Page 3: Introduction
TABLE OF CONTENTS SECTION ............. 3 INTRODUCTION THINGS TO KNOW BEFORE STARTING YOUR VEHICLE UNDERSTANDING THE FEATURES OF YOUR VEHICLE...
Page 5: Table Of Contents
CONTENTS Introduction ......4 How To Use This Manual ....4 Warnings And Cautions .
Page 6: Introduction
4 INTRODUCTION INTRODUCTION Congratulations on selecting your new Chrysler LLC vehicle. Be assured that it represents precision workman- ship, distinctive styling, and high quality - all essentials that are traditional to our vehicles. This Owner’s Manual has been prepared with the assis- tance of service and engineering specialists to acquaint you with the operation and maintenance of your vehicle.
Page 7 INTRODUCTION 5...
Page 8: Vehicle Identification Number
6 INTRODUCTION WARNINGS AND CAUTIONS This Owner’s Manual contains WARNINGS against op- erating procedures that could result in an accident or bodily injury. It also contains CAUTIONS against proce- dures that could result in damage to your vehicle. If you do not read this entire manual, you may miss important information.
Page 9: Vehicle Modifications/Alterations
INTRODUCTION 7 VEHICLE MODIFICATIONS/ALTERATIONS WARNING! Any modifications or alterations to this vehicle could seriously affect its roadworthiness and safety and may lead to an accident resulting in serious injury or death.
Page 11: Things To Know Before Starting Your Vehicle
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE CONTENTS A Word About Your Keys ....12 Wireless Ignition Node (WIN) Sentry Key ......14 Replacement Keys .
Page 12 10 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Sliding Side Door ..... . 40 Power Sliding Side Door — If Equipped ..41 Sliding Side Door Child Protection Lock .
Page 13 Rear Seat Delete Feature (Commercial Vehicles Only) — If Equipped ..88 Restraining Infants And Small Children With Seat Delete Feature (Commercial Vehicles Only) ....89 Engine Break-In Recommendations THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 11 Safety Tips...
Page 14: Things To Know Before Starting Your Vehicle 9
12 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE A WORD ABOUT YOUR KEYS Your vehicle uses a keyless ignition system. This system consists of a Remote Keyless Entry (RKE) transmitter with integrated ignition key and a Wireless Ignition Node (WIN) with integral ignition switch. You can insert the double-sided key into the ignition switch with either side up.
Page 15 Integrated Ignition Key The integrated ignition key operates the ignition switch. It also contains the Remote Keyless Entry (RKE) trans- mitter and a emergency key, which stores in the rear of the RKE transmitter. The emergency key allows for entry into the vehicle should the battery in the vehicle or the RKE transmitter go dead.
Page 16: Sentry Key
14 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: Power window switches will also remain active for up to 90 seconds after the ignition switch has been turned OFF, depending upon the accessory delay setting. Opening the front door will cancel this feature. WARNING! NEVER leave children alone in a vehicle.
Page 17 the vehicle. The system will shut the engine off in two seconds if an invalid RKE transmitter is used to start the engine. After turning the ignition switch to the ON position, the Vehicle Security Light will turn on for three seconds for a bulb check.
Page 18: Replacement Keys
16 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Replacement Keys NOTE: Only RKE transmitters that are programmed to the vehicle electronics can be used to start and operate the vehicle. Once an RKE transmitter is programmed to a vehicle, it cannot be reprogrammed to any other vehicle. CAUTION! Always remove the keys from the vehicle and lock all doors when leaving the vehicle unattended.
Page 19: Vehicle Security Alarm - If Equipped
VEHICLE SECURITY ALARM — IF EQUIPPED The Vehicle Security Alarm monitors the vehicle doors for unauthorized entry and the ignition switch for unau- thorized operation. When the alarm is activated, the Vehicle Security Alarm provides both audible and visible signals. For the first three minutes, the headlights, park lamps and/or turn signals will flash and Vehicle Security Light will flash repeatedly and the horn will sound.
Page 20 18 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Disarm The System Either press the UNLOCK button on the RKE transmitter or insert a valid ignition key into the ignition switch. NOTE: • The driver’s door key cylinder and the liftgate button on the RKE transmitter cannot arm or disarm the Vehicle Security Alarm.
Page 21: Illuminated Entry System - If Equipped
Security System Manual Override The Vehicle Security Alarm will not arm if you lock the doors using the manual door lock plunger. ILLUMINATED ENTRY SYSTEM — IF EQUIPPED The courtesy lights will turn on when you use the Remote Keyless Entry (RKE) transmitter or open the doors.
Page 22: Using The Rke Transmitter
20 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE equipped from the factory with three-button RKE trans- mitters, and those built with power options will be equipped with up to seven-button RKE transmitters. Using the RKE Transmitter Three-button RKE transmitters will provide basic UN- LOCK, LOCK and PANIC functions.
Page 23 Remote Unlock Doors and Liftgate Press and release the UNLOCK button on the RKE transmitter once to unlock the driver’s side or twice to unlock all doors and liftgate. The Illuminated Entry system also turns on. Remote Key Unlock on First Press This feature lets you program the system to unlock either the driver’s side, or all doors, on the first press of the UNLOCK button on the RKE transmitter.
Page 24 22 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Remote Lock Doors and Liftgate Press and release the LOCK button on the RKE transmit- ter to lock all doors and liftgate. The horn will chirp once to acknowledge the signal. Express Down Window Feature This feature allows you to remotely lower both front door windows at the same time.
Page 25 NOTE: Pressing the LOCK button on the RKE transmit- ter while you are in the vehicle will activate the Vehicle Security Alarm. Opening a door with the Vehicle Security Alarm activated will cause the alarm to sound. Press the UNLOCK button to deactivate the Vehicle Security Alarm. Using the Panic Alarm To turn the Panic Alarm feature on or off, press and hold the PANIC button on the RKE transmitter for at least one...
Page 26 24 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Power Open/Close Left Power Sliding Door — If Equipped Press the LEFT Power Sliding Door button twice on the RKE transmitter within five seconds to Power Open/ Close the Left Power Sliding Door. If the button on the RKE transmitter is pushed while the door is being power-closed, the door will reverse to the full open position.
Page 27 2. Press and hold the UNLOCK button on a programmed RKE transmitter for at least 4 seconds, but no longer than 10 seconds. Then, press and hold the LOCK button while still holding the UNLOCK button. 3. Release both buttons at the same time. 4.
Page 28 26 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: • Perchlorate Material — special handling may apply. See: www.dtsc.ca.gov/hazardouswaste/perchlorate. • Do not touch the battery terminals that are on the back housing or the printed circuit board. 1. Battery access is through a door located on the back of the RKE transmitter.
Page 29: Remote Starting System - If Equipped
REMOTE STARTING SYSTEM — IF EQUIPPED This system uses the Remote Keyless Entry (RKE) transmitter to start the engine conve- niently from outside the vehicle while still maintaining security. The system has a range of 328 ft (100 m). NOTE: The vehicle must be equipped with an auto- matic transmission to be equipped with Remote Start.
Page 30 28 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: • If your power door locks were unlocked, Remote Start will automatically lock the doors. • The park lights will turn on and remain on during Remote Start mode. • For security, power window and power sunroof op- eration (if equipped) are disabled when the vehicle is in the Remote Start mode.
Page 31 Cancel Remote Start Remote Starting will also cancel if any of the following occur: • The engine stalls or engine speed exceeds 2500 rpm • Any engine warning lights come on • The hood is opened • The hazard switch is pressed •...
Page 32: Door Locks
30 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE DOOR LOCKS Manual Door Locks Lock the doors by pushing down on the lock plungers on each door trim panel. Manual Door Lock If the lock plunger is down when you shut the door, the door will lock.
Page 33: Power Door Locks - If Equipped
WARNING! • For personal security and safety in the event of an accident, lock the vehicle doors as you drive as well as when you park and leave the vehicle. • When leaving the vehicle, always remove the key from the ignition switch, and lock your vehicle. Do not leave unattended children in the vehicle, or with access to an unlocked vehicle.
Page 34 32 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE chime will sound if the key is in the ignition switch and a door is open, as a reminder to remove the key. Front Passenger Power Door Switches 1 - Window Open/Close 3 - Doors Unlock 2 - Doors Lock If you press the power door lock switch while the sliding...
Page 35 2. Fasten your seat belt. (Fastening the seat belt will cancel any chiming that may confuse you during this programming procedure.) 3. Place the key into the ignition. 4. Within 15-seconds, cycle the ignition key from the LOCK position to the ON/RUN position a minimum of five times, ending in the ON position (do not start the engine).
Page 36 34 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Settings (Customer-Programmable Features) in the “Electronic Vehicle Information Center (EVIC),” in Section 4 of this manual. • On vehicles not equipped with the optional EVIC perform the following steps: 1. Enter your vehicle and close all doors. 2.
Page 37: Windows
WINDOWS Power Vent Windows — If Equipped Switches on the driver’s door trim panel let the driver operate the two vent windows from the driver’s seat. Power Vent Window Switches 1 – Open 2 – Close THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 35 Power Windows You can control either the front or rear windows using switches located on the driver’s door trim panel.
Page 38 36 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: Power Window switches will also remain active for up to 10 minutes after the ignition switch has been turned OFF, depending upon the accessory delay setting. Opening a front door will cancel this feature. Power Window Lockout Switch —...
Page 39 Front Passenger Power Window Switch There is a single switch on the front passenger’s door trim panel which operates the passenger door window and locks and unlocks all doors. The switch will operate only when the ignition switch is in the ON or ACC position and during power accessory delay.
Page 40 38 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE The switches will operate only when the ignition switch is in the ON or ACC position and during power acces- sory delay. Sliding Door Power Window Switch NOTE: The sliding door windows do not fully open, stopping several inches above the window sill.
Page 41 To stop the window from going all the way up during the Auto Up operation, push down on the switch briefly. To close the window part way, lift the window switch to the first detent and release when you want the window to stop.
Page 42: Sliding Side Door
40 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Wind Buffeting Wind buffeting can be described as the perception of pressure on the ears or a helicopter-type sound in the ears. Your vehicle may exhibit wind buffeting with the windows down, or the sunroof (if equipped) in certain open or partially open positions.
Page 43: Power Sliding Side Door - If Equipped
NOTE: The left side sliding door cannot be opened while the fuel door is open. This feature operates only when the sliding door is fully closed prior to opening the fuel door. Power Sliding Side Door — If Equipped The power sliding door may be opened or closed manu- ally or by using the buttons on the RKE transmitter, overhead console switch, or rear door switch.
Page 44 42 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: The power sliding side door must be unlocked before the power sliding door switches will operate. Power Sliding Door 1 — Heated Seat 4 — Door Handle 2 — Power Window 5 —...
Page 45 • If anything obstructs the power sliding side door while it is closing or opening, the door will automati- cally reverse to the closed or open position, provided it meets sufficient resistance. • If the power sliding side door is not in the full open or close position, it will fully open when a power sliding door switch is pressed.
Page 46 44 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Power Sliding Side Door Master Lock Switch To provide a safer environment for small children riding in the rear seats, the second row sliding door switches and handles may be overridden by pressing the ON side of the Master Lock Out Switch located in the front overhead console.
Page 47: Sliding Side Door Child Protection Lock
Sliding Side Door Child Protection Lock To provide a safer environment for small children riding in the rear seats, the sliding doors are equipped with a Child Protection Door Lock system. NOTE: When the Child Protection Door Lock system is engaged, the door can be opened only by using the outside door handle even though the inside door lock is in the unlocked position.
Page 48 46 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • When the Child Protection Door Lock system is en- gaged, (even if the inside door lock is in the unlocked position) the door can be opened only by using the outside door handle, the RKE transmitter, the switches on the overhead console or the switches located on the trim panel just in front of the power sliding door.
Page 49: Liftgate
NOTE: • After setting the Child Protection Door Lock system, always test the door from the inside to make certain it is in the desired position. • The power sliding side door switches will not open the power sliding doors if the vehicle is in gear or the vehicle speed is above 0 mph (0 km/h).
Page 50: Power Liftgate - If Equipped
48 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE transmitter will result in the liftgate becoming unlocked for 30 seconds allowing you to manually access the liftgate area. Power Liftgate — If Equipped The power liftgate may be opened manually or by using the button on the Remote Keyless Entry (RKE) transmit- ter.
Page 51 Rear Power Liftgate Switch When the RKE transmitter button is pressed and the Flash Lights feature is enabled, the tail lights will flash to signal that the liftgate is opening or closing. THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 49 WARNING! During power operation, personal injury or cargo damage may occur.
Page 52 50 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • The power liftgate must be in the full open or close positions for any of the buttons to operate. If the liftgate is not in the full open or close positions, it must be opened or closed manually.
Page 53: Storage Bin Safety Warning
STORAGE BIN SAFETY WARNING Safety Warning Carefully follow these warnings to help prevent personal injury or damage to your vehicle: WARNING! • Always close the storage bin covers when your vehicle is unattended. • Do not allow children to have access to the second row seat storage bins.
Page 54: Occupant Restraints
52 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Seat Storage Bin Cover Emergency Release Lever As a security measure, your vehicle may be built with a Storage Bin Cover Emergency Release is built into the storage bin cover latching mechanism. Storage Bin Cover Emergency Release Lever NOTE: In the event of an individual being locked inside the storage bin, the storage bin cover can be opened from...
Page 55 • Knee bolsters/blockers for front seat occupants • Front seat belt retractors incorporate pretensioners to enhance occupant protection by managing occupant energy during an impact event. If you will be carrying children too small for adult-sized seat belts, the seat belts or the Lower Anchors and Tether for CHildren (LATCH) feature also can be used to hold infant and child restraint systems.
Page 56: Lap/Shoulder Belts
54 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE ejection and the risk of injury caused by striking the inside of the vehicle. Everyone in a motor vehicle should be belted at all times. Lap/Shoulder Belts All seats in your vehicle are equipped with lap/shoulder belts.
Page 57 WARNING! (Continued) • Wearing your belt in the wrong place could make your injuries in a collision much worse. You might suffer internal injuries, or you could even slide out of part of the belt. Follow these instructions to wear your seat belt safely and to keep your pas- sengers safe, too.
Page 58 56 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! • A belt that is worn under your arm is very danger- ous. Your body could strike the inside surfaces of the vehicle in a collision, increasing head and neck injury. A belt worn under the arm can cause internal injuries.
Page 59 WARNING! • A belt that is buckled into the wrong buckle will not protect you properly. The lap portion could ride too high on your body, possibly causing internal injuries. Always buckle your belt into the buckle nearest you. • A belt that is too loose will not protect you as well. In a sudden stop you could move too far forward, increasing the possibility of injury.
Page 60 58 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! • A lap belt worn too high can increase the risk of internal injury in a collision. The belt forces won’t be at the strong hip and pelvic bones, but across your abdomen.
Page 61 is long enough to fit, insert the large latch plate into the buckle until you hear a “click.” The retractor should withdraw any slack in the belt. To release the small latch plate, position the end of the large latch plate against the red button on the small latch plate and push upward.
Page 62: Automatic Locking Retractors (Alr) Mode - If Equipped
60 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Automatic Locking Retractors (ALR) Mode — If Equipped In this mode, the shoulder belt is automatically pre- locked. The belt will still retract to remove any slack in the shoulder belt. The Automatic Locking Mode is avail- able on all passenger-seating positions with a combina- tion lap/shoulder belt.
Page 63: Enhanced Seat Belt Use Reminder System (Beltalert )
NOTE: These devices are not a substitute for proper seat belt placement by the occupant. The seat belt still must be worn snugly and positioned properly. The pretensioners are triggered by the Occupant Re- straint Controller (ORC). Like the front airbags, the pretensioners are single use items.
Page 64: Seat Belts And Pregnant Women
62 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 3. Within 60 seconds of turning the ignition switch to the ON/RUN position, unbuckle and then re-buckle the driver’s seat belt at least three times within 60 seconds, ending with the seat belt buckled. NOTE: Watch for the Seat Belt Reminder Light to turn on while unbuckling and off while re-buckling the seat belt.
Page 65: Supplemental Restraint System (Srs) - Airbags
WARNING! Using a seat belt extender when not needed can increase the risk of injury in a collision. Only use when the lap belt is not long enough when it is worn low and snug, and in the recommended seating positions.
Page 66: Front Seat Airbag Features
64 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • Front Passenger Airbag • Front and Side Impact Sensors • Steering Wheel and Column • Instrument Panel • Seat Belt Reminder Light • Knee Impact Bolster • Front Seat Belt Retractor Pretensioners •...
Page 67 In addition to the small size, the inflating gases exit through strategically placed vents, which direct the gas away from the occupant. Front Passenger Airbag Special Features A new active venting front passenger airbag is designed to reduce the risk of occupants who may be out of position by the use of active vents positioned on each side of the airbag.
Page 68 66 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: • Should a vehicle rollover occur, the SABIC curtains on both sides of the vehicle are deployed. • Airbag covers may not be obvious in the interior trim; but they will open to allow airbag deployment. The system includes sensors adjacent to both front and rear seat occupants that are calibrated to deploy during an impact severe enough to require airbag occupant...
Page 69 restraints should NEVER ride in the front seat of a vehicle with a passenger front airbag. An airbag deploy- ment can cause severe injury or death to infants in that position. Children that are not big enough to wear the vehicle seat belt properly (see Section on Child Restraints should be secured in the rear seat in child restraints or belt- positioning booster seats).
Page 70: Airbag Deployment Sensors And Controls
68 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! • Relying on the airbags alone could lead to more severe injuries in a collision. The airbags work with your seat belt to restrain you properly. In some collisions, the airbags won’t deploy at all. Always wear your seat belts even though you have airbags.
Page 71 The ORC contains a backup power supply system that will deploy the airbags even if the battery loses power or it becomes disconnected prior to deployment. Also, the ORC turns on the Airbag Warning Light in the instrument panel for approxi- mately four to six seconds for a self-check when the ignition is first turned on.
Page 72 70 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Acceleration Sensors Acceleration Sensors trigger airbag deployment based on dramatic acceleration change of the vehicle. Pressure Sensors Pressure Sensors trigger airbag deployment based on door cavity pressure changes. Rollover Sensors Rollover Sensors trigger airbag deployment in the event of vehicle rollover and aid the ORC in deploying Side Airbag Inflatable Curtains (SABIC) for rollover events.
Page 73 If a Deployment Occurs The airbag systems are designed to deploy when the Occupant Restraint Controller (ORC) detects a moderate- to-severe collision, to help restrain the driver, front passenger and rear passengers, and then immediately deflate. NOTE: A frontal collision that is not severe enough to need airbag protection will not activate the system.
Page 74 72 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! Deployed airbags and seat belt pretensioners cannot protect you in another collision. Have the airbags, seat belt pretensioners, and the front passenger seat belt retractor assembly replaced by an authorized dealer as soon as possible. Also, have the Occupant Restraint Controller (ORC) system serviced as well.
Page 75 WARNING! (Continued) • Do not attempt to modify any part of your ad- vanced airbag system. The airbag may inflate accidentally or may not function properly if modi- fications are made. Take your vehicle to an autho- rized dealer for any advanced airbag system ser- vice.
Page 76: Event Data Recorder (Edr)
74 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE located on the inside of the fuse block cover for the proper airbag fuses. See your authorized dealer if the fuse is good. Event Data Recorder (EDR) In the event of an accident, your vehicle is designed to record up to five seconds of specific vehicle data param- eters (see the following list) in an event data recorder prior to the moment of airbag deployment, or near...
Page 77 court with legal jurisdiction (i.e., pursuant to a warrant). A copy of the data will be provided to the custodial entity upon request. General data that does not identify par- ticular vehicles or crashes may be released for incorpo- ration in aggregate crash databases, such as those main- tained by the U.S.
Page 78: Integrated Child Booster Seat - If Equipped
76 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • Cruise control status • Traction/stability control status • Tire Pressure Monitoring System status (if equipped) Integrated Child Booster Seat — If Equipped The Integrated Child Booster Seat (if equipped) is located in each second-row passenger seat.
Page 79 Booster Seat Position WARNING! Failure to comply with the following conditions could result in serious injury of death: THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 77 WARNING! (Continued) • The swivel seat should be locked in the forward- facing position when using the booster seat with the vehicle in motion.
Page 80: Integrated Child Seat - If Equipped
78 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 5. Once the seat belt is long enough to fit properly, insert the latch plate into the buckle until you hear a “click.” 6. To remove the slack from the lap belt, pull upward on the shoulder portion of the seat belt.
Page 81: Child Restraints
To obtain Integrated Child Seat replacement instruc- tions: Refer to the Publication order forms at the back of this manual specify publication 81–226–0919. Child Restraints Everyone in your vehicle needs to be buckled up all the time, including babies and children. Every state in the United States and all Canadian provinces require that small children ride in proper restraint systems.
Page 82 80 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • Safety experts recommend rearward-facing in the vehicle until they are at least one year old and weigh at least 20 lbs (9 kg). Two types of child restraints can be used rearward-facing: infant carriers and convertible child seats.
Page 83 Older Children and Child Restraints Children who weigh more than 20 lbs (9 kg) and who are older than one year can ride forward-facing in the vehicle. Forward-facing child seats and convertible child seats used in the forward-facing direction are for children who weigh 20 to 40 lbs (9 to 18 kg) and who are older than one year.
Page 84 82 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: For additional information, refer to www.seatcheck.org or call 1–866–SEATCHECK. Cana- dian residents, should refer to Transport Canada’s web- site for additional information. http://www.tc.gc.ca/ roadsafety/childsafety/menu.htm WARNING! • Improper installation can lead to failure of an infant or child restraint.
Page 85 • Carefully follow the instructions that come with the restraint. If you install the restraint improperly, it may not work when you need it. • The passenger seat belts are equipped with cinching latch plates, which are designed to keep the lap portion tight around the child restraint so that it is not necessary to use a locking clip.
Page 86 84 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Lower Anchors and Tether for CHildren (LATCH) Each vehicle, except commercial cargo vehicles, is equipped with the child restraint anchorage system called LATCH, which stands for Lower Anchors and Tether for CHildren. Two LATCH child restraint anchor- age systems are installed on all second-row seats and in the center position on all third row fold-in-floor seats.
Page 87 Rear Seat Tether Strap Mounting When using the tether anchorages in the center position on third row fold-in-floor seating, ensure that the strap is routed underneath the head restraint and over the seat- back. THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 85 WARNING! An incorrectly anchored tether strap could lead to increased head motion and possible injury to the...
Page 88 86 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE of reach of children. It is recommended that before installing the child restraint, buckle the seat belt so the seat belt is tucked behind the child restraint and out of reach. If the buckled seat belt interferes with the child restraint installation, instead of tucking the seat belt behind the child restraint, route the seat belt through the child restraint belt path and then buckle it.
Page 89 Installing the Child Restraint System We urge you to carefully follow the directions of the manufacturer when installing your child restraint. Many, but not all restraint systems will be equipped with separate straps on each side, with each having a hook or connector, and a means for adjusting the tension in the strap.
Page 90: Rear Seat Delete Feature (Commercial Vehicles Only) - If Equipped
88 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE REAR SEAT DELETE FEATURE (COMMERCIAL VEHICLES ONLY) — IF EQUIPPED Commercial cargo vehicles are not designed for use as a family vehicle and are not intended for carrying children in the front passenger seat. However, if you must carry a child in a vehicle without a rear seat, the passenger seat should be moved to the full rearward position and the child must be in a proper restraint system based on its...
Page 91: Restraining Infants And Small Children With Seat Delete Feature (Commercial Vehicles Only)
WARNING! Rearward-facing infant restraints must never be se- cured in the passenger seat of a vehicle with a passenger airbag. In an accident, a passenger airbag may deploy causing severe injury or death to infants riding in rearward-facing infant restraints. Restraining Infants and Small Children with Seat Delete Feature (Commercial Vehicles Only) There are different sizes and types of restraints for...
Page 92 90 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE should ride properly buckled in the passenger seat with the seat adjusted to the rearmost position. Never allow children to slide the shoulder belt behind them or under their arm. Tether Installation for Commercial Vehicles with Rear Seat Delete To secure the child restraint upper tether strap to the vehicle, follow the instructions shown:...
Page 93: Engine Break-In Recommendations
WARNING! The vehicle tether anchor is designed to be used with a child restraint only. It should not be used for any other purpose. Before use, inspect the tether anchor strap for nicks, abrasions, discoloration, and loose threads. If these or any other condition that might affect the performance of the strap is observed, DO NOT USE that strap.
Page 94: Safety Tips
92 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE SAFETY TIPS Transporting Passengers NEVER TRANSPORT PASSENGERS IN THE CARGO AREA. WARNING! • It is extremely dangerous to ride in a cargo area, inside or outside of a vehicle. In a collision, people riding in these areas are more likely to be seri- ously injured or killed.
Page 95: Safety Checks You Should Make Inside The Vehicle
If you are required to drive with the trunk/liftgate open, make sure that all windows are closed and the climate control BLOWER switch is set at high speed. DO NOT use the recirculation mode. The best protection against carbon monoxide entry into the vehicle body is a properly maintained engine exhaust system.
Page 96: Periodic Safety Checks You Should Make Outside The Vehicle
94 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Defroster Check operation by selecting the defrost mode and place the blower control on high speed. You should be able to feel the air directed against the windshield. See your authorized dealer for service if your defroster is inoperable.
Page 97 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CONTENTS Mirrors ......100 Inside Day/Night Mirror — If Equipped Automatic Dimming Mirror —...
Page 98 96 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Phone Call Features ....123 uconnect phone Features Advanced Phone Connectivity Things You Should Know About Your uconnect phone .
Page 99 Driver Memory Seat — If Equipped ..170 Setting Memory Positions And Linking RKE Transmitter To Memory ....171 Easy Entry/Exit Seat (Available With Memory Seat Only) .
Page 100 98 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Electronic Speed Control — If Equipped ..188 To Activate ......188 To Set At A Desired Speed .
Page 101 Power Inverter — If Equipped ... . 213 Cupholders ......214 Instrument Panel Cupholders .
Page 102: Mirrors
100 UNDERSTANDING THE FEATURES OF YOUR VEHICLE MIRRORS Inside Day/Night Mirror — If Equipped A two-point pivot system allows for horizontal and vertical adjustment of the mirror. Adjust the mirror to center on the view through the rear window. Headlight glare can be reduced by moving the small control under the mirror to the night position (toward the rear of the vehicle).
Page 103: Outside Mirrors
Automatic Dimming Mirror CAUTION! To avoid damage to the mirror during cleaning, never spray any cleaning solution directly onto the mirror. Apply the solution onto a clean cloth and wipe the mirror clean. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 101 Outside Mirrors To receive maximum benefit, adjust the outside mirror(s) to center on the adjacent lane of traffic with a slight...
Page 104: Driver's Outside Automatic Dimming Mirror - If Equipped
102 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Driver’s Outside Automatic Dimming Mirror — If Equipped The outside mirror will automatically adjust for glare from vehicles behind you. This feature is controlled by the inside automatic dimming mirror and can be turned on or off by pressing the button at the base of the inside mirror.
Page 105: Heated Mirrors - If Equipped
Select a mirror and press one of the four arrows for the direction you want the mirror to move. Driver’s power mirror preselected positions can be con- trolled by the optional Driver Memory Seat Feature. Refer to “Driver Memory Seat” in Section 3. Heated Mirrors —...
Page 106: Blind Spot Monitoring - If Equipped
104 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Illuminated Vanity Mirrors — If Equipped An illuminated vanity mirror is located on the sun visor. To use the mirror, rotate the sun visor down and swing the mirror cover upward. The lights turn on automati- cally.
Page 107 When the vehicle is started, the BSM warning light will be momentarily illuminated in both outside rear view mirrors to let the driver know that the system is opera- tional. The BSM system sensors operate when the vehicle is in any forward gear or REVERSE and enters stand by mode when the vehicle is in PARK.
Page 108 106 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The area on the rear fascia where the radar sensors are located must remain free of snow, ice, and dirt/road contamination so that the BSM system can function properly. Do not block the area of the rear fascia where the radar sensors are located with foreign objects (bumper stickers, bicycle racks, etc.).
Page 109 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 107 The BSM system can also be configured to sound an audible (chime) alert and mute the radio to notify the driver of objects that have entered the detection zones. Refer to “Modes Of Operation” in this section. The BSM system monitors the detection zone from three different entry points (Side, Rear, Front) while driving to see if an alert is necessary.
Page 110 108 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Entering From The Rear Vehicles that come up from behind your vehicle on either side and enter the rear detection zone with a relative speed of less than 30 mph (48 km/h). Rear Monitoring Overtaking Traffic If you pass another vehicle slowly (with a relative speed less than 10 mph (16 km/h) and the vehicle remains in...
Page 111 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 109 Overtaking/Passing Stationary Objects The BSM system is designed not to issue an alert on stationary objects such as guardrails, posts, walls, foliage, berms, etc. However, occasionally the system may alert on such objects. This is normal operation and your vehicle does not require service.
Page 112: Rear Cross Path
110 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The BSM system will not alert you of objects that are traveling in the opposite direction of the vehicle in adjacent lanes. Opposing Traffic WARNING! The Blind Spot Monitoring system is only an aid to help detect objects in the blind spot zones.
Page 113 RCP Detection Zones RCP monitors the rear detection zones on both sides of the vehicle, for objects that are moving toward the side of the vehicle with a minimum speed of approximately 1 to 2 mph (1 km/h to 3 km/h), to objects moving a maxi- mum of approximately 10 mph (16 km/h), such as in parking lot situations.
Page 114: Modes Of Operation
112 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Modes Of Operation Three selectable modes of operation are available in the Electronic Vehicle Information Center (EVIC). Refer to “Personal Settings (Customer-Programmable Features) under Electronic Vehicle Information Center (EVIC)” in Section 4. Blind Spot Alert When operating in Blind Spot Alert mode, the BSM system will provide a visual alert in the appropriate side view mirror based on a detected object.
Page 115: Uconnect Phone - If Equipped
NOTE: The uconnect phone requires a cellular phone equipped with the Bluetooth Hands-Free Profile, Ver- sion 0.96 or higher. See the uconnect website for sup- ported phones. For uconnect customer support, visit the following websites: • www.chrysler.com/uconnect • www.dodge.com/uconnect • www.jeep.com/uconnect • or call 1–877–855–8400...
Page 116 114 UNDERSTANDING THE FEATURES OF YOUR VEHICLE uconnect allows you to transfer calls between the sys- tem and your cellular phone as you enter or exit your vehicle and enables you to mute the system’s microphone for private conversation. The uconnect phone is driven through your Bluetooth “Hands-Free Profile”...
Page 117: Operation
The uconnect phone is fully integrated with the vehi- cle’s audio system. The volume of the uconnect phone can be adjusted either from the radio volume control knob or from the steering wheel radio control (right switch), if so equipped. The radio display will be used for visual prompts from the uconnect phone such as CELL or caller ID on certain radios.
Page 118 116 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Help Command If you need assistance at any prompt, or if you want to know your options at any prompt, say Help following the beep. The uconnect phone will play all the options at any prompt if you ask for help.
Page 119 • For identification purposes, you will be prompted to give the uconnect phone a name for your cellular phone. Each cellular phone that is paired should be given a unique phone name. • You will then be asked to give your cellular phone a priority level between one and seven, with one being the highest priority.
Page 120 118 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • The system will prompt you to say the name of the person you want to call. • After the Ready prompt and the following beep, say the name of the person you want to call. For example, you can say John Doe, where John Doe is a previ- ously stored name entry in the uconnect phonebook or downloaded phonebook.
Page 121 The uconnect phone will allow you to enter up to 32 names in the phonebook with each name having up to four associated phone numbers and designations. Each language has a separate 32-name phonebook accessible only in that language. In addition, if equipped and supported by your phone, uconnect phone automati- cally downloads your cellular phone’s phonebook.
Page 122 120 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • This downloaded phonebook cannot be edited or deleted on the uconnect phone. These can only be edited on the cellular phone. The changes are trans- ferred and updated to uconnect phone on the next phone connection.
Page 123 Edit uconnect Phonebook Entries NOTE: • Editing names in the phonebook is recommended when the vehicle is not in motion. • Automatic downloaded phonebook entries cannot be deleted or edited. • Press the PHONE button to begin. • After the Ready prompt and the following beep, say Phonebook Edit.
Page 124 122 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • After you enter the Phonebook Delete menu, you will then be asked for the name of the entry that you wish to delete. You can either say the name of a phonebook entry that you wish to delete or you can say List Names to hear a list of the entries in the phonebook from which you choose.
Page 125: Understanding The Features Of Your Vehicle 123
• After the Ready prompt and the following beep, say Phonebook List Names. • The uconnect phone will play the names of all the phonebook entries, including the downloaded phone- book entries, if available. • To call one of the names in the list, press the VOICE RECOGNITION button during the playing of the desired name, and say Call.
Page 126 124 UNDERSTANDING THE FEATURES OF YOUR VEHICLE cellular phone. Press the PHONE button to place the current call on hold and answer the incoming call. NOTE: The uconnect phone compatible phones in the market today do not support rejecting an incoming call when another call is in progress.
Page 127 Three-Way Calling To initiate three-way calling, press the VOICE RECOG- NITION button while a call is in progress, and make a second phone call, as described under Making a Second Call While Current Call is in Progress. After the second call has established, press and hold the PHONE button until you hear a double beep, indicating that the two calls have been joined into one conference call.
Page 128: Uconnect Phone Features
126 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • After the ignition key is switched to OFF, a call can continue on the uconnect phone for a certain dura- tion, after which the call is automatically transferred from the uconnect phone to the cellular phone. •...
Page 129 • After the Ready prompt and the following beep, say Emergency and the uconnect phone will instruct the paired cellular phone to call the emergency num- ber. This feature is supported in the U.S., Canada, and Mexico. NOTE: • The emergency number dialed is based on the country where the vehicle is purchased (911 for the U.S.
Page 130 128 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: • The towing assistance number dialed is based on the country where the vehicle is purchased (1-800-528- 2069 for the U.S., 1-877-213-4525 for Canada, 55-14- 3454 for Mexico City and 1-800-712-3040 for outside Mexico City in Mexico).
Page 131 navigating through an automated customer service cen- ter menu structure, and to leave a number on a pager. You can also send stored uconnect phonebook entries as tones for fast and easy access to voice mail and pager entries. To use this feature, dial the number you wish to call and then press the VOICE RECOGNITION button and say, “Send.”...
Page 132 130 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Phone and Network Status Indicators If available on the radio and/or on a premium display such as the instrument panel cluster, and supported by your cellular phone, the uconnect phone will provide notification to inform you of your phone and network status when you are attempting to make a phone call using uconnect phone.
Page 133: Advanced Phone Connectivity
Advanced Phone Connectivity Transfer Call to and from Cellular Phone The uconnect phone allows ongoing calls to be trans- ferred from your cellular phone to the uconnect phone without terminating the call. To transfer an ongoing call from your uconnect phone paired cellular phone to the uconnect phone or vice versa, press the VOICE REC- OGNITION button and say Transfer Call.
Page 134: Things You Should Know About Your Uconnect Phone
132 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • After the Ready prompt and the following beep, say Setup Select Phone and follow the prompts. • You can also press the VOICE RECOGNITION button at any time while the list is being played, and then choose the phone that you wish to select.
Page 135 • Press the VOICE RECOGNITION button and say the Setup, Voice Training command. Repeat the words and phrases when prompted by the uconnect phone. For best results, the Voice Training session should be completed when the vehicle is parked with the engine running, all windows closed, and the blower fan switched off.
Page 136 134 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • Even though the system is designed for users speaking in North American English, French, and Spanish ac- cents, the system may not always work for some. • When navigating through an automated system such as voice mail, or when sending a page, at the end of speaking the digit string, make sure to say Send.
Page 137 • Performance, such as audio clarity, echo, and loudness to a large degree rely on the phone and network, and not the uconnect phone. • Echo at the far end can sometimes be reduced by lowering the in-vehicle audio volume. •...
Page 138 136 UNDERSTANDING THE FEATURES OF YOUR VEHICLE...
Page 139 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 137...
Page 140 138 UNDERSTANDING THE FEATURES OF YOUR VEHICLE...
Page 141 Voice Commands Primary Alternate(s) zero three four five seven eight nine star (*) plus (+) pound (#) add location UNDERSTANDING THE FEATURES OF YOUR VEHICLE 139 Voice Commands Primary Alternate(s) call cancel confirmation prompts continue delete dial download edit emergency English erase all Espanol...
Page 142 140 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Voice Commands Primary Alternate(s) language list names list phones mobile mute mute off new entry pager pair a phone phone pairing pairing phonebook phone book previous record again redial Voice Commands Primary Alternate(s) return to main menu return or main menu select phone...
Page 143: General Information
General Information This device complies with Part 15 of the FCC rules and RSS 210 of Industry Canada. Operation is subject to the following conditions: • Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
Page 144 142 UNDERSTANDING THE FEATURES OF YOUR VEHICLE When you press the VR button, you will hear a beep. The beep is your signal to give a command. NOTE: If you do not say a command within a few seconds, the system will present you with a list of options.
Page 145: Commands
Commands The Voice Recognition (VR) system understands two types of commands. Universal commands are available at all times. Local commands are available if the supported radio mode is active. Changing the Volume 1. Start a dialogue by pressing the VR button. 2.
Page 146 144 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Radio FM To switch to the FM band, say “FM” or “Radio FM”. In this mode, you may say the following commands: • “Frequency” (to change the frequency) • “Next Station” (to select the next station) •...
Page 147 Memo To switch to the voice recorder mode, say “Memo”. In this mode, you may say the following commands: • “New Memo” (to record a new memo) — During the recording, you may press the VR button to stop recording. You proceed by saying one of the following commands: −...
Page 148: Voice Training
146 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: Keep in mind that you have to press the VR button first and wait for the beep before speaking the “Barge In” commands. Voice Training For users experiencing difficulty with the system recog- nizing their voice commands or numbers, uconnect phone Voice Training feature may be used.
Page 149: Manual Front And Second Row Seat Adjuster
Manual Front And Second Row Seat Adjuster The adjusting bar is located under the front of the seat. Pull the bar upward and move the seat to the desired position. Release the bar to lock the seat into position. Manual Seat Adjuster UNDERSTANDING THE FEATURES OF YOUR VEHICLE 147 Using body pressure, move forward and rearward on the seat to be sure the seat adjusters have latched.
Page 150: Eight-Way Driver And Passenger Power Seat - If Equipped
148 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Eight–Way Driver And Passenger Power Seat — If Equipped The power seat switches are located on the outboard side of the seat. The front switch controls the up/down, forward/rearward and tilt adjustment. The rear switch controls the recline adjustment of the seatback.
Page 151: Adjustable Head Restraints
CAUTION! DO NOT place any article under a power seat or impede its ability to move as it may cause damage to the seat controls. Seat travel may become limited if movement is stopped by an obstruction in the seat’s path.
Page 152: Heated Seats - If Equipped
150 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Heated Seats — If Equipped This feature heats the front driver and passenger seats. The controls for front heated seats are located on the center instrument panel area. After turning the ignition ON, you can choose from High, Low, or Off heat settings.
Page 153: Manual Reclining Seats - If Equipped
WARNING! Persons who are unable to feel pain to the skin because of advanced age, chronic illness, diabetes, spinal cord injury, medication, alcohol use, exhaus- tion or other physical condition must exercise care when using the seat heater. It may cause burns even at low temperatures, especially if used for long periods of time.
Page 154: Manual Lumbar Adjust Lever - If Equipped
152 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! DO NOT ride with the seatback reclined so that the shoulder belt is no longer resting against your chest. In a collision you could slide under the seat belt and be seriously or fatally injured. Use the recliner only when the vehicle is parked.
Page 155: Stow 'N Go Seating - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 153 Stow ’n Go Seating — If Equipped On vehicles equipped with Stow ’n Go seating, the second and third row seats may be folded into the floor for convenient storage. To Fold Second Row Seats 1.
Page 156 154 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 4. Pull up on the seatback recliner lever located on the outboard side of the seat and fold the seatback down. To assure the seatback is latched in the folded position, additional downward pressure on the seatback may be required when folding.
Page 157 CAUTION! The storage bin cover must be locked and flat to avoid damage from contact with the front seat tracks, which have minimal clearance to the cover. WARNING! In an accident, serious injury could result if the seat storage bin covers are not properly latched. •...
Page 158: Easy Access Seating
156 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 3. Pull upward on the seatback recliner lever, located on the outboard side of the seat, to return the seatback to its full upright position. Second Row Seatback Release Lever 4. Adjust the head restraint to the desired position, close the storage bin cover and slide the storage bin locking mechanism to the Unlocked position.
Page 159: Swivel 'N Go Premium Seating - If Equipped
Tilting Second Row Stow ’n Go Seat WARNING! In the event of a collision you could be injured if the seat is not fully latched. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 157 Swivel ’n Go Premium Seating — If Equipped Premium second row Swivel ’n Go Seating features include: •...
Page 160 158 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • Seats are removable Swivel ’n Go Seating Features 1 — Moveable Armrest 4 — Fore-Aft Adjustment 2 — Seatback Release 5 — Seat Release 3 — Swivel Release WARNING! When the seatback release handle is lifted, the seat- back will rotate forward.
Page 161 Swivel Release Seatbacks fold forward on an angle, not flat. This allows the seats to swivel when the seatbacks are folded. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 159 WARNING! Failure to comply with the following conditions could result in serious injury or even death: •...
Page 162 160 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Removing Swivel ’n Go Premium Seating — If Equipped 1. Remove any obstructions from the floor behind the seat, and stow the third row seat. 2. Pull up on the release bar located at the bottom front edge of the swivel seat.
Page 163 WARNING! In a collision, you or others in your vehicle could be injured if seats are not properly latched to their floor attachments. Always be sure the seats are fully latched. Swivel ’n Go Premium Seating Table — If Equipped The Swivel ’n Go Seating Table consists of an easily assembled post and top.
Page 164 162 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The table and leg are stored beneath the floor when not in use. To install the table follow these steps: 1. Open the floor storage cover in front of the second row seats. Table and Leg Storage 2.
Page 165 5. Twist the pole in a clockwise rotation until it stops. NOTE: You will hear an audible “click” when the lock button engages the base. 6. Place the table top over the installed pole aligning with the mating feature of the underside of the table top. Apply pressure on the table top and press downward.
Page 166 164 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To separate the table top from the pole, follow these steps: 1. Locate the release latch on the underside of the table top. Table Top Release 2. Pull horizontally on the latch to activate the release from the pole.
Page 167: Second Row Bench Seat - If Equipped
Plastic Grocery Bag Retainer Hooks Retainer hooks which will hold plastic grocery bag handles are built into the seatbacks of all rear seats and some front seats. The floor supports the partial weight of the bagged goods. Second Row Bench Seat — If Equipped While the bench seat does not stow in the floor, it is removable for added cargo space.
Page 168: Third Row Power Seat - If Equipped
166 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! If not properly latched, the bench seats could become loose. Personal injuries could result. After reinstall- ing these seats, be sure the red indicator button on the release handles return into the handles. Third Row Power Seat —...
Page 169 The switch is only functional when the liftgate is open and the vehicle is in PARK. One Touch Folding Seat Third Row The rear switch bank allows multiple power folding and unfolding positions for the third row seats. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 167 Left and right third row seats can be folded individually or together.
Page 170 168 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: The third row power seat system includes obstacle detection for safe operation. When the system detects an obstacle, the motors will stop and reverse the motion a short distance to move the seat away from the obstacle.
Page 171 To Unfold Third Row Seats 1. Pull up on the assist strap to lift the seat out of the storage bin and push the seat forward until the anchors latch. 2. Pull release strap marked “1” to unlock the recliner. 3.
Page 172: Driver Memory Seat - If Equipped
170 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! To avoid serious injury or death, NEVER operate the vehicle with occupants in the third row seat while in the tailgate mode. DRIVER MEMORY SEAT — IF EQUIPPED The Memory Buttons 1 and 2 on the driver’s door panel can be programmed to recall the driver’s seat, driver’s outside mirror, adjustable brake and accelerator pedals, and radio station preset settings.
Page 173: Setting Memory Positions And Linking Rke Transmitter To Memory
Setting Memory Positions and Linking RKE Transmitter to Memory NOTE: Each time the SET (S) button and a numbered button (1 or 2) is pressed, you erase the memory settings for that button and store a new one. 1. Insert the ignition key and turn the ignition switch to the ON position.
Page 174 172 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 11. Select Remote Linked to Memory in the Electronic Vehicle Information Center (EVIC) and enter “Yes”. Refer to the “Customer-Programmable Features” in the “Elec- tronic Vehicle Information Center (EVIC)” section for more information. 12.
Page 175: Easy Entry/Exit Seat (Available With Memory Seat Only)
3. Press and release the memory SET (S) button located on the driver’s door. A chime will sound signaling that you are in the memory set mode. 4. Within five seconds, press and release MEMORY button 1 on the driver’s door. A chime will sound signaling to you that the driver memory has been set.
Page 176 174 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • When you remove the key from the ignition switch the driver seat will move to a position 0.3 in (7.7 mm) forward of the rear stop if the driver seat position is between 0.9 –...
Page 177: To Open And Close The Hood
TO OPEN AND CLOSE THE HOOD To open the hood, two latches must be released. 1. Pull the hood release lever located on the instrument panel, below the steering column. Hood Release Lever UNDERSTANDING THE FEATURES OF YOUR VEHICLE 175 2.
Page 178: Lights
176 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CAUTION! To prevent possible damage, do not slam the hood to close it. Lower the hood until it is open approxi- mately 12 in (30 cm) and then drop it. This should secure both latches. Never drive your vehicle unless the hood is fully closed, with both latches engaged.
Page 179: Interior Lighting
Interior Lighting Interior lights are turned on when a door or liftgate is opened, the Remote Keyless Entry (RKE) transmitter is activated, or when the dimmer control is moved to the extreme top. The interior lights will automatically turn off in approxi- mately 10 minutes for the first activation and 90 seconds every activation thereafter until the engine is started, if one of the following occur:...
Page 180: Parking Lights
178 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Parade Mode (Daytime Brightness Feature) Rotate the dimmer control to the first detent. This feature brightens the odometer, radio and overhead dis- plays when the parking lights or head- lights are on. Dimmer Control With the parking lights or headlights on, rotating the dimmer control for the interior lights on the instrument panel...
Page 181: Headlights
Headlights Turn the headlight switch knob to the second detent to turn the headlights and parking lights on. This also turns on all instrument panel lighting. To change the brightness of the instrument panel lights, rotate the dimmer control up or down. Automatic Headlights —...
Page 182: Headlight Delay - If Equipped
180 UNDERSTANDING THE FEATURES OF YOUR VEHICLE on when windshield wipers are on may be found on vehicles equipped with an automatic headlight system. Refer to the Electronic Vehicle Information Center (EVIC) in Section 4 under “Personal Settings (customer- programmable features)” for more information. Headlight Delay —...
Page 183: Daytime Running Lights (Canada/Fleet Vehicles Only)
Daytime Running Lights (Canada/Fleet Vehicles Only) The headlights on your vehicle will illuminate when the engine is started and the transmission is in any gear except PARK. This provides a constant lights on condi- tion until the ignition is turned OFF. The lights illuminate at less than 50% of normal intensity.
Page 184: Multifunction Lever
182 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Multifunction Lever The multifunction lever is located on the left side of the steering column. The multifunction lever controls the: • Turn Signals • Headlight Beams Low/High • Flash-To-Pass (Optical Horn) • Front and Rear Wipers — Washer Functions Turn Signals Move the multifunction lever up or down and the arrows on each side of the instrument cluster flash to show...
Page 185: Lane Change Assist
Turn Signal Warning If the vehicle electronics sense that the vehicle has traveled at over 18 mph (29 km/h) for about 1 mile (1.6 km) with the turn signals on, a chime will sound to alert the driver. Lane Change Assist Tap the lever up or down once, without moving beyond the detent, and the turn signal (right or left) will flash three times then automatically turn off.
Page 186 184 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: Always remove any buildup of snow that pre- vents the windshield wiper blades from returning to the off position. If the windshield wiper switch is turned off and the blades cannot return to the off position, damage to the wiper motor may occur.
Page 187: Tilt Steering Column - If Equipped
2. Intermittent, Low and High Speed Wipers Use the intermittent wipers when weather conditions make a single wiping cycle, with a variable pause be- tween cycles, desirable. Rotate the end of the multifunc- tion lever to the first detent position, then turn the end of the multifunction lever to select the desired delay inter- val.
Page 188: Adjustable Pedals - If Equipped
186 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To tilt the column, push the lever downward to the unlocked position. Move the steering column up or down, as desired. Pull the lever upward to the locked position to lock the steering column firmly in place. Tilt Steering Column Lever 1 —...
Page 189 Adjustable Pedal Switch Press the button forward to move the pedals forward (toward the front of the vehicle). Press the button rearward to move the pedals rearward (toward the driver). • The pedals can be adjusted with the ignition OFF. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 187 •...
Page 190: Electronic Speed Control - If Equipped
188 UNDERSTANDING THE FEATURES OF YOUR VEHICLE ELECTRONIC SPEED CONTROL — IF EQUIPPED When engaged, Electronic Speed Control takes over the accelerator operation at speeds greater than 25 mph (40 km/h). Electronic Speed Control Switches To Activate Push the ON/OFF button (located in the end of the lever) once, and the cruise indicator light (located in the mes- sage window of the odometer) will illuminate, showing that the Electronic Speed Control system is on.
Page 191: To Set At A Desired Speed
WARNING! Leaving the Electronic Speed Control system on when not in use is dangerous. You could accidently set the system or cause it to go faster than you want. You could lose control and have an accident. Always leave the Electronic Speed Control system off when you are not using it.
Page 192: Accelerating To Pass
190 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To decrease speed while speed control is set, press the SET/DECEL lever downward, and hold. Release the Electronic Speed Control lever when the desired speed is reached, and the new speed will be set. Tapping the SET/DECEL lever downward, once, will result in a 1 mph (1.6 km/h) speed decrease.
Page 193: Rear Park Assist - If Equipped
REAR PARK ASSIST — IF EQUIPPED The Rear Park Assist provides visible and audible indi- cations of the distance between the rear fascia and the detected obstacle, when backing up. When backing up, you should also use the inside rearview and outside mirrors.
Page 194 192 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Rear Park Assist Warning Display The Rear Park Assist Warning Display, located in the headliner near the liftgate glass, provides both visible and audible warnings to indicate the distance between the rear fascia and the detected obstacle. Rear Park Assist LED Lights When the ignition switch is turned to the RUN/ON position, the warning display will turn on all of its LEDs...
Page 195 WARNING DISPLAY DISTANCES DISPLAY INDICA- OBSTACLE DISTANCE FROM: REAR CORNERS Inner LED 1st LED 2nd LED 3rd LED 31.5 in (80 cm) 4th LED 25.5 in (65 cm) 5th LED 20 in (50 cm) 6th LED 16 in (40 cm) 7th LED 6 in (15 cm) NOTE: The Rear Park Assist will MUTE the radio, if on, when the audible warning is activated.
Page 196 194 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! • Drivers must be careful when backing up, even when using the Rear Park Assist. Always check carefully behind your vehicle, and be sure to check for pedestrians, animals, other vehicles, obstruc- tions, or blind spots before backing up.
Page 197 CAUTION! • To avoid vehicle damage, the Rear Park Assist should only be used as a parking aid and is unable to recognize every obstacle, including small ob- jects. Parking curbs might be temporarily detected or not detected at all. Obstacles located above or below the sensors will not be detected when they are in close proximity to the rear of the vehicle.
Page 198: Rear Backup Camera System - If Equipped
196 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Service The Rear Park Assist If the Rear Park Assist malfunctions, the instrument cluster will actuate a single chime, once per ignition cycle, and it will display the SERVICE PARK ASSIST SYSTEM message. Refer to “Compass Mini Trip Com- puter (CMTC) or “Electronic Vehicle Information Center (EVIC) —...
Page 199: Turning The Rear Camera On Or Off - With Navigation Radio
WARNING! Drivers must be careful when backing up even when using the Rear Backup Camera System. Always check carefully behind your vehicle, and be sure to check for pedestrians, animals, other vehicles, ob- structions, or blind spots before backing up. You are responsible for the safety of your surroundings and must continue to pay attention while backing up.
Page 200: Turning The Rear Camera On Or Off - Without Navigation Radio
198 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 4. Enable or disable the rear camera feature by selecting enable rear camera in reverse soft key. 5. Press the “save” soft key. 6. When the vehicle is shifted into REVERSE, an image of the rear of the vehicle will appear with a caution note to check entire surroundings displayed across the top of the screen.
Page 201 NOTE: Premium sunroof console models include all of above except sunglass storage. Front Premium Overhead Console Features 1 — Cupholder LED 4 — Storage/Mirror 2 — ATC Sensor 5 — Switch Bank 3 — Interior Lights UNDERSTANDING THE FEATURES OF YOUR VEHICLE 199 Courtesy/Interior Lighting At the forward end of the console are two courtesy lights (standard dome light has two buttons).
Page 202 200 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Sunglass Storage (non-sunroof only) At the rear of the front overhead console, a compartment is provided for the storage of two pairs of sunglasses. From the closed position, press the door over-travel latch to open the compartment.
Page 203: Garage Door Opener - If Equipped
Rear Courtesy/Reading Lights — If Equipped The overhead console has two sets of courtesy lights. The lights turn on when a front door, a sliding door or the liftgate is opened. If your vehicle is equipped with Remote Keyless Entry (RKE), the lights will also turn on when the UNLOCK button on the RKE transmitter is pressed.
Page 204 202 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The HomeLink buttons that are located in the headliner or sun visor designate the three different HomeLink channels. HomeLink Buttons NOTE: HomeLink is disabled when the Vehicle Secu- rity Alarm is active. WARNING! •...
Page 205: Programming Homelink
Programming Homelink Before You Begin If you have not trained any of the HomeLink buttons, erase all channels before you begin training. To do this, press and hold the two outside buttons for up to 20 seconds until the red indicator flashes. It is recommended that a new battery be placed in the hand-held transmitter of the device being programmed to HomeLink for more efficient training and accurate...
Page 206 204 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • After training a HomeLink channel, if the garage door does not operate with HomeLink and the ga- rage door opener was manufactured after 1995, the garage door opener may have a rolling code. If so, proceed to Step 5 “Programming A Rolling Code System.”...
Page 207 6. Firmly press and release the “Learn” or “Training” button. The name and color of the button may vary by manufacturer. NOTE: There are 30 seconds in which to initiate the next step after the “Learn” button has been pressed. 7.
Page 208: Gate Operator/Canadian Programming
206 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Gate Operator/Canadian Programming Canadian radio frequency laws require transmitter sig- nals to time-out (or quit) after several seconds of trans- mission – which may not be long enough for HomeLink to pick up the signal during programming. Similar to this Canadian law, some U.S.
Page 209: Troubleshooting Tips
Troubleshooting Tips If you are having trouble programming HomeLink , here are some of the most common solutions: • Replace the battery in the original transmitter. • Press the “Learn” button on the Garage Door Opener to complete the training for a Rolling Code. •...
Page 210: Power Sunroof Operation
208 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Power Sunroof Operation Opening the Sunroof Manually Press the switch rearward and hold, and the sunroof will open automatically from any position. The sunroof will open fully, then stop automatically. During this opera- tion, any release of the sunroof switch will stop the sunroof.
Page 211 WARNING! Never leave children in a vehicle with the key in the ignition switch. Occupants, particularly unattended children, can become entrapped by the power sun- roof while operating the power sunroof switch. Such entrapment may result in serious injury or death. Express-Open Press the switch rearward and release, and the sunroof will open automatically from any position.
Page 212: Electrical Power Outlets - If Equipped
210 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Auto-Express with Anti-Pinch Protection During express closing, anytime an obstacle that restricts glass movement is detected, the motor will stop and reverse travel to avoid pinching the object. Auto Express will stop and reverse travel up to three times in succession.
Page 213 12-Volt Power Outlets One outlet in the removable floor console shares a fuse with the lower outlet in the instrument panel and is also connected to the battery. Do not exceed a maximum power of 160 Watts (13 Amps) shared between the lower panel outlet and the removable floor console outlet.
Page 214 212 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! (Continued) • Close the lid when not in use and while driving the vehicle. • If this outlet is mishandled, it may cause an electric shock and failure. CAUTION! • Many accessories that can be plugged in draw power from the vehicle’s battery, even when not in use (i.e., cellular phones, etc.).
Page 215: Power Inverter - If Equipped
POWER INVERTER — IF EQUIPPED A 110-Volt, 150-Watt inverter outlet (if equipped) con- verts DC current to AC current, and is located on the left rear trim panel immediately behind the second row left passenger seat. This outlet can power cellular phones, electronics and other low power devices requiring power up to 150 Watts.
Page 216: Cupholders
214 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To turn on the power outlet, press the switch once. Press the switch a second time to turn the power outlet off. Power Inverter Switch CUPHOLDERS There are nine cupholders in the interior. Two cupholders in the center front instrument panel, four in the floor consoles and three more are located in the third row quarter trim panel.
Page 217: Interior Bottle Holders
Front Cupholders Pull the drawer out firmly until it stops, and place the container to be held in either one of the cupholder wells. The cupholders are designed to accommodate a wide variety of container types and sizes. Press down on the container to engage the cupholder retention features.
Page 218: Smoker's Package Kit - If Equipped
216 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Two outboard mesh pockets are on intermediate seating. The mesh pockets are flexible enough to hold juice boxes, toys, games or MP3 players, etc. Smoker’s Package Kit — If Equipped With the optional authorized dealer-installed Smoker’s Package Kit, a removable ash receiver is inserted into one of the two cupholders in the center front instrument panel.
Page 219: Door Trim Panel Storage
Glove Compartment Features 1 — Lower Compartment 3 — Upper Latch 2 — Lower Latch/Lock 4 — Upper Compartment Lower Glove Compartment To open the lower compartment pull out on the release handle. NOTE: The lower compartment is equipped with a lock that is part of the compartment handle (2).
Page 220: Driver Seatback Storage - If Equipped
218 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Sliding Side Door Bottle Holder Both sliding doors have a bottle holder molded right into the trim. Sliding Door Bottle Holder Driver Seatback Storage — If Equipped The driver’s seatback has a primary storage pocket on all models and an optional secondary mesh pocket.
Page 221: Second Row Seat Storage Bins - If Equipped
Umbrella Holder Second Row Seat Storage Bins — If Equipped The seat storage bins are located on the floor in front of the second row seats. The area below the covers can be used for storage when the second row seat is in the upright position.
Page 222: Coat Hooks
220 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CAUTION! NOTE: The storage bin cover must be locked and flat to avoid damage from contact with the front seat tracks, which have minimal clearance to the cover. WARNING! In an accident, serious injury could result if the seat storage bin covers are not properly latched.
Page 223: Console Features
Rear Cargo Area Loading Limit NOTE: With all rear seats stowed or removed, 4 x 8 foot sheets of building material will fit on the vehicle floor with the liftgate closed. The front seats must be moved slightly forward of the rearmost position. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 221 CONSOLE FEATURES There are two consoles available: Basic and Premium.
Page 224: Premium Console - If Equipped
222 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To Remove The Basic Floor Console 1. Remove the front anchor cup plug and clip. 2. Slide the console base forward while lifting slightly to clear the rear load floor hook. 3. Remove the console. To Reinstall The Basic Floor Console 1.
Page 225 • Upper storage bin can hold nine regular or 18 thin CDs or other items • Large console center storage will store headphones for the available rear DVD entertainment system or other items • 12-Volt DC power outlet provides continuous power inside the console for cell phones or other electronics.
Page 226 224 UNDERSTANDING THE FEATURES OF YOUR VEHICLE holder insert for both cavities can easily be removed for cleaning. The cupholders will also accommodate large size cups and 20 oz (.6 L) bottles. Position 1 shows the console closed with four cupholders and a convenient storage tray.
Page 227 Dual Storage Bins Position 3 shows the top portion of the console in a rearward position. This is accomplished by lifting the upper most latch at the front of the console. This provides easy access to the storage area below and provides two of the four cupholders for the second row passengers.
Page 228: Rear Window Features
226 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To Remove The Premium Floor Console 1. Pull up on the bottom release handle in the front of the console. 2. Lift the rear of the console up several inches/ centimeters. 3. Pull rearward to disengage from floor and remove console.
Page 229: Load-Leveling System
NOTE: • You can turn off the heated mirror feature at anytime by pressing the rear window defroster switch a second time. • To prevent excessive battery drain, use the rear win- dow defroster only when the engine is operating. CAUTION! Failure to follow these cautions can cause damage to the heating elements:...
Page 230: Roof Luggage Rack - If Equipped
228 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! Do not install the load-leveling system on vehicles that are not equipped with Anti-Lock Brakes. Ve- hicles without Anti-Lock Brakes (ABS) have a height- sensing proportioning valve. Installing a leveling system will render this system ineffective, inappro- priately reducing rear brake pressure, resulting in increased stopping distances.
Page 231 The tie down holes on the crossbar ends should always be used to tie down the load. Check the straps frequently to be sure that the load remains securely attached. CAUTION! • Crossbars should remain equally spaced or paral- lel at any luggage rack position for proper func- tion.
Page 232: Sun Screens - If Equipped
230 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! Cargo must be securely tied before driving your vehicle. Improperly secured loads can fly off the vehicle, particularly at high speeds, resulting in per- sonal injury or property damage. Follow the Roof Rack Cautions when carrying cargo on your roof rack.
Page 233 Sun Screen Attaching To Retainer Clips Once the screen is completely to the top of the window, extend the top bar of the sun screen over the two hooks attached to the top of the window. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 231 Sun Screen Extended To lower the sun screen, gently lift the tab upward to disengage the hooks, and feed the screen back into the...
Page 235 UNDERSTANDING YOUR INSTRUMENT PANEL CONTENTS Instrument Panel Features ....237 Instrument Cluster – Base ....238 Instrument Cluster –...
Page 236 234 UNDERSTANDING YOUR INSTRUMENT PANEL AM/FM/CD/DVD Radio (RER/REN) – If Equipped ......268 Operating Instructions —...
Page 237 Play Mode ......292 List Or Browse Mode ....294 uconnect studios (Satellite Radio) —...
Page 238 236 UNDERSTANDING YOUR INSTRUMENT PANEL Climate Controls ..... 305 Manual Heating And Air Conditioning System ......305 Rear Manual Climate Control —...
Page 239: Instrument Panel Features
INSTRUMENT PANEL FEATURES 1 — Air Vents 5 — Storage Bin 2 — Instrument Cluster 6 — Upper Glove Compartment 3 — Shift Lever 7 — Lower Glove Compartment 4 — Radio 8 — Climate Controls UNDERSTANDING YOUR INSTRUMENT PANEL 237 9 —...
Page 240: Instrument Cluster - Base
238 UNDERSTANDING YOUR INSTRUMENT PANEL INSTRUMENT CLUSTER – BASE...
Page 241: Instrument Cluster - Premium
UNDERSTANDING YOUR INSTRUMENT PANEL 239 INSTRUMENT CLUSTER – PREMIUM...
Page 242: Instrument Cluster Descriptions
240 UNDERSTANDING YOUR INSTRUMENT PANEL INSTRUMENT CLUSTER DESCRIPTIONS 1. Fuel Gauge The pointer shows the level of fuel in the fuel tank when the ignition switch is in the ON position. 2. Fuel Door Reminder The arrow in this symbol is a reminder that the Fuel Filler Door is located on the left side of the vehicle.
Page 243 WARNING! A hot engine cooling system is dangerous. You or others could be badly burned by steam or boiling coolant. You may want to call an authorized dealer if your vehicle overheats. If you decide to look under the hood yourself, see Section 7 of this manual. Follow the warnings under the Cooling System Pres- sure Cap paragraph.
Page 244 242 UNDERSTANDING YOUR INSTRUMENT PANEL If the ABS light is on, the brake system should be serviced as soon as possible to restore the benefits of Anti-Lock brakes. If the ABS light does not turn on when the Ignition switch is turned to the ON position, have the light inspected by an authorized dealer.
Page 245 If brake failure is indicated, immediate repair is neces- sary. WARNING! Driving a vehicle with the red brake light on is dangerous. Part of the brake system may have failed. It will take longer to stop the vehicle. You could have an accident.
Page 246 244 UNDERSTANDING YOUR INSTRUMENT PANEL 11. Odometer / Trip Odometer — If Equipped The odometer shows the total distance the vehicle has been driven. U.S. federal regulations require that upon transfer of vehicle ownership, the seller certify to the purchaser the correct mileage that the vehicle has been driven.
Page 247 NOTE: • If your vehicle is equipped with a hood switch, in the case of hood ajar, a warning message will be displayed in either the PRNDL/Odometer display as “hood” or “Hood Ajar” in the EVIC display. • Some of the above warnings will be displayed in the Compass Mini-Trip Computer / Electronic Vehicle Information Center Display Area located in the instru- ment cluster.
Page 248 246 UNDERSTANDING YOUR INSTRUMENT PANEL means the engine oil change interval may fluctuate dependent upon your personal driving style. Unless reset, this message will continue to display each time you turn the ignition switch to the ON/RUN position. To turn off the message temporarily, press and release the Trip Odometer button on the instrument cluster.
Page 249 the ON position before engine start. If the bulb does not come on when turning the key from OFF to ON, have the condition checked promptly. Certain conditions such as a loose or missing gas cap, poor fuel quality, etc., may illuminate the MIL after engine start.
Page 250 248 UNDERSTANDING YOUR INSTRUMENT PANEL If a problem is detected, the light will come on while the engine is running. Cycle the ignition key when the vehicle has completely stopped and the shift lever is placed in the PARK position, the light should turn off. If the light remains lit with the engine running, your vehicle will usually be drivable;...
Page 251 21. Vehicle Security Light — If Equipped This light will flash at a fast rate for approxi- mately 15 seconds when the vehicle security alarm is arming and then will flash slowly until vehicle is disarmed. 22. Airbag Warning Light This light turns on and remains on for four seconds as a bulb check when the ignition switch is first turned ON.
Page 252 250 UNDERSTANDING YOUR INSTRUMENT PANEL As an added safety feature, your vehicle has been equipped with a Tire Pressure Monitoring System (TPMS) that illuminates a low tire pressure telltale when one or more of your tires is significantly under-inflated. Accordingly, when the low tire pressure telltale illumi- nates, you should stop and check your tires as soon as possible, and inflate them to the proper pressure.
Page 253 CAUTION! The TPMS has been optimized for the original equipment tires and wheels. TPMS pressures and warning have been established for the tire size equipped on your vehicle. Undesirable system opera- tion or sensor damage may result when using re- placement equipment that is not of the same size, type, and/or style.
Page 254: Compass Mini-Trip Computer (Cmtc) - If Equipped
252 UNDERSTANDING YOUR INSTRUMENT PANEL 28. Compass Mini-Trip Computer (CMTC) Display / Electronic Vehicle Information Center (EVIC) Display— If Equipped Compass Mini-Trip Computer (CMTC) Display — If Equipped On vehicles equipped with Compass Mini-Trip Com- puter (CMTC), the display provides the outside tempera- ture, one of eight compass headings to indicate the direction the vehicle is facing and the current radio station.
Page 255: Cmtc Reset Buttons
CMTC Reset Buttons CMTC Reset Button Press the left reset button located on the instrument cluster to scroll through sub menus (i.e., Trip Functions: AVG Fuel Economy, DTE, Elapsed Time, and Units). To reset the display shown, turn the ignition switch to the ON position, then press and hold the reset button for approximately two seconds.
Page 256: Compass/Temperature Display
254 UNDERSTANDING YOUR INSTRUMENT PANEL Compass/Temperature Display Compass Variance Compass Variance is the difference between Magnetic North and Geographic North. To ensure compass accu- racy, the compass variance should be properly set accord- ing to the variance map for the zone where the vehicle will be driven.
Page 257 To Set the Variance Start the engine and leave the transmission gear selector lever in the PARK position. Press and hold the CMTC reset button (for approximately ten seconds) until the current variance zone number is displayed. To change the zone, press and release the CMTC reset button to increase the variance one step.
Page 258: Electronic Vehicle Information Center (Evic) - If Equipped
256 UNDERSTANDING YOUR INSTRUMENT PANEL ELECTRONIC VEHICLE INFORMATION CENTER (EVIC) — IF EQUIPPED The Electronic Vehicle Information Center (EVIC) fea- tures a driver-interactive display that is located in the instrument cluster. Electronic Vehicle Information Center (EVIC) This system conveniently allows the driver to select a variety of useful information by pressing the switches mounted on the steering wheel.
Page 259 EVIC Menu / Step Control Button, as it appears on the left side of the steer- ing column. Press and release the MENU button, and the mode displayed will change Compass/Temperature, Trip, System Status, and Personal Settings. Press the STEP button to scroll through sub menus (i.e., Trip Functions, Avg.
Page 260: Electronic Vehicle Information Center (Evic) Displays
258 UNDERSTANDING YOUR INSTRUMENT PANEL Electronic Vehicle Information Center (EVIC) Displays When the appropriate conditions exist, the EVIC displays the following messages: • Door(s) Ajar (with a single chime, if vehicle is in motion) • Liftgate Ajar (chime will sound when vehicle starts moving) •...
Page 261 rear view icons will be illuminated. If electronic inter- ference is present, the BSM system will illuminate the icon only on the side of interference as long as interference is present. • Service Blind Spot System — This message is dis- played to indicate the Blind Spot Monitor (BSM) system is permanently unavailable.
Page 262: Trip Functions
260 UNDERSTANDING YOUR INSTRUMENT PANEL Trip Functions Press and release the MENU button until one of the following Trip Functions displays in the EVIC. Press the STEP button to scroll through all the Trip Computer functions. The Trip Functions mode displays the following informa- tion.
Page 263: Compass Display
Display Units of Measure in: To make your selection, press and release the STEP button until “ENGLISH” or “METRIC” appears. To Reset the Display Reset will only occur while a resettable function is being displayed. Press and release the RESET button once to clear the resettable function being displayed.
Page 264 262 UNDERSTANDING YOUR INSTRUMENT PANEL 3. Press the STEP button until “Calibrate Compass” is displayed in the EVIC. 4. Press and release the RESET button to start the cali- bration. The “CAL” indicator will be displayed in the EVIC. 5. Complete one or more 360–degree turns (in an area free from large metal or metallic objects) until the “CAL”...
Page 265: Personal Settings
2. Press and hold the compass button for approximately two seconds. 3. Press the STEP button until “Compass Variance” mes- sage, and the last variance zone number, displays in the EVIC. 4. Press and release the STEP button until the proper variance zone is selected, according to the map.
Page 266 264 UNDERSTANDING YOUR INSTRUMENT PANEL Auto UNLK On Exit When ON is selected, all doors will unlock when the vehicle is stopped and the transmission is in the PARK or NEUTRAL position and the driver’s door is opened. To make your selection, press and release the RESET button until ON or OFF appears.
Page 267 Headlamp Off Delay When this feature is selected, the driver can choose to have the headlights remain on for 0, 30, 60, or 90 seconds when exiting the vehicle. To make your selection, press and release the RESET button until 0, 30, 60, or 90 appears.
Page 268 266 UNDERSTANDING YOUR INSTRUMENT PANEL unlocked with the RKE transmitter. To make your selec- tion, press and release the RESET button until “OFF,” “30 sec.,” “60 sec.,” or “90 sec.” appears. Blind Spot Alert There are 3 selections when operating Blind Spot Alert. By pressing and releasing the RESET button once, the Blind Spot Alert feature can be activated in “Blind Spot Alert Lights”...
Page 269 Door Alert When this feature is selected the signal lamps activate when power or manual sliding doors are in operation, signaling other drivers that someone may be exiting or entering the vehicle. Sound Horn with Remote Key Lock When ON is selected, a short horn sound will occur when the RKE transmitter LOCK button is pressed.
Page 270: Am/Fm/Cd/Dvd Radio (Rer/Ren) - If
268 UNDERSTANDING YOUR INSTRUMENT PANEL AM/FM/CD/DVD RADIO (RER/REN) – IF EQUIPPED NOTE: The sales code is located on the lower right side of the unit’s faceplate. The REN and RER radios contain a CD/DVD player, USB port, and a 30-gigabyte hard drive (HDD). Sirius Satellite Radio is optional.
Page 271 4. To move the hour forward, touch the screen where the word “Hour” with the arrow pointing upward is dis- played. To move the hour backward, touch the screen where the word “Hour” with the arrow pointing down- ward is displayed. 5.
Page 272: Sales Code Res - Am/Fm Stereo Radio With Cd Player (Mp3 Aux Jack)
270 UNDERSTANDING YOUR INSTRUMENT PANEL Changing the Time Zone 1. Turn on the radio. 2. Touch the screen where the time is displayed. The clock setting menu will appear on the screen. 3. Touch the screen where the words “Set Time Zone” are displayed.
Page 273 Power Switch/Volume Control (Rotary) Push the ON/VOLUME control knob to turn on the radio. Push the ON/VOLUME control knob a second time to turn off the radio. Electronic Volume Control The electronic volume control turns continuously (360 degrees) in either direction, without stopping. Turning the ON/VOLUME control knob to the right increases the volume, and to the left decreases it.
Page 274 272 UNDERSTANDING YOUR INSTRUMENT PANEL RW/FF Pressing the RW (Rewind) or FF (Fast Forward) buttons causes the tuner to search for the next frequency in the direction of the arrows. This feature operates in either AM or FM frequencies. TUNE Control Turn the rotary TUNE/SCROLL control knob clockwise to increase or counterclockwise to decrease the frequency.
Page 275: Operation Instructions - Cd Mode For Cd And Mp3 Audio Play
SET/RND Button — To Set the Pushbutton Memory When you are receiving a station that you wish to commit to pushbutton memory, press the SET/RND button. The symbol SET 1 will now show in the display window. Select the button (1 to 6) you wish to lock onto this station and press and release that button.
Page 276 274 UNDERSTANDING YOUR INSTRUMENT PANEL Inserting Compact Disc(s) Gently insert one CD into the CD player with the CD label facing up. The CD will automatically be pulled into the CD player and the CD icon will illuminate on the radio display.
Page 277: Notes On Playing Mp3 Files
NOTE: Ejecting with the ignition OFF is not allowed on convertible or soft-top models (if equipped). SEEK Button Press the right SEEK button for the next selection on the CD. Press the left SEEK button to return to the beginning of the current selection, or return to the beginning of the previous selection if the CD is within the first second of the current selection.
Page 278 276 UNDERSTANDING YOUR INSTRUMENT PANEL Supported Media (Disc Types) The MP3 file recording media supported by the radio are CDDA, CD-R, CD-RW, MP3, and CDDA+MP3. Supported Medium Formats (File Systems) The medium formats supported by the radio are ISO 9660 Level 1 and Level 2 and includes the Joliet extension.
Page 279 Supported MP3 File Formats The radio will recognize only files with the *.MP3 exten- sion as MP3 files. Non-MP3 files named with the *.MP3 extension may cause playback problems. The radio is designed to recognize the file as an invalid MP3 and will not play the file.
Page 280: Operation Instructions - Auxiliary Mode
278 UNDERSTANDING YOUR INSTRUMENT PANEL Playback of MP3 Files When a medium containing MP3 data is loaded, the radio checks all files on the medium. If the medium contains a lot of folders or files, the radio will take more time to start playing the MP3 files.
Page 281: Sales Code Res/Rsc - Am/Fm Stereo Radio With Cd Player (Mp3 Aux Jack) And Sirius Radio
SALES CODE RES/RSC — AM/FM STEREO RADIO WITH CD PLAYER (MP3 AUX JACK) AND SIRIUS RADIO NOTE: The radio sales code is located on the lower right side of the radio faceplate. RES/RSC Radio UNDERSTANDING YOUR INSTRUMENT PANEL 279 Operating Instructions — Radio Mode NOTE: The ignition switch must be in the ON or ACC position to operate the radio.
Page 282 280 UNDERSTANDING YOUR INSTRUMENT PANEL to seek up and the left switch to seek down. The radio will remain tuned to the new station until you make another selection. Holding either button will bypass stations without stopping until you release it. Voice Recognition System (Radio) —...
Page 283 5. To exit, press any button/knob or wait five seconds. The clock can also be set by pressing the SETUP button. For vehicles equipped with satellite radio, press the SETUP button, use the TUNE/SCROLL control to select SET CLOCK, and then follow the above procedure, starting at Step 2.
Page 284 282 UNDERSTANDING YOUR INSTRUMENT PANEL Push the rotary TUNE/SCROLL control knob a fourth time and BALANCE will display. Turn the TUNE/ SCROLL control knob to the right or left to adjust the sound level from the right or left side speakers. Push the rotary TUNE/SCROLL control knob a fifth time and FADE will display.
Page 285 16-Digit Character Program Type Personality Public Rhythm and Blues Religious Music Religious Talk Rock Soft Soft Rock Soft Rhythm and Blues Sports Talk Top 40 Weather By pressing the SEEK button when the Music Type icon is displayed, the radio will be tuned to the next frequency UNDERSTANDING YOUR INSTRUMENT PANEL 283 station with the same selected Music Type name.
Page 286: Operation Instructions - Cd Mode For Cd And Mp3 Audio Play
284 UNDERSTANDING YOUR INSTRUMENT PANEL SET/RND Button — To Set the Pushbutton Memory When you are receiving a station that you wish to commit to pushbutton memory, press the SET/RND button. The symbol SET 1 will now show in the display window.
Page 287 Inserting Compact Disc(s) Gently insert one CD into the CD player with the CD label facing up. The CD will automatically be pulled into the CD player and the CD icon will illuminate on the radio display. If a CD does not go into the slot more than 1.0 in (2.5 cm), a disc may already be loaded and must be ejected before a new disc can be loaded.
Page 288: Notes On Playing Mp3 Files
286 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: Ejecting with the ignition OFF is not allowed on convertible or soft-top models (if equipped). SEEK Button Press the right SEEK button for the next selection on the CD. Press the left SEEK button to return to the beginning of the current selection, or return to the beginning of the previous selection if the CD is within the first second of the current selection.
Page 289 Supported Media (Disc Types) The MP3 file recording media supported by the radio are CDDA, CD-R, CD-RW, MP3, and CDDA+MP3. Supported Medium Formats (File Systems) The medium formats supported by the radio are ISO 9660 Level 1 and Level 2 and includes the Joliet extension. When reading discs recorded using formats other than ISO 9660 Level 1 and Level 2, the radio may fail to read files properly and may be unable to play the file nor-...
Page 290 288 UNDERSTANDING YOUR INSTRUMENT PANEL Supported MP3 File Formats The radio will recognize only files with the *.MP3 exten- sion as MP3 files. Non-MP3 files named with the *.MP3 extension may cause playback problems. The radio is designed to recognize the file as an invalid MP3 and will not play the file.
Page 291: List Button (Cd Mode For Mp3 Play)
Playback of MP3 Files When a medium containing MP3 data is loaded, the radio checks all files on the medium. If the medium contains a lot of folders or files, the radio will take more time to start playing the MP3 files. Loading times for playback of MP3 files may be affected by the following: •...
Page 292: Universal Consumer Interface (Uci) - If Equipped
290 UNDERSTANDING YOUR INSTRUMENT PANEL Press and hold the INFO button again for three seconds to return to elapsed time display. Operation Instructions - Auxiliary Mode The auxiliary (AUX) jack is an audio input jack which allows the user to plug in a portable device such as an MP3 player or cassette player and utilize the vehicle’s audio system to amplify the source and play through the vehicle speakers.
Page 293: Connecting The Ipod
feature, refer to the separate RER, REN or REZ User’s Manual. UCI is available only if equipped as an option with these radios. This feature allows you to plug an iPod vehicle’s sound system through a 16–pin connector, using the provided interface cable. UCI supports Mini, 4G, Photo, Nano, 5G iPod iPhone devices.
Page 294: Using This Feature
292 UNDERSTANDING YOUR INSTRUMENT PANEL • If the iPod battery is completely discharged, it may not communicate with the UCI system until a mini- mum charge is attained. Leaving the iPod connected to the UCI system may charge it to the required level. Using This Feature By using the optional connection cable to connect an iPod to the vehicle’s UCI 16–pin connector port:...
Page 295 • Jump backward in the current track by pressing and holding the << RW button. Holding the << RW button long enough will take you to the beginning of the current track. • Jump forward in the current track by pressing and holding the FF >>...
Page 296: List Or Browse Mode
294 UNDERSTANDING YOUR INSTRUMENT PANEL Shuffle OFF modes for the iPod . If the RND icon is showing on the radio display, then the shuffle mode is List Or Browse Mode During Play mode, pressing any of the buttons described below, takes you to List mode.
Page 297 • To Exit List mode without selecting a track, press the same PRESET button again to go back to Play mode. • LIST button: The LIST button will display the top level menu of the iPod . Turn the TUNE control knob to list the top-menu item you wish to select and press the TUNE control knob.
Page 298: Uconnect Studios (Satellite Radio) - If Equipped (Ren/Req/Rer/Res/Reu Radios Only)
296 UNDERSTANDING YOUR INSTRUMENT PANEL uconnect studios (SATELLITE RADIO) — IF EQUIPPED (REN/REQ/RER/RES/REU RADIOS ONLY) Satellite radio uses direct satellite-to-receiver broadcast- ing technology to provide clear digital sound, coast to coast. The subscription service provider is Sirius Satellite Radio. This service offers over 130 channels of music, sports, news, entertainment, and programming for chil- dren, directly from its satellites and broadcasting studios.
Page 299: Selecting Uconnect Studios (Satellite) Mode
selected. Press the TUNE/SCROLL control knob and the Sirius ID number will display. The Sirius ID number display will time out in two minutes. Press any button on the radio to exit this screen. ESN/SID Access With REN/RER Radios While in SAT mode, press the MENU button on the radio faceplate.
Page 300: Operating Instructions - Uconnect Studios (Satellite) Mode
298 UNDERSTANDING YOUR INSTRUMENT PANEL • Dense tree coverage may interrupt reception in the form of short audio mutes. • Driving under wide bridges or along tall buildings can cause intermittent reception. • Placing objects over or too close to the antenna can cause signal blockage.
Page 301 RW/FF Pressing the RW (Rewind) or FF (Fast Forward) buttons causes the tuner to search for the next channel in the direction of the arrows. TUNE Control (Rotary) Turn the rotary TUNE/SCROLL control knob clockwise to increase or counterclockwise to decrease the channel. MUSIC TYPE Button —...
Page 302: Operating Instructions - Uconnect Phone (If Equipped)
300 UNDERSTANDING YOUR INSTRUMENT PANEL SETUP Button Pressing the SETUP button allows you to select the following items: • Display Sirius ID number — Press the AUDIO/ SELECT button to display the Sirius ID number. This number is used to activate, deactivate, or change the Sirius subscription.
Page 303: Operating Instructions - Video
Operating Instructions — Video Entertainment System (VES)™ (If Equipped) Refer to separate “Video Entertainment System (VES)™ Guide.” uconnect studios (SIRIUS BACKSEAT TV™) — IF EQUIPPED Satellite video uses direct satellite receiver broadcasting technology to provide streaming video. The subscription service provider is SIRIUS Satellite Radio. SIRIUS Back- seat TV™...
Page 304 302 UNDERSTANDING YOUR INSTRUMENT PANEL • Ten different medias to choose from in each screen (AM, FM, Sirius Radio, Sirius Backseat TV™, DVD1, DVD2, Hard Disc Drive (HDD), AUX in radio, AUX1, AUX2) The LCD screen(s) are located in the overhead compart- ment console.
Page 305: Remote Sound System Controls - If Equipped
REMOTE SOUND SYSTEM CONTROLS — IF EQUIPPED Remote Sound System Controls (Back View Of Steering Wheel) The remote sound system controls are located on the rear surface of the steering wheel, at the three and nine o’clock positions. UNDERSTANDING YOUR INSTRUMENT PANEL 303 The right-hand rocker switch has a pushbutton in the center, and controls the volume and mode of the sound system.
Page 306: Cd Player
304 UNDERSTANDING YOUR INSTRUMENT PANEL The button located in the center of the left-hand switch will tune to the next preset station that you have pro- grammed in the radio preset pushbutton. CD Player Pressing the top of the switch once will go to the next track on the CD.
Page 307: Radio Operation And Cellular Phones
RADIO OPERATION AND CELLULAR PHONES Under certain conditions, the cellular phone being on in your vehicle can cause erratic or noisy performance from your radio. This condition may be lessened or eliminated by relocating the cellular phone antenna. This condition is not harmful to the radio.
Page 308 306 UNDERSTANDING YOUR INSTRUMENT PANEL Front Blower Control There are seven blower speeds. Use this control to regulate the amount of air forced through the system in any mode you select. The blower speed increases as you move the control clockwise from the off position.
Page 309 Mode Control (Air Direction) Mode control allows you to choose from several selections of air distribu- tion. You can select either a primary mode, as identified by the symbols, or a blend of two of these modes. The closer the control is to a particular mode, the more air distribution you receive from that mode.
Page 310 308 UNDERSTANDING YOUR INSTRUMENT PANEL Mix Mode Air is directed through the floor, defrost and side window demist outlets. This setting works best in cold or snowy conditions that require extra heat at the windshield. This setting is good for maintaining comfort, while reducing moisture on the windshield.
Page 311 NOTE: • If the RECIRCULATION button is pressed when the system is in MIX, DEFROST, or FLOOR mode the RECIRCULATION LED indicator will flash 3 times and then turn off to indicate RECIRCULATION mode is not allowed. • Continuous use of the RECIRCULATION mode may make the inside air stuffy and window fogging may occur.
Page 312 310 UNDERSTANDING YOUR INSTRUMENT PANEL Air Conditioning Operation Push on this button to engage the Air Condition- ing (A/C). A light will illuminate when the A/C System is engaged NOTE: The air conditioning compressor will not engage until the engine has been running for about 10 seconds. Max A/C For maximum cooling use the A/C and RECIRCULA- TION mode buttons at the same time.
Page 313: Rear Manual Climate Control - If Equipped
The Three-Zone Temperature Control bottom panel con- trols rear Heating, Ventilation, and Air Conditioning operations. Front Lower Three-Zone Temperature Control Features 1 – Left Heated Seat 3 – Rear Temperature 2 – Rear Blower 4 – Right Heated Seat UNDERSTANDING YOUR INSTRUMENT PANEL 311 The primary control for the rear blower is on the front climate control unit located on the instrument panel.
Page 314 312 UNDERSTANDING YOUR INSTRUMENT PANEL The rear blower and temperature controls for the rear seat passengers are located in the headliner, near the center of the vehicle. Rear Manual Climate Controls 1 – Rear Blower 3 – Rear Climate Control Lock 2 –...
Page 315 CAUTION! Interior air enters the Rear Manual Climate Control system through an intake grille, located in the pas- senger side trim panel behind the third row seats. The heater outlets are located in the passenger side trim panel, just behind the sliding door. Do not block or place objects directly in front of the inlet grille or heater outlets.
Page 316: Automatic Temperature Control (Atc) - If Equipped
314 UNDERSTANDING YOUR INSTRUMENT PANEL Rear Mode Control Headliner Mode Air comes from the outlets in the headliner. Each of these outlets can be individually adjusted to direct the flow of air. Moving the air vanes of the outlets to one side will shut off the airflow.
Page 317 Front Upper ATC Panel 1 - System On/Off 9 - Air Conditioning (A/C) On/Off 2 - Blower Indicator 10 - AUTO Mode / Blower 3 - Left Front Temperature 11 - Front MODE 4 - Rear Blower / Temperature / 12 - RECIRCULATE Mode 5 - SYNC Indicator...
Page 318 316 UNDERSTANDING YOUR INSTRUMENT PANEL Automatic Operation 1. Press the AUTO button on the Front Upper ATC Panel and the word AUTO will illuminate in the front ATC display, along with three temperatures for driver, front passenger, and rear seats. The system will then automati- cally regulate the amount of airflow.
Page 319 Manual Operation This system offers a full complement of manual override features. The AUTO symbol in the front ATC display will be turned off when the system is being used in the manual mode. NOTE: Each of these features operate independently from each other.
Page 320 318 UNDERSTANDING YOUR INSTRUMENT PANEL Floor Mode Air comes from the floor outlets. A slight amount of air is directed through the defrost and side window demister outlets. Mix Mode Air comes from the floor, defrost and side window demist outlets. This mode works best in cold or snowy conditions.
Page 321 Recirculation Control When outside air contains smoke, odors, or high humidity, or if rapid cooling is desired, you may wish to recirculate interior air by pressing the RECIRCULATION mode control button. RECIRCULATION mode should only be used temporarily. The recirculation symbol will illuminate in the display when this button is selected.
Page 322 320 UNDERSTANDING YOUR INSTRUMENT PANEL The Rear ATC System is located in the headliner, near the center of the vehicle. Rear ATC Control Features 1 - Blower Speed 3 - Rear ATC Lock 2 - Rear Temperature 4 - Rear MODE 1.
Page 323 NOTE: • It is not necessary to move the temperature settings for cold or hot vehicles. The system automatically adjusts the temperature, mode and fan speed to provide comfort as quickly as possible. • The temperature can be displayed in English or Metric units by selecting the “Display Units of Measure in”...
Page 324: Summer Operation
322 UNDERSTANDING YOUR INSTRUMENT PANEL When rear controls are locked by the front system, the LOCK symbol on the temperature knob is illuminated and any rear overhead adjustments are ignored. Rear Mode Control Auto Mode The rear system automatically maintains the correct mode and comfort level desired by the rear seat occu- pants.
Page 325: Winter Operation
Winter Operation To ensure the best possible heater and defroster perfor- mance, make sure the engine cooling system is function- ing properly and the proper amount, type, and concen- tration of coolant is used. Refer to “Maintenance Procedures” in section 7 of this manual for proper coolant selection.
Page 326: Operating Tips
324 UNDERSTANDING YOUR INSTRUMENT PANEL Operating Tips A/C Air Filter— If Equipped On vehicles equipped with Automatic Temperature Con- trol (ATC), the climate control system filters out dust and pollen from the air. Refer to “Air Conditioning” in Section 7 of this manual for filter replacement instructions.
Page 327: Starting And Operating
STARTING AND OPERATING CONTENTS Starting Procedures ....329 Automatic Transaxle ....329 Normal Starting .
Page 328 326 STARTING AND OPERATING Driving Through Water ....340 Flowing/Rising Water ....340 Shallow Standing Water .
Page 329 Fuel Requirements ....378 3.3L/3.8L Gasoline Engine ... . . 378 4.0L Gasoline Engine .
Page 330 328 STARTING AND OPERATING Trailer Towing ..... . . 393 Common Towing Definitions Towing Tips ..... . . 406 Recreational Towing (Behind Motorhome, Etc.) .
Page 331: Starting Procedures
STARTING PROCEDURES Before starting your vehicle, adjust your seat, adjust the inside and outside mirrors, fasten your seat belt, and if present, instruct all other occupants to buckle their seat belts. WARNING! • Never leave unattended children alone in a ve- hicle.
Page 332: Extreme Cold Weather (Below 20°F Or -29°C)
330 STARTING AND OPERATING NOTE: This vehicle is equipped with a transaxle shift interlocking system. The brake pedal must be pressed to shift out of PARK. Extreme Cold Weather (Below Follow the same instructions in the “Normal Starting” procedure. To ensure reliable starting at these temperatures, use of an externally powered electric engine block heater (avail- able from your authorized dealer) is recommended.
Page 333: After Starting
CAUTION! To prevent damage to the starter, DO NOT crank the engine for more than 15–second intervals at one time. Wait 10 to 15 seconds before trying again. If the engine has been flooded, it may start to run, but not have enough power to continue running when the key is released.
Page 334: Automatic Transaxle
332 STARTING AND OPERATING AUTOMATIC TRANSAXLE CAUTION! Damage to the transaxle may occur if the following precautions are not observed: • Move the shift lever into PARK only after the vehicle has come to a complete stop. • Do not move the shift lever from REVERSE, PARK, or NEUTRAL into any forward gear when the engine is above idle speed.
Page 335: Four-Speed Or Six-Speed Automatic Transaxle
Automatic Transaxle Ignition Interlock System For electrical system malfunctions, there is an override for the interlock system. In order to override this system, remove the cover located to the top right of the shift lever in the instrument panel. The override can be activated by pressing the white-colored tab, which can be accessed through the hole in the instrument panel.
Page 336: Gear Ranges
334 STARTING AND OPERATING Gear Ranges Do not race the engine when moving the shift lever from PARK or NEUTRAL positions into another gear range. PARK This range supplements the parking brake by locking the transaxle. The engine can be started in this gear. Never attempt to use PARK while the vehicle is in motion.
Page 337 The following indicators should be used to ensure that you have placed the shift lever into the PARK position: • When moving the shift lever into PARK, press the button on the shift lever and firmly move the lever all the way forward until it stops.
Page 338 336 STARTING AND OPERATING DRIVE — Six-Speed Transaxle This range should be used for most city and highway driving. It provides the smoothest upshifts, downshifts, and best fuel economy. However, use the Electronic Range Select (ERS) mode by moving the lever — / + and select the “5”...
Page 339 the transaxle into third gear, the transaxle will never shift above third gear, but can shift down to second or first gear automatically, when needed. Switching from ERS to DRIVE can be done at any vehicle speed. To shift from DRIVE mode to ERS mode, move the shift lever to the left (-) once.
Page 340 338 STARTING AND OPERATING Reset Mode - Electronic Transaxle The transaxle is monitored electronically for abnormal conditions. If a condition is detected that could cause damage, the transaxle automatically shifts into second gear (third gear for six-speed). The transaxle remains in second gear (third gear for six-speed) despite the forward gear selected.
Page 341: Driving On Slippery Surfaces
DRIVING ON SLIPPERY SURFACES Acceleration Rapid acceleration on snow covered, wet, or other slip- pery surfaces may cause the front wheels to pull errati- cally to the right or left. This phenomenon occurs when there is a difference in the surface traction under the front (driving) wheels.
Page 342: Driving Through Water
340 STARTING AND OPERATING DRIVING THROUGH WATER Driving through water more than a few inches/ centimeters deep will require extra caution to ensure safety and prevent damage to your vehicle. Flowing/Rising Water WARNING! Do not drive on or across a road or path where water is flowing and/or rising (as in storm run-off).
Page 343 CAUTION! (Continued) • Driving through standing water may cause dam- age to your vehicle’s drivetrain components. Al- ways inspect your vehicle’s fluids (i.e., engine oil, transmission/transaxle, axle, etc.) for signs of con- tamination (i.e., fluid that is milky or foamy in appearance) after driving through standing water.
Page 344: Power Steering
342 STARTING AND OPERATING POWER STEERING The standard power steering system will give you good vehicle response and increased ease of maneuverability in tight spaces. The system will provide mechanical steering capability if power assist is lost. If for some reason the power assist is interrupted, it will still be possible to steer your vehicle.
Page 345: Parking Brake
apparent, and/or the system is not functioning as antici- pated. Coordinate inspection efforts through an autho- rized dealer. CAUTION! Do not use chemical flushes in your power steering system as the chemicals can damage your power steering components. Such damage is not covered by the New Vehicle Limited Warranty.
Page 346 344 STARTING AND OPERATING Before leaving the vehicle, make sure that the parking brake is fully applied and place the shift lever in the PARK position. To release the parking brake, press the emergency brake pedal a second time and let your foot up as you feel the brake disengage.
Page 347: Anti-Lock Brake System (Abs)
WARNING! (Continued) • Never leave children alone in a vehicle. Leaving unattended children in a vehicle is dangerous for a number of reasons. A child or others could be seriously or fatally injured. Do not leave the key in the ignition. A child could operate power win- dows, other controls, or move the vehicle When parking on a hill, turn the front wheels toward the curb on a downhill grade, and away from the curb on an...
Page 348 346 STARTING AND OPERATING WARNING! • The Anti-Lock Brake System contains sophisti- cated electronic equipment that may be suscep- tible to interference caused by improperly in- stalled, high output equipment. This interference can cause possible loss of anti-lock braking capability. Installation of such equipment should be performed by qualified professionals.
Page 349: Anti-Lock Brake Warning Light
Anti-Lock Brake Warning Light The “Anti-Lock Brake Warning Light” moni- tors the anti-lock brake system. The light will come on when the ignition switch is turned to the ON position and may stay on for as long as four seconds. If the “Anti-Lock Brake Warning Light”...
Page 350: Brake Assist System (Bas)
348 STARTING AND OPERATING wheel(s) and engine power is reduced, to provide en- hanced acceleration and stability. A feature of the TCS functions similarly to a limited-slip differential, and controls the wheel spin across a driven axle. If one wheel on a driven axle is spinning faster than the other, the system will apply the brake of the spinning wheel.
Page 351: Electronic Stability Program (Esp)
application, and then applies optimum pressure to the brakes. This can help reduce braking distances. The BAS complements the ABS. Applying the brakes very quickly results in the best BAS assistance. To receive the benefit of the system, you must apply continuous braking pressure during the stopping sequence.
Page 352 350 STARTING AND OPERATING ESP uses sensors in the vehicle to determine the vehicle path intended by the driver and compares it to the actual path of the vehicle. When the actual path does not match the intended path, ESP applies the brake of the appropri- ate wheel to assist in counteracting the oversteer or understeer condition.
Page 353: Esp/Bas Warning Light
NOTE: To improve the vehicle’s traction when driving with snow chains, or starting off in deep snow, sand or gravel, it may be desirable to switch to the “Partial Off” mode by pressing the “ESP OFF” switch. Once the situation requiring ESP to be switched to the “Partial Off” mode is overcome, turn ESP back on by momentarily pressing the “ESP OFF”...
Page 354: Tire Safety Information
352 STARTING AND OPERATING TIRE SAFETY INFORMATION Tire Markings 1 — U.S. DOT Safety Stan- 4 — Maximum Load dards Code (TIN) 2 — Size Designation 5 — Maximum Pressure 3 — Service Description 6 — Treadwear, Traction and Temperature Grades NOTE: •...
Page 355 molded into the sidewall preceding the size designa- tion. Example: T145/80D18 103M. Tire Sizing Chart Size Designation: P = Passenger car tire size based on U.S. design standards ...blank... = Passenger car tire based on European design standards LT = Light truck tire based on U.S. design standards T = Temporary spare tire 31 = Overall diameter in inches (in) 215 = Section width in millimeters (mm)
Page 356 354 STARTING AND OPERATING Service Description: 95 = Load Index — A numerical code associated with the maximum load a tire can carry H = Speed Symbol — A symbol indicating the range of speeds at which a tire can carry a load corresponding to its load index under certain operating conditions —...
Page 357: Tire Identification Number (Tin)
Tire Identification Number (TIN) The TIN may be found on one or both sides of the tire, however, the date code may only be on one side. Tires with white sidewalls will have the full TIN, including the date code, located on the white sidewall side of the tire. DOT = Department of Transportation —...
Page 358: Tire Loading And Tire Pressure
356 STARTING AND OPERATING Tire Loading and Tire Pressure Tire Placard Location NOTE: The proper cold tire inflation pressure is listed on the driver’s side B-Pillar. Tire and Loading Information Placard Tire and Loading Information Placard This placard tells you important information about the: 1) number of people that can be carried in the vehicle 2) total weight your vehicle can carry...
Page 359 Loading The vehicle maximum load on the tire must not exceed the load carrying capacity of the tire on your vehicle. You will not exceed the tire’s load carrying capacity if you adhere to the loading conditions, tire size, and cold tire inflation pressures specified on the Tire and Loading Information placard and in the “Vehicle Loading”...
Page 360 358 STARTING AND OPERATING available cargo and luggage load capacity is 650 lbs (295 kg) (since 5 x 150 = 750, and 1400 – 750 = 650 lbs [295 kg]). 5. Determine the combined weight of luggage and cargo being loaded on the vehicle. That weight may not safely exceed the available cargo and luggage load capacity calculated in Step 4.
Page 361 STARTING AND OPERATING 359...
Page 362: Tires - General Information
360 STARTING AND OPERATING WARNING! Overloading of your tires is dangerous. Overloading can cause tire failure, affect vehicle handling, and increase your stopping distance. Use tires of the recommended load capacity for your vehicle. Never overload them. TIRES — GENERAL INFORMATION Tire Pressure Proper tire inflation pressure is essential to the safe and satisfactory operation of your vehicle.
Page 363 WARNING! (Continued) • Unequal tire pressures from one side of the ve- hicle to the other can cause the vehicle to drift to the right or left. • Always drive with each tire inflated to the recom- mended cold tire inflation pressure. Economy Improper inflation pressures can cause uneven wear patterns to develop across the tire tread.
Page 364 362 STARTING AND OPERATING Inflation pressures specified on the placard are always “cold tire inflation pressure.” Cold tire inflation pressure is defined as the tire pressure after the vehicle has not been driven for at least three hours, or driven less than 1 mile (1.6 km) after a three-hour period.
Page 365 WARNING! High-speed driving, with your vehicle at or above maximum load, is dangerous. The added strain on your tires could cause them to fail. You could have a serious accident. Do not drive a vehicle loaded to the maximum capacity at continuous speeds above 75 mph (120 km/h).
Page 366 364 STARTING AND OPERATING WARNING! (Continued) • Temporary-use spare tires have limited tread life. When the tread is worn to the tread wear indica- tors, the temporary use spare tire needs to be replaced. • Be sure to follow the warnings that apply to your spare.
Page 367 WARNING! • Fast spinning tires can be dangerous. Forces gen- erated by excessive wheel speeds may cause tire damage or failure. A tire could explode and injure someone. • Do not spin your vehicle’s wheels faster than 30 mph (48 km/h), or for more than 30 seconds continuously, when you are stuck;...
Page 368 366 STARTING AND OPERATING Tire Life The service life of a tire is dependent upon varying factors, including, but not limited to: • Driving style • Tire pressure • Distance driven WARNING! The tires and the spare tire should be replaced after six years, regardless of the remaining tread.
Page 369: Tire Chains
WARNING! • Do not use a tire, wheel size or rating other than that specified for your vehicle. Some combinations of unapproved tires and wheels may change sus- pension dimensions and performance characteris- tics, resulting in changes to steering, handling, and braking of your vehicle.
Page 370 368 STARTING AND OPERATING CAUTION! To avoid damage to your vehicle or tires, observe the following precautions: • Use chains on P225/65R16 tires only. P225/65R17 tires do not provide adequate clearance. • Because of restricted chain clearance between tires and other suspension components, it is important that only chains in good condition are used.
Page 371: Snow Tires
SNOW TIRES Some areas of the country require the use of snow tires during Winter. Standard tires are of the all-season type and satisfy this requirement as indicated by the M+S designation on the tire sidewall. If you need snow tires, select tires equivalent in size and type to the original equipment tires.
Page 372: Tire Pressure Monitor System (Tpms)
370 STARTING AND OPERATING The suggested rotation method is shown in the following diagram. Tire Rotation TIRE PRESSURE MONITOR SYSTEM (TPMS) The TPMS will warn the driver of a low tire pressure based on the cold inflation tire pressure requirements found on the tire placard located on the driver’s-side B-pillar.
Page 373 The TPMS will continue to warn the driver of low tire pressure as long as the condition exists, and will not turn off until the tire pressure is at or above recommended cold tire placard pressure. Once the low tire pressure warning has been illuminated, the tire pressure must be increased to the recommended cold tire placard pressure in order for the “TPMS Warning Lamp”...
Page 374: Base System
372 STARTING AND OPERATING CAUTION! (Continued) • After inspecting or adjusting the tire pressure always reinstall the valve stem cap. This will prevent moisture and dirt from entering the valve stem, which could damage the TPMS sensor. NOTE: • The TPMS is not intended to replace normal tire care and maintenance, or to provide warning of a tire failure or condition.
Page 375 The Basic TPMS consists of the following components: • Receiver Module • Four Tire Pressure Monitoring Sensors • TPMS Telltale Warning Light Tire Pressure Monitoring Low Tire Pressure Warnings The “TPMS Telltale Warning Light” will illu- minate in the instrument cluster, and an au- dible chime will be activated when one or more of the four active road tire pressures are low.
Page 376: Premium System - If Equipped
374 STARTING AND OPERATING 3. Accumulation of excessive snow and/or ice around the wheels or wheel housings. 4. Using tire chains on the vehicle. 5. Using wheels/tires not equipped with TPMS sensors. Vehicles with Compact Spare 1. The compact spare tire (if equipped) does not have a TPMS sensor.
Page 377 NOTE: It is particularly important to regularly check and maintain proper tire pressure in all the tires. The Premium TPMS consists of the following compo- nents: • Receiver Module • Four TPMS Sensors • Three Trigger Modules (mounted in three of the four wheel wells) •...
Page 378 376 STARTING AND OPERATING Should a low tire condition occur on any of the four active road tire(s), you should stop as soon as possible, and inflate the low tire(s) that is flashing on the graphic display to the vehicle’s recommended cold tire pressure value.
Page 379 will not be present, and a pressure value will be dis- played instead of dashes. A system fault can occur by any of the following scenarios: 1. Jamming due to electronic devices or driving next to facilities emitting the same radio frequencies as the TPMS sensors.
Page 380: Fuel Requirements
378 STARTING AND OPERATING 5. Once you repair or replace the original road tire, and reinstall it on the vehicle in place of the compact spare, the TPMS will update automatically. In addition, the “TPMS Telltale Warning Light” will turn off and the graphic in the EVIC will display a new pressure value instead of dashes (- -), as long no tire pressure is below the low pressure warning limit in any of the four active...
Page 381: 4.0L Gasoline Engine
“regular” gasoline be- fore considering service for the vehicle. STARTING AND OPERATING 379 Over 40 automobile manufacturers around the world have issued and endorsed consistent gasoline specifica- tions (the World Wide Fuel Charter, WWFC) to define fuel properties necessary to deliver enhanced emissions, engine performance, and durability for your vehicle.
Page 382: Gasoline/Oxygenate Blends
380 STARTING AND OPERATING Gasoline/Oxygenate Blends Some fuel suppliers blend unleaded gasoline with oxy- genates such as 10% ethanol, MTBE, and ETBE. Oxygen- ates are required in some areas of the country during the winter months to reduce carbon monoxide emissions. Fuels blended with these oxygenates may be used in your vehicle.
Page 383: Mmt In Gasoline
• disconnect and reconnect the battery to reset the engine controller memory More extensive repairs will be required for prolonged exposure to E-85 fuel. MMT In Gasoline MMT is a manganese containing metallic additive that is blended into some gasoline to increase octane. Gasoline blended with MMT provides no performance advantage beyond gasoline of the same octane number without MMT.
Page 384: Carbon Monoxide Warnings
382 STARTING AND OPERATING • An out-of-tune engine, or certain fuel or ignition malfunctions, can cause the catalytic converter to overheat. If you notice a pungent burning odor or some light smoke, your engine may be out of tune or malfunctioning and may require immediate service.
Page 385: Flexible Fuel (3.3L Engines Only) - If Equipped
WARNING! (Continued) • Guard against carbon monoxide with proper maintenance. Have the exhaust system inspected every time the vehicle is raised. Have any abnor- mal conditions repaired promptly. Until repaired, drive with all side windows fully open. • Keep the liftgate closed when driving your vehicle to prevent carbon monoxide and other poisonous exhaust gases from entering the vehicle.
Page 386: Ethanol Fuel (E-85)
384 STARTING AND OPERATING CAUTION! Only vehicles with the E-85 fuel filler door label can operate on E-85. E-85 Badge ETHANOL FUEL (E-85) E-85 is a mixture of approximately 85% fuel ethanol and 15% unleaded gasoline. WARNING! Ethanol vapors are extremely flammable and could cause serious personal injury.
Page 387: Selection Of Engine Oil For Flexible Fuel Vehicles E-85 And Gasoline Vehicles
For best results, a refueling pattern that avoids alternat- ing between E-85 and unleaded gasoline is recom- mended. When you do switch fuel types, it is recommended that: • you do not add less than 5 gal (19 L) when refueling •...
Page 388: Starting
386 STARTING AND OPERATING Starting The characteristics of E-85 fuel make it unsuitable for use when ambient temperatures fall below 0°F (-18°C). In the range of 0°F (-18°C) to 32°F (0°C), you may experience an increase in the time it takes for your engine to start, and a deterioration in driveability (sags and/or hesitations) until the engine is fully warmed up.
Page 389: Adding Fuel
ADDING FUEL Fuel Filler Cap (Gas Cap) As a reminder, a fuel icon with an arrow indicating which side of the vehicle the fuel filler door is located on, is located in the instrument cluster, just below the fuel gauge. The gas cap is located behind the fuel filler door on the left side of the vehicle.
Page 390: Loose Fuel Filler Cap Message
388 STARTING AND OPERATING WARNING! • Never have any smoking materials lit in or near the vehicle when the gas cap is removed or the tank filled. • Never add fuel when the engine is running. This is in violation of most state and federal fire regula- tions and will cause the “Malfunction Indicator Light”...
Page 391: Vehicle Loading
If the problem continues, the message will appear the next time the vehicle is started. See your authorized dealer as soon as possible. VEHICLE LOADING As required by National Highway Traffic Safety Admin- istration regulations, your vehicle has a certification label affixed to the driver’s side door or B-Pillar.
Page 392 390 STARTING AND OPERATING Gross Axle Weight Rating (GAWR) The GAWR is the maximum capacity of the front and rear axles. Distribute the load over the front and rear axles evenly. Make sure that you do not exceed either front or rear GAWR.
Page 393 Overloading The load carrying components (axle, springs, tires, wheels, etc.) of your vehicle will provide satisfactory service as long as you do not exceed the GVWR and front and rear GAWR. The best way to figure out the total weight of your vehicle is to weigh it when it is fully loaded and ready for operation.
Page 394 392 STARTING AND OPERATING A loaded vehicle is shown in the illustration. Note that neither the GVWR or the GAWR capacities have been exceeded. LOADING TABLE — EXAMPLE ONLY Front Axle Empty Weight 2,140 lbs (971 kg) Load (Driver, 360 lbs (163 kg) passengers, and cargo/luggage) TOTAL...
Page 395 TRAILER TOWING In this section you will find safety tips and information on limits to the type of towing you can reasonably do with your vehicle. Before towing a trailer, carefully review this information to tow your load as efficiently and safely as possible.
Page 396 394 STARTING AND OPERATING WARNING! It is important that you do not exceed the maximum front or rear GAWR. A dangerous driving condition can result if either rating is exceeded. You could lose control of the vehicle and have an accident. Trailer Tongue Weight (TW) The TW is the downward force exerted on the hitch ball by the trailer.
Page 397 also dampens sway caused by traffic and crosswinds and contributes positively to tow vehicle and trailer stability. Trailer sway control and a weight distributing (load equalizing) hitch are recommended for heavier tongue weights (TW), and may be required depending on vehicle and trailer configuration/loading to comply with gross axle weight rating (GAWR) requirements.
Page 398 396 STARTING AND OPERATING With Weight-Distributing Hitch (Correct) Improper Adjustment of Weight-Distributing Hitch (Incorrect)
Page 399 Trailer Hitch Classification Your vehicle may be factory-equipped for safe towing of trailers weighing over 2,000 lbs (907 kg) with the optional Trailer Tow Prep Package. See an authorized dealer for package content. The following chart provides the industry standard for the maximum trailer weight a given trailer hitch class can tow, and should be used to assist you in selecting the correct trailer hitch for your intended towing condition.
Page 400 398 STARTING AND OPERATING Trailer Towing Weights (Maximum Trailer Weight Ratings) The following chart provides the maximum trailer weight ratings towable for your given drivetrain. GCWR (Gross Com- Engine/Transaxle bined Wt. Rating) 7,000 lbs (3 175 kg) 3.3L, 3.8L and 4.0L/ 7,000 lbs (3 175 kg) Automatic 7,000 lbs (3 175 kg)
Page 401 GCWR (Gross Com- Engine/Transaxle bined Wt. Rating) 9,000 lbs (4 082 kg) 3.8L and 4.0L/ 9,000 lbs (4 082 kg) Automatic (with Tow Package) 9,000 lbs (4 082 kg) * For vehicles equipped with Fold-in-Floor seating, the Gross Trailer Weight must be reduced by 100 lbs (45 kg). Refer to local laws for maximum trailer towing speeds.
Page 402 400 STARTING AND OPERATING Trailer and Trailer Tongue Weight Always load a trailer with 60% to 65% of the weight in the front of the trailer. This places 10% to 15% of the Gross Trailer Weight (GTW) on the tow hitch of your vehicle.
Page 403 NOTE: Remember that everything put into or on the trailer adds to the load on your vehicle. Also, additional factory-installed options, or authorized dealer-installed options, must be considered as part of the total load on your vehicle. Refer to the Tire and Loading Information placard in the “Tire-Safety Information”...
Page 404 402 STARTING AND OPERATING • When hauling cargo or towing a trailer, do not over- load your vehicle or trailer. Overloading can cause a loss of control, poor performance or damage to brakes, axle, engine, transaxle, steering, suspension, chassis structure or tires. •...
Page 405 Towing Requirements — Tires • Do not attempt to tow a trailer while using a compact spare tire. • Proper tire inflation pressures are essential to the safe and satisfactory operation of your vehicle. Refer to “Tires–General Information” in this section for proper tire inflation procedures.
Page 406 404 STARTING AND OPERATING CAUTION! If the trailer weighs more than 1,000 lbs (454 kg) loaded, it should have its own brakes and they should be of adequate capacity. Failure to do this could lead to accelerated brake lining wear, higher brake pedal effort, and longer stopping distances.
Page 407 Towing Requirements — Trailer Lights and Wiring Whenever you pull a trailer, regardless of the trailer size, stop lights and turn signals on the trailer are required for motoring safety. The Trailer Tow Package may include a four-pin or a seven-pin wiring harness.
Page 408 406 STARTING AND OPERATING Seven-Pin Connector 1 — Battery 5 — Ground 2 — Backup Lamps 6 — Left Stop/Turn 3 — Right Stop/Turn 7 — Running Lamps 4 — Electric Brakes Towing Tips Before setting out on a trip, practice turning, stopping and backing the trailer in an area away from heavy traffic.
Page 409 The automatic transaxle fluid and filter should be changed if you REGULARLY tow a trailer for more than 45 minutes of continuous operation. Refer to the “Main- tenance Schedule” in Section 8 of this manual for the proper maintenance intervals. NOTE: •...
Page 410 408 STARTING AND OPERATING Cooling System To reduce potential for engine and transaxle overheating, take the following actions: • City Driving When stopped for short periods of time, put the shift lever in NEUTRAL but do not increase engine idle speed. •...
Page 411: What To Do In Emergencies
WHAT TO DO IN EMERGENCIES CONTENTS Hazard Warning Flasher ....410 If Your Engine Overheats ....410 Jacking And Tire Changing .
Page 412: Hazard Warning Flasher
410 WHAT TO DO IN EMERGENCIES HAZARD WARNING FLASHER The Hazard Warning flasher switch is located in the center of the instrument panel above the radio. Press the switch to turn on the Hazard Warning flasher. When the switch is activated, all directional turn signals will flash on and off to warn oncoming traffic of an emergency.
Page 413: Jacking And Tire Changing
CAUTION! Driving with a hot cooling system could damage your vehicle. If temperature gauge reads “H”, pull over and stop the vehicle. Idle the vehicle with the air conditioner turned off until the pointer drops back into the normal range. If the pointer remains on the “H”, turn the engine off immediately, and call for service.
Page 414: Jack Location
412 WHAT TO DO IN EMERGENCIES WARNING! (Continued) • For vehicles equipped with Stow ’n Go seating, if it is necessary to retrieve the spare tire from under the vehicle on the side of the vehicle close to moving traffic. Pull far enough off the road to avoid the danger of being hit.
Page 415 Spare Tire Removal For vehicles equipped with Stow ’n Go seating, the spare tire is stowed inside a protective cover located under the center of the vehicle by means of a cable winch mechanism. The “spare tire drive” nut is located on the floor, under a plastic cap at the front of the floor console.
Page 416 414 WHAT TO DO IN EMERGENCIES Preparations For Jacking 1. Park the vehicle on a firm, level surface. Avoid ice or slippery areas. WARNING! Do not attempt to change a tire on the side of the vehicle close to moving traffic. Pull far enough off the road to avoid being hit when operating the jack or changing the wheel.
Page 417 Jacking Instructions WARNING! Carefully follow these tire changing warnings to help prevent personal injury or damage to your vehicle: • Always park on a firm, level surface as far from the edge of the roadway as possible before raising the vehicle. •...
Page 418 416 WHAT TO DO IN EMERGENCIES WARNING! (Continued) • Turn on the Hazard Warning flasher. Jack Warning Label 1. Loosen (but do not remove) the wheel lug nuts by turning them to the left one turn while the wheel is still on the ground.
Page 419 3. Assemble the winch handle extensions to form the Spare Tire Hook and pull the compact spare tire/cover assembly from under the vehicle. WARNING! Getting under a jacked-up vehicle is dangerous. The vehicle could slip off the jack and fall on you. You could be crushed.
Page 420 418 WHAT TO DO IN EMERGENCIES 4. When the compact spare tire/cover assembly is clear of the vehicle, stand the tire/cover assembly upright and remove the wheel spacer by squeezing the two retainer tabs together. Squeezing Winch Retainer Tabs 5. There are two jack engagement locations on each side of the vehicle body.
Page 421 WHAT TO DO IN EMERGENCIES 419 Jack Location...
Page 422 420 WHAT TO DO IN EMERGENCIES CAUTION! Do not attempt to raise the vehicle by jacking on locations other than those indicated in Step 5. 6. Place the wrench on the jack screw and turn to the right until the jack head is properly engaged in the described location.
Page 423 10. Lower the vehicle by turning the jack screw to the left. 11. Finish tightening the lug nuts. Push down on the wrench while tightening for increased leverage. Alternate lug nuts until each nut has been tightened twice. The correct wheel nut tightness is 95 ft lbs (130 N·m). If in doubt about the correct tightness, have them checked with a torque wrench by your authorized dealer or at a service station.
Page 424 422 WHAT TO DO IN EMERGENCIES of operation, and after each time a tire is changed, to allow the wheel nuts to become properly set. All nuts should first be firmly seated against the wheel. The nuts should then be tightened to recommended torque. Tighten the nuts to final torque in increments.
Page 425 2. Assemble the winch handle extensions to form the spare tire hook, and pull the wheel spacer from under the vehicle. 3. Turn the compact spare tire so that the valve stem is down, and place the tire into the spare tire/cover assem- bly.
Page 426: Jump-Starting Procedure
424 WHAT TO DO IN EMERGENCIES CAUTION! For vehicles equipped with Stow ’n Go seating, the winch mechanism is designed specifically to stow a compact spare tire only. Do not attempt to use the winch to stow the full size flat tire, or any other full-size tire.
Page 427 WARNING! (Continued) • Take special care to avoid the radiator cooling fan whenever the hood is raised. The cooling fan is electrically operated and can start anytime the ignition switch is ON. You can be hurt by the fan. • During cold weather when temperatures are be- low the freezing point, electrolyte in a discharged battery may freeze.
Page 428 426 WHAT TO DO IN EMERGENCIES WARNING! Do not permit vehicles to touch each other, as this could establish a ground connection and personal injury could result. 5. Connect the other cable, first to the negative terminal of the booster battery, and then to the engine of the vehicle with the discharged battery.
Page 429: Freeing A Stuck Vehicle
FREEING A STUCK VEHICLE If your vehicle becomes stuck in mud, sand or snow, it can often be moved by a rocking motion. Turn your steering wheel right and left to clear the area around the front wheels. Then move the shift lever back and forth between REVERSE and DRIVE.
Page 430 428 WHAT TO DO IN EMERGENCIES CAUTION! Exceeding these towing limits may cause a transmis- sion gear failure. If the transmission is inoperative, or if the vehicle is to be towed more than 100 miles (160 km), the vehicle must be towed with the front wheels off the ground.
Page 431 If it is necessary to use the accessories while being towed (wipers, defrosters, etc.), the key must be in the ON position, not the ACC position. Make certain the trans- mission remains in NEUTRAL. Towing Without The Ignition Key Special care must be taken when the vehicle is towed with the ignition in the OFF position.
Page 433 MAINTAINING YOUR VEHICLE CONTENTS Engine Compartment — 3.3/3.8L Engine Compartment — 4.0L ... . 434 Onboard Diagnostic System — OBD II Loose Fuel Filler Cap Message — Gascap Emissions Inspection And Maintenance Programs .
Page 434 432 MAINTAINING YOUR VEHICLE Cooling System ....451 Brakes ......456 Automatic Transaxle .
Page 435: Engine Compartment - 3.3/3.8L
ENGINE COMPARTMENT — 3.3/3.8L 1 — Air Cleaner Filter 2 — Automatic Transmission Dipstick (3.3L Only) 3 — Brake Fluid Reservoir 4 — Battery 5 — Totally Integrated Power Module 6 — Engine Coolant Reservoir MAINTAINING YOUR VEHICLE 433 7 — Engine Oil Fill 8 —...
Page 436: Engine Compartment - 4.0L
434 MAINTAINING YOUR VEHICLE ENGINE COMPARTMENT — 4.0L 1 — Power Steering Fluid Reservoir 2 — Air Cleaner Filter 3 — Brake Fluid Reservoir 4 — Battery 5 — Totally Integrated Power Module 6 — Engine Coolant Reservoir 7 — Engine Oil Dipstick 8 —...
Page 437: Onboard Diagnostic System - Obd Ii
ONBOARD DIAGNOSTIC SYSTEM — OBD II Your vehicle is equipped with a sophisticated onboard diagnostic system called OBD II. This system monitors the performance of the emissions, engine, and automatic transmission control systems. When these systems are operating properly, your vehicle will provide excellent performance and fuel economy, as well as engine emis- sions well within current government regulations.
Page 438: Emissions Inspection And Maintenance Programs
436 MAINTAINING YOUR VEHICLE filler cap message will be displayed in the instrument cluster. Tighten the gas cap until a clicking sound is heard. This is an indication that the gas cap is properly tightened. Press the odometer reset button to turn the message off.
Page 439: Replacement Parts
4. As soon as you turn your key to the ON position, you will see the MIL symbol come on as part of a normal bulb check. 5. Approximately 15 seconds later, one of two things will happen: a. The MIL will flash for about 10 seconds and then return to being fully illuminated until you turn OFF the ignition or start the engine.
Page 440: Dealer Service
438 MAINTAINING YOUR VEHICLE DEALER SERVICE Your authorized dealer has the qualified service person- nel, special tools, and equipment to perform all service operations in an expert manner. Service Manuals are available which include detailed service information for your vehicle. Refer to these manuals before attempting any procedure yourself.
Page 441: Engine Oil
CAUTION! Your vehicle has been built with improved fluids that protect the performance and durability of your vehicle and also allow extended maintenance inter- vals. Do not use chemical flushes in these compo- nents as the chemicals can damage your engine, transmission, power steering or air conditioning.
Page 442 440 MAINTAINING YOUR VEHICLE Change Engine Oil The oil change indicator system will remind you that it is time to take your vehicle in for scheduled maintenance. Refer to the “Maintenance Schedule” in Section 8 of this manual for information on this system. NOTE: Under no circumstances should oil change intervals exceed 6,000 miles (10 000 km) or six months,...
Page 443 Engine Oil Viscosity (SAE Grade) — 3.3L & 3.8L Gasoline Engines SAE 5W-20 engine oil is recommended for all operating temperatures. This engine oil improves low temperature starting and vehicle fuel economy. Your engine oil filler cap also shows the recommended engine oil viscosity for your vehicle.
Page 444: Engine Oil Filter
442 MAINTAINING YOUR VEHICLE Disposing of Used Engine Oil and Oil Filters Care should be taken in disposing of used engine oil and oil filters from your vehicle. Used oil and oil filters, indiscriminately discarded, can present a problem to the environment.
Page 445: Exhaust System
used to assure most efficient service. MOPAR engine air cleaner filters are a high quality filter and are recommended. Exhaust System The best protection against carbon monoxide entry into the vehicle body is a properly maintained engine exhaust system. Whenever a change is noticed in the sound of the exhaust system, when exhaust fumes can be detected inside the vehicle, or when the underside or rear of the vehicle is damaged, have a competent mechanic inspect the com-...
Page 446 444 MAINTAINING YOUR VEHICLE CAUTION! Damage to the catalytic converter can result if your vehicle is not kept in proper operating condition. In the event of engine malfunction, particularly involv- ing engine misfire or other apparent loss of perfor- mance, have your vehicle serviced promptly. Contin- ued operation of your vehicle with a severe malfunction could cause the converter to overheat, resulting in possible damage to the converter and the...
Page 447: Maintenance-Free Battery
To minimize the possibility of catalyst damage: • Do not shut OFF the engine or interrupt the ignition when the transaxle is in gear and the vehicle is in motion. • Do not try to start the engine by pushing or towing the vehicle.
Page 448: Air Conditioner Maintenance
446 MAINTAINING YOUR VEHICLE CAUTION! • It is essential when replacing the cables on the battery that the positive cable is attached to the positive post and the negative cable is attached to the negative post. Battery posts are marked posi- tive (+) and negative (-) and are identified on the battery case.
Page 449 WARNING! • Use only refrigerants and compressor lubricants approved by the manufacturer for your air condi- tioning system. Some unapproved refrigerants are flammable and can explode, injuring you. Other unapproved refrigerants or lubricants can cause the system to fail, requiring costly repairs. Refer to Section 3 of the Warranty Information book for further warranty information.
Page 450 448 MAINTAINING YOUR VEHICLE A/C Air Filter — If Equipped Refer to the “Maintenance Schedule” in Section 8 for the proper maintenance intervals. WARNING! Do not remove the A/C air filter while the blower is operating or personal injury may result. The A/C air filter is located in the fresh air inlet behind the glove box.
Page 451: Body Lubrication
CAUTION! The A/C air filter is labeled with an arrow to indicate airflow direction through the filter. Failure to prop- erly install the filter will result in the need to replace it more often. 7. Rotate the glove compartment door back into position. Body Lubrication Locks and all body pivot points, including such items as seat tracks, door hinge pivot points and rollers, liftgate,...
Page 452 450 MAINTAINING YOUR VEHICLE Avoid using the wiper blades to remove frost or ice from the windshield. Keep the blade rubber out of contact with petroleum products such as engine oil, gasoline, etc. NOTE: Life expectancy of wiper blades varies depend- ing on geographical area and frequency of use.
Page 453: Cooling System
Cooling System WARNING! • When working near the radiator cooling fan, dis- connect the fan motor lead or turn the ignition switch to the OFF position. The fan is temperature controlled and can start at anytime the ignition switch is in the ON position. •...
Page 454 452 MAINTAINING YOUR VEHICLE Cooling System — Drain, Flush and Refill If the engine coolant (antifreeze) is dirty or contains a considerable amount of sediment, clean and flush with a reliable cooling system cleaner. Follow with a thorough rinsing to remove all deposits and chemicals. Properly dispose of the old engine coolant (antifreeze) solution.
Page 455 CAUTION! (Continued) • This vehicle has not been designed for use with Propylene Glycol-based engine coolant (anti- freeze). Use of Propylene Glycol-based engine coolant (antifreeze) is not recommended. Adding Coolant Your vehicle has been built with an improved engine coolant (antifreeze) that allows extended maintenance intervals.
Page 456 454 MAINTAINING YOUR VEHICLE Please note that it is the owner’s responsibility to main- tain the proper level of protection against freezing ac- cording to the temperatures occurring in the area where the vehicle is operated. NOTE: Mixing engine coolant (antifreeze) types will decrease the life of the engine coolant (antifreeze) and will require more frequent coolant changes.
Page 457 rules for your community. To prevent ingestion by ani- mals or children, do not store ethylene glycol-based engine coolant (antifreeze) in open containers or allow it to remain in puddles on the ground. If ingested by a child, contact a physician immediately. Clean up any ground spills immediately.
Page 458: Brakes
456 MAINTAINING YOUR VEHICLE engine coolant (antifreeze) needs to be added, contents of the coolant recovery bottle must also be protected against freezing. • If frequent engine coolant (antifreeze) additions are required, or if the level in the coolant recovery bottle does not drop when the engine cools, the cooling system should be pressure tested for leaks.
Page 459 Master Cylinder — Brake Fluid Level Check The fluid level in the master cylinder should be checked when performing underhood services, or immediately if the “Brake System Warning Light” indicates system failure. Clean the top of the master cylinder area before removing the cap.
Page 460: Automatic Transaxle
458 MAINTAINING YOUR VEHICLE CAUTION! Do not allow petroleum based fluid to contaminate the brake fluid — all brake seal components could be damaged, causing partial or complete brake failure. Automatic Transaxle The automatic transaxle and differential assembly are contained within a single housing. The fluid level in the automatic transaxle should be checked whenever the vehicle is serviced.
Page 461 CAUTION! Using a transmission fluid other than the manufac- turer’s recommended fluid may cause deterioration in transaxle shift quality and/or torque converter shudder. Using a transmission fluid other than the manufacturer’s recommended fluid will result in more frequent fluid and filter changes. Refer to “Fluids, Lubricants and Genuine Parts”...
Page 462 460 MAINTAINING YOUR VEHICLE 5. Remove the dipstick and determine if the fluid is hot or warm. Hot fluid is approximately 180°F (82°C), which is the normal operating temperature after the vehicle has been driven at least 15 miles (24 km). The fluid cannot be comfortably held between the fingertips.
Page 463: Appearance Care And Protection From Corrosion
the use of special dyes to aid in detecting fluid leaks. In addition, avoid using transaxle sealers as they may adversely affect seals. CAUTION! Do not use chemical flushes in your transmission as the chemicals can damage your transmission compo- nents.
Page 464 462 MAINTAINING YOUR VEHICLE Washing • Wash your vehicle regularly. Always wash your ve- hicle in the shade using MOPAR Car Wash or a mild car wash soap, and rinse the panels completely with clear water. • If insects, tar or other similar deposits have accumu- lated on your vehicle, use MOPAR Super Kleen Bug and Tar Remover to remove.
Page 465 coating, have your vehicle repaired as soon as pos- sible. The cost of such repairs is considered the respon- sibility of the owner. • If you carry special cargo such as chemicals, fertilizers, de-icer salt, etc., be sure that such materials are well packaged and sealed.
Page 466 464 MAINTAINING YOUR VEHICLE • For grease stains, apply MOPAR Cleaner to a clean, damp cloth and remove the stain. Use a fresh, damp towel to remove soap residue. • Do not use any solvents or protectants on Stain Repel products.
Page 467 WARNING! Do not use volatile solvents for cleaning purposes. Many are potentially flammable, and if used in closed areas they may cause respiratory harm. Cleaning High Gloss Front Door and Pillar Appliques When cleaning the front door B-Pillar appliques, care must be taken to avoid scratching the plastic.
Page 468: Cleaning The Instrument Panel Cupholders
466 MAINTAINING YOUR VEHICLE cleaner. Use caution when cleaning the inside rear win- dow equipped with electric defrosters or the right rear quarter window equipped with the radio antenna. Do not use scrapers or other sharp instruments that may scratch the elements. When cleaning the rearview mirror, spray cleaner on the towel or rag that you are using.
Page 469: Fuses
Soak the liner in a mixture of medium hot tap water and one teaspoon of mild liquid dish soap. Let soak for approximately 30 minutes. After 30 minutes, pull the liner from the water and dip it back into the water about six times.
Page 470 468 MAINTAINING YOUR VEHICLE The numbers inside the TIPM cover correspond to the following table. FUSES/TIPM Cartridge Mini- Cavity Fuse Fuse 40 Amp — Power Folding Seat Green 30 Amp — Power Liftgate Mod- Pink 30 Amp — Rear Door Module Pink (RR Door Node) 25 Amp...
Page 471 FUSES/TIPM Cartridge Mini- Cavity Fuse Fuse 30 Amp — Rear Blower Pink 40 Amp — Starter Solenoid Green 20 Amp — Powertrain Control Blue Module (PCM) Trans Range 60 Amp — Radiator Fan Yellow 30 Amp — Front Wiper LO/HI Pink 20 Amp —...
Page 472 470 MAINTAINING YOUR VEHICLE FUSES/TIPM Cartridge Mini- Cavity Fuse Fuse — 20 Amp Yellow — 20 Amp Yellow — 15 Amp Blue Description Cavity Front Heated Seat (If Equipped) Rear Heated Seat (If Equipped) Ignition Off Draw — Vehicle Entertainment System (IOD-VES), Satellite Digital Audio Receiver (SDARS),...
Page 473 FUSES/TIPM Cartridge Mini- Cavity Fuse Fuse — 20 Amp Spare Fuse Yellow — 20 Amp Rear View Mirror Yellow (RR VW MIR), Cabin Compartment Node (CCN), Multi- Function Control Switch (MULTIFTCN SW), Tire Pressure Monitor (TPM), Glow Plug Module (GLW PLG MOD) —...
Page 474 472 MAINTAINING YOUR VEHICLE FUSES/TIPM Cartridge Mini- Cavity Fuse Fuse — 15 Amp Blue — 20 Amp Yellow — 10 Amp — 10 Amp — 25 Amp Natural Description Cavity Cabin Compartment Node Interior Light (CCN INT LIGHT), Switch Bank (SW BANK), Steering Con- trol Module (SCM), Switch Steering Wheel...
Page 475 FUSES/TIPM Cartridge Mini- Cavity Fuse Fuse — 10 Amp Next Generation Con- troller (NGC), PCM, Transmission Feed (TRANS FEED), TCM — 10 Amp Occupant Classifica- tion Module (OCM) — 15 Amp Rear Wiper Module Blue (RR WIPER MOD), Power Folding Mirror (PWR FOLD MIR), J1962 Diagnostic Feed Cartridge...
Page 476 474 MAINTAINING YOUR VEHICLE FUSES/TIPM Cartridge Mini- Cavity Fuse Fuse — 10 Amp — 10 Amp Description Cavity Park Assist (PRK ASST), Heater Ventila- tion, Air Conditioning Module (HVAC MOD), Headlamp Wash (HDLP WASH), Compass (COMPAS), IR Sensor, Rear Cam- era, Lamp Door FT Drv/Pass, Lamp Flashlight, AHLM,...
Page 477: Vehicle Storage
The heated mirrors, lower instrument panel power outlet and removable floor console, when in the front position are fused with self-resetting fuses that are only service- able by an authorized dealer. The power seats are fused by a 30 Amp circuit breaker located under the driver’s seat.
Page 478: Bulb Replacement
476 MAINTAINING YOUR VEHICLE NOTE: For lighted switches, see your authorized dealer for replacement instructions. All of the interior bulbs are glass wedge base or glass cartridge types. Aluminum base bulbs are not approved and should not be used for replacement. LIGHT BULBS —...
Page 479: Front Park/Turn Signal Lamps
5. Connect the wiring connector to bulb and slide red lock tab forward. Front Park/Turn Signal Lamps 1. Raise the hood to access the rear of the headlamp housing. 2. Twist the turn signal socket and remove from the headlamp housing, then pull the bulb out. 3.
Page 480: Rear Tail, Stop, Turn Signal, Side Marker And Backup Lamps
478 MAINTAINING YOUR VEHICLE Rear Tail, Stop, Turn Signal, Side Marker and Backup Lamps 1. Raise the liftgate. 2. Remove the tail lamp assembly by removing the two screws from the inboard side. Use a fiber stick or similar tool to gently pry the light on the outboard side to disengage the two ball studs.
Page 481: Center High-Mounted Stop Lamp (Chmsl)
1 — Stop, Tail, Turn Signal 2 — Backup Bulb Bulb Combo 3. Twist the socket and remove from the lamp assembly. 4. Pull the bulb to remove it from the socket. 5. Replace the bulb, reinstall the socket, and reattach the lamp assembly.
Page 482: Fluids And Capacities
480 MAINTAINING YOUR VEHICLE FLUIDS AND CAPACITIES Fuel (Approximate) Engine Oil with Filter 3.3L and 3.8L Engine (SAE 5W-20, API Certified) 4.0L Engine (SAE 10W-30, API Certified) Cooling System * 3.3L, 3.8L, and 4.0L Engine (MOPAR Engine Coolant/ Antifreeze 5 Year/100,000 Mile Formula) * Includes heater and coolant recovery bottle filled to MAX level.
Page 483: Fluids, Lubricants And Genuine Parts
FLUIDS, LUBRICANTS AND GENUINE PARTS Engine Component Engine Coolant Engine Oil (3.3L and 3.8L Engines) Engine Oil (4.0L Engine) Engine Oil Filter Spark Plugs (3.3L and 3.8L Engines) Spark Plugs (4.0L Engine) Fuel Selection (3.3L and 3.8L Engines) Fuel Selection (4.0L Engine) Fluid, Lubricant, or Genuine Part MOPAR Antifreeze/Coolant Five Year/100,000 Mile Formula HOAT (Hybrid Organic Additive Technology)
Page 484: Chassis
482 MAINTAINING YOUR VEHICLE Chassis Component Automatic Transaxle Brake Master Cylinder Power Steering Reservoir Fluid, Lubricant, or Genuine Part MOPAR ATF+4 Automatic Transmission Fluid MOPAR DOT 3 and SAE J1703 should be used or equivalent. If DOT 3 brake fluid is not available, then DOT 4 is acceptable. Use only rec- ommended brake fluids.
Page 485: Maintenance Schedules
MAINTENANCE SCHEDULES CONTENTS Emissions Control System Maintenance Maintenance Schedule ....484 Required Maintenance Intervals ..484 ..486...
Page 486 484 MAINTENANCE SCHEDULES EMISSIONS CONTROL SYSTEM MAINTENANCE The Scheduled Maintenance services listed in bold type must be done at the times or mileages specified to ensure the continued proper functioning of the emissions control system. These and all other maintenance services in- cluded in this manual, should be done to provide best vehicle performance and reliability.
Page 487 NOTE: • The oil change indicator message will not monitor the time since the last oil change. Change your vehicle’s oil if it has been six months since your last oil change, even if the oil change indicator message is NOT illuminated.
Page 488 486 MAINTENANCE SCHEDULES Once A Month • Check tire pressure and look for unusual wear or damage. • Inspect the battery and clean and tighten the terminals as required. • Check the fluid levels of the coolant reservoir, the brake master cylinder, the power steering and the transaxle and add as needed.
Page 489 6,000 Miles (10,000 km) or 6 Months Maintenance Service Schedule J Change the engine oil and engine oil filter. J Rotate tires. Odometer Reading Date Repair Order # Dealer Code Signature Authorized Chrysler Dealer 12,000 Miles (20,000 km) or 12 Months Maintenance Service Schedule J Change the engine oil and engine oil filter.
Page 490: Service Schedule
488 MAINTENANCE SCHEDULES 18,000 Miles (30,000 km) or 18 Months Maintenance Service Schedule J Change the engine oil and engine oil filter. J Rotate tires. Odometer Reading Repair Order # Dealer Code Signature Authorized Chrysler Dealer 24,000 Miles (40,000 km) or 24 Months Maintenance Service Schedule J Change the engine oil and engine oil filter.
Page 491 30,000 Miles (50,000 km) or 30 Months Maintenance Service Schedule J Change the engine oil and engine oil filter. J Rotate tires. J Replace the engine air cleaner filter. Odometer Reading Date Repair Order # Dealer Code Signature Authorized Chrysler Dealer 36,000 Miles (60,000 km) or 36 Months Maintenance Service Schedule...
Page 492 490 MAINTENANCE SCHEDULES 48,000 Miles (80,000 km) or 48 Months Maintenance Service Schedule J Change the engine oil and engine oil filter. J Rotate tires. J If using your vehicle for any of the following: Dusty or off-road conditions. Inspect the engine air cleaner filter, replace if necessary.
Page 493 60,000 Miles (100,000 km) or 60 Months Maintenance Service Schedule J Change the engine oil and engine oil filter. J Rotate tires. J Replace the engine air cleaner filter. J Replace the air conditioning filter. J Inspect the brake linings, replace if necessary. J Change the automatic transaxle fluid &...
Page 494 492 MAINTENANCE SCHEDULES 72,000 Miles (120,000 km) or 72 Months Maintenance Service Schedule J Change the engine oil and engine oil filter. J Rotate tires. J If using your vehicle for any of the following: Dusty or off-road conditions. Inspect the engine air cleaner filter, replace if necessary.
Page 495 84,000 Miles (140,000 km) or 84 Months Maintenance Service Schedule J Change the engine oil and engine oil filter. J Rotate tires. J If using your vehicle for any of the following: Dusty or off-road conditions. Inspect the engine air cleaner filter, replace if necessary.
Page 496 494 MAINTENANCE SCHEDULES 96,000 Miles (160,000 km) or 96 Months Maintenance Service Schedule J Change the engine oil and engine oil filter. J Rotate tires. J If using your vehicle for any of the following: Dusty or off-road conditions. Inspect the engine air cleaner filter, replace if necessary.
Page 497 108,000 Miles (180,000 km) or 108 Months Maintenance Service Schedule J Change the engine oil and engine oil filter. J Rotate tires. J If using your vehicle for any of the following: Dusty or off-road conditions. Inspect the engine air cleaner filter, replace if necessary.
Page 498 496 MAINTENANCE SCHEDULES 120,000 Miles (200,000 km) or 120 Months Maintenance Service Schedule J Change the engine oil and engine oil filter. J Rotate tires. J Replace the engine air cleaner filter. J Replace the air conditioning filter. J Inspect the brake linings, replace if necessary. J Inspect the CV Joints.
Page 499 132,000 Miles (220,000 km) or 132 Months Maintenance Service Schedule J Change the engine oil and engine oil filter. J Rotate tires. J If using your vehicle for any of the following: Dusty or off-road conditions. Inspect the engine air cleaner filter, replace if necessary.
Page 500 498 MAINTENANCE SCHEDULES 144,000 Miles (240,000 km) or 144 Months Maintenance Service Schedule J Change the engine oil and engine oil filter. J Rotate tires. J If using your vehicle for any of the following: Dusty or off-road conditions. Inspect the engine air cleaner filter, replace if necessary.
Page 501 † This maintenance is recommended by the manufac- turer, but is not required to maintain emissions warranty. WARNING! You can be badly injured working on or around a motor vehicle. Do only that service work for which you have the knowledge and the right equipment. If you have any doubt about your ability to perform a service job, take your vehicle to a competent me- chanic.
Page 503: If You Need Consumer Assistance
IF YOU NEED CONSUMER ASSISTANCE CONTENTS Suggestions For Obtaining Service For Your Vehicle......503 Prepare For The Appointment Prepare A List .
Page 504 502 IF YOU NEED CONSUMER ASSISTANCE Publication Order Forms ....507 Department Of Transportation Uniform Tire Quality Grades ......509 Treadwear .
Page 505: Suggestions For Obtaining Service For Your Vehicle
SUGGESTIONS FOR OBTAINING SERVICE FOR YOUR VEHICLE Prepare For The Appointment If you’re having warranty work done, be sure to have the right papers with you. Take your warranty folder. All work to be performed may not be covered by the warranty.
Page 506: Chrysler Llc Customer Center
504 IF YOU NEED CONSUMER ASSISTANCE This is why you should always talk to an authorized dealer’s service manager first. Most matters can be re- solved with this process. • If for some reason you are still not satisfied, talk to the general manager or owner of the authorized dealer- ship.
Page 507: Customer Assistance For The Hearing Or Speech Impaired (Tdd/Tty)
Customer Assistance For The Hearing Or Speech Impaired (TDD/TTY) To assist customers who have hearing difficulties, the manufacturer has installed special TDD (Telecommuni- cation Devices for the Deaf) equipment at its customer center. Any hearing or speech impaired customer, who has access to a TDD or a conventional teletypewriter (TTY) in the United States, can communicate with the manufacturer by dialing 1–800–380–CHRY.
Page 508: Warranty Information (U.s. Vehicles Only)
506 IF YOU NEED CONSUMER ASSISTANCE We appreciate that you have made a major investment when you purchased the vehicle. An authorized dealer has also made a major investment in facilities, tools, and training to assure that you are absolutely delighted with the ownership experience.
Page 509: In Canada
a group of vehicles, it may order a recall and remedy campaign. However, NHTSA cannot become involved in individual problems between you, your authorized dealer, and the manufacturer. To contact NHTSA, you may either call the Auto Safety Hotline toll free at 1–888–327–4236 (TTY: 1–800–424– 9153), or go to http://www.safercar.gov;...
Page 510 508 IF YOU NEED CONSUMER ASSISTANCE • Diagnostic Procedure Manuals Diagnostic Procedure Manuals are filled with dia- grams, charts and detailed illustrations. These practi- cal manuals make it easy for students and technicians to find and fix problems on computer-controlled ve- hicle systems and features.
Page 511 DEPARTMENT OF TRANSPORTATION UNIFORM TIRE QUALITY GRADES The following tire grading categories were established by the National Highway Traffic Safety Administration. The specific grade rating assigned by the tire’s manufacturer in each category is shown on the sidewall of the tires on your vehicle.
Page 512 510 IF YOU NEED CONSUMER ASSISTANCE Temperature Grades The temperature grades are A (the highest), B, and C, representing the tire’s resistance to the generation of heat and its ability to dissipate heat, when tested under controlled conditions on a specified indoor laboratory test wheel.
Page 513 INDEX...
Page 514 512 INDEX Adding Engine Coolant (Antifreeze) ..453 Adding Fuel ......387 Adding Washer Fluid .
Page 515 Automatic Temperature Control (ATC) ..314 Automatic Transaxle ..... . 332 Adding Fluid ......459 Fluid Level Check .
Page 516 514 INDEX Calibration, Compass ....255,261 Camera, Rear ......196 Capacities, Fluid .
Page 517 Compass Calibration ....255,261 Compass Variance ....254,262 Computer, Trip/Travel .
Page 518 516 INDEX Power Steering ......342 Disabled Vehicle Towing ....427 Disposal Antifreeze (Engine Coolant) .
Page 519 Cooling ......451 Exhaust Gas Caution ....50,92,382 Flooded, Starting .
Page 520 518 INDEX Flexible Fuel Vehicles Cruising Range ..... . . 386 Engine Oil ......385 Fuel Requirements .
Page 521 Garage Door Opener (HomeLink ) ... 201 Gas Cap (Fuel Filler Cap) ....387,388 Gasoline, Clean Air ..... . 379 Gasoline (Fuel) .
Page 522 520 INDEX Hitches Trailer Towing ......397 HomeLink (Garage Door Opener) Transmitter . . . 201 Hood Release ......175 Hook, Coat .
Page 523 Latches ....... . 94 Hood ......175 Lead Free Gasoline .
Page 524 522 INDEX Reading ......199 Rear Servicing ......478 Rear Tail .
Page 525 Exterior Folding ..... . . 102 Heated ......103 Memory .
Page 526 524 INDEX Owner’s Manual (Operator Manual) ..4,507 Panic Alarm ......23 Park Sense System, Rear .
Page 527 Rear Heater ......311 Rear Park Sense System ....191 Rear Window Defroster .
Page 528 526 INDEX And Pregnant Women ....62 Child Restraint ..... . . 79,81 Extender .
Page 529 Speedometer ......241 Starting ....... 329 Automatic Transmission .
Page 530 528 INDEX Changing ......411 Compact Spare ......363 Flat Changing .
Page 531 Trailer Weight ......398 Transaxle ......332 Automatic .
Page 532 530 INDEX Warning Flasher, Hazard ....410 Warning Lights (Instrument Cluster Description) ... . . 240 Warnings and Cautions .
Page 533 INTRODUCTION INTRODUCTION HOW TO USE THIS MANUAL WARNINGS AND CAUTIONS VEHICLE IDENTIFICATION NUMBER VEHICLE MODIFICATIONS/ALTERATIONS THINGS TO KNOW BEFORE STARTING YOUR VEHICLE A WORD ABOUT YOUR KEYS Wireless Ignition Node (WIN)SENTRY KEY Replacement KeysVEHICLE SECURITY ALARM - IF EQUIPPED Rearming Of The SystemILLUMINATED ENTRY SYSTEM - IF EQUIPPED REMOTE KEYLESS ENTRY (RKE) - IF EQUIPPED Using the RKE TransmitterREMOTE STARTING SYSTEM - IF EQUIPPED How to Use Remote StartDOOR LOCKS Manual Door LocksPower Door Locks - If EquippedWINDOWS Power Vent Windows - If EquippedPower WindowsSLIDING SIDE DOOR Power Sliding Side Door - If EquippedSliding Side Door Child Protection LockLIFTGATE Power Liftgate - If EquippedSTORAGE BIN SAFETY WARNING Safety WarningOCCUPANT RESTRAINTS Lap/Shoulder BeltsAutomatic Locking Retractors (ALR) Mode - If EquippedSeat Belt PretensionersEnhanced Seat Belt Use Reminder System (BeltAlert)Seat Belts and Pregnant WomenSeat Belt ExtenderSupplemental Restraint System (SRS) - AirbagsAirbag System ComponentsFront Seat Airbag FeaturesAirbag Deployment Sensors and ControlsEvent Data Recorder (EDR)Integrated Child Booster Seat...
Page 534 INSTALLATION OF RADIO TRANSMITTING EQUIPMENT Special design considerations are incorporated into this vehicle’s electronic system to provide immunity to radio frequency signals. Mobile two-way radios and telephone equipment must be installed properly by trained person- nel. The following must be observed during installation. The positive power connection should be made directly to the battery and fused as close to the battery as possible.

This manual is also suitable for:

Caravan 2009

Dodge 2009 Caravan Owner's Manual

Introduction 1

M Introduction

M How to Use this Manual

Things to Know before Starting Your Vehicle

Understanding the Features of Your Vehicle

Understanding Your Instrument Panel

Starting and Operating

What to Do in Emergencies

M Hazard Warning Flasher

M if Your Engine Overheats

M Jackingand Tire Changing

Quick Links

Chapters

Related Manuals for Dodge 2009 Caravan

Summary of Contents for Dodge 2009 Caravan
