. Child-Protection Door Lock System (Rear Doors) Insert the tip of the ignition key into the lock and rotate it to either the LOCK or UNLOCK positions.
Page 34: Windows
32 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: For emergency exit with the system engaged, move the lock plunger up (unlocked position), roll down the window, and open the door with the outside door handle. WINDOWS Power Windows The power window controls are located on the driver’s door trim panel.
Page 35 WARNING! Never leave children in a vehicle with the keys in the ignition switch. Occupants, particularly unattended children, can become entrapped by the windows while operating the power window switches. Such entrapment may result in serious injury or death. Auto Down Feature The driver’s and front passenger’s (if equipped for pas- senger side) power window switches have an “Auto Down”...
Page 36 34 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Auto Up Feature with Anti-Pinch Protection — If Equipped On some models, the driver’s power window switch has an “Auto Up” feature. Pull the window switch up to the second detent, release, and the window will go up automatically.
Page 37 WARNING! There is no anti-pinch protection when the window is almost closed. Be sure to clear all objects from the window before closing. Reset At some point in time, it may be necessary to reactivate the auto-up feature. To do so, perform the following procedure: 1.
Page 38: Wind Buffeting
36 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Wind Buffeting Wind buffeting can be described as the perception of pressure on the ears or a helicopter type sound in the ears. Your vehicle may exhibit wind buffeting with the windows down, or the sunroof (if equipped) in certain open or partially open positions.
Page 39: Occupant Restraints
Liftgate Release WARNING! Driving with the liftgate open can allow poisonous exhaust gases into your vehicle. You and your pas- sengers could be injured by these fumes. Keep the liftgate closed when you are operating the vehicle. THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 37 OCCUPANT RESTRAINTS Some of the most important safety features in your vehicle are the restraint systems.
Page 40: Lap/Shoulder Belts
38 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! In a collision, you and your passengers can suffer injuries, including fatalities, if you are not properly buckled up. You can strike the interior of your vehicle or other passengers, or you can be thrown out of the vehicle.
Page 41: Lap/Shoulder Belt Operating Instructions
WARNING! Wearing a seat belt incorrectly is dangerous. Seat belts are designed to go around the large bones of your body. These are the strongest parts of your body and can take the forces of a collision the best. Wearing your belt in the wrong place could make your injuries in a collision much worse.
Page 42 40 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 3. When the belt is long enough to fit, insert the latch plate into the buckle until you hear a “click.” Latch Plate To Buckle WARNING! A belt that is buckled into the wrong buckle will not protect you properly.
Page 43 WARNING! (Continued) A shoulder belt placed behind will not protect you from injury during a collision. You are more likely to hit your head in a collision if you do not wear your shoulder belt. The lap and shoulder belt are meant to be used together.
Page 44 42 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 5. Position the shoulder belt on your chest so that it is comfortable and not resting on your neck. The retractor will withdraw any slack in the belt. Removing Slack From Belt 6.
Page 45: Adjustable Upper Shoulder Belt Anchorage
Adjustable Upper Shoulder Belt Anchorage In the front seating positions, the shoulder belt can be adjusted upward or downward to position the belt away from your neck. Press the release button to release the anchorage, and then move it up or down to the position that fits you best.
Page 46: Automatic Locking Mode - If Equipped
44 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Automatic Locking Mode — If Equipped In this mode, the shoulder belt is automatically pre- locked. The belt will still retract to remove any slack in the shoulder belt. When To Use The Automatic Locking Mode Anytime a child safety seat is installed in the rear center seating position.
Page 47: Enhanced Seat Belt Use Reminder System (Beltalert )
WARNING! The belt and retractor assembly must be replaced if the seat belt assembly “automatic locking retrac- tor” feature or any other seat belt function is not working properly when checked according to the procedures in the Service Manual. Failure to replace the belt and retractor assembly could increase the risk of injury in collisions.
Page 48 46 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE The Enhanced Warning System (BeltAlert ) can be en- abled or disabled by your authorized dealer or by following these steps: NOTE: The following steps must occur within the first 60 seconds of the ignition switch being turned to the ON or START position.
Page 49: Seat Belts And Pregnant Women
Seat Belts and Pregnant Women We recommend that pregnant women use the seat belts throughout their pregnancy. Keeping the mother safe is the best way to keep the baby safe. Pregnant women should wear the lap part of the belt across the thighs and as snug across the hips as possible.
Page 50: Driver And Front Passenger Supplemental Restraint Systems (Srs)
48 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Driver And Front Passenger Supplemental Restraint Systems (SRS) Front Airbag Components 1 — Driver Airbag 2 — Passenger Airbag This vehicle has airbags for both the driver and right front passenger as a supplement to the seat belt restraint systems.
Page 51 This vehicle is equipped with window bags to protect the driver, front, and rear passengers sitting next to a win- dow. They are located above the side windows. Their covers are also labeled SRS/AIRBAG. Window Airbag Location THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 49 NOTE: Airbag covers may not be obvious in the interior trim, but they will open to allow airbag deployment.
Page 52 50 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! (Continued) Do not have any accessory items installed which will alter the roof, including adding a sunroof to your vehicle. Do not add roof racks that require permanent attachments (bolts or screws) for instal- lation on the vehicle roof.
Page 53 Here are some simple steps you can take to minimize the risk of harm from a deploying airbag. 1. Children 12 years and younger should always ride buckled up in a rear seat. Infants in rear facing child restraints should NEVER ride in the front seat of a vehicle with a passenger airbag.
Page 54 52 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! Relying on the airbags alone could lead to more severe injuries in a collision. The airbags work with your seat belt to restrain you properly. In some collisions the airbags won’t deploy at all. Always wear your seat belts even though you have airbags.
Page 55 Occupant Classification System (OCS) — Front Pas- senger Seat Only − Occupant Classification Module − Passenger Airbag Disable (PAD) Indicator Light − Weight Sensors How The Airbag System Works The Occupant Restraint Control (ORC) module de- termines if a frontal, side, or rollover collision is severe enough to require the airbags to inflate.
Page 56 54 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! Ignoring the “Airbag Warning Light” in your instru- ment panel could mean you won’t have the airbags to protect you in a collision. If the light does not come on, stays on after you start the vehicle, or if it comes on as you drive, have the airbag system checked right away.
Page 57 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 55 The “PAD Indicator Light” should not be illuminated when an adult passenger is properly seated in the front passenger seat. In this case, the airbag is ready to be inflated if a collision requiring an airbag occurs. For occupants classified in the “child”...
Page 58 56 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: Even though this vehicle is equipped with an Occupant Classification System, children 12 years and younger should always ride buckled up in a rear seat in an appropriate child restraint. Passenger Air- Front Passenger bag Disable Seat Occupant...
Page 59 improperly classified. Ensure that the front passenger seatback does not touch anything placed on the back seat because this can also affect occupant classification. Also, if you fold down the rear seat, check to be sure it doesn’t touch the front passenger seat. If the front passenger seat is damaged in any way, it should only be serviced by an authorized dealer.
Page 60 58 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE The driver front airbag gas is vented through the vent holes in the sides of the airbag. The passenger front airbag gas is vented through the vent holes in the sides of the airbag. In this way, the airbags do not interfere with your control of the vehicle.
Page 61 The front passenger seat assembly contains critical com- ponents that affect the front passenger airbag deploy- ment. Correctly functioning front passenger seat compo- nents are critical for the Occupant Classification System (OCS) to properly classify the front passenger and calcu- late the proper airbag deployment.
Page 62 60 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE If A Deployment Occurs The airbag system is designed to deploy when the Occupant Restraint Control (ORC) module detects a moderate-to-severe frontal collision to help restrain the driver and front passenger, and then to immediately deflate.
Page 63 WARNING! Deployed airbags cannot protect you in another col- lision. Have the airbags, and seat belt retractor as- sembly replaced by an authorized dealer as soon as possible. Also, have the Occupant Classification Sys- tem serviced as well. Enhanced Accident Response System In the event of an impact that causes airbag deployment with the vehicle stopped, the vehicle communication network intact, and the power intact, the Enhanced...
Page 64 62 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! (Continued) Do not attempt to modify any part of your ad- vanced airbag system. The airbag may inflate accidentally or may not function properly if modi- fications are made. Take your vehicle to an autho- rized dealer for any advanced airbag system ser- vice.
Page 65 Airbag Warning Light You will want to have the airbag system ready to inflate for your protection in an impact. The airbag system is designed to be maintenance free. If any of the following occurs, have an authorized dealer service the system promptly: Does not come on during the six to eight seconds after the ignition switch is first turned ON.
Page 66 64 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE In the event that an investigation is undertaken by Chrysler LLC (regardless of initiative), the company or its designated representative will first obtain permission of the appropriate custodial entity for the vehicle (usually the vehicle owner or lessee) before accessing the elec- tronic data stored, unless ordered to download data by a court with legal jurisdiction (i.e., pursuant to a warrant).
Page 67: Child Restraint
Brake status (service and parking brakes) Accelerator status (including vehicle speed) Engine control status (including engine speed) Transmission gear selection Cruise control status Traction/stability control status Tire Pressure Monitoring System status Child Restraint Everyone in your vehicle needs to be buckled up all the time including babies and children.
Page 68 66 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Infants and Child Restraints Safety experts recommend rearward-facing in the vehicle until they are at least one year old and weigh at least 20 lbs (9 kg). Two types of child restraints can be used: rearward-facing infant carriers and “convertible”...
Page 69 Here are some tips for getting the most out of your child restraint: Before buying any restraint system, make sure that it has a label certifying that it meets all applicable safety standards. The manufacturer also recommends that you try a child restraint in the vehicle seats where you will use it before you buy it.
Page 70 68 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE In the rear seat, you may have trouble tightening the lap/shoulder belt on the child restraint because the buckle or latch plate is too close to the belt path opening on the restraint. Disconnect the latch plate from the buckle and twist the short buckle-end belt several times to shorten it.
Page 71 The belt-positioning booster seat is for children weighing more than 40 lbs (18 kg), but who are still too small to fit the vehicle’s seat belts properly. If the child cannot sit with knees bent over the vehicle’s seat cushion while the child’s back is against the seatback, they should use a belt-positioning booster seat.
Page 72 70 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE LATCH-compatible child restraint systems are now avail- able. However, because the lower anchorages are to be introduced over a period of years, child restraint systems having attachments for those anchorages will continue to also have features for installation using the vehicle’s seat belts.
Page 73 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 71 Installing the LATCH-Compatible Child Restraint System We urge that you carefully follow the directions of the manufacturer when installing your child restraint. Not all child restraint systems will be installed as described here. Again, carefully follow the installation instructions that were provided with the child restraint system.
Page 74 72 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE In addition, there are tether strap anchorages behind each rear seating position located on the back of the seat. Tether Strap Mounting Many, but not all restraint systems will be equipped with separate straps on each side, with each having a hook or connector for attachment to the lower anchorage and a means of adjusting the tension in the strap.
Page 75 child restraint rearward and downward into the seat, removing slack in the straps according to the child restraint manufacturer’s instructions. WARNING! Improper installation of a child restraint to the LATCH anchorages can lead to failure of an infant or child restraint. The child could be badly injured or killed.
Page 76 74 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE If the belt still can’t be tightened, or if by pulling and pushing on the restraint loosens the belt, you may need to do something more. Disconnect the latch plate from the buckle, turn the buckle around, and insert the latch plate into the buckle again.
Page 77: Engine Break-In Recommendations
Transporting Pets Airbags deploying in the front seat could harm your pet. An unrestrained pet will be thrown about and possibly injured, or injure a passenger during panic braking or in a collision. Pets should be restrained in the rear seat in pet harnesses or pet carriers that are secured by seat belts.
Page 78: Safety Tips
76 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE SAFETY TIPS Exhaust Gas WARNING! Exhaust gases can injure or kill. They contain carbon monoxide (CO) which is colorless and odorless. Breathing it can make you unconscious and can eventually poison you. To avoid breathing (CO), follow these safety tips: Do not inhale exhaust gases.
Page 79: Safety Checks You Should Make Outside The Vehicle
Seat belt assemblies must be replaced after an accident if they have been damaged i.e., (bent retractor, torn web- bing, etc.). If there is any question regarding belt or retractor condition, replace the belt. Airbag Warning Light The light should come on, and remain on for six to eight seconds as a bulb check, when the ignition switch is first turned ON.
Page 81 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CONTENTS Mirrors ......83 Inside Day/Night Mirror ....83 Automatic Dimming Mirror —...
Page 82 80 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Voice Training ..... . . 120 Seats ....... 120 Front Manual Seat Adjustment .
Page 83 Mist Feature ......133 Tilt Steering Column ....134 Electronic Speed Control —...
Page 84 82 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Closing Sunroof - Express ....151 Closing Sunroof - Manual Mode ..152 Pinch Protect Feature .
Page 85: Mirrors
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 83 MIRRORS Inside Day/Night Mirror A two-point pivot system allows for horizontal and vertical adjustment of the mirror. The mirror should be adjusted to center on the view through the rear window. Headlight glare can be reduced by moving the small control under the mirror to the night position (toward the rear of the vehicle).
Page 86: Understanding The Features Of Your Vehicle
84 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Automatic Dimming Mirror — If Equipped This mirror will automatically adjust for headlight glare from vehicles behind you. You can turn the feature on or off by pressing the button at the base of the mirror. A light in the button will illuminate indicate when the dimming feature is activated.
Page 87: Power Mirrors
WARNING! Vehicles and other objects seen in the right side convex mirror will look smaller and farther away than they really are. Relying too much on your right side mirror could cause you to collide with another vehicle or other object. Use your inside mirror when judging the size or distance of a vehicle seen in the right side mirror.
Page 88: Illuminated Vanity Mirrors - If Equipped
86 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Illuminated Vanity Mirrors — If Equipped An illuminated vanity mirror is on each sun visor. To use the mirror, rotate the sun visor down and swing the mirror cover upward. The lights will turn on automati- cally.
Page 89 NOTE: For UConnect customer support, visit the following websites: www.chrysler.com/uconnect www.dodge.com/uconnect www.jeep.com/uconnect UNDERSTANDING THE FEATURES OF YOUR VEHICLE 87 or call 1–877–855–8400 UConnect allows you to transfer calls between the system and your cellular phone as you enter or exit your vehicle and enables you to mute the system’s microphone...
Page 90: Operation
88 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Phone Button The rearview mirror contains the microphone for the system (depending on the type of mirror and radio equipped), and either the radio or the mirror has the two control buttons (PHONE Button and VOICE RECOGNITION button) that will enable you to access the system.
Page 91 For certain operations, compound commands can be used. For example, instead of saying Setup and then Phone Pairing, the following compound command can be said: Setup Phone Pairing. For each feature explanation in this section, only the combined form of the voice command is given. You can also break the commands into parts and say each part of the command when you are asked for it.
Page 92 90 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To complete the pairing process, you will need to refer- ence your cellular phone Owner’s Manual. The UConnect website may also provide detailed instruc- tions for pairing. The following are general phone to UConnect system pairing instructions: Press the PHONE button to begin.
Page 93 Dial by Saying a Number Press the PHONE button to begin. After the Ready prompt and the following beep, say Dial. The system will prompt you to say the number you want to call. For example, you can say 234-567-8901 . The UConnect system will confirm the phone num- ber and then dial.
Page 94 92 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Add Names to Your UConnect Phonebook NOTE: Adding names to the UConnect phonebook is recommended when the vehicle is not in motion. Press the PHONE button to begin. After the Ready prompt and the following beep, say Phonebook New Entry.
Page 95 Phonebook Download – Automatic Phonebook Transfer From Mobile Phone If equipped and specifically supported by your phone, UConnect automatically downloads names (text names) and number entries from the mobile phone’s phonebook. Specific Bluetooth Phones with Phone Book Access Profile may support this feature. See UConnect website for supported phones.
Page 96 94 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Phonebook Download — Single Entry If equipped and supported by your phone, UConnect allows the user to download entries from their phone via Bluetooth . To use this feature, press the PHONE button and say “Phonebook Download.”...
Page 97 You will then be asked for the name of the phonebook entry that you wish to edit. Next, choose the number designation (home, work, mobile, or pager) that you wish to edit. When prompted, recite the new phone number for the phonebook entry that you are editing.
Page 98 96 UNDERSTANDING THE FEATURES OF YOUR VEHICLE After you enter the name, the UConnect system will ask you which designation you wish to delete: home, work, mobile, pager, or all. Say the designation you wish to delete. Note that only the phonebook entry in the current language is deleted.
Page 99: Phone Call Features
The UConnect system will then prompt you as to the number designation you wish to call. The selected number will be dialed. Phone Call Features The following features can be accessed through the UConnect system if the feature(s) are available on your cellular service plan.
Page 100 98 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Making a Second Call While Current Call is in Progress To make a second call while you are currently on a call, press the VOICE RECOGNITION button and say Dial or Call followed by the phone number or phonebook entry you wish to call.
Page 101 Call Termination To end a call in progress, momentarily press the PHONE button. Only the active call(s) will be terminated and if there is a call on hold, it will become the new active call. If the active call is terminated by the far end, a call on hold may not become active automatically.
Page 102: Uconnect System Features
100 UNDERSTANDING THE FEATURES OF YOUR VEHICLE UConnect System Features Language Selection To change the language that the UConnect system is using: Press the PHONE button to begin. After the Ready prompt and the following beep, say the name of the language you wish to switch to English, Espanol, or Francais.
Page 103 Canada and 060 for Mexico). The number dialed may not be applicable with the available cellular service and area. If supported, this number may be programmable on some systems. To do this, press the PHONE button and say ‘Setup’, followed by ‘Emergency’. The UConnect system does slightly lower your chances of successfully making a phone call as to that...
Page 104 102 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Paging To learn how to page, refer to Working with Automated Systems. Paging works properly except for pagers of certain companies, which time out a little too soon to work properly with the UConnect system. Voice Mail Calling To learn how to access your voice mail, refer to Working with Automated Systems.
Page 105 NOTE: You may not hear all of the tones due to cellular phone network configurations. This is normal. Some paging and voice mail systems have system time out settings that are too short and may not allow the use of this feature. Barge In - Overriding Prompts The “Voice Recognition”...
Page 106 104 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Dialing Using the Cellular Phone Keypad You can dial a phone number with your cellular phone keypad and still use the UConnect system (while dial- ing via the cellular phone keypad, the user must exercise caution and take precautionary safety measures).
Page 107: Advanced Phone Connectivity
Advanced Phone Connectivity Transfer Call to and from Cellular Phone The UConnect system allows ongoing calls to be trans- ferred from your cellular phone to the UConnect system without terminating the call. To transfer an ongoing call from your UConnect paired cellular phone to the UConnect system or vice versa, press the VOICE REC- OGNITION button and say Transfer Call.
Page 108: Things You Should Know About Your Uconnect System
106 UNDERSTANDING THE FEATURES OF YOUR VEHICLE After the Ready prompt and the following beep, say Setup Select Phone and follow the prompts. You can also press the VOICE RECOGNITION button at any time while the list is being played, and then choose the phone that you wish to select.
Page 109 From outside the UConnect mode (e.g., from radio mode): Press and hold the VOICE RECOGNITION button for five seconds until the session begins, or, Press the VOICE RECOGNITION button and say the Setup, Voice Training command. Repeat the words and phrases when prompted by the UConnect system.
Page 110 108 UNDERSTANDING THE FEATURES OF YOUR VEHICLE fully closed windows, dry weather condition. Even though the system is designed for users speaking in North American English, French, and Spanish ac- cents, the system may not always work for some. When navigating through an automated system such as voice mail, or when sending a page, at the end of speaking the digit string, make sure to say Send.
Page 111 dry weather conditions, and operation from the driver’s seat. Performance, such as audio clarity, echo, and loudness to a large degree rely on the phone and network, and not the UConnect system. Echo at the far end can sometimes be reduced by lowering the in-vehicle audio volume.
Page 112 110 UNDERSTANDING THE FEATURES OF YOUR VEHICLE...
Page 113 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 111...
Page 114 112 UNDERSTANDING THE FEATURES OF YOUR VEHICLE...
Page 115 Voice Commands Primary Alternate(s) zero three four five seven eight nine star (*) plus (+) pound (#) add location UNDERSTANDING THE FEATURES OF YOUR VEHICLE 113 Voice Commands Primary Alternate(s) call cancel confirmation prompts continue delete dial download edit emergency English erase all Espanol...
Page 116 114 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Voice Commands Primary Alternate(s) language list names list phones mobile mute mute off new entry pager pair a phone phone pairing pairing phonebook phone book previous record again Voice Commands Primary Alternate(s) redial return to main menu return or main menu select phone...
Page 117: General Information
General Information This device complies with Part 15 of the FCC rules and RSS 210 of Industry Canada. Operation is subject to the following conditions: Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
Page 118 116 UNDERSTANDING THE FEATURES OF YOUR VEHICLE When you press the VR hard-key, you will hear a beep. The beep is your signal to give a command. NOTE: If you do not say a command within a few seconds, the system will present you with a list of options.
Page 119: Commands
Commands The Voice Recognition system understands two types of commands. Universal commands are available at all times. Local commands are available if the supported radio mode is active. Changing the Volume 1. Start a dialogue by pressing the VR hard-key. 2.
Page 120 118 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Radio FM To switch to the FM band say “FM” or “Radio FM”. In this mode, you may say the following commands: “Frequency” (to change the frequency) “Next Station” (to select the next station) “Previous Station”...
Page 121 Memo To switch to the voice recorder mode say “Memo”. In this mode, you may say the following commands: “New Memo” (to record a new memo) — During the recording you may press the VR hard-key to stop recording. You proceed by saying one of the following commands: −...
Page 122: Voice Training
120 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Voice Training For users experiencing difficulty with the system recog- nizing their voice commands or numbers, the UConnect system Voice Training feature may be used. 1. Press the VR hard-key, say “System Setup” and once you are in that menu then say “Voice Training.”...
Page 123: Front Seat Adjustment - Recline
Using body pressure, move forward and rearward on the seat to be sure the seat adjusters have latched. WARNING! Adjusting a seat while the vehicle is moving is dangerous. The sudden movement of the seat could cause you to lose control. The seat belt might not be properly adjusted and you could be injured.
Page 124: Six-Way Driver's Power Seat With Manual Recliner
122 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! Do not ride with the seatback reclined so that the seat belt is no longer resting against your chest. In a collision you could slide under the seat belt and be seriously or even fatally injured. Use the recliner only when the vehicle is parked.
Page 125: Fold Flat Front Passenger Seat
Fold Flat Front Passenger Seat The front passenger seat can be folded flat to allow for extended cargo space. Pull up on the lever to fold down the seat back. Fold Flat Passenger Seat UNDERSTANDING THE FEATURES OF YOUR VEHICLE 123 Head Restraints Head restraints can reduce the risk of whiplash injury in the event of impact from the rear.
Page 126: Heated Seats - If Equipped
124 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Heated Seats — If Equipped This feature heats the front driver and passenger seats. The controls for each heater are located near the bottom center of the instrument panel. Heated Seat Switches After turning ON the ignition, Press the switch once to select High level heating.
Page 127: 60/40 Split Folding Rear Seat With Fold Flat Feature
WARNING! Persons who are unable to feel pain to the skin because of advanced age, chronic illness, diabetes, spinal cord injury, medication, alcohol use, ex- haustion or other physical condition must exercise care when using the seat heater. It may cause burns even at low temperatures, especially if used for long periods of time.
Page 128 126 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Be sure that the front seats are fully upright and positioned forward. This will allow the rear seat to fold down easily. WARNING! It is extremely dangerous to ride in a cargo area, inside or outside of a vehicle.
Page 129: To Open And Close The Hood
To Raise Rear Seat If locked in the folded position, pull the release strap (toward the front of the vehicle). Raise the seatback and lock it into place. If interference from the cargo area prevents the seatback from fully locking, you will have difficulty returning the seat to its proper position.
Page 130 128 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 2. Push the safety latch lever to the right. It is located between the grille and hood opening left of the center. Underhood Safety Latch To prevent possible damage: Do not slam the hood to close it. Use a firm downward push at the center front edge of the hood to ensure that both latches engage.
Page 131: Lights
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 129 LIGHTS Multifunction Lever The multifunction lever controls the operation of the parking lights, headlights, headlight beam selection, passing light, fog lights, instrument panel light dimming and turn signals. The multifunction lever is located on the left side of the steering column.
Page 132: Parking Lights, Instrument Panel Lights And Headlights
130 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Parking Lights, Instrument Panel Lights and Headlights Turn the end of the multifunction lever to the first detent for parking lights and instrument panel lights. Turn to the second detent for headlight operation. Headlight Switch To change the brightness of the instrument panel lights, rotate the center portion of the multifunction lever up or...
Page 133: Flash-To-Pass
Flash-to-Pass You can signal another vehicle with your headlights by lightly pulling the multifunction lever toward the steer- ing wheel. This will cause the headlights to turn on at high beam and remain on until the lever is released. Front Fog Lights — If Equipped The front fog light switch is in the multifunction lever.
Page 134: Interior Lights
132 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Interior Lights The overhead light comes on when a door is opened. It may also be turned on by rotating the control for the dimmer switch on the multifunction lever fully upward. The overhead light will automatically turn off in approxi- mately 10 minutes if a door is left open or the dimmer control is left in the dome light position and the key is not in the ignition.
Page 135: Intermittent Wiper System
CAUTION! In cold weather, always turn off the wiper switch and allow the wipers to return to the park position before turning off the engine. If the wiper switch is left on and the wipers freeze to the windshield, damage to the wiper motor may occur when the vehicle is restarted.
Page 136: Tilt Steering Column
134 UNDERSTANDING THE FEATURES OF YOUR VEHICLE TILT STEERING COLUMN To tilt the column, push down on the lever under the multifunction lever and move the wheel up or down as desired. Pull the lever back upwards to lock the column firmly in place.
Page 137: Electronic Speed Control - If Equipped
ELECTRONIC SPEED CONTROL — IF EQUIPPED When engaged, the Electronic Speed Control takes over the accelerator operation at speeds greater than 25 mph (40 km/h). The Electronic Speed Control lever is located on the right side of the steering wheel. Electronic Speed Control Lever UNDERSTANDING THE FEATURES OF YOUR VEHICLE 135 To Activate...
Page 138: To Deactivate
136 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: The vehicle should be traveling at a steady speed and on level ground before pressing the SET lever. To Deactivate A soft tap on the brake pedal, pulling the Electronic Speed Control lever toward you, “CANCEL”, or normal brake or clutch pressure while slowing the vehicle will deactivate speed control without erasing the set speed memory.
Page 139: Manual Transmission
Manual Transmission Depressing the clutch pedal will disengage the Electronic Speed Control. A slight increase in engine RPM before the speed control disengages is normal. Vehicles equipped with manual transmissions may need to be shifted into a lower gear to climb hills without speed loss.
Page 140: System Usage Precautions
138 UNDERSTANDING THE FEATURES OF YOUR VEHICLE System Usage Precautions NOTE: Ensure that the rear bumper is free of dirt and debris to keep the Rear Park Assist System operating prop- erly. Jackhammers, large trucks, and other vibrations could affect the performance of the Rear Park Assist System. When you turn off the Rear Park Assist System, the instrument cluster will display “PARK ASSIST DIS- ABLED.”...
Page 141 CAUTION! (Continued) The vehicle must be driven slowly when using the Rear Park Assist System to be able to stop in time when the obstacle is detected. It is recommended that the driver looks over his/her shoulder when using the Rear Park Assist System. Clean the Rear Park Assist Sensors with water, car wash soap, and a soft cloth.
Page 142: Enabling And Disabling The System
140 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! (Continued) Before using the Rear Park Assist System, it is strongly recommended that the ball mount and hitch ball assembly is disconnected from the ve- hicle when the vehicle is not used for towing. Failure to do so can result in injury or damage to vehicles or obstacles because the hitch ball will be much closer to the obstacle than the rear fascia...
Page 143: System Operation
Vehicles Equipped with Rear Park Assist Switch You can turn the Rear Park Assist System on or off by pressing the Rear Park Assist switch located the lower switch bank below the climate controls. Rear Park Assist Switch UNDERSTANDING THE FEATURES OF YOUR VEHICLE 141 System Operation The system uses four sensors located in the rear bumper fascia to scan for obstacles up to 79 in (200 cm) away from...
Page 144 142 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The warning display contains two sets of yellow and red LEDs, one set to warn of obstacles behind the left rear of the vehicle and the other set to warn of obstacles behind the right rear of the vehicle.
Page 145: Rear Center
WARNING DISPLAY DISTANCES DISPLAY LED OBSTACLE DISTANCE FROM: REAR CORNERS Inner LED 1st LED 2nd LED 3rd LED 31.5 in (80 cm) 4th LED 25.5 in (65 cm) 5th LED 20 in (50 cm) 6th LED 16 in (40 cm) 7th LED 6 in (15 cm) UNDERSTANDING THE FEATURES OF YOUR VEHICLE 143...
Page 146: Garage Door Opener - If Equipped
144 UNDERSTANDING THE FEATURES OF YOUR VEHICLE GARAGE DOOR OPENER — IF EQUIPPED HomeLink replaces up to three remote controls (hand- held transmitters) that operate devices such as garage door openers, motorized gates, lighting, or home security systems. The HomeLink unit operates off your vehicle’s battery.
Page 147: Programming Homelink
WARNING! Your motorized door or gate will open and close while you are training the Universal Transceiver. Do not train the transceiver if people or pets are in the path of the door or gate. Only use this trans- ceiver with a garage door opener that has a “stop and reverse”...
Page 148 146 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Place the hand-held transmitter 1–3 in (3-8 cm) away from the HomeLink button you wish to program while keeping the indicator light in view. 3. Simultaneously press and hold both the chosen HomeLink button and the hand-held transmitter button until the HomeLink indicator changes from a slow to a rapidly blinking light, then release both the HomeLink and hand-held transmitter buttons.
Page 149 This can usually be found where the hanging antenna wire is attached to the garage door opener motor (it is NOT the button normally used to open and close the door). 1 — Garage Door Opener 2 — Training Button UNDERSTANDING THE FEATURES OF YOUR VEHICLE 147 6.
Page 150: Gate Operator/Canadian Programming
148 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Gate Operator/Canadian Programming Canadian radio-frequency laws require transmitter sig- nals to “time-out” (or quit) after several seconds of transmission – which may not be long enough for HomeLink to pick up the signal during programming. Similar to this Canadian law, some U.S.
Page 151: Reprogramming A Single Homelink Button
Reprogramming A Single HomeLink Button To re-program a channel that has been previously trained, follow these steps: 1. Turn the ignition switch to the ON/RUN position. 2. Press and hold the desired HomeLink button until the indicator light begins to flash after 20 seconds. Do not release the button.
Page 152: General Information
150 UNDERSTANDING THE FEATURES OF YOUR VEHICLE General Information This device complies with FCC rules Part 15 and Industry Canada RSS-210. Operation is subject to the following two conditions: 1. This device may not cause harmful interference 2. This device must accept any interference that may be received including interference that may cause undesired operation NOTE: The transmitter has been tested and it complies...
Page 153: Opening Sunroof - Express
WARNING! Never leave unattended children in a vehicle with the key in the ignition switch. Occupants, particu- larly unattended children, can become entrapped by the power sunroof while operating the power sunroof switch. Such entrapment may result in serious injury or death. In an accident, there is a greater risk of being thrown from a vehicle with an open sunroof.
Page 154: Closing Sunroof - Manual Mode
152 UNDERSTANDING THE FEATURES OF YOUR VEHICLE position. The sunroof will close fully and stop automati- cally. This is called Express Close. During Express Close operation, any movement of the switch will stop the sunroof. NOTE: To ensure the sunroof is fully closed, press and hold the switch until the sunroof has completely stopped moving.
Page 155: Sunshade Operation
Sunshade Operation The sunshade can be opened manually. However, the sunshade will open automatically as the sunroof opens. NOTE: The sunshade cannot be closed if the sunroof is open. Wind Buffeting Wind buffeting can be described as the perception of pressure on the ears or a helicopter-type sound in the ears.
Page 156: Electrical Power Outlet
154 UNDERSTANDING THE FEATURES OF YOUR VEHICLE ELECTRICAL POWER OUTLET This vehicle has two 12-Volt auxiliary power outlets that can provide up to 20 Amps of current for accessories designed for use with the standard power outlet adapt- ers. The front power outlet, located in the lower portion of the instrument panel, has a snap on plastic cap so that it can be covered when not in use.
Page 157 WARNING! (Continued) Do not touch with wet hands. Close the lid when not in use and while driving the vehicle. If this outlet is mishandled, it may cause an electric shock and failure. CAUTION! Many accessories that can be plugged in draw power from the vehicle’s battery, even when not in use (i.e., cellular phones, etc.).
Page 158: Power Inverter - If Equipped
156 UNDERSTANDING THE FEATURES OF YOUR VEHICLE POWER INVERTER — IF EQUIPPED There is a 110-Volt, 150-Watt power inverter outlet lo- cated on the back of the center console to convert DC current to AC current. This outlet can be used to power small appliances and electronics.
Page 159 NOTE: When the inverter switch is pressed, there will be a delay of approximately one second before the inverter status indicator turns ON. The status indicator of the AC power inverter indicates whether the inverter is producing AC power. Power Inverter Switch UNDERSTANDING THE FEATURES OF YOUR VEHICLE 157 NOTE: Due to built in overload protection;...
Page 160: Cupholders
158 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CUPHOLDERS In the center console, there are two cupholders for the front seat passengers. Front Cupholders The rear passengers have cupholders at the rear of the center console. Rear Cupholders...
Page 161: Storage
STORAGE Front Storage Compartment The front storage compartment (located on the left side of the instrument panel) can hold cell phones, PDAs, and other small items. Front Storage Compartment UNDERSTANDING THE FEATURES OF YOUR VEHICLE 159 Console Storage Compartment To open, press the latch and lift the cover. Center Console...
Page 162: Cargo Area Features
160 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The center console has a removable storage tray which can hold cell phones, PDAs, and other small items. Removable Storage Tray CARGO AREA FEATURES Cargo Light The cargo area light is activated by opening the liftgate, opening any door, or by rotating the dimmer control on the multifunction lever to the extreme top position.
Page 163 WARNING! The weight and position of cargo and passengers can change the vehicle center of gravity and vehicle handling. To avoid loss of control resulting in per- sonal injury, follow these guidelines for loading your vehicle: Do not carry loads which exceed the load limits described on the label attached to the left door or left door center pillar.
Page 164: Cargo Load Floor - If Equipped
162 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Cargo Load Floor — If Equipped The panel in the load floor is reversible for added utility. One side features a plastic lined tray which can hold a variety of items. The maximum load capacity of the load floor is 400 lbs (181 kg).
Page 165: Rear Cargo Slide Out System (Load N Go ) - If Equipped
2. Lift the cover. 3. Flip the cover over, and lock panel back into position. Load Floor UNDERSTANDING THE FEATURES OF YOUR VEHICLE 163 Rear Cargo Slide Out System (Load N Go ) — If Equipped The sliding cargo load floor (Load N Go ) slides back and forth on steel tracks for convenience.
Page 166 164 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 2. Squeeze the right hand release handle. Release Handle 3. Pull out the sliding panel. Sliding Panel 4. Squeeze the right hand release handle to slide the panel back into the vehicle.
Page 167: Rear Window Features
REAR WINDOW FEATURES Rear Window Wiper/Washer — If Equipped A rotary ring switch on the control lever (located on the right side of the steering column), controls operation of the rear wiper/washer function. Rotating the center of the switch up to the ON position will activate the wiper. Rotating the switch ring beyond the ON or OFF position will activate the rear washer.
Page 168: Rear Window Defroster - If Equipped
166 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Rear Window Defroster — If Equipped The pushbutton for the rear window defroster is located on the mode knob of the climate control switch bank. Press this button to turn on the rear window defroster and the electric remote control heated mirrors (optional).
Page 169 NOTE: Metal rails/crossbars are offered by Mopar accessories. See your authorized dealer. External racks do not increase the total load carrying capacity of the vehicle. Be sure that the total occupant and luggage load inside the vehicle, plus the load on the luggage rack, do not exceed the maximum vehicle load capacity.
Page 171: Understanding Your Instrument Panel
UNDERSTANDING YOUR INSTRUMENT PANEL CONTENTS Instrument Panel Features ....172 Instrument Cluster ..... 173 Instrument Cluster Description .
Page 172 170 UNDERSTANDING YOUR INSTRUMENT PANEL Sales Code REQ — AM/FM Stereo Radio And 6–Disc CD/DVD Changer (MP3/WMA AUX Jack)....... . 200 Operating Instructions - Radio Mode .
Page 173 Operation Instructions — CD Mode For CD And MP3 Audio Play ....233 Notes On Playing MP3 Files ... . . 235 List Button (CD Mode For MP3 Play) .
Page 174: Instrument Panel Features
172 UNDERSTANDING YOUR INSTRUMENT PANEL INSTRUMENT PANEL FEATURES 1 - Air Outlet 2 - Instrument Cluster 3 - Storage Tray 4 - Center Air Outlet 5 - Radio 6 - Glove Compartment 7 - Climate Control 8 - Heated Seat Switch * 9 - Rear Park Assist Switch * 10 - Passenger Airbag Disable Light 11 - Hazard Warning Flasher...
Page 175: Instrument Cluster
UNDERSTANDING YOUR INSTRUMENT PANEL 173 INSTRUMENT CLUSTER...
Page 176: Instrument Cluster Description
174 UNDERSTANDING YOUR INSTRUMENT PANEL INSTRUMENT CLUSTER DESCRIPTION 1. Fuel Gauge The fuel gauge shows level of fuel in tank when ignition switch is in the ON position. 2. Fuel Door Reminder This symbol indicates the side of the vehicle where the fuel cap is located.
Page 177 WARNING! A hot engine cooling system is dangerous. You or others could be badly burned by steam or boiling coolant. You may want to call an authorized dealer- ship for service if your vehicle overheats. If you decide to look under the hood yourself, see Section 7 of this manual.
Page 178 176 UNDERSTANDING YOUR INSTRUMENT PANEL 7. Speedometer Shows the vehicles speed. 8. High Beam Indicator This indicator shows that the headlights are on high beam. Push the multifunction lever forward to switch the headlights to high beam, and pull toward yourself (normal position) to return to low beam.
Page 179 If the vehicle electronics sense that the vehicle has traveled about one mile with the turn signals on, a continuous chime will sound to alert you to turn the signals off. If either indicator flashes at a rapid rate, check for a defective outside light bulb.
Page 180 178 UNDERSTANDING YOUR INSTRUMENT PANEL The dual brake system provides a reserve braking capac- ity in the event of a failure to a portion of the hydraulic system. A leak in either half of the dual brake system is indicated by the Brake Warning Light, which will turn on when the brake fluid level in the master cylinder has dropped below a specified level.
Page 181 The light also will turn on when the parking brake is applied with the ignition switch in the ON position. NOTE: This light shows only that the parking brake is applied. It does not show the degree of brake application. 15.
Page 182 180 UNDERSTANDING YOUR INSTRUMENT PANEL 17. Charging System Light This light shows the status of the electrical charg- ing system. The light should come on when the ignition switch is first turned ON and remain on briefly as a bulb check. If the light stays on or comes on while driving, turn off some of the vehicle’s non-essential electrical devices or increase engine speed (if at idle).
Page 183 21. Oil Pressure Warning Light This light indicates low engine oil pressure. The light should turn on momentarily when the engine is started. If the light turns on while driving, stop the vehicle and shut off the engine as soon as possible. A chime will sound for four minutes when this light turns Do not operate the vehicle until the cause is corrected.
Page 184 182 UNDERSTANDING YOUR INSTRUMENT PANEL 25. Tire Pressure Monitoring Telltale Light Each tire, including the spare (if provided), should be checked monthly, when cold and inflated to the inflation pressure recommended by the vehicle manufacturer on the vehicle placard or tire inflation pressure label. (If your vehicle has tires of a different size than the size indicated on the vehicle placard or tire inflation pressure label, you should determine the proper tire inflation pressure for those...
Page 185 as intended. TPMS malfunctions may occur for a variety of reasons, including the installation of replacement or alternate tires or wheels on the vehicle that prevent the TPMS from functioning properly. Always check the TPMS malfunction telltale after replacing one or more tires or wheels on your vehicle, to ensure that the replacement or alternate tires and wheels allow the TPMS to continue to function properly.
Page 186 184 UNDERSTANDING YOUR INSTRUMENT PANEL 26. Odometer/Trip Odometer The odometer shows the total distance the vehicle has been driven. The TRIP ODOMETER shows individual trip mileage. To toggle between the odometer and the trip odometer, press the ODOMETER/TRIP ODOMETER button. To reset the TRIP ODOMETER, press and hold the button while in trip mode, until the TRIP ODOMETER resets.
Page 187 U.S. federal regulations require that upon transfer of vehicle ownership, the seller certify to the purchaser the correct mileage that the vehicle has been driven. There- fore, if the odometer reading is changed during repair or replacement, be sure to keep a record of the reading before and after the service so that the correct mileage can be determined.
Page 188 186 UNDERSTANDING YOUR INSTRUMENT PANEL 27. Malfunction Indicator Light (MIL) The Malfunction Indicator Light (MIL) is part of an onboard diagnostic system, called OBD, that monitors engine and automatic transmission con- trol systems. The light will illuminate when the key is in the ON position, before engine start.
Page 189: Compass And Trip Computer - If Equipped
30. Compass/Trip Computer or Electronic Vehicle Information Center (EVIC) Display — If Equipped When the appropriate conditions exist, this display shows the Compass/Trip Computer or Electronic Vehicle Information Center (EVIC) messages. COMPASS AND TRIP COMPUTER — IF EQUIPPED The Compass/Trip Computer features a driver- interactive display (displays information on outside tem- perature, compass direction, and trip information).
Page 190: Control Buttons
188 UNDERSTANDING YOUR INSTRUMENT PANEL These messages can be manually turned off by pressing the right button (on the instrument cluster). Control Buttons Press and release the odometer/trip odometer reset but- ton (right side of the instrument cluster) to access the compass/trip computer displays.
Page 191: Compass/Temperature Display
Compass/Temperature Display Compass Variance Compass Variance is the difference between Magnetic North and Geographic North. To compensate for the differences, the variance should be set for the zone where the vehicle is driven, per the zone map. Once properly set, the compass will automatically compensate for the differences and provide the most accurate compass head- ing.
Page 192 190 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: The factory default zone is 8. During program- ming, the zone value will wrap around from zone 15 to zone 1. Manual Compass Calibration If the compass appears erratic, inaccurate or abnormal, you may wish to calibrate the compass. Prior to calibrat- ing the compass, make sure the proper zone is selected.
Page 193: Electronic Vehicle Information Center (Evic) - If Equipped
ELECTRONIC VEHICLE INFORMATION CENTER (EVIC) — IF EQUIPPED The Electronic Vehicle Information Center (EVIC) fea- tures a driver-interactive display that is located in the instrument cluster. Electronic Vehicle Information Center (EVIC) UNDERSTANDING YOUR INSTRUMENT PANEL 191 This system conveniently allows the driver to select a variety of useful information by pressing the switches mounted on the steering wheel.
Page 194: Electronic Vehicle Information Center (Evic) Displays
192 UNDERSTANDING YOUR INSTRUMENT PANEL The system allows the driver to select information by pressing the following buttons mounted on the steering wheel: Press and release the MENU button and the mode displayed will change between Trip Functions, Navigation (if equipped), System Status, Personal Settings.
Page 195: Oil Change Required
Left/right front door ajar (one or more, with a single chime if speed is above 1 mph/1 km/h) Left/right rear door ajar (one or more, with a single chime if speed is above 1 mph/1 km/h) Door(s) ajar (with a single chime if vehicle is in motion) Liftgate ajar (with a single chime) Left front low pressure (with a single chime).
Page 196: Trip Functions
194 UNDERSTANDING YOUR INSTRUMENT PANEL 1. Turn the ignition switch to the ON position. (Do not start the engine). 2. Fully depress the accelerator pedal slowly three times within 10 seconds. 3. Turn the ignition switch to the OFF/LOCK position. NOTE: If the indicator message illuminates when you start the engine, the oil change indicator system did not reset.
Page 197: Compass Display
NOTE: Significant changes in driving style or vehicle loading will greatly affect the actual drivable distance of the vehicle, regardless of the DTE displayed value. When the DTE value is less than 30 miles (48 km) estimated driving distance, the DTE display will change to a text display of LOW FUEL.
Page 198 196 UNDERSTANDING YOUR INSTRUMENT PANEL Automatic Compass Calibration This compass is self-calibrating, which eliminates the need to manually reset the compass. When the vehicle is new, the compass may appear erratic and the EVIC will display CAL until the compass is calibrated. You may also calibrate the compass by completing one or more 360–degree turns (in an area free from large metal or metallic objects) until the CAL indicator displayed in the...
Page 199 Compass Variance Compass variance is the difference between magnetic North and geographic North. In some areas of the country, the difference between magnetic and geographic North is great enough to cause the compass to give false readings. For the most accurate compass performance, the compass variance must be set using the following procedure: NOTE: Magnetic materials should be kept away from...
Page 200: Personal Settings (Customer-Programmable Features)
198 UNDERSTANDING YOUR INSTRUMENT PANEL 4. Press and release the FUNCTION SELECT button until the proper variance zone is selected according to the map. 5. Press and release the COMPASS button to exit. Personal Settings (Customer-Programmable Features) Personal Settings allows the driver to set and recall features when the transmission is in PARK.
Page 201 transmitter UNLOCK button twice to unlock the passen- gers’ doors. When All Doors 1st Press is selected, all of the doors will unlock on the first press of the RKE transmitter UNLOCK button. To make your selection, press and release the FUNCTION SELECT button until “Driver Door 1st Press”...
Page 202: Sales Code Req - Am/Fm Stereo Radio And
200 UNDERSTANDING YOUR INSTRUMENT PANEL Delay Power Off to Accessories Until Exit When this feature is selected, the power window switches, radio, hands–free system (if equipped), DVD video system (if equipped), power sunroof (if equipped), and power outlets will remain active for up to 60 minutes after the ignition switch is turned off.
Page 203: Operating Instructions - Radio Mode
Operating Instructions - Radio Mode NOTE: The ignition switch must be in the ON or ACC position to operate the radio. Power Switch/Volume Control (Rotary) Push the ON/VOLUME control knob to turn on the radio. Press the ON/VOLUME control knob a second time to turn off the radio.
Page 204 202 UNDERSTANDING YOUR INSTRUMENT PANEL Phone Button (UConnect Hands-Free Phone) — If Equipped Press this button to operate the Hands-Free Phone (UConnect ) feature (if equipped). Refer to “Hands-Free Communication (UConnect )” in Section 3. If your vehicle is not equipped with or this feature is not available on your vehicle, a “Not Equipped With UConnect”...
Page 205 RW/FF Pressing the RW (Rewind) or FF (Fast Forward) buttons causes the tuner to search for the next frequency in the direction of the arrows. This feature operates in AM, FM or Satellite (if equipped) frequencies. TUNE Control Turn the rotary TUNE/SCROLL control knob clockwise to increase or counterclockwise to decrease the frequency.
Page 206 204 UNDERSTANDING YOUR INSTRUMENT PANEL MUSIC TYPE Button Pressing this button once will turn on the Music Type mode for five seconds. Pressing the MUSIC TYPE button or turning the TUNE/SCROLL control knob within five seconds will allow the program format type to be se- lected.
Page 207 16-Digit Character Program Type Sports Talk Top 40 Weather By pressing the SEEK button when the Music Type icon is displayed, the radio will be tuned to the next frequency station with the same selected Music Type name. The Music Type function only operates when in the FM mode.
Page 208 206 UNDERSTANDING YOUR INSTRUMENT PANEL Audio Stream – Repeatedly pressing SELECT will switch to different audio languages (if supported on the disc) (if equipped). Angle – Repeatedly pressing SELECT will change the viewing angle if supported by the DVD disc (if equipped).
Page 209 Enter the four-digit country code using the TUNE/ SCROLL control knob to scroll up and down to select the number and then push to select. Audio Language — If Equipped Selecting this item allows you to choose a default audio language (effective only if the language is supported by the disc).
Page 210 208 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: The user will have to set these defaults before loading a disc. If changes are made to these settings after a disc is loaded, changes will not be effective. Also, the defaults are effective only if the disc supports the customer-preferred settings.
Page 211: Operation Instructions - (Disc Mode For Cd And Mp3/Wma Audio Play, Dvd-Video)
Operation Instructions - (DISC MODE for CD and MP3/WMA Audio Play, DVD-VIDEO) The radio DVD player and many DVD discs are coded by geographic region. These region codes must match in order for the disc to play. If the region code for the DVD disc does not match the region code for the radio DVD player, it will not play the disc.
Page 212 210 UNDERSTANDING YOUR INSTRUMENT PANEL Eject Button — Ejecting Compact Disc(s) Press the EJECT button and the pushbutton with the corresponding number (1-6) where the CD was loaded and the disc will unload and move to the entrance for easy removal. Radio display will show EJECTING DISC when the disc is being ejected and prompt the user to remove the disc.
Page 213: Notes On Playing Mp3/Wma Files
Notes On Playing MP3/WMA Files The radio can play MP3/WMA files; however, acceptable MP3/WMA file recording media and formats are limited. When writing MP3/WMA files, pay attention to the following restrictions. Supported Media (Disc Types) The MP3/WMA file recording media supported by the radio are CDDA, CD-R, CD-RW, MP3,WMA, DVD Video, DVD-R, DVD-RW, DVD+R, DVD+RW, and CDDA+MP3.
Page 214 212 UNDERSTANDING YOUR INSTRUMENT PANEL If a disc contains multi-formats, such as CD audio and MP3/WMA tracks, the radio will only play the MP3/ WMA tracks on that disc. Supported MP3/WMA File Formats The radio will recognize only files with the *.MP3/WMA extension as MP3/WMA files.
Page 215: List Button (Disc Mode For Mp3/Wma Play)
Playback of MP3/WMA Files When a medium containing MP3/WMA data is loaded, the radio checks all files on the medium. If the medium contains a lot of folders or files, the radio will take more time to start playing the MP3/WMA files. Loading times for playback of MP3/WMA files may be affected by the following: Media - CD-RW media may take longer to load than...
Page 216 214 UNDERSTANDING YOUR INSTRUMENT PANEL Press and hold the INFO button again for three seconds to return to elapsed time display. Operation Instructions - Auxiliary Mode The auxiliary (AUX) jack is an audio input jack, which allows the user to plug in a portable device such as an MP3/WMA player, cassette player, or microphone and utilize the vehicle’s audio system to amplify the source and play through the vehicle speakers.
Page 217 Operating Instructions — Voice Recognition System (VR) (If Equipped) For the radio, refer to “Voice Recognition System (VR)” in Section 3. For UConnect “Voice Recognition System (VR),” refer to “Hands-Free Communication (UConnect )” in Section 3. Operating Instructions - Hands-Free Phone (UConnect ) (If Equipped) Refer to “Hands-Free Communication (UConnect )”...
Page 218: Am/Fm/Cd/Dvd Multimedia System Radio (Rer/Ren) - If Equipped
216 UNDERSTANDING YOUR INSTRUMENT PANEL AM/FM/CD/DVD MULTIMEDIA SYSTEM RADIO (RER/REN) – IF EQUIPPED NOTE: The sales code is located on the lower right side of the unit’s faceplate. The REN and RER Multimedia systems contain a radio, CD/DVD player, USB port, and a 30-gigabyte hard drive (HDD).
Page 219 To Manually Set the Clock — RER/REN 1. Turn on the multimedia system. 2. Touch the screen where the time is displayed. 3. Touch the screen where “User Clock” is displayed. The clock setting menu will appear on the screen. 4.
Page 220 218 UNDERSTANDING YOUR INSTRUMENT PANEL Show Time if Radio is Off When selected, this feature will display the time of day on the touch screen when the multimedia system is turned off. Proceed as follows to change the current setting: 1.
Page 221: Sales Code Res - Am/Fm Stereo Radio With Cd Player (Mp3 Aux Jack)
SALES CODE RES — AM/FM STEREO RADIO WITH CD PLAYER (MP3 AUX JACK) NOTE: The radio sales code is located on the lower right side of the radio faceplate. RES Radio UNDERSTANDING YOUR INSTRUMENT PANEL 219 Operating Instructions — Radio Mode NOTE: The ignition switch must be in the ON or ACC position to operate the radio.
Page 222 220 UNDERSTANDING YOUR INSTRUMENT PANEL SEEK Buttons Press and release the SEEK buttons to search for the next listenable station in AM/FM mode. Press the right switch to seek up and the left switch to seek down. The radio will remain tuned to the new station until you make another selection.
Page 223 Push the rotary Tune/Scroll control knob a second time and MID will display. Turn the Tune/Scroll control knob to the right or left to increase or decrease the mid-range tones. Push the rotary Tune/Scroll control knob a third time and TREBLE will display.
Page 224: Operation Instructions - Cd Mode For Cd And Mp3 Audio Play
222 UNDERSTANDING YOUR INSTRUMENT PANEL Every time a preset button is used, a corresponding button number will display. Buttons 1 - 6 These buttons tune the radio to the stations that you commit to pushbutton memory (12 AM and 12 FM stations).
Page 225 CAUTION! This CD player will accept 4-3/4 in (12 cm) discs only. The use of other sized discs may damage the CD player mechanism. Do not use adhesive labels. These labels can peel away and jam the player mechanism. RES is a single CD player. Do not attempt to insert a second CD if one is already loaded.
Page 226: Notes On Playing Mp3 Files
224 UNDERSTANDING YOUR INSTRUMENT PANEL RW/FF Press the RW button to stop the CD at the beginning of the current CD track/title. Press and hold the FF (Fast Forward) button and the CD player will begin to fast forward until FF is released, or RW or another CD button is pressed.
Page 227 The radio uses the following limits for file systems: Maximum number of folder levels: 8 Maximum number of files: 255 Maximum number of folders. (The radio display of file names and folder names is limited. For large numbers of files and/or folders, the radio may be unable to display the file name and folder name, and will assign a number instead.
Page 228 226 UNDERSTANDING YOUR INSTRUMENT PANEL rates (VBR) are also supported. The majority of MP3 files use a 44.1 kHz sampling rate and a 192, 160, 128, 96 or VBR bit rate. MPEG Sampling Specification Frequency (kHz) MPEG-1 Audio 48, 44.1, 32 Layer 3 MPEG-2 Audio 24, 22.05, 16...
Page 229: Operation Instructions - Auxiliary Mode
Operation Instructions - Auxiliary Mode The auxiliary (AUX) jack is an audio input jack, which allows the user to plug in a portable device, such as an MP3 player, or cassette player, and utilize the vehicle’s audio system to amplify the source and play through the vehicle speakers.
Page 230: Operating Instructions - Radio Mode
228 UNDERSTANDING YOUR INSTRUMENT PANEL Operating Instructions — Radio Mode NOTE: The ignition switch must be in the ON or ACC position to operate the radio. Power Switch/Volume Control (Rotary) Push the On/Volume control knob to turn on the radio. Push the On/Volume control knob a second time to turn off the radio.
Page 231 Phone Button (UConnect Hands-Free Phone) — If Equipped Press this button to operate the Hands-Free Phone (UConnect ) feature (if equipped). Refer to “Hands-Free Communication (UConnect )” in Section 3. If your vehicle is not equipped with or this feature is not available on your vehicle, a “Not Equipped With UConnect”...
Page 232 230 UNDERSTANDING YOUR INSTRUMENT PANEL INFO Button Press the INFO button for an RDS station (one with call letters displayed). The radio will return a Radio Text message broadcast from an FM station (FM mode only). RW/FF Pressing the RW (Rewind) or FF (Fast Forward) buttons causes the tuner to search for the next frequency in the direction of the arrows.
Page 233 MUSIC TYPE Button Pressing this button once will turn on the Music Type mode for five seconds. Pressing the MUSIC TYPE button or turning the Tune/Scroll control knob within five seconds will allow the program format type to be se- lected.
Page 234 232 UNDERSTANDING YOUR INSTRUMENT PANEL Program Type Sports Talk Top 40 Weather By pressing the SEEK button when the Music Type icon is displayed, the radio will be tuned to the next frequency station with the same selected Music Type name. The Music Type function only operates when in the FM mode.
Page 235: Operation Instructions - Cd Mode For Cd And Mp3 Audio Play
You may add a second station to each pushbutton by repeating the above procedure with this exception: Press the SET/RND button twice and SET 2 will show in the display window. Each button can be set for SET 1 and SET 2 in both AM and FM.
Page 236 234 UNDERSTANDING YOUR INSTRUMENT PANEL If you insert a disc with the ignition ON and the radio ON, the unit will switch from radio to CD mode and begin to play when you insert the disc. The display will show the disc number, the track number, and index time in minutes and seconds.
Page 237: Notes On Playing Mp3 Files
TIME Button Press this button to change the display from a large CD playing time display to a small CD playing time display. RW/FF Press the RW button to stop the CD at the beginning of the current CD track/title. Press and hold FF (Fast Forward) and the CD player will begin to fast forward until FF is released or RW or another CD button is pressed.
Page 238 236 UNDERSTANDING YOUR INSTRUMENT PANEL Supported Medium Formats (File Systems) The medium formats supported by the radio are ISO 9660 Level 1 and Level 2 and includes the Joliet extension. When reading discs recorded using formats other than ISO 9660 Level 1 and Level 2, the radio may fail to read files properly and may be unable to play the file nor- mally.
Page 239 Supported MP3 File Formats The radio will recognize only files with the *.MP3 exten- sion as MP3 files. Non-MP3 files named with the *.MP3 extension may cause playback problems. The radio is designed to recognize the file as an invalid MP3 and will not play the file.
Page 240: List Button (Cd Mode For Mp3 Play)
238 UNDERSTANDING YOUR INSTRUMENT PANEL Playback of MP3 Files When a medium containing MP3 data is loaded, the radio checks all files on the medium. If the medium contains a lot of folders or files, the radio will take more time to start playing the MP3 files.
Page 241 Press and hold the INFO button again for three seconds to return to elapsed time display. Operation Instructions - Auxiliary Mode The auxiliary (AUX) jack is an audio input jack, which allows the user to plug in a portable device such as an MP3 player, or cassette player, and utilize the vehicle’s audio system to amplify the source and play through the vehicle speakers.
Page 242: Satellite Radio - If Equipped (Ren/Req/Rer/Res/Reu Radios Only)
240 UNDERSTANDING YOUR INSTRUMENT PANEL SATELLITE RADIO — IF EQUIPPED (REN/REQ/RER/RES/REU RADIOS ONLY) Satellite radio uses direct satellite-to-receiver broadcast- ing technology to provide clear digital sound, coast to coast. The subscription service provider is Sirius Satellite Radio. This service offers over 130 channels of music, sports, news, entertainment, and programming for chil- dren, directly from its satellites and broadcasting studios.
Page 243: Selecting Satellite Mode
Sirius ID number will display. The Sirius ID number display will time out in two minutes. Press any button on the radio to exit this screen. ESN/SID Access With REN/RER Radios While in SAT mode, press the MENU button on the radio faceplate.
Page 244: Reception Quality
242 UNDERSTANDING YOUR INSTRUMENT PANEL Reception Quality Satellite reception may be interrupted due to one of the following reasons: The vehicle is parked in an underground parking structure or under a physical obstacle. Dense tree coverage may interrupt reception in the form of short audio mutes.
Page 245 INFO Button — Except REU Radio Pressing the INFO button will cycle the display informa- tion between Artist, Song Title, and Composer (if avail- able). Also, pressing and holding the INFO button for an additional three seconds will make the radio display the Song Title all of the time (press and hold again to return to normal display).
Page 246 244 UNDERSTANDING YOUR INSTRUMENT PANEL MUSIC TYPE Button — REU Radio Pressing this button provides a MUSIC TYPES list from which you can make a selection. Once a selection is made, you can seek up, or down, or scan the channels and the radio will tune to the next station matching the selected format.
Page 247: Operating Instructions - Hands-Free Phone (If Equipped)
Buttons 1 - 6 These buttons tune the radio to the channels that you commit to pushbutton memory (12 Satellite stations). Operating Instructions — Hands-Free Phone (If Equipped) Refer to “Hands-Free Communication (UConnect )” in Section 3. Operating Instructions — Video Entertainment System (VES)™...
Page 248: Remote Sound System Controls - If Equipped
246 UNDERSTANDING YOUR INSTRUMENT PANEL VES™ Remote Control Location REMOTE SOUND SYSTEM CONTROLS — IF EQUIPPED The remote sound system controls are located on the rear surface of the steering wheel. Reach behind the wheel to access the switches. Remote Sound System Controls The right-hand control is a rocker type switch with a pushbutton in the center.
Page 249: Radio Operation
The left-hand control is a rocker type switch with a pushbutton in the center. The function of the left-hand control is different depending on which mode you are in. Radio Operation Press the top of the switch to SEEK up for the next listenable station.
Page 250: Climate Controls
248 UNDERSTANDING YOUR INSTRUMENT PANEL 5. Store the disc in its case after playing. 6. Do not expose the disc to direct sunlight. 7. Do not store the disc where temperatures may become too high. NOTE: If you experience difficulty in playing a particu- lar disc, it may be damaged (i.e.
Page 251 Blower Control Use this control to regulate the amount of air forced through the sys- tem in any mode you select. The fan speed increases as you turn the outer control ring to the right from the OFF position. NOTE: For vehicles equipped with Remote Start, the climate controls will not function during Remote Start operation if the blower control is left in the “O”...
Page 252 250 UNDERSTANDING YOUR INSTRUMENT PANEL Mode Control The mode control allows you to choose from several patterns of air distribution. You can select either a primary mode, as identified by the symbols, or a blend of two of these modes. The closer the control is to a particular mode, the more air distribu- tion you receive from that mode.
Page 253 NOTE: The air conditioning compressor operates in both MIX and DEFROST or a blend of these modes even if the fan switch is not in the A/C position. This dehu- midifies the air to help dry the windshield. To improve fuel economy, use these modes only when necessary.
Page 254: Operating Tips
252 UNDERSTANDING YOUR INSTRUMENT PANEL Operating Tips Window Fogging Windows will fog on the inside when the humidity inside the vehicle is high. This often occurs in mild or cool temperatures when it’s rainy or humid. In most cases, turning on the air conditioning (pressing the “Snow- flake”...
Page 255 Your air conditioning system is also equipped with an automatic recirculation system. When the system senses a heavy load or high heat conditions, it may use partial recirculation A/C mode to provide additional comfort. Winter Operation When operating the system during the winter months, make sure the air intake, located directly in front of the windshield, is free of ice, slush, snow, or other obstructions.
Page 257: Starting And Operating
STARTING AND OPERATING CONTENTS Starting Procedures ....259 Normal Starting ..... 259 Extreme Cold Weather (Below –20°F Or –29°C) .
Page 258 256 STARTING AND OPERATING Shifting Procedure - Electronically Shifted Transfer Case ..... . . 276 On-Road Driving Tips ....277 Off-Road Driving Tips .
Page 259 Tires — General Information ....305 Tire Pressure ......305 Tire Inflation Pressures .
Page 260 258 STARTING AND OPERATING Carbon Monoxide Warnings ... . . 330 Adding Fuel ......331 Fuel Filler Cap (Gas Cap) .
Page 261: Starting Procedures
STARTING PROCEDURES Before starting your vehicle, adjust your seat, adjust both inside and outside mirrors, and fasten your seat belts. WARNING! Do not leave children or animals inside parked vehicles in hot weather. Interior heat build up may cause serious injury or death. Start the engine with the shift lever in the NEUTRAL or PARK position.
Page 262: If Engine Fails To Start
260 STARTING AND OPERATING If Engine Fails to Start WARNING! Never pour fuel or other flammable liquids into the throttle body air inlet opening in an attempt to start the vehicle. This could result in a flash fire causing serious personal injury. WARNING! (Continued) Do not attempt to push or tow your vehicle to get it started.
Page 263 CAUTION! To prevent damage to the starter, do not crank the engine for more than 15 seconds at a time. Wait 10 to 15 seconds before trying again. If the engine has been flooded, it may start to run, but not have enough power to continue running when the key is released.
Page 264: After Starting
262 STARTING AND OPERATING After Starting The idle speed will automatically decrease as the engine warms up. WARNING! Do not leave children or animals inside parked vehicles in hot weather. Interior heat buildup may cause serious injury or death. ENGINE BLOCK HEATER — IF EQUIPPED The engine block heater warms the engine, and permits quicker starts in cold weather.
Page 265: Brake/Transmission Interlock System
CAUTION! (Continued) Shift into or out of REVERSE only after the vehicle has come to a complete stop and the engine is at idle speed. Do not shift from REVERSE, PARK, or NEUTRAL into any forward gear when the engine is above idle speed.
Page 266: Brake/Transmission Interlock Manual Override
264 STARTING AND OPERATING Brake/Transmission Interlock Manual Override Your vehicle may be equipped with a shift lock manual override. The manual override may be used in the event that the shift lever should fail to move from PARK with the key in the ON position and the brake pedal de- pressed.
Page 267: 4-Speed Automatic Transmission (3.7L Engine)
4–Speed Automatic Transmission (3.7L Engine) NOTE: Under extreme cold temperatures (-6°F (-21°C) and when in DRIVE, transmission operation may be briefly limited to only 2nd gear operation. Normal op- eration will resume once the transmission temperature has risen to a suitable level. Shifting from DRIVE to PARK or REVERSE should be done only after the accelerator pedal is released and the vehicle is stopped.
Page 268 266 STARTING AND OPERATING PARK This gear position supplements the parking brake by locking the transmission. The engine can be started in this range. Never use PARK while the vehicle is in motion. Apply the parking brake when leaving the vehicle in this range.
Page 269 NEUTRAL Move the shift lever into this gear only after the vehicle has come to a complete stop. Always depress and main- tain firm pressure on the brake pedal while in this range. Apply the parking brake when leaving the vehicle in this range for extended periods of time.
Page 270 268 STARTING AND OPERATING NOTE: If the vehicle is started in extremely cold tem- peratures, the transmission may not shift into OVER- DRIVE and will automatically select the most desirable gear for operation at this temperature. Normal operation will resume when the transmission fluid temperature has risen to a suitable level.
Page 271 NOTE: TOW/HAUL mode locks out Overdrive. Tow/Haul Button The “TOW/HAUL Indicator Light” will illuminate in the instrument cluster to indicate when the switch has been activated. Pressing the switch a second time restores normal operation. If the TOW/HAUL mode is desired, the switch must be pressed each time the engine is started.
Page 272: 5-Speed Automatic Transmission (4.0L Engine)
270 STARTING AND OPERATING If the problem is no longer detected, the transmission will return to normal operation. If the problem persists, PARK, REVERSE, and NEUTRAL will continue to oper- ate. Only 2nd gear range will operate in the DRIVE position.
Page 273: Gear Ranges
Gear Ranges NOTE: After selecting any gear range, wait a moment to allow the selected gear to engage before accelerating. This is especially important when the engine is cold. If there is a need to restart the engine, be sure to cycle the key to the LOCK position before restarting.
Page 274 272 STARTING AND OPERATING NEUTRAL Shift into NEUTRAL when the vehicle is standing for prolonged periods with the engine running. The engine may be started in this range. Set the parking brake if you must leave the vehicle. NOTE: Towing the vehicle, coasting, or driving for any other reason with the shift lever in NEUTRAL can result in severe transmission damage.
Page 275 Overdrive Operation The overdrive automatic transmission contains an elec- tronically controlled 5th gear (OVERDRIVE). The trans- mission will automatically shift from 4th gear to OVER- DRIVE if the following conditions are present: the transmission selector is in DRIVE the engine coolant has reached normal operating tem- perature the vehicle speed is above approximately 30 mph (48 km/h)
Page 276 274 STARTING AND OPERATING To reset the transmission, use the following procedure: 1. Stop the vehicle. 2. Move the shift lever to the PARK position. 3. Turn OFF the engine and be sure to turn the key to the LOCK position. 4.
Page 277: Four-Wheel Drive Operation - If Equipped
If the vehicle has not been driven in several days, the first few seconds of operation after shifting the trans- mission into gear may seem sluggish. This is due to the fluid partially draining from the torque converter into the transmission. This condition is normal and will not cause damage to the transmission.
Page 278: Shifting Procedure - Electronically Shifted Transfer Case
276 STARTING AND OPERATING When additional traction is required, the transfer case 4WD LOCK position can be used to lock the front and rear driveshafts together and force the front and rear wheels to rotate at the same speed. This is accomplished by rotating the 4WD Control Switch to the desired position.
Page 279: On-Road Driving Tips
4WD LOCK Rotate the 4WD Control Switch to the desired position. Shifts between 2WD and 4WD LOCK can be done with the vehicle stopped or in motion. With the vehicle in motion, the transfer case will engage/disengage faster if you momentarily release the accelerator pedal after turn- ing the control switch.
Page 280: Off-Road Driving Tips
278 STARTING AND OPERATING OFF-ROAD DRIVING TIPS When To Use 4L or 4LO (Low) Range When off-road driving, shift to 4L or 4LO for additional traction and control on slippery or difficult terrain, ascending or descending steep hills, and to increase low-speed pulling power.
Page 281: Driving In Snow, Mud And Sand
Flowing Water If the water is swift flowing and rising (as in storm run-off) avoid crossing until the water level recedes and/or the flow rate is reduced. If you must cross flowing water, avoid depths in excess of nine inches. The flowing water can erode the streambed causing your vehicle to sink into deeper water.
Page 282: Hill Climbing
280 STARTING AND OPERATING Hill Climbing NOTE: Before attempting to climb a hill, determine the conditions at the crest and/or on the other side. Before climbing a steep hill, shift the transmission to a lower gear and shift the transfer case to 4L or 4LO. Use first gear and 4L or 4LO for very steep hills.
Page 283: Traction Downhill
Traction Downhill Shift the transmission into a low gear and the transfer case to 4L or 4LO range. Let the vehicle go slowly down the hill with all four wheels turning against engine compression drag. This will permit you to control the vehicle speed and direction.
Page 284: Power Steering
282 STARTING AND OPERATING WARNING! Abrasive material in any part of the brakes may cause excessive wear or unpredictable braking. You might not have full braking power when you need it to prevent an accident. If you have been operating your vehicle in dirty conditions, get your brakes checked and cleaned as necessary.
Page 285: Power Steering Fluid Check
WARNING! Continued operation with reduced power steering assist could pose a safety risk to yourself and others. Service should be obtained as soon as possible. CAUTION! Prolonged operation of the steering system at the end of the steering wheel travel will increase the steering fluid temperature and it should be avoided when possible.
Page 286: Parking Brake
284 STARTING AND OPERATING PARKING BRAKE To set the parking brake, pull the lever up as firmly as possible. When the parking brake is applied with the ignition ON, the “Brake Warning Light” in the instru- ment cluster will light. To release the parking brake, pull up slightly, press the center button, then lower the lever completely.
Page 287: Anti-Lock Brake System
WARNING! Always apply the parking brake fully when leav- ing your vehicle or it may roll and cause damage or injury. Also, be certain to leave the transmission in the PARK position. Failure to do so may allow the vehicle to roll and cause damage or injury. Leaving unattended children in a vehicle is dan- gerous for a number of reasons.
Page 288 286 STARTING AND OPERATING WARNING! Significant over or under-inflation of tires or mixing sizes of tires or wheels on the vehicle can lead to loss of braking effectiveness. The ABS conducts a low-speed self-test at about 12 mph (20 km/h). If you have your foot lightly on the brake while this test is occurring, you may feel slight pedal movement.
Page 289 WARNING! (Continued) The capabilities of an ABS equipped vehicle must never be exploited in a reckless or dangerous manner, which could jeopardize the user’s safety or the safety of others. CAUTION! The Anti-Lock Brake System (ABS) is subject to possible detrimental effects of electronic interference caused by improperly installed aftermarket radios or telephones.
Page 290: Electronic Brake Control System
288 STARTING AND OPERATING Do not drive too fast for road conditions, especially when roads are wet or slushy. A wedge of water can build up between the tire tread and the road. This hydroplaning action can cause loss of traction, braking ability, and control.
Page 291: Traction Control System (Tcs)
WARNING! Anti-Lock Brake System (ABS) cannot prevent the natural laws of physics from acting on the vehicle, nor can it increase the traction afforded by prevailing road conditions. ABS cannot prevent accidents, in- cluding those resulting from excessive speed in turns, driving on very slippery surfaces, or hydro- planing.
Page 292: Brake Assist System (Bas)
290 STARTING AND OPERATING Brake Assist System (BAS) The BAS is designed to optimize the vehicle’s braking capability during emergency braking maneuvers. The system detects an emergency braking situation by sens- ing the rate and amount of brake application and then applies optimum pressure to the brakes.
Page 293: Electronic Roll Mitigation (Erm)
Electronic Roll Mitigation (ERM) This system anticipates the potential for wheel lift by monitoring the driver’s steering wheel input and the speed of the vehicle. When ERM determines that the rate of change of the steering wheel angle and vehicles speed are sufficient to potentially cause wheel lift, it applies the appropriate brake and may reduce engine power to lessen the chance that wheel lift will occur.
Page 294: Electronic Stability Program (Esp)
292 STARTING AND OPERATING Electronic Stability Program (ESP) This system enhances directional control and stability of the vehicle under various driving conditions. ESP cor- rects for over/under steering of the vehicle by applying the brake of the appropriate wheel to assist in counter- acting the over/under steer condition.
Page 295 WARNING! The Electronic Stability Program (ESP) cannot pre- vent the natural laws of physics from acting on the vehicle, nor can it increase the traction afforded by prevailing road conditions. ESP cannot prevent acci- dents, including those resulting from excessive speed in turns, driving on very slippery surfaces, or hydro- planing.
Page 296 294 STARTING AND OPERATING Partial Off This mode is entered by momentarily depressing the ESP OFF switch (located in the center stack lower switch bank). When in “Partial Off” mode, the TCS portion of ESP, except for the “limited slip” feature described in the TCS section, has been disabled and the “ESP/TCS Indi- cator Light”...
Page 297: Esp/Bas Warning Lamp
NOTE: To improve the vehicle’s traction when driving with snow chains, or starting off in deep snow, sand or gravel, it may be desirable to switch to the “Partial Off” mode by pressing the ESP OFF switch. Once the situation requiring ESP to be switched to the “Partial Off”...
Page 298: Tire Safety Information
296 STARTING AND OPERATING TIRE SAFETY INFORMATION Tire Markings 1 — U.S. DOT Safety Stan- 4 — Maximum Load dards Code (TIN) 2 — Size Designation 5 — Maximum Pressure 3 — Service Description 6 — Treadwear, Traction and Temperature Grades NOTE: P (Passenger) - Metric tire sizing is based on U.S.
Page 299 LT (Light Truck) - Metric tire sizing is based on U.S. design standards. The size designation for LT-Metric tires is the same as for P-Metric tires except for the letters “LT” that are molded into the sidewall preced- ing the size designation. Example: LT235/85R16. Temporary spare tires are high-pressure compact spares designed for temporary emergency use only.
Page 300 298 STARTING AND OPERATING Tire Sizing Chart Size Designation: P = Passenger car tire size based on U.S. design standards ...blank... = Passenger car tire based on European design standards LT = Light truck tire based on U.S. design standards T = Temporary spare tire 31 = Overall diameter in inches (in) 215 = Section width in millimeters (mm)
Page 301 Service Description: 95 = Load Index — A numerical code associated with the maximum load a tire can carry H = Speed Symbol — A symbol indicating the range of speeds at which a tire can carry a load corresponding to its load index under certain operating conditions —...
Page 302: Tire Identification Number (Tin)
300 STARTING AND OPERATING Tire Identification Number (TIN) The TIN may be found on one or both sides of the tire, however, the date code may only be on one side. Tires with white sidewalls will have the full TIN, including the date code, located on the white sidewall side of the tire.
Page 303: Tire Loading And Tire Pressure
Tire Loading and Tire Pressure Tire Placard Location NOTE: The proper cold tire inflation pressure is listed on the driver’s side B-Pillar. Tire and Loading Information Placard Tire and Loading Information Placard STARTING AND OPERATING 301 This placard tells you important information about the: 1) number of people that can be carried in the vehicle 2) total weight your vehicle can carry...
Page 304 302 STARTING AND OPERATING NOTE: Under a maximum loaded vehicle condition, gross axle weight ratings (GAWRs) for the front and rear axles must not be exceeded. For further information on GAWRs, vehicle loading, and trailer towing, refer to “Vehicle Loading” in this section. To determine the maximum loading conditions of your vehicle, locate the statement “The combined weight of occupants and cargo should never exceed XXX lbs or...
Page 305 6. If your vehicle will be towing a trailer, load from your trailer will be transferred to your vehicle. Consult this manual to determine how this reduces the available cargo and luggage load capacity of your vehicle. NOTE: The following table shows examples on how to calcu- late total load, cargo/luggage, and towing capacities of your vehicle with varying seating configurations STARTING AND OPERATING 303...
Page 306 304 STARTING AND OPERATING...
Page 307: Tires - General Information
WARNING! Overloading of your tires is dangerous. Overloading can cause tire failure, affect vehicle handling, and increase your stopping distance. Use tires of the recommended load capacity for your vehicle. Never overload them. TIRES — GENERAL INFORMATION Tire Pressure Proper tire inflation pressure is essential to the safe and satisfactory operation of your vehicle.
Page 308: Tire Inflation Pressures
306 STARTING AND OPERATING WARNING! (Continued) Unequal tire pressures from one side of the vehicle to the other can cause the vehicle to drift to the right or left. Always drive with each tire inflated to the recom- mended cold tire inflation pressure. Economy Improper inflation pressures can cause uneven wear patterns to develop across the tire tread.
Page 309 CAUTION! After inspecting or adjusting the tire pressure, al- ways reinstall the valve stem cap (if equipped). This will prevent moisture and dirt from entering the valve stem, which could damage it. Inflation pressures specified on the placard are always cold tire inflation pressure.
Page 310: Tire Pressures For High Speed Operation
308 STARTING AND OPERATING Tire Pressures For High Speed Operation The manufacturer advocates driving at safe speeds within posted speed limits. Where speed limits or condi- tions are such that the vehicle can be driven at high speeds, maintaining correct tire inflation pressure is very important.
Page 311: Limited-Use Spare - If Equipped
WARNING! Temporary use spare tires are for emergency use only. With these tires, do not drive more than 50 mph (80 km/h). Temporary use spare tires have limited tread life. When the tread is worn to the tread wear indicators, the temporary use spare tire needs to be replaced.
Page 312: Tire Spinning
310 STARTING AND OPERATING WARNING! The limited-use spare tires are for emergency use only. Installation of this limited-use spare tire affects vehicle handling. With this tire, do not drive more than 50 mph (80 km/h). Keep inflated to the cold tire inflation pressure listed on either your tire placard or limited-use spare tire and wheel assembly.
Page 313: Tread Wear Indicators
Tread Wear Indicators Tread wear indicators are in the original equipment tires to help you in determining when your tires should be replaced. 1 — Worn Tire 2 — New Tire STARTING AND OPERATING 311 These indicators are molded into the bottom of the tread grooves.
Page 314: Replacement Tires
312 STARTING AND OPERATING WARNING! Tires and the spare tire should be replaced after six years, regardless of the remaining tread. Failure to follow this warning can result in sudden tire failure. You could lose control and have an accident resulting in serious injury or death.
Page 315 WARNING! Do not use a tire, wheel size or rating other than that specified for your vehicle. Some combinations of unapproved tires and wheels may change sus- pension dimensions and performance characteris- tics, resulting in changes to steering, handling, and braking of your vehicle.
Page 316: Tire Chains
314 STARTING AND OPERATING TIRE CHAINS Use “Class S” chains or other traction aids that meet SAE Type “S” specifications. NOTE: Chains must be the proper size for the vehicle as recommended by the chain manufacturer. CAUTION! To avoid damage to your vehicle, tires or chains, observe the following precautions: Because of limited chain clearance between tires and other suspension components, it is important...
Page 317: Tire Rotation Recommendations
These cautions apply to all chain traction devices, includ- ing link and cable (radial) chains. Tire chain use is permitted only on the rear tires. NOTE: The use of class “S” chains is permitted with P235/65R17 and P225/75R16 tires. CAUTION! Do not use tire chains on vehicles equipped with tires other than P235/65R17 and P225/75R16 tires.
Page 318: Tire Pressure Monitor System (Tpms)
316 STARTING AND OPERATING These effects can be reduced by timely rotation of tires. The benefits of rotation are especially worthwhile with aggressive tread designs such as those on On/Off-Road type tires. Rotation will increase tread life, help to main- tain mud, snow, and wet traction levels, and contribute to a smooth, quiet ride.
Page 319 The tire pressure will also increase as the vehicle is driven. This is normal and there should be no adjust- ment for this increased pressure. The TPMS will warn the driver of a low tire pressure if the tire pressure falls below the low-pressure warn- ing limit for any reason, including low temperature effects and natural pressure loss through the tire.
Page 320 318 STARTING AND OPERATING CAUTION! The TPMS has been optimized for the original equipment tires and wheels. TPMS pressures and warning have been established for the tire size equipped on your vehicle. Undesirable system operation or sensor damage may result when us- ing replacement equipment that is not of the same size, type, and/or style.
Page 321: Base System
Seasonal temperature changes will affect tire pressure, and the TPMS will monitor the actual tire pressure in the tire. Base System The Tire Pressure Monitor System (TPMS) uses wireless technology with wheel rim mounted electronic sensors to monitor tire pressure levels. Sensors, mounted to each wheel as part of the valve stem, transmit tire pressure readings to the receiver module.
Page 322 320 STARTING AND OPERATING light will turn off. The vehicle may need to be driven for up to 20 minutes above 15 mph (25 km/h) in order for the TPMS to receive this information. Check TPMS Warning When a system fault is detected, the Tire Pressure Moni- toring Telltale light will flash on and off for 75 seconds and then remain on solid.
Page 323: Premium System - If Equipped
NOTE: Vehicles with Compact Spare 1. The compact spare tire does not have a tire pressure monitoring sensor. Therefore, the TPMS will not monitor the pressure in the compact spare tire. 2. If you install the compact spare tire in place of a road tire that has a pressure below the low-pressure warning limit, a chime will sound and the TPMS Telltale light will turn on upon the next ignition key cycle.
Page 324 322 STARTING AND OPERATING Three Trigger modules (mounted in three of the four wheel-wells) Various Tire Pressure Monitoring System messages, which display in the Electronic Vehicle Information Center (EVIC) Tire Pressure Monitoring Telltale light The matching full size spare wheel and tire assembly (if equipped) has a tire pressure monitoring sensor.
Page 325 Should this occur, you should stop as soon as possible and inflate the tires with low pressure (those flashing in the EVIC graphic) to the vehicle’s recommended cold placard pressure value. Once the system receives the updated tire pressures, the system will automatically update, the graphic display in the EVIC will stop flash- ing, and the Tire Pressure Monitoring Telltale light will turn off.
Page 326 324 STARTING AND OPERATING If the ignition key is cycled, this sequence will repeat, providing the system fault still exists. If the system fault no longer exists, the Tire Pressure Monitoring Telltale light will no longer flash, and the CHECK TPM SYS- TEM message will no longer display, and a pressure value will display in place of the dashes.
Page 327 NOTE: Vehicles with Compact Spare 1. The compact spare tire does not have a tire pressure monitoring sensor. Therefore, the TPMS will not monitor the pressure in the compact spare tire. 2. If you install the compact spare tire in place of a road tire that has a pressure below the low-pressure warning limit, upon the next ignition key cycle, the TPMS Telltale light will remain on and a chime will sound.
Page 328: General Information
326 STARTING AND OPERATING General Information This device complies with Part 15 of the FCC rules and RSS 210 of Industry Canada. Operation is subject to the following conditions: This device may not cause harmful interference. This device must accept any interference received, including interference that may cause undesired operation.
Page 329: L Engine
4.0L Engine The 4.0L engine is designed to meet all emissions regulations and provide satisfac- tory fuel economy and performance when using high quality unleaded gasoline hav- ing an octane range of 87 to 89. The manu- facturer recommends the use of 89 octane for optimum performance.
Page 330: Gasoline/Oxygenate Blends
328 STARTING AND OPERATING The manufacturer supports the use of reformulated gaso- lines. Properly blended reformulated gasolines will pro- vide excellent performance and durability of engine and fuel system components. Gasoline/Oxygenate Blends Some fuel suppliers blend unleaded gasoline with oxy- genates such as 10% ethanol, MTBE, and ETBE.
Page 331: Mmt In Gasoline
To fix a Non-FFV vehicle inadvertently fueled once with E-85 perform the following: drain the fuel tank (see your authorized dealer) change the engine oil and oil filter disconnect and reconnect the battery to reset the engine controller memory More extensive repairs will be required for prolonged exposure to E-85 fuel.
Page 332: Fuel System Cautions
330 STARTING AND OPERATING Fuel System Cautions CAUTION! Follow these guidelines to maintain your vehicle’s performance: The use of leaded gas is prohibited by Federal law. Using leaded gasoline can impair engine performance and damage the emission control system. An out-of-tune engine or certain fuel or ignition mal- functions, can cause the catalytic converter to over- heat.
Page 333: Adding Fuel
stopped in an open area with the engine running for more than a short period, adjust the ventilation system to force fresh, outside air into the vehicle. Guard against carbon monoxide with proper mainte- nance. Have the exhaust system inspected every time the vehicle is raised.
Page 334 332 STARTING AND OPERATING CAUTION! Damage to the fuel system or emission control system could result from using an improper fuel cap (gas cap). A poorly fitting cap could let impu- rities into the fuel system. Also, a poorly fitting aftermarket cap can cause the Malfunction Indica- tor Light (MIL) to illuminate, due to fuel vapors escaping from the system.
Page 335: Loose Fuel Filler Cap Message
WARNING! A fire may result if gasoline is pumped into a portable container that is inside of a vehicle. You could be burned. Always place gas containers on the ground while filling. Loose Fuel Filler Cap Message If the vehicle diagnostic system determines that the fuel filler cap is loose, improperly installed, or damaged, a “CHECK GASCAP”...
Page 336: Vehicle Loading
334 STARTING AND OPERATING VEHICLE LOADING Certification Label As required by National Highway Traffic Safety Admin- istration regulations, your vehicle has a certification label affixed to the driver’s side door or B-Pillar. This label contains the month and year of manufacture, Gross Vehicle Weight Rating (GVWR), Gross Axle Weight Rating (GAWR) front and rear, and Vehicle Identification Number (VIN).
Page 337 Tire Size The tire size on the label represents the actual tire size on your vehicle. Replacement tires must be equal to the load capacity of this tire size. Rim Size This is the rim size that is appropriate for the tire size listed.
Page 338: Trailer Towing
336 STARTING AND OPERATING Improper weight distributions can have an adverse affect on the way your vehicle steers and handles, and the way the brakes operate. CAUTION! Do not load your vehicle any heavier than the GVWR or the maximum front and rear GAWR. If you do, parts on your vehicle can break, or it can change the way your vehicle handles.
Page 339 measure GTW is to put your fully loaded trailer on a vehicle scale. The entire weight of the trailer must be supported by the scale. WARNING! If the gross trailer weight is 3,500 lbs (1 587 kg) or more, it is mandatory to use a weight-distributing hitch to ensure stable handling of your vehicle.
Page 340 338 STARTING AND OPERATING Frontal Area The frontal area is the maximum height and maximum width of the front of a trailer. Trailer Sway Control The trailer sway control is a telescoping link that can be installed between the hitch receiver and the trailer tongue that typically provides adjustable friction associated with the telescoping motion to dampen any unwanted trailer swaying motions while traveling.
Page 341 STARTING AND OPERATING 339 WARNING! An improperly adjusted weight distributing hitch system may reduce handling, stability, and braking performance and could result in an accident. Weight distributing systems may not be compatible with surge brake couplers. Consult with your hitch and trailer manufacturer or a reputable recreational vehicle dealer for additional information.
Page 342 340 STARTING AND OPERATING With Weight-Distributing Hitch (Correct) Improper Adjustment of Weight-Distributing Hitch (Incorrect)
Page 343: Trailer Hitch Classification
Trailer Hitch Classification Your vehicle is capable of towing trailers up to 2,000 lbs (907 kg) without added equipment or alterations to the standard equipment. Your vehicle may be factory equipped for safe towing of trailers weighing over 2,000 lbs (907 kg) with the optional trailer tow prep package.
Page 344: Trailer Towing Weights (Maximum Trailer Weight Ratings)
342 STARTING AND OPERATING Trailer Towing Weights (Maximum Trailer Weight Ratings) The following chart provides the maximum trailer weight ratings towable for your given drivetrain. Engine/ Model Transmission 3.7L/Automatic 3.7L/Automatic 3.7L/Automatic w/ Cooler 3.7L/Automatic w/Cooler 4.0L/Automatic 4.0L/Automatic 4.0L/Automatic w/ Cooler 4.0L/Automatic w/ Cooler Refer to local laws for maximum trailer towing speeds.
Page 345 When Towing Trailers with Gross Trailer Weight (GTW) between 3,500 Lbs (1 588 kg) and 5,000 Lbs (2 268 kg) The following chart provides maximum trailer weight ratings towable for the following engine/transmission combinations, ONLY if using a weight distributing hitch. Engine/ Model Transmission...
Page 346: Trailer And Tongue Weight
344 STARTING AND OPERATING Trailer and Tongue Weight Always load a trailer with 60% to 65% of the weight in the front of the trailer. This places 10% to 15% of the Gross Trailer Weight (GTW) on the tow hitch of your vehicle.
Page 347: Towing Requirements
NOTE: Remember that everything put into or on the trailer adds to the load on your vehicle. Also, additional factory-installed options or authorized dealer-installed options must be considered as part of the total load on your vehicle. Refer to the tire and loading information placard in the Tire Safety Information section of this manual for the maximum combined weight of occupants and cargo for your vehicle.
Page 348 346 STARTING AND OPERATING WARNING! (Continued) Make certain that the load is secured in the trailer and will not shift during travel. When trailering cargo that is not fully secured, dynamic load shifts can occur that may be difficult for the driver to control.
Page 349 Towing Requirements — Tires − Do not attempt to tow a trailer while using a compact spare tire. − Proper tire inflation pressures are essential to the safe and satisfactory operation of your vehicle. Refer to the Tires–General Information section of this manual on Tire Pressures for proper tire inflation procedures.
Page 350 348 STARTING AND OPERATING CAUTION! If the trailer weighs more than 1,000 lbs (454 kg) loaded, it should have its own brakes and they should be of adequate capacity. Failure to do this could lead to accelerated brake lining wear, higher brake pedal effort, and longer stopping distances.
Page 351 The electrical connections are all complete to the vehicle, but you must mate the harness to a trailer connector. Refer to the following illustrations. 4-Pin Connector 1 — Female Pins 4 — Park 2 — Male Pin 5 — Left Stop/Turn 3 —...
Page 352: Towing Tips
350 STARTING AND OPERATING Towing Tips Before setting out on a trip, practice turning, stopping and backing up the trailer in an area away from heavy traffic. Towing Tips — Automatic Transmission The “D” range can be selected when towing. However, if frequent shifting occurs while in this range, the TOW/ HAUL button should be selected.
Page 353: Recreational Towing (Behind Motorhome, Etc.)
Towing Tips — Cooling System To reduce potential for engine and transmission over- heating, take the following actions: − City Driving When stopped for short periods of time, put the trans- mission in NEUTRAL and increase engine idle speed. − Highway Driving Reduce speed.
Page 354: Towing - 4Wd Or All-Wheel Drive Models
352 STARTING AND OPERATING Towing — 4WD or All-Wheel Drive Models CAUTION! Front or rear wheel lifts should not be used. Internal damage to the transmission or transfer case will occur if a front or rear wheel lift is used when recreational towing.
Page 355: What To Do In Emergencies
WHAT TO DO IN EMERGENCIES CONTENTS Hazard Warning Flasher ....354 If Your Engine Overheats ....355 Jacking And Tire Changing .
Page 356: Hazard Warning Flasher
354 WHAT TO DO IN EMERGENCIES HAZARD WARNING FLASHER The Hazard Warning Flasher switch is located on the lower switch bank below the climate controls. Hazard Warning Switch To operate the Hazard Warning flasher, press the switch and all front and rear directional signals will flash intermittently.
Page 357: If Your Engine Overheats
IF YOUR ENGINE OVERHEATS In any of the following situations, you can reduce the potential for overheating your engine by taking the appropriate action. On the highways — slow down. In city traffic — while stopped, put transmission in NEUTRAL, but do not increase engine idle speed. NOTE: There are steps that you can take to slow down an impending overheat condition.
Page 358: Jacking And Tire Changing
356 WHAT TO DO IN EMERGENCIES JACKING AND TIRE CHANGING WARNING! Getting under a jacked-up vehicle is dangerous. The vehicle could slip off the jack and fall on you. You could be crushed. Never get any part of your body under a vehicle that is on a jack. If you need to get under a raised vehicle, take it to a service center where it can be raised on a lift.
Page 359: Spare Tire Removal
Spare Tire Removal Fit the jack handle extension over the drive nut. Use the lug wrench to rotate the nut counterclockwise until the spare is on the ground with enough slack in the cable to allow you to pull the tire out from under the vehicle. Lowering/Raising Spare Tire WHAT TO DO IN EMERGENCIES 357 CAUTION!
Page 360: Preparations For Jacking
358 WHAT TO DO IN EMERGENCIES Preparations For Jacking 1. Park the vehicle on a firm level surface. Avoid icy or slippery areas. WARNING! Do not attempt to change a tire on the side of the vehicle close to moving traffic. Pull far enough off the road to avoid being hit when operating the jack or changing the wheel.
Page 361 WARNING! (Continued) Set the parking brake firmly and set an automatic transmission in PARK; a manual transmission in REVERSE. Never start or run the engine with the vehicle on a jack. Do not let anyone sit in the vehicle when it is on a jack.
Page 362 360 WHAT TO DO IN EMERGENCIES 4. Locate the jack as shown. For the front tires, place it in the notch on the body weld seam behind wheel to be changed. For the rear tires, place it under the axle by the wheel to be changed.
Page 363 WARNING! Raising the vehicle higher than necessary can make the vehicle less stable and cause an accident. It could slip off the jack and hurt someone near it. Raise the vehicle only enough to remove the tire. 6. Remove the lug nuts and wheel. 7.
Page 364: Jump-Starting
362 WHAT TO DO IN EMERGENCIES JUMP-STARTING WARNING! Battery fluid is a corrosive acid solution; do not allow battery fluid to contact eyes, skin or cloth- ing. Don’t lean over battery when attaching clamps or allow the clamps to touch each other. If acid splashes in eyes or on skin, flush the contami- nated area immediately with large quantities of water.
Page 365 5. Connect the other cable, first to the negative terminal of the booster battery and then to the engine of the vehicle with the discharged battery. Make sure you have a good contact on the engine. WARNING! Do not connect the cable to the negative post of the discharge battery.
Page 366: Towing A Disabled Vehicle
364 WHAT TO DO IN EMERGENCIES TOWING A DISABLED VEHICLE Proper towing or lifting equipment is required to prevent damage to your vehicle. Use of safety chains is recom- mended. Attach towing device to main structural mem- bers of the vehicle not to bumpers or associated brack- ets.
Page 367: Maintaining Your Vehicle
MAINTAINING YOUR VEHICLE CONTENTS Engine Compartment — 3.7L ... . . 367 Engine Compartment — 4.0L ... . . 368 Onboard Diagnostic System —...
Page 368 366 MAINTAINING YOUR VEHICLE Brake System ..... . . 388 Automatic Transmission ....389 Transfer Case .
Page 369: Engine Compartment - 3.7L
ENGINE COMPARTMENT — 3.7L 1 — Air Cleaner Filter 2 — Engine Oil Dipstick 3 — Brake Fluid Reservoir 4 — Integrated Power Module 5 — Battery MAINTAINING YOUR VEHICLE 367 6 — Washer Fluid Reservoir 7 — Engine Coolant Reservoir 8 —...
Page 370: Engine Compartment - 4.0L
368 MAINTAINING YOUR VEHICLE ENGINE COMPARTMENT — 4.0L 1 — Air Cleaner Filter 2 — Engine Oil Dipstick 3 — Brake Fluid Reservoir 4 — Integrated Power Module 5 — Battery 6 — Engine Oil Fill 7 — Washer Fluid Reservoir 8 —...
Page 371: Onboard Diagnostic System - Obd Ii
ONBOARD DIAGNOSTIC SYSTEM — OBD II Your vehicle is equipped with a sophisticated Onboard Diagnostic system called OBD II. This system monitors the performance of the emissions, engine, and automatic transmission control systems. When these systems are operating properly, your vehicle will provide excellent performance and fuel economy, as well as engine emis- sions well within current government regulations.
Page 372: Loose Fuel Filler Cap Message
370 MAINTAINING YOUR VEHICLE Loose Fuel Filler Cap Message After fuel is added, the vehicle diagnostic system can determine if the fuel filler cap is possibly loose, improp- erly installed, or damaged. A loose fuel filler cap message will be displayed in the instrument cluster. Tighten the gas cap until a clicking sound is heard.
Page 373 Your vehicle has a simple ignition key-actuated test, which you can use prior to going to the test station. To check if your vehicle’s OBD II system is ready, you must do the following: 1. Insert your ignition key into the ignition switch. 2.
Page 374: Replacement Parts
372 MAINTAINING YOUR VEHICLE Regardless of whether your vehicle’s OBD II system is ready or not, if the MIL is illuminated during normal vehicle operation you should have your vehicle serviced before going to the I/M station. The I/M station can fail your vehicle because the MIL is on with the engine running.
Page 375: Maintenance Procedures
MAINTENANCE PROCEDURES The pages that follow contain the required maintenance services determined by the engineers who designed your vehicle. Besides the maintenance items for which there are fixed maintenance intervals, there are other items that should operate satisfactorily without periodic maintenance. However, if a malfunction of these items does occur, it could adversely affect the engine or vehicle performance.
Page 376 374 MAINTAINING YOUR VEHICLE Change Engine Oil Refer to the Maintenance Schedule in Section 8 for the proper maintenance intervals. NOTE: Under no circumstances should oil change in- tervals exceed 6,000 miles (10 000 km) or 6 months, whichever comes first. Engine Oil Selection For best performance and maximum protection for all engines under all types of operating conditions, the...
Page 377 Lubricants which do not have both the engine oil certi- fication mark and the correct SAE viscosity grade num- ber should not be used. Engine Oil Viscosity (4.0L Engine) SAE 10W-30 engine oil is preferred. SAE 5W-30 engine oil is allowed during cold weather only to improve cold weather starting.
Page 378: Engine Air Cleaner Filter
376 MAINTAINING YOUR VEHICLE NOTE: For best access to the oil filter, a drive on hoist should be used instead of a chassis hoist (3.7L Only). Engine Oil Filter Selection All of the manufacturer’s engines have a full-flow type disposable oil filter. Use a filter of this type for replace- ment.
Page 379: Maintenance-Free Battery
Maintenance-Free Battery The top of the maintenance-free battery is permanently sealed. You will never have to add water, nor is periodic maintenance required. WARNING! Battery acid is a corrosive acid solution and can burn or even blind you. Do not allow battery fluid to contact your eyes, skin, or clothing.
Page 380: Air Conditioner Maintenance
378 MAINTAINING YOUR VEHICLE Air Conditioner Maintenance For best possible performance, your air conditioner should be checked and serviced by an authorized dealer at the start of each warm season. This service should include cleaning of the condenser fins and a performance test.
Page 381: Body Lubrication
Body Lubrication Locks and all body pivot points, including such items as seat tracks, door hinge pivot points and rollers, liftgate, tailgate, sliding doors and hood hinges, should be lubri- cated periodically with a lithium based grease such as MOPAR Spray White Lube to assure quiet, easy opera- tion and to protect against rust and wear.
Page 382: Exhaust System
380 MAINTAINING YOUR VEHICLE WARNING! Commercial windshield washer solvents are flam- mable. They could ignite and burn you. Care must be exercised when filling or working around the washer solution. Exhaust System The best protection against carbon monoxide entry into the vehicle body is a properly maintained engine exhaust system.
Page 383 CAUTION! Damage to the catalytic converter can result if your vehicle is not kept in proper operating condition. In the event of engine malfunction, particularly involv- ing engine misfire or other apparent loss of perfor- mance, have your vehicle serviced promptly. Contin- ued operation of your vehicle with a severe malfunction could cause the converter to overheat, resulting in possible damage to the converter and...
Page 384: Cooling System
382 MAINTAINING YOUR VEHICLE To minimize the possibility of catalytic converter dam- age: Do not shut off the engine or interrupt the ignition when the transmission is in gear and the vehicle is in motion. Do not try to start the engine by pushing or towing the vehicle.
Page 385 Engine Coolant Checks Check engine coolant (antifreeze) protection every 12 months (before the onset of freezing weather, where applicable). If the engine coolant (antifreeze) is dirty or rusty in appearance, the system should be drained, flushed and refilled with fresh engine coolant (anti- freeze).
Page 386 384 MAINTAINING YOUR VEHICLE CAUTION! Mixing of engine coolant (antifreeze) other than the specified HOAT engine coolant (antifreeze) may result in decreased corrosion protection and engine damage. If a non-HOAT engine coolant (antifreeze) is introduced into the cooling system in an emergency, it should be replaced with the specified engine coolant (antifreeze) as soon as possible.
Page 387 When adding engine coolant (antifreeze): The manufacturer recommends using MOPAR Antifreeze/ Coolant 5 Year/100,000 Mile Formula HOAT (Hybrid Organic Additive Technology). Mix a minimum solution of 50% HOAT engine coolant (antifreeze) and distilled water. Use higher concentra- tions (not to exceed 70%) if temperatures below -34°F (-37°C) are anticipated.
Page 388 386 MAINTAINING YOUR VEHICLE WARNING! The warning words “DO NOT OPEN HOT” on the cooling system pressure cap are a safety precaution. Never add engine coolant (antifreeze) when the engine is overheated. Do not loosen or remove the cap to cool an overheated engine. Heat causes pressure to build up in the cooling system.
Page 389 When additional engine coolant (antifreeze) is needed to maintain the proper level, it should be added to the coolant bottle. Do not overfill. Points to Remember NOTE: When the vehicle is stopped after a few miles/ kilometers of operation, you may observe vapor coming from the front of the engine compartment.
Page 390: Brake System
388 MAINTAINING YOUR VEHICLE Do not change the thermostat for Summer or Winter operation. If replacement is ever necessary, install only the correct type thermostat. Other designs may result in unsatisfactory cooling performance, poor gas mile- age, and increased emissions. Brake System In order to assure brake system performance, all brake system components should be inspected periodically.
Page 391: Automatic Transmission
WARNING! Overfilling the brake fluid reservoir can result in spilling brake fluid on hot engine parts and the brake fluid catching fire. Use of a brake fluid that may have a lower initial boiling point or unidentified as to specification, may result in sudden brake failure during hard prolonged braking.
Page 392: Transfer Case
390 MAINTAINING YOUR VEHICLE Selection of Lubricant It is important that the proper lubricant is used in the transmission to assure optimum transmission perfor- mance. Use only manufacturer’s recommended transmis- sion fluid. Refer to “Fluids, Lubricants, and Genuine Parts” in this section for the correct fluid type. It is important that the transmission fluid be maintained at the prescribed level using the recommended fluid.
Page 393: Front/Rear Axle Fluid
Adding Fluid Fluid should be added only at filler hole until fluid begins to run out of the hole. Drain First remove fill plug (B), then drain plug (C). Recom- mended tightening torque for drain and fill plugs is 15–25 ft lbs (20–34 N·m). MAINTAINING YOUR VEHICLE 391 CAUTION! When replacing plugs, do not overtighten.
Page 394: Appearance Care And Protection From Corrosion
392 MAINTAINING YOUR VEHICLE Adding Fluid Add lubricant only at the fill hole and only to the level specified above. Selection of Lubricant Use only manufacturer’s recommended fluid. Refer to “Fluids, Lubricants, and Genuine Parts” in this section for the correct fluid type. Appearance Care And Protection From Corrosion Protection Of Body And Paint From Corrosion Vehicle body care requirements vary according to geo-...
Page 395 Washing Wash your vehicle regularly. Always wash your ve- hicle in the shade using MOPAR Car Wash or a mild car wash soap, and rinse the panels completely with clear water. If insects, tar, or other similar deposits have accumu- lated on your vehicle, use MOPAR Super Kleen Bug and Tar Remover to remove.
Page 396 394 MAINTAINING YOUR VEHICLE If you detect any stone chips or scratches in the paint, touch them up immediately. The cost of such repairs is considered the responsibility of the owner. If your vehicle is damaged due to an accident or similar cause which destroys the paint and protective coating, have your vehicle repaired as soon as pos- sible.
Page 397 For tough stains, apply MOPAR Total Clean or a mild soap solution to a clean, damp cloth and remove stain. Use a fresh, damp towel to remove soap residue. For grease stains, apply MOPAR Cleaner to a clean, damp cloth and remove stain. Use a fresh, damp towel to remove soap residue.
Page 398: Fuses
396 MAINTAINING YOUR VEHICLE Cleaning Plastic Instrument Cluster Lenses The lenses in front of the instruments in this vehicle are molded in clear plastic. When cleaning the lenses, care must be taken to avoid scratching the plastic. 1. Clean with a wet soft rag. A mild soap solution may be used, but do not use high alcohol content or abrasive cleaners.
Page 399 Totally Integrated Power Module (TIPM) Cavity Cartridge Mini- Fuse Fuse 40 Amp Power Folding Seat Green 30 Amp Transfer Case/Pwr Pink Liftgate Module Cavity Cartridge Fuse 40 Amp Green 25 Amp Natural 25 Amp Natural 40 Amp Green 30 Amp Pink 40 Amp Green...
Page 400 398 MAINTAINING YOUR VEHICLE Cavity Cartridge Mini- Fuse Fuse 30 Amp Sway Bar/ Pink THATCHAM Lock- Unlock/Power Sliding Door Module 60 Amp Ignition Off Draw Yellow (IOD) — Main 40 Amp EBL (Rear Window Green Defogger) 30 Amp Rear Blower Pink 40 Amp Starter Solenoid...
Page 401 Cavity Cartridge Mini- Fuse Fuse 20 Amp Front Heated Seat Yellow 20 Amp Rear Heated Seat (If Yellow Equipped) 20 Amp Ignition Off Draw — Yellow Vehicle Entertainment System (IOD-VES), Sat- ellite Digital Audio Re- ceiver (SDARS), DVD, Hands-Free Module (HFM), RADIO, An- tenna (ANT), Universal Garage Door Opener...
Page 402 400 MAINTAINING YOUR VEHICLE Cavity Cartridge Mini- Fuse Fuse 20 Amp COL MOD, IR SNS, Yellow Heater Ventilation, Air Conditioning/ Automatic Tempera- ture Control (HVAC/ ATC), Rearview Mirror (RR VW MIR), Cabin Compartment Node (CCN), Transfer Case Switch (T-CASE SW), RUN/ST, Multifunc- tion Control Switch (MULTIFTCN SW),...
Page 403 Cavity Cartridge Mini- Fuse Fuse 25 Amp Rear Wiper (REAR Natural WIPER) 20 Amp Fuel Pump (FUEL Yellow PUMP), Diesel Lift Pump (DSL LIFT PUMP) — Export Only 10 Amp Power Mirror Switch (PWR MIRR SW), Driver Window Switch (DRVR WIND SW) 10 Amp Ignition Switch (IGN SW), Window Module...
Page 404 402 MAINTAINING YOUR VEHICLE Cavity Cartridge Mini- Fuse Fuse 10 Amp 20 Amp Yellow 10 Amp 25 Amp Natural Description When installing the integrated power module Heated Mirrors cover, it is important to ensure the cover is prop- erly positioned and fully latched. Failure to do so Power Outlet #3 (BATT) may allow water to get into the integrated power...
Page 405: Replacement Light Bulbs
REPLACEMENT LIGHT BULBS LIGHT BULBS — Interior Dome Light ......TL212–2 Liftgate Lamp ......567 Overhead Console Lights .
Page 406: Left Front Turn Signal
404 MAINTAINING YOUR VEHICLE 5. Disconnect the electrical connector and replace the bulb. Left Front Turn Signal 1. Turn the steering wheel all the way to the right (full right lock). 2. Remove the door in the left wheel liner by twisting counter clockwise.
Page 407: Right Front Turn Signal
Right Front Turn Signal 1. Open the hood. 2. Reach behind the headlight unit in the engine com- partment to access the turn signal bulb. 3. Twist the bulb counterclockwise to remove. 4. Disconnect the electrical connector and replace the bulb.
Page 408: Rear Tail, Stop, Turn Signal, And Backup Lights
406 MAINTAINING YOUR VEHICLE CAUTION! Do not touch the new bulb with your fingers. Oil contamination will severely shorten bulb life. If the bulb comes in contact with any oily surface, clean the bulb with rubbing alcohol. Rear Tail, Stop, Turn Signal, and Backup Lights 1.
Page 409: Center High Mounted Stop Light (Chmsl)
6. Disconnect the electrical connector. 7. Remove the bulb from the backplate. Center High Mounted Stop Light (CHMSL) 1. Remove the two screws securing the CHMSL. Screw Locations MAINTAINING YOUR VEHICLE 407 2. Disconnect the electrical connector and washer hose (if equipped) from the CHMSL.
Page 410: Fluid Capacities
408 MAINTAINING YOUR VEHICLE FLUID CAPACITIES Fuel (Approximate) Engine Oil with Filter 3.7 Liter Engine (SAE 5W-20, API Certified) 4.0 Liter Engine (SAE 10W-30, API Certified) Cooling System * 3.7 Liter Engine (MOPAR Antifreeze/Engine Coolant 5 Year/100,000 Mile Formula) 4.0 Liter Engine (MOPAR Antifreeze/Engine Coolant 5 Year/100,000 Mile Formula) * Includes heater and coolant recovery bottle filled to MAX level.
Page 411: Fluids, Lubricants And Genuine Parts
FLUIDS, LUBRICANTS AND GENUINE PARTS Engine Component Engine Coolant Engine Oil (3.7L Engine) Engine Oil (4.0L Engine) Engine Oil Filter Spark Plugs (3.7L Engine) Spark Plugs (4.0L Engine) Fuel Selection (3.7L Engine) Fuel Selection (4.0L Engine) Fluid, Lubricant, or Genuine Part MOPAR Antifreeze/Coolant 5 Year/100,000 Mile Formula HOAT (Hybrid Organic Additive Technology) or equivalent Use API Certified SAE 5W-20 Engine Oil, meeting the requirements of...
Page 412: Chassis
410 MAINTAINING YOUR VEHICLE Chassis Component Automatic Transmission Transfer Case Front Axle Rear Axle Brake Master Cylinder Power Steering Reservoir Fluid, Lubricant, or Genuine Part MOPAR ATF+4 Automatic Transmission Fluid MOPAR ATF+4 Automatic Transmission Fluid SAE 80W-90 Multi-Purpose Type, GL-5 Gear Lubricant or equivalent SAE 75W-140 Synthetic Gear Lubricant or equivalent MOPAR DOT 3 Brake Fluid, SAE J1703 should be used.
Page 413: Maintenance Schedules
MAINTENANCE SCHEDULES CONTENTS Emissions Control System Maintenance ..412 Maintenance Schedule ....412 Required Maintenance Intervals ..414...
Page 414: Emissions Control System Maintenance
412 MAINTENANCE SCHEDULES EMISSIONS CONTROL SYSTEM MAINTENANCE The Scheduled Maintenance services listed in bold type must be done at the times or mileages specified to ensure the continued proper functioning of the emissions control system. These and all other maintenance services in- cluded in this manual, should be done to provide best vehicle performance and reliability.
Page 415 NOTE: The oil change indicator message will not monitor the time since the last oil change. Change your vehicles oil if it has been 6 months since your last oil change even if the oil change indicator message is NOT illumi- nated.
Page 416 414 MAINTENANCE SCHEDULES Once a Month Check tire pressure and look for unusual wear or damage. Inspect the battery and clean and tighten the terminals as required. Check the fluid levels of coolant reservoir, brake master cylinder, and transmission and add as needed. Check all lights and other electrical items for correct operation.
Page 417 6,000 Miles (10,000 km) or 6 Months Maintenance Service Schedule Change the engine oil and engine oil filter. Rotate tires. Odometer Reading Date Repair Order # Dealer Code Signature Authorized Chrysler Dealer 12,000 Miles (20,000 km) or 12 Months Maintenance Service Schedule Change the engine oil and engine oil filter.
Page 418: Service Schedule
416 MAINTENANCE SCHEDULES 18,000 Miles (30,000 km) or 18 Months Maintenance Service Schedule Change the engine oil and engine oil filter. Rotate tires. Inspect the front and rear axle fluid; change if using your vehicle for police, taxi, fleet, off-road or frequent trailer towing.
Page 419 36,000 Miles (60,000 km) or 36 Months Maintenance Service Schedule Change the engine oil and engine oil filter. Rotate tires. If using your vehicle for any of the following: Dusty or off-road conditions. Inspect the engine air cleaner filter; replace if necessary. Inspect the brake linings;...
Page 420 418 MAINTENANCE SCHEDULES 54,000 Miles (90,000 km) or 54 Months Maintenance Service Schedule Change the engine oil and engine oil filter. Rotate tires. Inspect the front and rear axle fluid; change if using your vehicle for police, taxi, fleet, off-road or frequent trailer towing.
Page 421 66,000 Miles (110,000 km) or 66 Months Maintenance Service Schedule Change the engine oil and engine oil filter. Rotate tires. Odometer Reading Date Repair Order # Dealer Code Signature Authorized Chrysler Dealer 72,000 Miles (120,000 km) or 72 Months Maintenance Service Schedule Change the engine oil and engine oil filter.
Page 422 420 MAINTENANCE SCHEDULES 78,000 Miles (130,000 km) or 78 Months Maintenance Service Schedule Change the engine oil and engine oil filter. Rotate tires. Odometer Reading Repair Order # Dealer Code Signature Authorized Chrysler Dealer 84,000 Miles (140,000 km) or 84 Months Maintenance Service Schedule Change the engine oil and engine oil filter.
Page 423 90,000 Miles (150,000 km) or 90 Months Maintenance Service Schedule Change the engine oil and engine oil filter. Rotate tires. Replace the engine air cleaner filter. Inspect and replace PCV valve if necessary. † Replace the spark plugs (3.7L Engine). Adjust parking brake on vehicles equipped with four-wheel disc brakes.
Page 424 422 MAINTENANCE SCHEDULES 102,000 Miles (170,000 km) or 102 Months Maintenance Service Schedule Change the engine oil and engine oil filter. Rotate tires. Replace the spark plugs (4.0L Engine). Replace the timing belt (4.0L Engine). Flush and replace the engine coolant. Odometer Reading Repair Order # Dealer Code...
Page 425 120,000 Miles (200,000 km) or 120 Months Maintenance Service Schedule Change the engine oil and engine oil filter. Rotate tires. Replace the engine air cleaner filter. Replace the ignition cables (3.7L Engine). Replace the spark plugs (3.7L Engine). Inspect the brake linings; replace if necessary. Adjust parking brake on vehicles equipped with four-wheel disc brakes.
Page 426 424 MAINTENANCE SCHEDULES 132,000 Miles (220,000 km) or 132 Months Maintenance Service Schedule Change the engine oil and engine oil filter. Rotate tires. If using your vehicle for any of the following: Dusty or off-road conditions. Inspect the engine air cleaner filter; replace if necessary.
Page 427 144,000 Miles (240,000 km) or 144 Months Maintenance Service Schedule Change the engine oil and engine oil filter. Rotate tires. If using your vehicle for any of the following: Dusty or off-road conditions. Inspect the engine air cleaner filter; replace if necessary. Inspect the brake linings;...
Page 428 426 MAINTENANCE SCHEDULES † This maintenance is recommended by the manufacturer to the owner, but is not required to maintain emissions warranty. WARNING! You can be badly injured working on or around a motor vehicle. Do only that service work for which you have the knowledge and the right equipment.
Page 429: If You Need Consumer Assistance
IF YOU NEED CONSUMER ASSISTANCE CONTENTS Suggestions For Obtaining Service For Your Vehicle......429 Prepare For The Appointment .
Page 430 428 IF YOU NEED CONSUMER ASSISTANCE Publication Order Forms ....433 Department Of Transportation Uniform Tire Quality Grades ......435 Treadwear .
Page 431: Suggestions For Obtaining Service For Your Vehicle
SUGGESTIONS FOR OBTAINING SERVICE FOR YOUR VEHICLE Prepare For The Appointment If you’re having warranty work done, be sure to have the right papers with you. Take your warranty folder. All work to be performed may not be covered by the warranty.
Page 432: Chrysler Llc Customer Center
430 IF YOU NEED CONSUMER ASSISTANCE This is why you should always talk to an authorized dealer’s service manager first. Most matters can be re- solved with this process. If for some reason you are still not satisfied, talk to the general manager or owner of the authorized dealer- ship.
Page 433: Customer Assistance For The Hearing Or Speech Impaired (Tdd/Tty)
Customer Assistance For The Hearing Or Speech Impaired (TDD/TTY) To assist customers who have hearing difficulties, the manufacturer has installed special TDD (Telecommuni- cation Devices for the Deaf) equipment at its Customer Center. Any hearing or speech impaired customer, who has access to a TDD or a conventional teletypewriter (TTY) in the United States, can communicate with the manufacturer by dialing 1–800–380–CHRY.
Page 434: Warranty Information (U.s. Vehicles Only)
432 IF YOU NEED CONSUMER ASSISTANCE WARNING! Engine exhaust, some of its constituents, and certain vehicle components contain, or emit, chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. In addition, certain fluids contained in vehicles and certain prod- ucts of component wear contain, or emit, chemicals known to the State of California to cause cancer and birth defects or other reproductive harm.
Page 435: In Canada
To contact NHTSA, you may either call the Auto Safety Hotline toll free at 1–888–327–4236 (TTY: 1–800–424– 9153), or go to http://www.safercar.gov; or write to: Administra- tor, NHTSA, 400 Seventh Street, SW., Washington, D.C. 20590. You can also obtain other information about motor vehicle safety from http://www.safercar.gov.
Page 436 434 IF YOU NEED CONSUMER ASSISTANCE Diagnostic Procedure Manuals Diagnostic Procedure Manuals are filled with dia- grams, charts and detailed illustrations. These practi- cal manuals make it easy for students and technicians to find and fix problems on computer-controlled ve- hicle systems and features.
Page 437: Department Of Transportation Uniform Tire
DEPARTMENT OF TRANSPORTATION UNIFORM TIRE QUALITY GRADES The following tire grading categories were established by the National Highway Traffic Safety Administration. The specific grade rating assigned by the tire’s manufacturer in each category is shown on the sidewall of the tires on your vehicle.
Page 438 436 IF YOU NEED CONSUMER ASSISTANCE Temperature Grades The temperature grades are A (the highest), B, and C, representing the tire’s resistance to the generation of heat and its ability to dissipate heat, when tested under controlled conditions on a specified indoor laboratory test wheel.
Page 439 INDEX...
Page 440 438 INDEX About Your Brakes ..... . . 284 ABS (Anti-Lock Brake System) ....285 Adding Fuel .
Page 441 Autostick ......272 Auxiliary Electrical Outlet (Power Outlet) ..154 Auxiliary Power Outlet .
Page 442 440 INDEX Cargo Load Floor ......162 Cargo Slide Out System Load N Go ......163 Cargo Tie-Downs .
Page 443 Selection of Coolant (Antifreeze) ..383,408,409 Corrosion Protection ..... 392 Cupholders ......158 Customer Assistance .
Page 444 442 INDEX Emergency, In Case of Jacking ......356 Overheating ......355 Towing .
Page 445 Flashers Hazard Warning ..... . . 354 Turn Signal ....176,404,405,406 Flooded Engine Starting .
Page 446 444 INDEX Gasoline, Reformulated ....327 Gasoline/Oxygenate Blends ....328 Gauges Coolant Temperature .
Page 447 Infant Restraint ......65,66 Inflation Pressure Tires ....306 Information Center, Vehicle .
Page 448 446 INDEX Brake Warning ......177 Bulb Replacement ..... . 403 Cargo .
Page 449 Load N Go Sliding Cargo Floor ....163 Loading Vehicle ......334 Tires .
Page 450 448 INDEX Octane Rating, Gasoline (Fuel) ... . 326,327 Odometer Trip ....... . 186 Off-Pavement Driving (Off-Road) .
Page 451 Power Door Locks ......28 Inverter ......156 Mirrors .
Page 452 450 INDEX Restraints, Occupant ..... . 37 Roll Over Warning ......4 Roof Type Carrier .
Page 453 Service Contract ......431 Service Engine Soon Light (Malfunction Indicator) ....186 Service Manuals .
Page 454 452 INDEX Supplemental Restraint System - Airbag ..48 Synthetic Engine Oil ..... . 375 System, Remote Starting .
Page 455 Towing ....... 336 24-Hour Towing Assistance ....101 Disabled Vehicle .
Page 456 454 INDEX Uniform Tire Quality Grades ....435 Universal Transmitter ..... 144 Upholstery Care .
Page 457: Installation Of Radio Transmitting Equipment
INSTALLATION OF RADIO TRANSMITTING EQUIPMENT Special design considerations are incorporated into this vehicle’s electronic system to provide immunity to radio frequency signals. Mobile two-way radios and telephone equipment must be installed properly by trained person- nel. The following must be observed during installation. The positive power connection should be made directly to the battery and fused as close to the battery as possible.
Page 458 INSTALLATION OF RADIO TRANSMITTING EQUIPMENT Special design considerations are incorporated into this vehicle’s electronic system to provide immunity to radio frequency signals. Mobile two-way radios and telephone equipment must be installed properly by trained person- nel. The following must be observed during installation. The positive power connection should be made directly to the battery and fused as close to the battery as possible.
Page 459 Chrysler LLC 81-326-0913 First Edition Printed in U.S.A.

This manual is also suitable for:

2009 nitro

Save PDF
